Overview

1
Overview

• Gary Frank
• Manager Applications and Technology

2
Overview

• Capability and Functionality
• Availability Components
• Market Penetration
• Host Controllers
• Software Development Tools
• Comparisons

3
Capability and Functionality

• DeviceNet offers robust, efficient data handling
  because it is based on producer/consumer
  technology. This modern communications model
  offers key capabilities that allow the user to
  effectively determine what information is needed
  and when.
• Users also benefit from ODVA's strong conformance
  testing policies, which ensure that products are
  interoperable. As a result, users can
  mix-and-match products from a variety of
  suppliers and integrate them seamlessly.

4
ISO Layers

Application Layer Physical Signaling Transceiver
Transmission Media
ISO Layer 7 -Application

ISO Layer 2 -Data Link
Data Link Layer

ISO Layer 1 -Physical

ISO Layer 0 -Media
5
Capability and Functionality

• Technology
• CAN messaging layer 2 (data link layer) - ISO
  11898 and 11519-1
• DeviceNet is layer 7 (application layer ) and
  layer 1 (physical layer) designed for industrial
  automation

• History
• Base technology developed by Allen-Bradley
• Introduced March, 1994
• Technology transferred to ODVA in April, 1995

6
Capability and Functionality
7
Key Benefits

• Reduced Wiring and Installation Cost
• Reduced Start-Up Time
• Reduced Downtime
• Rapid Troubleshooting
• Removal, insertion and replacement of devices on
  the network under power
• Interchangeability of devices from multiple
  vendors
• Configuration of devices over the network (set-up
  or runtime)

8
Network Specifications
9
Network Messaging Services
10
Polled I/O Messaging
Polling
CTLR1
HMI
CTLR2
Sensor
Drive1
Drive3
Drive2
11
Typical Sealed-Style Physical Media
Tee Taps
Trunk line segments -molded mini-connectors
Field Installable trunk line connectors
Multiport Taps
Drop lines - molded connectors - 0 to 20
ft. - mini or micro at device
12
Device Interchangeability

• Standardized Data Sets (profiles) for various
  device types
• Allows user to substitute logically equivalent
  devices among vendors
• only provides for same device types, data
  structures and meaning
• NOT complete functional interchangeability
• User still has to determine application
  equivalency
• accuracy, life, mechanical strength and mounting,
  environmental ratings, response time, capacity,
  etc.
• this is the same as when replacing a device
  connected to an I/O point
• substitution with another vendors product not
  likely if user has utilized any vendor specific
  parameters
• System can key devices to prevent illegal
  substitutions
• For example, system can be configured to not
  accept a reflective photoeye for a diffuse
  photoeye

13
DeviveNet on EtherNet/IP

• EtherNet/IP I/O Scanner (Client)
• DeviceNet Monitor Software

• EtherNet/IP Freeware (Server)

• EtherNet/IP Protocol Analyzer

EtherNet/IP
EtherNet/IP I/O Adapter
EtherNet/IP to DeviceNet Gateway
DeviceNet
Photoeye
Photoeye
I/O
14
Wireless LANs

• IEEE 802.11
• 1 or 2 Mbps at 2.4 GHz band
• Frequency hopping spread spectrum (FHSS)
• Direct sequence spread spectrum (DSSS)
• About 100m range
• IEEE 802.11b (Wi-LAN)
• 1, 2, 5.5, or 11 Mbps DSSS at 2.4 GHz
• Now dominating the market
• IEEE 802.11a (HiperLAN2)
• 1 to 56 Mbps DSSS at 5 GHz
• Future market domination (2006)

14
15
Market Assessment

• Market penetration estimates
• 90 New Zealand/Australia
• 50 North America
• 50 Japan
• 10 Europe
• A fast-growing force in China and Korea

Source 2001 Open DeviceNet Vendor Association
16
Vendors Supporting

• AD Co., Ltd
• ABB Industrial Systems
• ABB Robotics Products AB
• ABB Welding AB
• AC Technology Corp.
• ACCU-Sort Systems, Inc.
• Accutron Technologies Inc.
• Acrosser Technology Co., Ltd
• ACT'L sa
• AD Link Technology Inc.
• Adept Technology, Inc.
• Advanced Energy Industries, Inc
• Advanced Micro Controls Inc. (AMCI)
• Advanet Inc.
• Advantech Co. Ltd.

• Aera
• Aera Japan Ltd
• AG-E Szamitastechnikal KFT
• AILES Electronics Ind. Co., Ltd.
• AITECH Engineering Corp.
• Akita Myotoku Ltd.
• ALCATEL High Vacuum Technology
• Alfa Instrumentos Eletronicos Ltda
• Alfa Laval LKM ApS
• Alstom Automation
• AMC Technologies Corporation
• American Science Engineering
• AMP Incorporated
• Ampere Inc.
• AMSC. Co., Ltd

17
Vendors Supporting

• Anatol Automation, Inc.
• ANELVA Corporation
• API Controls Inc.
• Apollo Fire Detectors Limited
• Applicom International
• Applied Materials, Inc.
• APV Systems
• Arcom Control Systems Ltd
• Arlington Laboratory
• ARO S.A.
• Aros Electronics AB
• Asahi Engineering Co., Ltd
• Asahi Optical Co., Ltd.
• asahi sangyo co., ltd.
• ASAP, Inc.

• ASCO Pneumatic Controls
• Ascom Hasler Mailing Sys
• aska corporation
• ASM Japan K.K.
• Athena Controls, Inc.
• ATI Industrial Automation
• Atlas Copco Controls SA
• Atlas Copco Controls UK
• AuCom Electronics Ltd
• Aucos GmbH
• Auma Actuators Inc
• Automationdirect.com
• AVG Automation (Uticor)
• Avtron Manufacturing, Inc.
• AW Company Ltd

18
Vendors Supporting

• Axiomatic Technologies Corp
• AXNET sa
• Baldor-Optimised Control
• BALLUFF, Inc.
• Balogh Inc.
• Banner Engineering Corp.
• BCE-Elektronik GbRmbH
• BEAD Interconnect Ltd
• Beckhoff Industrie Elektronik
• Beijing Huakong Technology Co. Ltd.
• Bekaert Engineering NV
• Belden Wire Cable Company
• Benshaw Inc.
• Berk-Tek/Alcatel Inc.
• Bihl Weidemann

• Binar Elektronik AB
• Binary Electronics Ltd
• Bionics Instrument Co., Ltd.
• BITS Co., Ltd
• BL Autotec, Ltd.
• Bray Valve Controls USA
• BRITISH Federal Ltd
• Bronkhorst High-Tech B.V.
• Brooks Automation Canada
• Brooks Instrument (div of Emerson)
• Burkert Werke GmbH Co
• BUSWARE Direct
• BYSTRONIC AG
• Cabinplant International
• Caterpillar, Inc.

19
Vendors Supporting

• CD Systems B.V.
• CKD Corporation
• Clever Devices
• Clippard Instrument Laboratory
• Coester Equipamentos Eletronicos Ltda.
• Cognex
• Colorado Flow Tech Inc.
• Comas S.p.A.
• COMAU Robotica
• Comdel Inc.
• CommScope Inc.
• Computer Optical Products, Inc.
• CONOS Inc.
• Contec Co.,Ltd.
• Contemporary Controls

• Contrex Inc.
• Control Logic Inc.
• Control Solutions
• Control Techniques PLC
• Control Technology Corporation
• Control Technology Incorporated
• Controlweigh
• Conxall Corporation Inc.
• Cooper Services
• Cosmo Instruments Co., Ltd.
• Cosmotechs Co., Ltd.
• Creative Micro Designs
• Creator Teknisk Utvedkling AB
• Creatrix Labs, Inc.
• Crouse-Hinds Molded Products

20
Vendors Supporting

• Crouzet Automatismes SA
• CTI Cryogenics
• Cummins Engine Company
• Custom Servo Motors Inc.
• Cutler-Hammer Products
• D.I.P. Inc.
• Daiden Co., Ltd
• DAIHEN Corporation
• Daishowa Swiki Co., Ltd.
• Danaher Controls
• Danfoss Electronic Drives
• Daniel Woodhead Co.
• Dart Container Corp.
• Data Link Products Inc.
• Dearborn Group Technology, Inc.

• Deltron Inc.
• Dengensha Mfg. Co. Ltd.
• Denshosha Co., Ltd.
• Denso Corporation
• Deutschmann Automation GmbH
• Digital Electronics Corp.
• DXL USA Inc.
• Dyadic Systems Co., Ltd.
• DYNAX Corporation
• EBARA Corporation
• EBARA Technologies Inc.
• EC Elettronica Srl
• Ecotecnia Socirtat Corp.
• ECT International, Inc.
• Edwards High Vacuum International Limited

21
Vendors Supporting

• Edwards Signaling
• Eiko Systemes Co., Ltd.
• Eilersen Electric A/S
• EIM Valve Controls
• Electrical Design Daiyu Co., Ltd
• Electroglas Inc.
• Electronic Innovation, Inc.(Falter Engineering)
• Electroplating Engineers of Japan Ltd.
• Elektronik-Systeme Lauer GmbH
• Embedded System Products, Inc.
• Emerson Motion Control
• ENI (Electronic Navigation Industry)
• Entek Ird Intl.
• Entrelec Inc.

• EOA Systems Inc.
• Erhardt Leimer GmbH
• Escort Memory Systems (A Datalogic Group Co.)
• esd electronic system design gmbh
• Estic Corp.
• Eurotherm Antriebstechnik GmbH
• Eurotherm Controls Inc
• EXOR Electronic R D
• ExtraTech Corp.
• Extron
• Facts Engineering
• FANUC Ltd.
• Fanuc Robotics North America, Inc.
• FASE Saldatura S.R.L.
• Federal Signal Corporation

22
Vendors Supporting

• Ferran Scientific Inc.
• Festo Corporation
• Fife Corporation
• Fincor
• Flexible Machine Controls
• FMT/Aircraft Gate Support Systems AB
• FRABA Sensorsysteme GmbH
• Fuji Electric Co., Ltd.
• Fuji Machine Mfg. Co., Ltd
• Fujikin , Inc.
• Fujikura Ltd.
• GCD Hardware Software GmbH
• GE EDC
• GE Fanuc Automation
• GEA Tuchenhagen GmbH

• Gestra GmbH
• Giddings Lewis, Inc.
• Gill Technologies
• Granville-Phillips Company
• Grape Systems Inc.
• Grayhill Inc.
• GreenSpring Computers, Inc
• Group 3 Technology Ltd
• GS Hydraulic Sales
• GWT/Global Weighing Technologies GmbH
• Haas-Laser GmbH Co. KG
• Hae Pyung Electronics Reserch Institute
• Hakko Automation
• Hana Information Technology Co., Ltd.

23
Vendors Supporting

• HAN-MI Co. Ltd.
• Hardy Instruments, Inc.
• Harmo Co. Ltd.
• Harmonic Drive Systems Inc.
• Hastings Instruments
• Hearn-Gu Lee
• Hengstler GmbH
• Hewlett-Packard
• HITECH Electronic Display Co.
• High Country Tek
• High Yield Technology
• Hilscher GmbH
• HIRATA Corp.
• Hirose Electric Co., Ltd
• Hirschmann USA
• Hitachi Cable Ltd.

• Hitachi Electric Systems
• Hitachi Metals Ltd, (SAM Research Co., Ltd)
• Hitachi Naka Electronics Co. Ltd.
• Hitachi, Ltd.
• Hitati Engineering Services CK., Ltd
• HLS Hard-Line Solutions Inc
• HM Computing Ltd.
• HMS Fieldbus Systems AB
• Hohner Corp.
• Hokuyo Electric Co. Ltd
• Holec Laagspanning B.V.
• Holjeron
• Honda Engineering Co., Ltd
• Honda RD Co., Ltd.

24
Vendors Supporting

• Horner Electric
• Horst GmbH
• Hubbell Wiring Device-Kellems (Delaware)
• Humphrey Products
• Huron Net Works
• Huttinger Elek. GmbH Co. KG
• Hyde Park Electronics, Inc.
• Hyundai Heavy Industry Co. (RD Info Cntr)
• IAI Corporation
• Ideacod-Hohner Automation
• IDEC IZUMI Corporation
• ifm efector, inc.

• IMAX
• IMI Intelligent Medical Imaging, Inc.
• IMI Norgren Limited
• INDRAMAT GmbH
• Industrial Control Communication
• Industrial Devices Corporation
• Industrial Indexing Systems, Inc.
• INFICON AG
• Ingersoll Rand (ARO) Fluid Power
• INSTRUMAR Limited
• Integrated Systems Engineering, Inc.
• Intelligent Motion Systems
• Intercond S.p.A.
• Interface Corporation
• InterlinkBT LLC

25
Vendors Supporting

• International Laboratory Corporation
• International Motion Controls Corp.
• Interroll Company
• Itoh Electric Co., Ltd.
• IVO GmbH Co.
• IXXAT automation GmbH (STZP)
• Japan Aviation Electronics Industry Ltd
• Japan Radio Co., Ltd
• Jeongil Intercom Co., Ltd.
• JP Tech
• Jun-Tech Co., Ltd.
• JVC
• Kaijo Corp.
• KAMRO Corp.

• Kanematsu Semiconductor Corp.
• KASHIYAMA Industries, Ltd
• Kasuga Electric Works
• Kawasaki Heavy Industries, Ltd.
• KEBA Automation Ges. M.b.H. Co.
• KEI System Co., Ltd
• Keisokugiken Corporation
• Keyence Corporation
• Keystone Valves Controls, Inc.
• Kimura Electric Co., Ltd
• Kinkei System Corporation
• Kistler-Morse Corporation
• Kodensha Ltd
• Koganei Cld.
• Kojima Instruments Inc.

26
Vendors Supporting

• Kokusai Denki Engineering Co., Ltd.
• Kokusai Electric Co., Ltd.
• Kollmorgen Industrial Drives
• KONAN Electric
• Koyo Electronics
• Krones, Inc
• KUKA Roboter GmbH
• Kumho Industrial Co., Ltd.
• Kuramo Electric Co., Ltd.
• Kuroda Precision Industries Ltd.
• KVASER AB
• KWS Computersystemem GmbH
• Kyopal Co., Ltd
• Kyosan Cable, Ltd.
• Kyushu Matsushita Electric Co., Ltd
• Lantronix, Inc.

• Leading Edge Design
• Leine Linde AB
• Lenze GmbH Co KG
• Leuze electronic GmbH
• Leybold Vacuum GmbH
• LG Industrial System Co., Ltd
• Lika Electronic SNC
• LINTEC Co., Ltd.
• Livingston Co., Inc.
• Logical Design Group, Inc.
• Loreme
• Love Controls Division/Dwyer Inst.
• LP-Elektronik
• Lumberg, Inc.
• Lutze, Inc.

27
Vendors Supporting

• MSYSTEM Co. Ltd
• M2C
• MAATEL SA
• MAC Valves, Inc.
• Madison Cable Corporation
• Magnetek
• Mainco
• Mannesmann Rexroth/Pneumatic Div
• Marathon Ltd.
• Marsh Bellofram-Bellofram PCD Division
• Matric Limited Inc.
• Matshushita Electric Works, Ltd.
• Matsushita Electric Industrial Co., Ltd
• Matsushita Electric Industrial Co., Ltd/Motor
  Company
• Matsushita Welding Systems Co.,Ltd.

• Max Stegmann GmbH
• MAXTEC International
• MDT, Software
• MECS Corporation
• Medar, Inc.
• Meidensha Corp.
• Meiji Electric
• Melec Inc.
• Mencom Corporation
• Mesa Systemtechnik
• Mettler-Toledo, Inc.
• Mibu Denki Industrial Co., Ltd.
• Michiproducts Co., Ltd.
• Micro Mo Electronics, Inc.
• Microcontrol (Australia) Pty Ltd

28
Vendors Supporting

• MicroControl GmbH Co.
• Microsmith, Inc.
• Miller Electric Mfg Co.
• Millipore
• Milwaukee Electrrnics
• Mink Consulting Inc.
• Mitsubishi Cable Industries Led.
• Mitsubishi Electric Automation
• Mitsubishi Electric Corporation
• Mitsubishi Electric System LSI Design Corp.
• Mitsubishi Heavy Industries Ltd
• Miura Corporation
• MKS Instruments, Inc.
• Moeller ElectroniX
• Mogami Wire Cable Corporation

• Molex Industrial Interfaces, Inc.
• Moog Inc.
• Morinaga Milk Industry Co.,Ltd.
• Motion Engineering, Inc.
• MTE Limited
• MTS Systems Corp.
• MTS Systems Corporation-Automation Division
• MTT Instruments, Inc.
• Muramiq, Ltd.
• Murata Machinery
• Murrelektronik GmbH
• Nachi Fujikoshi Corporation
• NADEX Co., Ltd
• Namco Controls Corp.
• National Instruments

29
Vendors Supporting

• Negretti Automation Ltd.
• Nemicon Co., Ltd
• NESLAB Instruments, Inc.
• Netlogic Inc.
• NetSafety Monitoring, Inc.
• network supply Co., Ltd.
• New Cosmos Co., Ltd.
• Nichigoh Communication Electric Wire Co., Ltd.
• Nidec-Shimpo Corp.
• Nihon Electric Wire Cable Co., Ltd
• Nihon Weidmuller Co., Ltd
• Niigata Electronic Instruments Co., Ltd.
• Nikki Denso Co., Ltd.
• Nippon Motorola Ltd
• Nippon Otis Elevator Company

• Nippon Seisen Cable, Ltd.
• Nippon System Development Co., Ltd
• Nissei Plastic Industrial Co., Ltd
• Nissin Electric Co., Ltd
• NKE Corporation
• Nor-Cal Products, Inc.
• Norcott Technologies Ltd
• Nordson Corporation
• North American Mfg.
• NSD Corporation
• NSI sa
• NSK Ltd.
• NTI Limited
• Numatics, Inc.
• O. G. Line

30
Vendors Supporting

• O.N. Electronic Co., Ltd.
• OBARA Corp.
• Oberg Industries Inc.
• OCM Technology Inc.
• ODVA Special Reserve
• Ohm Electric Co., Ltd.
• Oildyne
• Okano Electric Wire Co. Ltd
• Okaya Electronics Corporation
• Oki Electric Industry Co., Ltd
• OKUMA America
• OKUMA Corporation
• Olflex Wire Cable, Inc.
• Omron ASO Co., Ltd
• Omron Corporation

• Omron Software Co., Ltd
• Online Development Inc. (Automation Value)
• Optex Co.,Ltd.
• OPTO-22
• Oriental Motor Company
• ORION Machinery Company Ltd
• Oven Industries, Inc.
• PACE Control Systems
• Panel-Tec
• PanelWorks LLC
• Paradigm Controls Ltd.
• Parasense Development Centre
• Parker Hannifin Corp.
• Parker Hannifin/Compumotor Division
• Particle Measuring Systems, Inc.

31
Vendors Supporting

• Patlite Corporation
• Patriot Sensors Controls
• PDL Electronics Ltd.
• Pepperl Fuchs
• Pfeiffer Vacuum GmbH
• PFU Limited
• Phasetronics, Inc.
• Phoenix Contact
• Pilz GmbH Co
• Pinnacle Systems
• PMA
• POLSYS CORP
• POSCON
• Prima Electronics S.p.A.
• Professional Supply Inc.

• Pro-Log Corp.
• Proportion-Air, Inc.
• Proteous Industries
• Pyramid Solutions, Inc.
• Pyramid Technical Consultants, Inc.
• QLOG Corporation
• Qualiflow
• Quinn Systems Ltd.
• RadiSys Corporation
• Rapistan Systems
• RDI Software
• Real Time Automation (CID)
• Red Lion Controls
• Redwood Microsystems Inc. (RMI)
• Rikei Corporation

32
Vendors Supporting

• Riken Keiki Co., LTD
• RKC Instrument Inc.
• Robert Bosch GmbH
• Robicon
• Roboticsware, Inc.
• ROBOX SPA
• Rockwell Automation/Allen-Bradley Company, Inc.
• Rockwell Automation/DODGE
• Rockwell Automation/Electro-Craft Motion Control
• Rockwell Automation/Reliance Elec.
• Rockwell Automation-SprecherSchuh
• Rockwell Software, Inc.
• Ross Controls
• Rotork Controls
• Ryco Graphic Manufacturing Inc.

• SAB Brockskes GmbH Co. KG
• Sankyo Seiki Mfg. Co., Ltd
• Sansha Electric Mfg. Co.,Ltd.
• Santest Co., Ltd.
• Sanyo Denki Co., Ltd
• Sanyo Electric Co. Ltd.
• Sanyo Machine Works, Ltd.
• Saturn Electronics and Engineering
• Schenck-AccuRate, Inc.
• Schleicher GmbH Co.
• Schneider Automation, Inc.
• Schrader Bellows
• Scientific Technologies Incorporated
• SEC (Samsung Electronics Co., Ltd)
• SEG Kempen GmbH

33
Vendors Supporting

• Seiberco Inc.
• Seiko Seiki Co., Ltd.
• Selectron Lyss AG
• Sena Technologies, Inc.
• Sencon Inc.
• Sense Eletronica LTDA
• Seoil Electric Co., Ltd.
• Serck Controls Limited
• Serra Soldadura, S.A.
• SETO Electronics Industry Co., Ltd
• SEW Eurodrive GmbH
• SG Co., Ltd
• Shanghai Aton Electric Co., Ltd
• Shanghai Electrical Apparatus Research Institute
• Sharp Manufacturing Systems Corp.

• Sherrex Systems Ltd
• Shimaden Co. Ltd.
• Shimadzu Corporation
• Shimafuji Electric Co., Ltd
• Shin Caterpillar Mitsubishi Ltd.
• SHIN HO SYSTEM Co., Ltd.
• Shinagawa Electric
• Shinko Electric Co., Ltd
• SHINKO TECHNOS Co., Ltd.
• Showa Electric Wire Cable Co.
• SIEI S.p.A.
• Siemens Energy Automation
• SIG Positec BergerLahr GmbH
• Simplatroll Ltd
• Sinano Electric, Co., Ltd.

34
Vendors Supporting

• Six Tau S.p.A.
• Smartscan Ltd
• SMC Corporation of America
• Sodick Co.,Ltd.
• Softing GmbH
• Sony Max Corporation
• Sony Precision Technology Inc.
• Southwest Research Institute
• Spang Power Electronics
• Spectra Precision AB
• Spectrum Controls, Inc.
• Spraying Systems Company
• Square D Company
• SST
• STA Reutlingen

• Star Micronics, Co., Ltd.
• Startco Engineering Ltd.
• STAS
• Status Technologies
• STEC INSTRUMENTS, INC
• Sterling Controls
• StoneL Corporation
• Suetron Electronic GmbH
• Sumitomo Heavy Industries, Ltd.
• Sumitomo Metal Industries, Ltd
• Sumitomo Metal Industries, Ltd
• Sumitomo Wiring Systems, Ltd
• SungGi Internet Co., Ltd.
• SUNNY GIKEN Inc.
• SUNX Limited

35
Vendors Supporting

• Surface Combustion, Inc.
• Suzuki Motor Corporation
• SWAC GmbH
• Synergetic Micro Systems Inc.
• Syron Engineering Manufacturing,
• System Controls, Ltd.
• Taesan LCD Co.,Ltd.
• Tahara Electric
• Tait Control Systems Ltd.
• Taiwan Keiso Co., Ltd
• Takagi Industrial Co.,Ltd.
• Takamastsu Machineer Section
• Takebishi Electric
• Tamadic Co.
• Tandis Research, Inc.

• Tango Computer Service Corporation
• Tateyama System Laboratory Co., Ltd.
• Tatsuta Electric Wire Cable Co., Ltd.
• TB Woods, Inc
• TECHNO DIGITAL CORPORATION
• Technology Service, Inc.
• Teddington Controls Ltd
• Teejet Technologies
• Teknic, Inc.
• Tellima Technology Ltd
• TEM-TECH Lab Co., Ltd
• Tenta Technology
• Terasaki Electric Co., Ltd.
• Tescom Corporation
• TG Information Network Co., Ltd.

36
Vendors Supporting

• The Furukawa Electric
• The Lincoln Electric Company
• The Oilgear Company
• The University of Arizona
• Thermo BLH
• Tokyo Electron Device Ltd
• Tokyo Electron Kyushu Limited
• Tokyo Electron Yamanashi Ltd
• Tokyo Keiso Co., Ltd.
• Tokyo Seimitsu Co., Ltd.
• Tokyo Sokki Kenkyujo Co., Ltd
• Topworx
• Toshiba FA Systems Engineering Corporation
• Toshiba Information Systems (Japan) Corporation
• Toshiba International Corp.

• Toshiba Mie Plant
• Towa Shoko Co., Ltd
• Toyo Denki Seizo KK
• Toyo Electric Corporation
• Toyoda Machine Works, Ltd
• Toyogiken Co., Ltd.
• Toyooki Kogyo Co., Ltd.
• TPC Wire Cable
• TR Electronic GmbH
• Trio Motion Tech Ltd
• TRSystemtechnik GmbH
• Tsuken Electric Ind Co., Ltd
• Turck, Inc.
• TWK Elektronik GmbH
• ULVAC Japan Ltd.

37
Vendors Supporting

• Unico, Inc.
• UniControls as
• Union Electronics Co., Ltd.
• UNIPULSE Corporation
• UNIQUE Co. Ltd
• Unit Instruments, Kinetics
• Unitrode
• Univer S.p.A.
• UTEC Corporation
• Vaasa Control
• Vaasa Institute of Technology
• Valcom Co., Ltd.
• Vansco Electronics Ltd.
• Varian Vacuum Products
• VAT Vakuumventile AG

• Vector Informatik GmbH
• VIPA GmbH
• VIT Software HB
• VMIC
• Vorne Industries, Inc.
• Wago Corporation
• Warwick Manufacturing Group
• Watlow Electric Inc.
• Weidmuller, Inc.
• Weltronics/Technitron Corp.
• West Instruments Limited
• Western Reserve Controls Corp.
• Western Servo Design Inc.
• Westgate Technologies
• Westlock Controls Corp.

38
Vendors Supporting

• Whedco, Inc.
• White Eagle Systems Technology, Inc.
• Wieland Electric GmbH
• Wind River Systems, Inc.
• Wired Rite Systems
• Wittenstein Ternary Co., Ltd.
• Wizdom Controls, Inc.
• Woodhead Connectivity
• Worcester Controls Corporation
• WPI (Wire-Pro Inc.)
• XEBEC
• Xycom, Inc.
• YAMAHA Motor Co. Ltd.
• Yaskawa Electric America, Inc.
• Yazaki Parts Co., Ltd.

• Yokogawa Digital Computer Corporation
• Yokogawa Electric Corp.
• Yokogawa MC Corp
• Yokogawa MAT Corporation
• Yokoyama Shokai Co., Ltd.
• Yosio Electronic Co.
• ZPA-DP A.S.
• Z-World Engineering

39
Comparison of Technologies
Criterion WorldFIP CAN LONTalk Seriplex ISP BI
TBUS Perf. / Speed / Determinism Good Good Poor
Medium Good Medium Interoperability Good Medium
Good Poor Good Medium Cost and Tech.
Leverage Medium Good Medium Poor Medium Medium P
roduct Availability Medium Good Good Medium Poor
Good Development and Impl. Cost Poor Good Medium
Good Poor Good Outlook Medium Good Good Good M
edium Medium Reliability Good Good Good Medium
Good Good Peer-to-Peer Capability Medium Good Go
od Poor Medium Poor Memory Requirements Poor Goo
d Medium Good Poor Medium User Friend. /
Tools Medium Medium Good Medium Medium Medium Ow
nership Good Good Poor Poor Good Good Instal.
Base Sem. Mfg. / Proven Poor Medium Good Good Poor
Good Board Size Poor Good Medium Good Poor Goo
d Msg. Passing Capability Good Medium Good Poor
Good Medium Remaining Work Good Poor Good Poor M
edium Medium Table 1 Qualitative Candidate
Analysis W.R.T. Selection Criteria (Selection
criteria listed in order of importance) Source
ANALYSIS OF SENSOR / ACTUATOR BUS
INTEROPERABILITY STANDARD ALTERNATIVES FOR
SEMICONDUCTOR MANUFACTURING James R. Moyne, Nader
Najafi 1 , Daniel Judd 2 , and Allen Stock 3
University of Michigan, Center for Display
Technology Manufacturing, Ann Arbor, MI
48109-2108, 1 IBM, 2 Arlington Laboratories, 3
SEMATECH / Advanced Micro Devices
40
(No Transcript)
