Title: The Design and Development of an Active Smart Wing Model
1The Design and Development of an Active Smart
Wing Model
2Team Structure
- Thomas Ayers
- Project Leader
- Robert Aguirre
- Senior Testing Research Specialist
- Kevin Mackenzie
- Senior Modeling and Design Specialist
- Vu Tran
- Senior Research Specialist
- Dr. R. O. Stearman
- University of Texas Faculty Consultant
3Presentation Overview
- Project Objectives
- Aerodynamic Theory
- Model Design
- Model Testing Options
- Project Accomplishments
- Recommended Future Pursuits
- Summary
- Questions
4Project Background
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Randall Bolding
- Wrote a masters thesis in 1978 in which a wing
model was used to research the use of a
stabilator as an active control to suppress
flutter - Lockheed Martin Corporation
- A research project on the benefits that an
active wing can provide in contemporary aircraft
design
5High Airspeed Benefits
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- At high airspeeds normally latent aerodynamic
forces become powerful enough to affect the flow
about the airfoil - These changes cause torsional moments on the wing
- Theoretically, the use of active wing control on
the leading edge flaps and ailerons can be used
in order to better control these latent
aerodynamic forces
6Low Airspeed Benefits
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- At low speeds airflow about the wing can separate
from the wing causing a stall - In natural flight, resonant flapping is used to
sustain flight at low flight speeds - Theoretically, oscillating the wings by using the
control surfaces would create high lift
conditions for short, low airspeed maneuvers
7Project Objective
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- To create an active wing model for the purpose
of defining relationships between control surface
oscillation and flight performance
8Aerodynamic Theory
- Project Objectives
- Aerodynamic Theory
- Model Design
- Model Testing Options
- Project Accomplishments
- Recommended Future Pursuits
- Summary
- Questions
9Desirable Flow Types
Attached-flow Difference of the circulations of
the upper and lower boundary layers create a lift
force near a quarter chord of the airfoil.
(figure a) Detached-vortex-flow rolled-up
leading edge vortices create additional lift.
(figure b) 4
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
10Problems Encountered
- When a critical angle of attack achieved to
create high lift, separated unsteady flow is
unavoidable, and the vortices formed become
uncontrollable once they leave the body.
- Unsteady separation
- Vortex shedding
- Vortex breakdown
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
11Separation Control
- To control separation, essentially the boundary
vorticity flux control, a relationship between
pressure, inertial, and viscous forces must be
utilized. - Methods for controlling separation
- 1) Control tangential pressure gradient proper
design of airfoil and wing geometry - 2) Control skin friction field modify local
skin friction field near critical points - 3) Introduce local movable wall oscillating
flaps
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
12Reattachment Control
- When the boundary layer is already separated,
control of its reattachment is also feasible by
utilizing unsteady excitations. - Example Small leading-edge oscillating flap was
used to forced the shear layer separated from a
sharp leading edge to attach to just the upstream
of a round trailing edge, hence captured a strong
vortex above a two-dimensional airfoil with angle
of attack up to 27 degree. Lift was increased by
60. - 4
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
13Reattachment Control
The inviscid vortex method can be used to compare
flow patterns with or without leading-edge
oscillation Case (a) leading-edge vortex moves
downstream as new vorticies start to form. The
leading edge vortex cuts off the trailing edge
vortex sheet. The main vortex will eventually
shed. Case (b) main vortex is stabilized and
stays close to the wing with nearly uniform
vorticity distribution 4
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
14Reattachment Control
- An additional example
- Poly Vinylidence Flouride (PVDF) piezoelectric
film was used on the surface of a NACA 0012
airfoil to generate surface oscillation through
polarization changes in the material -
- 5
- Non-oscillated case Max lift coefficient
0.72, stall angle 14 degree - Oscillated case Max lift coefficient 0.76,
stall angle 15 degree - 5 5
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
15Reattachment Control
- For a highly swept wing, unsteady surface
excitations focus on delaying vortex breakdown,
or can be used to maintain highly concentrated
and stable leading-edge vortices - Schematic of mini-upper wing
- 4
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
16Reattachment Control
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Mini-upper Wing
- The wing has a larger incidence than the main
wing, thus forcing the flow below it to converge.
This implies an additional axial acceleration at
the vortex core, and therefore delays its burst.
However, the applicable angle of attack is
limited, due to limitations created by the wing
design
17Model Design
- Project Objectives
- Aerodynamic Theory
- Model Design
- Model Testing Options
- Accumulated Project Work
- Recommended Future Pursuits
- Summary
- Questions
18Actuator Designs
- Background
- Theory
- Model
- Work
- Summary
- Questions
- Hydraulic Actuator
- Electromechanical Actuator
- Electric Motor
19Benefits of ATAKs Design
- Size of Control System Electric motor and shaft
will be half the size of the previous groups - Ease of Operation Does not require
understanding of complex controller - Able to Test By taking wind tunnel dimensions
into account when designing we make sure that we
will be able to mount the wing in order to obtain
Cl and Cd measurements - Flexibility Leading and trailing edge flaps
will be able to oscillate. Will be able to
control angle of deflection and phase between
flaps
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
20Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Overall Model Assembly
21Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Wing Spar, Engine and Rods
22Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Gearing Assembly
23Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Bevel Gears
24Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Actuation System Push/Pull Rods
25Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Actuation System including Control Surfaces
26Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Wing Model Without Modified Control Surfaces
27Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Wing Model With Deflected Control Surfaces
28Model Design
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Overall Model Assembly
29Model Testing Options
- Project Objectives
- Aerodynamic Theory
- Model Design
- Model Testing Options
- Accumulated Project Work
- Recommended Future Pursuits
- Summary
- Questions
30Model Testing Goals
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Take next step in project development
- Obtain and reduce data
- Conduct repeated tests to ensure quality data
acquired
31Testing Data Acquisition
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Relationship between oscillation frequency and
- Variations of coefficient of lift
- Pressure distributions over wing
- Wing spar strain
- Wing tip flutter
- Relationships can be used to find optimum
frequencies for - Maximizing coefficient of lift
- Minimizing wing spar strain
- Minimizing wing tip flutter
32Model Testing Equipment
- Background
- Theory
- Model
- Testing
- Work
- Questions
- Summary
- Smoke wire
- Pressure taps
- Strain Gauges
- Accelerometer
33Model Testing Suggestions
- Background
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Modify model as needed
- Start testing as soon as possible
- Be familiar with theory and equations needed to
reduce data
34Project Accomplishments
- Project Objectives
- Aerodynamic Theory
- Model Design
- Optional Testing Procedures
- Project Accomplishments
- Recommended Future Pursuits
- Summary
- Questions
35Project Accomplishments
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Project has been advanced over the past four
terms - The Active Wing Group (AWG)
- Active Wing Technology (AWT)
- Active Wing Engineering (AWE)
- ATAK Technologies (ATAK)
36Active Wing Group
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Recovered F-111 wing-tail from storage
- Investigated limit cycle oscillations (LCO)
- Provided a strong foundation for Summer 2002
project continuation
37Active Wing Technologies
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Primarily Research on F-111
- Limit cycle oscillations (LCO)
- Increasing lift on fighter wings
- Implementation of control surfaces
- Digital and analog control systems
38Active Wing Engineering
- Researched the aerodynamic theory behind
oscillating flaps - Selected actuation system
- Constructed model wing with leading edge flaps
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
39ATAK Technologies
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Research
- Aerodynamic forces involved in active wing
technology - Control surface effect on lift
- Model Design
- Actuation system
- Structure design
- AutoCAD model
- Delivered spar design to machinist for
construction - Gathered all necessary model materials.
- Lab Maintenance
- Worked to clean WRW 316
40ATAK Technologies
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
Wing Structure
41Recommended Future Pursuits
- Project Objectives
- Aerodynamic Theory
- Model Design
- Optional Testing Procedures
- Project Accomplishments
- Recommended Future Pursuits
- Summary
- Questions
42Recommended Future Pursuits
- Objectives
- Theory
- Model
- Testing
- Work
- Summary
- Questions
- Complete the construction of the wing model
- Prepare for experimentation using the model
- Design testing equipment and conditions
- Place instruments on model design
- Use LabView software to coordinate data
acquisition - Conduct experiments using wing model
- Reduce acquired data and draw conclusions
concerning the relationship between frequencies
and the desired characteristics.
43 Presentation Summary
- Background Information
- Project Objectives
- Aerodynamic Theory
- Modeling and Final Design
- Proposed Testing Procedures
- Project Accomplishments
- Recommended Future Work
44References
- 1 Aguirre, Robert, Thomas Ayers, Kevin
Mackenzie, and Vu Tran. Design and Development
of an Active Wing Model. ATAK Technologies,
Austin, TX, Mar. 2003. - 2 Garret, Carlos, Justin Gray, and Kevin Marr.
Design of an Active Controlled Wing Model Using
Flap Oscillation. AWE Engineering, Austin, TX,
Dec. 2002. - 3 Fuentes, David, Basil Philips, and Naoki
Sato. Design and Control Modeling of an Active
Variable Geometry Wing. Active Wing
Technologies, Austin, TX, Aug. 2003. - 4 Wu, J.M., Wu, J.Z., Vortex Lift at a Very
High Angle of Attack with Massively Separated
Unsteady Flow, Fluid Dynamics of High Angle of
Attack, R. Kawamura, Y. Aihara ed.,
Springer-Verlag, Berlin Heidelberg, 1993, pp.
35-63. - 5 Kobayakawa, M., Kondo, Y., Suzuki, H.,
Airfoil Flow Control at High Angle of Attack by
Surface Oscillation, Fluid Dynamics of High
Angle of Attack, R. Kawamura, Y. Aihara ed.,
Springer-Verlag, Berlin Heidelberg, 1993, pp.
265-273.
45Questions?
