Cytoskeleton - Locomotion

1
Cytoskeleton - Locomotion
Kohidai, Laszlo MD, PhD Med. habil., Assoc.
Professor Dept. Genetics, Cell Immunobiology,
Semmelweis University
www.dgci.sote.hu
Ecelctive Course / 2011
2
Main functions of cytoskeleton

• Determines the shape of the cell
• Anchores organelles
• Movement of organelles
• Tensile strength
• Movement of chromosomes
• Polarity
• Motility

3
Cytoskeleton

• Microfilaments (actin)
• Microtubuli (tubulin)
• Intermedier filaments
• Microtubule associated proteins (MAP-s)
• Motor proteins

4
Microfilaments
Microtubuli
Intermedier filaments
5
SLIDING
Globular proteins
Ca2
ATP
Motor proteins
Fibrillar proteins
6
Microfilaments
7
Polymerization of actin

ATP
ADP
Depolymerization
-
cytochalasin inh. phalloidin - stabilizer
ATP
ADP
Pi
Polymerization - slow
8
Actin - still in Prokaryots !
((Ent et al. Nature 2001,413, 39)
9
Cyclosis

• Transitional connections between actin and
  myosin
• Ca2, temperature- and pH-dependent

(Lodish, H. et al. Mol. Cell Biol. 2000, 767)
10
Fountain mechanism
Ca2-dep. requires ATP
Mono- Poly- Lobo- podial Filo- Reticulo-
Formation of pseudopodium
stress-fibrillums
integrins
11
Cross-linking proteins of actin
contractile bundle a actinin in stress fibr.
gel-like network filamin - cortex
tight parallel bundle fimbrin in filopodium
12
Migrating keratinocyte
15 mm/sec
Formation of lobopodium
microtubuli
actin-network
13
Regulator proteins of actin polymerisation
gCAP39 Severin Gelsolin Villin CapZ
Tropomodulin
?
Cofilin Severin Gelsolin
14
Actin polymerisation acrosomal-reaction
(Lodish, H. et al. Mol. Cell Biol. 2000, 767)
15

• local actin polymerization
• speed 10 mm/min
• high ability to transmit
• in tissues

Listeria monocytogenes
actin
(Fred Soo Julie Theriot Laboratory)
16
Model of actin nucleation

WASP Wiscott-Aldrich syndr. prot.
17
Structure of cortical region
(Svitkina, TM, Borisy GG J. Cell Biol. 1999,
145, 1009)
18
Actin membrane links
membrane
F-Actin
19
Profilin-mechanism
Tb4 timozin b4
Proline-rich protein
(Lodish, H. et al. Mol. Cell Biol. 2000, 767)
20
Filamin Membrane link
filamin
actin
21
Structure of focal contact
actin filament
a actinin
vinculin

paxillin
talin
integrin
fibronectin
22
A plasma membrane cortex links
((Lux SE, 1979 Nature 281426)
23
E
Electromagnetic field induces the
transformation of cytoskeleton and formation of
pseudopodia
Adhesion plaque



-
-
24
Myosin
head
Ca2-dependent phosphorylation and its effect on
the 3D strcture
light chain
heavy chain a helix
myosin I. 150 kD
monomer
myosin I I. 260 kD
Head - ATP-ase - motor
dimer
25
Distribution of myosines in the migrating
Dyctiostelium and in dividing cell
myozin I. (green)
myozin II. (red)
(Fukui, Y. Mol. Cell Biol 2000, 785))
26
Main types of interactions between the
globular and fibrillar components of
cytoskeleton
membrane
27
MT-blocked
F-actin blocked
Non-treated
28
Microtubules
29
Tubulin still in Prokaryotes !
FtsZ
Tubulin
(Margolin Laboratory, University of Texas)
30
Polymerization of tubulin
GTP
GTP
Polymerization - fast
GTP
GTP
Protofilament (strait)
GDP
GDP
GDP
GDP
Protofilament (curved)
Depolymerization
31
Dynamics of microtubule-assembly
-

incorporation
balanced
release
32
Role of g-tubulin in nucleation
(Wiease et al. Curr.Opin.Struct.Biol. 1999, 9,
250)
33
Microtubular systems in the cells
- Centrosome - Cilia / flagellum - Mitotic
system - Vesicular transport
34
MTOC Mikrotubul organizing center
g-tubulin
((Brinkley, B.R. Encyclop. Neurosci. 1987, 665)
35
Network of microtubuli
Fibroblast
36
Cilia
cilia
flagellum
Paramecium
37
(No Transcript)
38
Composition of dynein-arms
ATP-independent binding
ATP-dependent hydrolisis
39
The role of dynein arms in beating of cilia
Bending
Telescoping
Proteolysis
40
Molecules composing the cilia
more than 250 types of molecules

• 70 a and b tubulin
• dynein arms
• outer - 9 polypeptides - ATP-ase
• inner composition varies
• radial spokes - 17 polypeptides

41
Microtubules of mitotic spindle and kinetochore
42
Arrangement of actin during cell-division
43
Intermedier filaments
44
Mechanical characterization of cytoskeleton
components
deformation
force
45
Role of intermedier filaments
Buffer against external mechanical stress
Tissue specificity
Nucleus lamines (lamina fibrosa)
Epithel keratin Connective tissue Muscles Neuro
glia Neurones - neurofilaments
vimentin
46
Structure of intermedier filamentums
(Lodish, H. et al. Mol. Cell Biol. 2000, 767)
47
Domain structures of intermedier filamentums
H2N-
a helical domain
-COOH
keratins
vimentin
neurofilam. prot.
nuclear prot
48
Intermedier filaments
Keratin filaments
Vimentin-like filaments
! They DO NOT co-polymerise !
49
Microvilli
myosin I.
actin
villin
terminal web

• a rigid bundle composed by 20-30 actin mol.s
• actin on the apical part
• villin is the linker molecule of actins
• terminal web intermed.fil. spectrin
• myosin I. and calmodulin anchore to the surface
  membrane

50
SEM structure of microvilli
actin bundle
linker molecules
terminal web
51
Intermedier filaments
Glial filaments few cross-linkers
Neuro-filaments many cross-linkers
The number of protein cross-links between the
intermedier filaments varies in different tissues
52
Microtubuli associated proteins (MAP-s)
53
Groups of MAP-s

• Structural MAP-s
• - MT-assembly
• - links to MF and to IF
• Motor proteins
• - sliding on MT
• Enzymes, signal molecules
• - glycolytic enzymek
• - kinases

Shape and polarity of the cell
Membrane transports
Assembly of molecules
54
Motor-proteins
55
Structure of motor-proteins
56
Motor proteins
-

dynein
kinesin
microtubule
heavy chain
light chain
kinesin
dynein
57
kinesin
-

dynein
cAMP
cAMP
pigment cells
58
Kinesin
ADP
ATP
ADP
ATP
59
MT-motor proteins and the transported elements
(Hirokawa, N. Science 1998, 279519
60
Dynein membrane relations
(Hirokawa, N. Science 1998, 279519)
61
There are other mechanisms over sliding
62
Locomotion with spasmoneme ofVorticella
63
Spasmoneme spring
Contracts 40 in few msecs Velocity 8 cm?/sec
Negative charges
Neutralization with Ca2
64
Actin spring in sperm of horse-shoe crab Limulus
polyphemus
!
acrosome
actin bundle

• The extension does not involve a myosin
• motor or actin polymerization
• The bundle is crystalline in its coiled and
• uncoiled states

65
Signalling mechanisms In a nutshell
66
Polymerization of microtubules- Significance of
motor proteins
67
Ameboid movement and microtubules
68
Complex effects of focal adhesion kinase (FAK)
69
LIM domains of proteins
70
Central role of vimentin in signalling mechanisms
of cytoskeleton
71
Phosphatases and cell migration
