HCAL HV splice box

1
HCAL HV splice box
2
HV cable 4 thick wires HV ( up to 15 kV)
transfer 7 thin wires bias voltages (lt 100 V)
transfer Shield to ground on RBX side.


To ground
3
Splice Box, general view
Metal case of splice box is grounded.
4
Splice Box, side and top view
To ground
5
View on line AA, one channel
Silicon compound RTV112 - Dielectric Strength
16 kV/mm
Isolation of HV splice connection
6
Connector for BV wires
7
Photo of Splice Box
Metal case of splice box is grounded.
8
Connection of HV cable to detector (RBX)
9
Connection of HV cable to HV power supply
