ZUMTOBEL

1
ZUMTOBEL
PANOS Q LF 1/32W TC-TELI EVG 190 FB
60811108
Description

Downlight, without frame lamp(s) 1/32W
TC-TELI/TEL horizontal lamp position with high
frequency ballast, (separate unit, dimensions
278x114x53mm) reflector body made of
high-quality, UV-resistant polycarbonate,
facetted, aluminium-sputtered, mirrorbrite and
iridescent-free wide-beam light distribution,
suitable for DSE workstation lighting whe...
Luminaire type Recessed ceiling light
Style Modern
Light - direction direct
Light - allocation/distribution spot, symmetrical
Shape / Form Rectangular
Switching function On / Off on site
Form of protection DIN 40050 IP20
Certification (approval mark / test symbol) CE, Fire protection "F"
Safety class I
Net weight in kilogram (kg) 1.5 kg
Color metallic
Material all metals, Aluminium
Surface shiny
Dimension body 230 x 190 x 101 mm
Lamp count 1
Socket GX24q-3
Control gear / converter for lamps 1 EVG Standard
Type Compact flourescent light, TC-T
Document created 03/09/2011 202100
more information http//www.luxoworks.com/databa
se/zumtobel/60811108/
