Organs of the Immune System: Lymph Nodes, Spleen

1
Organs of the Immune SystemLymph Nodes, Spleen
Thymus

• Teresa Kraus MD
• Teresa-Kraus_at_ouhsc.edu

Modified from a lecture by Dr. William Kern
2
Downloading any of the photographs, images or
diagrams from this presentation for any purpose
other than studying for the BHL course is
prohibited.
3
Lymphatics

• Thin-walled vessels
• Drain interstitial fluid from tissues back into
  venous system
• Carry antigens to lymph nodes for processing and
  beginning of immune response

4
Lymphatic System
5
Lymphatic System Abdomen
6
Function of Lymph Nodes

• Site where lymphocytes, macrophages and other
  cells can contact antigen and interact with each
  to generate immune response
• Trap malignant cells

7
Structure of Lymph Nodes

• Fibrous capsule
• Cortex Outer portion
• Follicles Predominantly B-cells
• Germinal centers mantle zones
• Paracortical (interfollicular) areas
  Predominantly T-cells
• Medulla Center portion
• Medullary sinuses

8
Structure of Lymph Node
Williams Hematology, 8th Ed.
9
Lymph Node
Germinal center
Williams Hematology, 8th Ed.
10
Secondary Follicle
Mantle zone
Germinal center
Jaffe Hematopathology
11
Secondary Follicle B-cells vs. T-cells
B-cell stain
T-cell stain
(Brown is positive)
Jaffe Hematopathology
12
The Germinal Center

• The GC is the primary site where B cell
  expansion, diversification, and affinity
  maturation occurs in response to antigen

Jaffe Hematopathology
13
Cells Within the GC

• Centroblasts undergo division and somatic
  hypermutation in the dark zone of the GC before
  exiting the cell cycle, re-expressing surface
  immunoglobulin, and migrating to the light zone
• In light zones, clones with increased antigen
  affinity are preferentially selected by their
  interaction with antigen on follicular dendritic
  cells and survival signals provided by follicular
  helper T cells

Ki-67
CD23
14
Extranodal Lymphoid Tissue

• Patches of lymphoid tissue located in GI tract,
  lungs, other extranodal sites
• Immunologic protection at areas vulnerable to
  potential invaders
• Important in IgA production

15
GI Tract Lymphoid Nodules
16
Lymph Node Enlargement

• Infections All types
• Drugs Phenytoin
• Metastatic malignancies
• Non-hematologic Carcinomas, others
• Hematologic Lymphomas, occasional myeloid
  malignancies
• Systemic diseases Sarcoidosis, systemic lupus
  erythematosus
• Miscellaneous

17
Reactive Lymph Node
18
Spleen

• Located in left upper quadrant of abdomen,
  beneath lower ribs
• Normal weight 100-150 grams (adults)
• Usually not palpable in adults
• Spleen tip may be palpable in a substantial
  number of children
• Spleen tip palpable in a small number of slender
  young adults
• Palpable splenomegaly is abnormal in older adults

19
Spleen Blood Supply Venous Drainage

• Arterial
• Splenic artery Branch of celiac trunk primary
  supply
• Branches of gastric arteries Minor
• Venous drainage
• Splenic vein Joins with superior mesenteric vein
  to form portal vein
• Small veins draining to gastric veins
• Gets approximately 5 of cardiac output

20
Arterial Supply of Spleen
21
(No Transcript)
22
Spleen Venous Drainage
23
Spleen Structure

• Fibrous capsule with trabecula extending into
  parenchyma
• Stroma composed of network of fibroblast-like
  reticular cells
• Splenic artery enters at hilum
• Gives off trabecular arteries ? central arteries
  ? penicilliary arteries

24
Spleen Microanatomy

• White pulp
• Lymphoid zone
• Surrounds central arteries
• Periarteriolar lymphoid sheath (PALS) T-cells
• Follicles and marginal zones B-cells
• Red pulp
• Network of splenic (stromal) cords vascular
  sinuses

25
Spleen Microanatomy
White pulp
Robbins Pathologic Basis of Disease, 8th ed.
26
Spleen
From Hoffman et al Hematology Basic Principles
Practice, 5th Ed.
27
Spleen
From Williams Hematology, 8th Ed.
28
Spleen
White Pulp
Red Pulp
Ross Pawlina Histology A Text and Atlas, 5th
Ed.
29
Spleen Red Pulp

• Most of blood goes directly into venous sinusoids
  Closed circulation
• Relatively fast
• Small amount goes into open splenic cords Open
  circulation
• Splenic cords lined by macrophages
• Erythrocytes screened phagocytized by
  macrophages
• Open circulation is very slow

30
Functions of Spleen

• A major site of protection against blood-born
  pathogens
• Site of antibody production
• Screens and eliminates senescent or defective red
  cells
• Stores platelets and some granulocytes
• Normally 1/3rd of platelets sequestered in spleen
• Site of hematopoiesis in fetal life
• May be reactivated in severe anemia, MPNs

31
Erythrocytes the Spleen

• Senescent RBCs phagocytized removed
• Spleen removes excess membrane lipids from young
  RBCs
• Spleen removes RBC inclusions Nuclei, nuclear
  fragments, iron granules
• RBCs must pass through narrow slit to enter
  vascular sinuses from splenic cords
• Requires flexibility

32
Howell-Jolly Bodies
From Hoffman et al Hematology Basic Principles
Practice, 5th Ed.
33
Disorders of Spleen

• Accessory spleen
• Common incidental finding
• Usually single hilum of spleen is common site
• Usually clinically insignificant
• Wandering spleen
• Abnormal positioning due to excessive mobility of
  splenic ligaments
• May present as abdominal mass, intermittent pain,
  or torsion with acute abdomen
• Splenogonadal fusion

34
Disorders of Spleen

• Hypersplenism
• Splenic enlargement with sequestration of WBCs,
  RBCs and platelets
• Usually due to passive splenic congestion
• Hyposplenism
• Increased risk of severe bacterial sepsis
• Due to surgical splenectomy, autosplenectomy in
  sickle cell diseases, congenital asplenia (rare)

35
Splenomegaly Causes

• Congestive splenomegaly
• Reactive splenomegaly
• Infiltrative diseases
• Gaucher disease, others
• Malignancies
• Hematologic
• Non-hematologic

36
Congestive Splenomegaly

• Backup of venous blood flow through splenic vein
• Causes Cirrhosis of liver, right heart failure,
  thrombosis of portal or splenic veins
• May be associated with hemorrhage from
  gastroesophageal varices
• Congestion of spleen may also occur in chronic
  hemolytic anemias
• Hereditary spherocytosis, thalassemia, others

37
Gastroesophageal Varices

• Backup of blood from portal vein through splenic
  vein to gastric veins may result in
  gastroesophageal varices
• Dilated veins near gastroesophageal junction
• May cause massive upper GI hemorrhage in patients
  with cirrhosis

38
Reactive Splenomegaly

• Infections of many types
• Viral EBV and others
• Parasitic infections Malaria and others
• Bacterial, fungal, mycobacterial
• Chronic inflammatory disorders
• Felty syndrome, systemic lupus erythematosus
  (SLE), sarcoidosis, others
• Hemolytic anemias

39
Neoplasms the Spleen

• Primary splenic neoplasms Rare usually vascular
  tumors
• Benign Hemangiomas, lymphangiomas
• Malignant Angiosarcomas
• Hematologic neoplasms
• Hodgkin and non-Hodgkin lymphomas
• Myeloproliferative neoplasms CML, P. vera,
  primary myelofibrosis, etc.
• Hairy cell leukemia
• Non-hematologic malignancies Rarely metastasize
  to spleen

40
Thymus

• Located in superior mediastinum
• Bilobed irregularly pyramidal
• Derived predominantly from 3rd pair of pharyngeal
  pouches 4th pouches
• Parathyroid glands also derived from pharyngeal
  pouches
• Atrophies after puberty ? few small islands of
  epithelial cells in older adults

41
(No Transcript)
42
From Jaffe ES et al Hematopathology
43
Thymus Function

• Site of T-cell selection and maturation
• T-cells originate in bone marrow, but immature
  T-cells must migrate to thymus to mature
• Selected for ability to recognize self HLA
  antigens to allow antigen presentation
• T-cells with strong autoreactivity deleted
• Prevent autoimmune reactions

44
Thymus Anatomy

• Two fused lobes
• Surrounded by a fibrous capsule
• Fibrous bands divide the thymus into lobules
• Predominantly consists of epithelial cells and
  immature T-cells

45
Thymus Microanatomy

• Divided into cortex and medulla
• Medulla contains Hassalls corpuscles (islands of
  squamous cells)
• The most immature T-cells are located in
  superficial cortex
• T-cells move down into medulla as they mature

46
Thymus
From Jaffe ES et al Hematopathology
47
Thymus Cortex
From Jaffe ES et al Hematopathology
48
Thymus Medulla
Hassalls corpuscle
From Jaffe ES et al Hematopathology
49
T Cell Maturation
Jaffe Hematopathology Fig 8-8
50
From Williams Hematology, 8th Ed.
51
Thymus Aplasia or Hypoplasia DiGeorge Syndrome

• Related to abnormalities of 3rd 4th pharyngeal
  pouches
• Absent or hypoplastic thymus ? immunodeficiency
• Aplasia or hypoplasia of parathyroid glands ?
  hypoparathyroidism ? hypocalcemia

Continued
52
Thymus Aplasia or Hypoplasia DiGeorge Syndrome

• Variable congenital cardiac anomalies
• Mild facial dysmorphism
• Subset of chromosome 22q11.2 deletion syndrome
• Confirmatory test Fluorescence in situ
  hybridization (FISH) looking for deletion of
  chromosome 22q11.2

53
Thymus Aplasia or HypoplasiaOther Variants

• Wiskott-Aldrich syndrome
• Abnormalities of gene producing WAS protein
• X-linked recessive inheritance
• Hypoplastic thymus, recurrent infections, eczema,
  thrombocytopenia with small platelets

http//emedicine.medscape.com/article/137015-overv
iewa0101
54
Thymus Aplasia or HypoplasiaOther Variants

• Ataxia-Telangiectasia
• Autosomal recessive mutations in ATM gene
  11q22-23
• Cerebellar ataxia, immunodeficiency
• Oculocutaneous telangiectasia
• Hypoplasia / agenesis of the thymus

55
Thymic Follicular Hyperplasia

• Presence of lymphoid follicles with germinal
  centers in thymus
• Lymphoid follicles not normally found in thymus
• Thymus size often normal
• Often associated with autoimmune diseases
  especially myasthenia gravis
• Muscle weakness due to antibody against
  acetylcholine receptor on muscle cells

56
Thymic Follicular Hyperplasia Autoimmune Disease

• Thymic follicular hyperplasia found in 65-75 of
  patients with myasthenia gravis
• Myasthenia gravis also found in patients with a
  thymic tumor called thymoma
• Thymic follicular hyperplasia may also be found
  with other autoimmune diseases
• Graves disease (autoimmune thyroiditis with
  hyperthyroidism), systemic lupus erythematosus,
  others

57
Neoplasms of Thymus

• Thymomas Tumors of thymic epithelial cells
• Most common tumors of thymus
• Hematologic neoplasms
• T lymphoblastic leukemia/lymphoma
• B-cell lymphomas
• Germ cell tumors Rare

58
Thymomas

• Tumors of thymic epithelial cells
• Three variants
• Encapsulated (noninvasive) Majority
• Invasive but cytologically benign 20
• Thymic carcinomas (cytologically malignant) Rare

59
Thymoma
Robbins Pathologic Basis of Disease, 8th ed.
60
Thymoma
Robbins Pathologic Basis of Disease, 8th ed.
61
Thymomas Autoimmune Diseases

• Thymomas may also be associated with autoimmune
  diseases
• Myasthenia gravis Not as often as thymic
  follicular hyperplasia
• Pure red cell aplasia
• Graves disease
• Others

62
Hematologic Neoplasms of the Thymus

• T lymphoblastic leukemia/lymphoma Most common
• Formerly called precursor T-cell
  ALL/lymphoblastic lymphoma
• Most common in adolescent males
• Present with large mediastinal mass
• May have respiratory compromise, pleural effusions

63
T Lymphoblastic Leukemia/Lymphoma

• Majority of precursor T-cell neoplasms present as
  lymphoma Tissue mass without blood or bone
  marrow involvement
• Minority of cases have blood and bone marrow
  involvement
• Distinction (lymphoma vs. leukemia) based on
  whether bone marrow involved
• Treatment and prognosis similar

64
Primary Mediastinal Large B-Cell Lymphoma

• Uncommon neoplasm of thymus
• Derived from thymic B-cells
• Histologic variant of diffuse large B-cell
  lymphoma
• Typically occurs in young women
