Chapter 4: Divide and Conquer

1
Chapter 4 Divide and Conquer
The Design and Analysis of Algorithms

• Master Theorem, Mergesort, Quicksort, Binary
  Search, Binary Trees

2
Chapter 4. Divide and Conquer Algorithms

• Basic Idea
• Merge Sort
• Quick Sort
• Binary Search
• Binary Tree Algorithms
• Closest Pair and Quickhull
• Conclusion

3
Basic Idea

• Divide instance of problem into two or more
  smaller instances
• Solve smaller instances recursively
• Obtain solution to original (larger) instance by
  combining these solutions

4
Basic Idea
5
General Divide-and-Conquer Recurrence

• T(n) aT(n/b) f (n) where f(n) ? ?(nd), d
  ? 0
• Master Theorem If a lt bd, T(n) ? ?(nd)
• If a bd, T(n)
  ? ?(nd log n)
• If a gt bd, T(n)
  ? ?(nlog b a )
• Examples
• T(n) T(n/2) n ? T(n) ? ?(n )
• Here a 1, b 2, d 1, a lt bd
• T(n) 2T(n/2) 1 ? T(n) ? ?(n log 2 2 ) ?(n
  )
• Here a 2, b 2, d 0, a gt bd

6
Examples

• T(n) T(n/2) 1 ? T(n) ? ?(log(n) )
• Here a 1, b 2, d 0, a bd
• T(n) 4T(n/2) n ? T(n) ? ?(n log 2 4 ) ?(n
  2 )
• Here a 4, b 2, d 1, a gt bd
• T(n) 4T(n/2) n2 ? T(n) ? ?(n2 log n)
• Here a 4, b 2, d 2, a bd
• T(n) 4T(n/2) n3 ? T(n) ? ?(n3)
• Here a 4, b 2, d 3, a lt bd

7
Recurrence Examples
8
Recursion Tree for T(n)3T(?n/4?)?(n2)
T(n)
cn2
T(n/4)
T(n/4)
T(n/4)
(a)
(b)
cn2
cn2
(3/16)cn2
c(n/4)2
c(n/4)2
c(n/4)2
log 4n
(3/16)2cn2
c(n/16)2
c(n/16)2
c(n/16)2
c(n/16)2
c(n/16)2
c(n/16)2
c(n/16)2
c(n/16)2
c(n/16)2
?(nlog 43)
T(1)
T(1)
T(1)
T(1)
T(1)
T(1)
3log4n nlog 43
Total O(n2)
(d)
9
Solution to T(n)3T(?n/4?)?(n2)

• The height is log 4n,
• leaf nodes 3log 4n nlog 43. Leaf node cost
  T(1).
• Total cost T(n)cn2(3/16) cn2(3/16)2 cn2
• ??? (3/16)log 4n-1 cn2 ?(nlog 43)
• (13/16(3/16)2 ??? (3/16)log 4n-1) cn2
  ?(nlog 43)
• lt(13/16(3/16)2 ??? (3/16)m ???) cn2
  ?(nlog 43)
• (1/(1-3/16)) cn2 ?(nlog 43)
• 16/13cn2 ?(nlog 43)
• O(n2).

10
Recursion Tree of T(n)T(n/3) T(2n/3)O(n)
11
Mergesort

• Split array A0..n-1 in two about equal halves
  and make copies of each half in arrays B and C
• Sort arrays B and C recursively
• Merge sorted arrays B and C into array A

12
Mergesort
13
Mergesort
14
Mergesort
15
Mergesort Code

• mergesort( int a, int left, int right)
• if (right gt left)
• middle left (right - left)/2
• mergesort(a, left, middle)
• mergesort(a, middle1, right)
• merge(a, left, middle, right)

16
Analysis of Mergesort

• T(N) 2T(N/2) N
• All cases have same efficiency T(n log n)
• Space requirement T(n) (not in-place)
• Can be implemented without recursion (bottom-up)

17
Features of Mergesort

• All cases T(n log n)
• Requires additional memory T(n)
• Recursive
• Not stable (does not preserve previous sorting)
• Never used for sorting in main memory, used for
  external sorting

18
Quicksort

• Let S be the set of N elements
• Quicksort(S)
• If N 0 or N 1, return
• Pick an element v - pivot, in S
• Partition S - v into two disjoint sets
• S1 x ? S - v x v, and
• S2 x ? S - v x v
• Return quicksort(S1), followed by v,
• followed by quicksort(S2)

19
Quicksort

• Select a pivot (partitioning element)
• Median of three algorithm
• Take the first, the last and the middle elements
  and sort them (within their positions).
• Choose the median of these three elements. Hide
  the pivot swap the pivot and the next to the
  last element.
• Example 5 8 9 1 4 2 7
• After sorting 1 8 9 5 4 2 7
• Hide the pivot 1 8 9 2 4 5 7

20
Quicksort

• Rearrange the list so that all the elements in
  the first s positions are smaller than or equal
  to the pivot and all the elements in the
  remaining n-s-1 positions are larger than or
  equal to the pivot. Note the pivot does not
  participate in rearranging the elements.
• Exchange the pivot with the first element in the
  second subarray the pivot is now in its final
  position
• Sort the two subarrays recursively

21

• left the smallest valid index
• right the largest valid index
•
• if( left 10 lt right)
• int i left, j right - 1
• for ( )
• while (ai lt pivot)
• while (pivot lt a--j )
•
• if (i lt j) swap (ai,aj)
• else break
• swap (ai, aright-1)
• quicksort ( a, left, i-1)
• quicksort (a, i1, right)

22
Analysis of Quicksort

• Best case split in the middle T(n log n)
• T(N) 2T(N/2) N
• Worst case sorted array T(n2)
• T(N) T(N-1) N
• Average case random arrays T(n log n)
• Quicksort is considered the method of choice for
  internal sorting of large files (n 10000)

23
Features of Quicksort

• Best and average case T(n log n) ,
• Worst case T(n2), it happens when the pivot is
  the smallest of the largest element
• In-place sorting, additional memory only for
  swapping
• Recursive
• Not stable
• Never used for life-critical and mission-critical
  applications, unless you assume the worst-case
  response time

24
Binary Search

• Very efficient algorithm for searching in sorted
  array
• K
• vs
• A0 . . . Am . . . An-1
• If K Am, stop (successful search)
• otherwise, continue searching by the same method
• in A0..m-1 if K lt Am,
• and in Am1..n-1 if K gt Am

25
Analysis of Binary Search

• Time efficiency T(N) T(N/2) 1
• Worst case O(log(n))
• Best case O(1)
• Optimal for searching a sorted array
• Limitations must be a sorted array
• (not linked list)

26
Binary Tree Algorithms

• Binary tree is a divide-and-conquer ready
  structure
• Ex. 1 Classic traversals
• (preorder, inorder, postorder)
• Algorithm Inorder(T)
• if T ? ?
• Inorder(Tleft)
• print(root of T)
• Inorder(Tright)
•

• Efficiency T(n)

27
Binary Tree Algorithms
Ex. 2 Computing the height of a binary tree
h(T) max h(TL), h(TR) 1 if T ? ? and
h(?) -1 Efficiency T(n)
28
Recursion tree for T(n)aT(n/b)f(n)
