1

• Gastric Rectal Cancer
• D. Genovesi
• Radiation Oncology Department CHIETI
• www.radioterapia.unich.it

2
GASTRIC CANCER
3
GASTRIC CANCER
4
GASTRIC CANCER TNM Classifications AJCC
5
Gastric Cancer Clinical Case Presentation
PS 100 (Karnofsky) 68 yrs old male
Cardiac stroke 8yrs ago, no other
diseases and no drugs at the moment.
Endoscopy (17/12/2008) ulcer with free bottom
and infiltrated margins at
antropyloric region, increased thickness with non
crossing stenosis. Contrast CT
Thoraxabdomen (01/09) negative lungs, liver
and bones. Increased wall thikcness of
gastric antrum (thickness of 2 cm) compatible
with Eteroplasy. Concomitant small
perivisceral nodes (0.5 cm) Bigger nodes
at celiac region (2.1 cm) interaortocaval region
(2.1 cm), paraortic region (1 cm).
05/01/09 Sub-total gastrectomylimphoadenect
omy D2. Histology Macroscopic vegetant lesion
of 4. 5 cm of antropyloric region at 1 cm from
distal margin Microscopic Carcinoma G3 (70) and
Adenocarcinoma G2 (30) with entire gastric wall
invasion. Free duodenal stump. Free proximal
margin M of Carcinoma G3 in 1/14 lesser
curvature nodes. No M in 22 greater curvature.
No omental tumour. No M in retrocoledocus,
retropancreatic, celiac, and left gastric artery
nodes. PATHOLOGIC STAGE p T2 p N1 M0
STAGE II
6
Key Points
Diagnostic Work-up for Staging
Prognostic Factors
Surgical Treatment
Neoadjuvant Treatments
Adjuvant Treatments
7
Key Points
Diagnostic Work-up for Staging

• Double Contrast Upper G.I.

• Barium Radiological Studies

• Endoscopy procedure of choice (8-10 biopsies)

• Chest-Abdomen-Pelvic enhanced CT
• sensitivity 23-56 Early Gastric Cancer
  92-95 in advanced tumors
• metastatic lymph node size criterion gt 10 mm

• Endoscopic Ultrasonography (EUS)

• MRI has not achieved clinical importance

• CT-PET investigational procedure

8
Key Points
Prognostic Factors

• Tumor Grading

• R0 R1 R2 resection (operating procedure)


• T stage

• Lymphadenectomy
• at least 15 lymph nodes removed and analyzed
• Japanese Classification 16 node stations in
  3 groups depending on T

• T location proximal cancer poorer SVV vs
  distal cancer

• Lymphatic, Venous or Perieneural invasion

• High CEA levels preop

9
Key Points
Surgical Treatment

• Total Gastrectomy proximal or middle third or
  diffuse T

• Total Gastrectomy vs Subtotal Gastrectomy
• no advantage for distal (antral) Stomach

• 5 cm free is required for resection margins

• D1 perigastric LFN along lesser and greater
  curvatures (1-6)

• D2 plus LFN along left gastric artery (7),
  common hepatic artery (8),
• celiac trunk (9), splenic hilus and
  splenic artery (10, 11)

• D3 plus LFN along hepatoduodenal ligament (12),
  posterior surface
• of head of the pancreas (13) and the
  root of the mesentery (14)

• D4 plus LFN paracolic region and abdominal
  aorta (15, 16)

10
Key Points
Neoadjuvant Treatments

• Preop Chemo high risk pts (T3-T4 N0-2 M0)
  feasibility in
• Phase II studies
  (increase R0 rate) improve
• SVV in 4 Random
  Trials (ECF schedule)
• Type 2 Level of Evidence for Stages II-IV

• Preop Radiotherapy (RT) benefit in only one
  random trial
• 40
  GyS vs S
• Further Randomised Trials are required

11
Key Points
Adjuvant Treatments

• Postop Chemo results often disappointing poor
  compliance
• with
  multidrugs schedules small-moderate
• benefit
• Type 2 Level of Evidence for Stages II-IV

• Postop Radiotherapy (RT) No Benefit

• Postop ChemoRadiotherapy
• SWOG-INT 116, Stage I-IV, M0 Surgery Obs
  vs CT-RT 5FU/L
• 5yrs OS 40 vs 28.4 (plt0.001)
• 5yrs DFS 31 vs 25 (plt0.001)
• 36 D1 only 10 D2
• Kim et al IJROBP 63, 2005 clinical benefit
  in D2 (SVV DFS)
• Type 2 Level of Evidence for Stages II-IV

12
Type II Level of Evidence
13
RESULTS
3 yr OS
41
48
41
Macdonald JS et Al New Eng J Med -2001
14
Type III Level of Evidence
15
Kim IJROBP, 2005
Results
DFS
OS
16
GASTRIC CANCER EBM for Radiotherapy
17
Gastric Cancer Clinical Case Presentation
PS 100 (Karnofsky) 68 yrs old male
Cardiac stroke 8yrs ago, no other
diseases and no drugs at the moment.
Endoscopy (17/12/2008) ulcer with free bottom
and infiltrated margins at
antropyloric region, increased thickness with non
crossing stenosis. Contrast CT
Thoraxabdomen (01/09) negative lungs, liver
and bones. Increased wall thikcness of
gastric antrum (thickness of 2 cm) compatible
with Eteroplasy. Concomitant small
perivisceral nodes (0.5 cm) Bigger nodes
at celiac region (2.1 cm) interaortocaval region
(2.1 cm), paraortic region (1 cm).
05/01/09 Sub-total gastrectomylimphoadenect
omy D2. Histology Macroscopic vegetant lesion
of 4. 5 cm of antropyloric region at 1 cm from
distal margin Microscopic Carcinoma G3 (70) and
Adenocarcinoma G2 (30) with entire gastric wall
invasion. Free duodenal stump. Free proximal
margin M of Carcinoma G3 in 1/14 lesser
curvature nodes. No M in 22 greater curvature.
No omental tumour. No M in retrocoledocus,
retropancreatic, celiac, and left gastric artery
nodes. PATHOLOGIC STAGE p T2 p N1 M0
STAGE II
18
GASTRIC CANCER Management of our Clinical
Case
Day 1- Day 28-31 Day 56-58
Day 84-98 Day 112-6
FU-FA (5 gg)
FU-FA (5 gg)
FU-FA (3 gg)
FU-FA (4 gg)
FU-FA (5 gg)
Radiotherapy
INT-0116
Macdonald JS et Al New Eng J Med -2001
19
Why preoperative treatments ?
pCR
R0 vs R
Ajani JA et Al JCO - 2005
20
(No Transcript)
21
RECTAL CANCER
22
RECTAL CANCER
11.000 12.000 new cases/year in Italy
De Carli A., La Vecchia C. 2002 Verdecchia A.,
Micheli A., Gatta G. 2002
23
RECTAL CANCER
24
RECTAL CANCER
25
Rectal Cancer Clinical Case Presentation
PS 100 (Karnofsky) 62
yrs old male no other diseases.
Endoscopy (13/01/2006) ulcerated and vegetant
lesion of 6 cm very near to internal
anal sphincter HISTOLOGY
Adenocarcinoma G2. Contrast CT
Thoraxabdomen (20/01/06) negative lungs and
liver. Neoplastic lesion which makes
the lumen substenotic, presence of some
lesions in perirectal adipous tissue.Two nodes
of 1 cm in perirectal adipous
tissue. CLINICAL STAGE c T3 c
N1 M0 IIIB STAGE
26
(No Transcript)
27
Key Points
Diagnostic Work-up for Staging
Pathology
Surgical Treatment
Radiotherapy and Chemotherapy
Ongoing Research
28
Key Points
Diagnostic Work-up for Staging

• Endoscopy with biopsies

• Endorectal ultrasound T1 vs T2 tumors vs
  borderline T3

• Multislice-CT is not sufficiently accurate for
  low tumors
• CT cannot accurately distinguish LFN vs LFN-

Phased Array MRI is highly accurate in
Staging Difficulty in differentiation T1 vs T2 vs
borderline T3

• Circumferential Resection Margin (CRM) MRI is
  highly
• accurate for the prediction of CRM

• MRI with specific contrast enhanced
  (USPIO)promising

• FDG-PETdisappointing results on N role in
  response evaluation

29
The Circumferential Resection Margin
predictivity MRI
Sensitivity 60-80 Specificity 73-100
30
T3 with involved mesorectal fascia
Beets-Tan et al. Lancet 2001 357 (9255) 497 - 504
31
The Value of CRM
32
Macroscopic assessment of Mesorectal excision

• CRM ( cm ) incomplete
• lt 0.1 43.9
• 0.1 - 0.2 27.8
• 0.2 - 0.5 27.8
• 0.5 - 1.0 12.9
• gt 1.0 11.1

33
Criterion for detection of node metastases

• No choice but to use the size of lymph nodes as
  the most reliable criterion
• In most cases, 5mm or larger, or 10mm or larger
  is regarded as criterion for lymph node
  metastases.

34
Metastatic nodes less than Ø 5mm in gt 50
Dworak et al. Surg Endos 1989396-9 Brown et al.
Radiology 2003227371-7
35
USPIO MRI for nodal staging
36
Key Points
Pathology

• Guideline and experience significantly improve
• the qualitywww.rcpath.org/resources/pdf/colore
  ctalcancer.pdf

• Careful Macroscopic and Microscopic examination

• Tumor Regression Grade (TRG) scales

37
Tumor-Regression-Grading TRG
Complete Regression
(100) Good Regression (gt 50)
Moderate Regression (25-50) Minimal
Regression (lt 25) No Regression
(0)
38
Key Points
Surgical Treatment

• The standard surgery Total Mesorectal Excision
• (TME)

• Preop Radio-chemoterapy S increase sphincter
• preservation (with good sphincter function)
  for
• downsizing

• Pathological studies of CRM in anorectal
  junction
• and anal canal sphincter show higher rates of
  CRM
• involvement

39
Key Points
Radiotherapy and Chemotherapy

• Early T local excision (adverse prognostic
  factors evaluation)
• endoluminal radiotherapy


• c T3-4/N0 or plus 15 Random Trials 3
  Meta-analysis
• increase LC conflicting results in SVV for
  preop Radiotherapy

• Short-Course preop (5Gyx5) vs RT-CT not seem
  effective
• for pts with predictive positive CRM e low
  tumor location

• 2 Random Trials (EORTC 22921 FFCD 9203) on
  role of
• chemo with preop-Radiotherapy in RT-CT preop
  group
• increase of LC, increase rate of p T0, G3
  tox, no
• benefit of 5 yrs OS

40
Key Points
Radiotherapy and Chemotherapy

• Polish Trial in c T3-4 5 Gy x 5 vs preop
  RT-CT
• no difference in sphincter preservation, LC,
  OS but
• LATE TOXICITY

• NCI Consensus Conference 1990 post-op CT-RT
  5FU-based
• Standard treatment in post-op p T3/ p N1-2
  rectal tumors

• Preop RT-CT vs Post-op RT-CT 5FU-based 4
• Random Trials.
• The most important closed Trial is German
  Study
• CAO/ARO/AIO 94

41
CAO/ARO/AIO 94
P H A S E
III
Trial
50.4 Gy Bolus CI 5-FU Surgery 5-FU x
4 wks 1,5 T3 50.4 Gy Bolus Surgery CI
5-FU 5-FU x 4 wks 1,5
42
CAO/ARO/AIO 94
P H A S E
III
Trial
Post-op Pre-op P Evaluable
394 405 - 5-Yr LF 15 6 0.006 5-Yr
Survival 76 74 ns Acute toxicity 40 27 0
.001 Chronic toxicity 24 14 0.012 5-Yr DF
38 36 ns Sphincter Preservation 15/78
(20) 45/116 (39) 0.004
Sauer et al NEJM 2004
43
CAO/ARO/AIO 94
P H A S E
III
Trial
The Value of Downstaging !!!
C. Rödel et al., J Clin Oncol 2005 238688-96
44
Meaning of Downstaging
Patients pT0-2/TOT LC 5 aa pT0-2 OS 5 aa pT0-2 DFS 5 aa pT0-2
Berger 97 Hosp Bretonneau 19/167 - 92 87
Kaminsky-F 98 Alexis Vautrin Cent. 21/98 94 100 94
Janjan 99 M.D.Anderson 68/117 - 93-100 75-83
Mohiuddin 00 Kentucky Univer. 22/77 100 100 100
Valentini 02 Catholic Univer 76/165 96 90 80-83
Theodoropoulos 02 Grant Med Center 16/88 100 100 100
Aguilar 03 Univ of Minnesota 21/168 100 95 95
45
Key Points
Radiotherapy and Chemotherapy

• No data with level 1 evidence for adjuvant
  post-op chemo
• after preoperative RT-CT it seems an effect
  of adjuvant
• chemo in responder pts

• Unresectable rectal cancer pre-op RT-CT
  5FU-based to
• enhance R0 resectability (50-54 Gy Radiation
  dose)
• IORT single institutions studies support a
  favourable
• effect

• Local Recurrence pre-op RT-CT /- IORT
  (conflicting
• results)
• Re-irradiation is under clinical evaluation

46
Key Points
Ongoing Research

• Topic for surgical research enhance organ
  preservation

• Intensification of pre-op RT-CT and post-op
  chemo
• - New Drugs (Oxaliplatin Capecitabine)
• - Altered fractionation RT dose

• EGFR and VEGF promising targets of antitumor
  treatment

• Individualised therapies based on
  clinical-pathological
• features and molecular and genetic markers

• New Imaging for response evaluation

47
Rectal Cancer Clinical Case Presentation
PS 100 (Karnofsky) 62
yrs old male no other diseases.
Endoscopy (13/01/2006) ulcerated and vegetant
lesion of 6 cm very near to internal
anal sphincter HISTOLOGY
Adenocarcinoma G2. Contrast CT
Thoraxabdomen (20/01/06) negative lungs and
liver. Neoplastic lesion which makes
the lumen substenotic, presence of some
lesions in perirectal adipous tissue.Two nodes
of 1 cm in perirectal adipous
tissue. CLINICAL STAGE c T3 c
N1 M0 IIIB STAGE
48

Rectal Cancer management of our clinical
case
PLAFUR Schedule
Follow-up
8 ws
S
50.4 Gy
CDDP 60 mg/mq 1 gg
Chemo N
5-FU 1000 mg/mq 1-5 gg
49
Post CRT
Pre CRT
y p T0
50
Diffusion MRI
PreCRT
51
(No Transcript)
