Cascade Systems

1
Cascade Systems

• Presents .

2
Crane Safe Load Indicator
3
System Specifications
Safe Load Indicator with Graphical Touch screen
LCD.
GSM/GPRS facility.
GPS tracking / monitoring on server.
Remote Monitoring for cranes via SMS.
Fuel Consumption details.
SMS indication to Crane Owner for Errors, Engine
on. etc
Enhanced graphical interface.
Colored bar Graph Indicators, indicating colors
for different range of values.
Compact size, can be fitted easily.
Graphic LCD available in different sizes 4.3inch,
7inch, 12inch.
High speed Arm11 processor.
128/256mb Ram available.
Quality sensors to measure the correct values of
Crane Parameters.
Onboard data Storage facility upto 4 GB.
4
Functions
5
System Hardware
6
Spares
7
Multilingual User Interface

• Punjabi

• Malayalam

8
System Display
9
Mechanical Accessories
Accessories provided with Data Logger

Line Rider Dynamometer

Cable / Roller Drum
Angle Meter
Limit Switch Assembly
Load Cell With Linkages

10
Associated Accessories


Cable Reeling Drum Assembly
Anti Two Block Assembly
GPS tracker
Motor Assembly
Boom Length Detector
11
REMOTE DATA LOGGER WITH SENSORS

12
Warning Alarms
13
Real-Time Data from Server www.realtimemachines.co
m
14
Remote Data Logging System

• Safe Load Indicators for Mobile Crane

• Safe Load Indicators for Tower Crane

• Mobile Tower Battery Monitoring System

15
Our R D Team
16
Our R D Team
17
Contact Us..
Cascade Systems
Shaligram Building, Opp Old T.M.C. Office
Near Z. P. Office, Station Road, Thane
(West) Maharashtra India www.cascadenet.in
www.realtimemachines.com Mob [phone],
0919930606952 E-mail mvtikhe_at_gmail.com,
cascadesystems13_at_gmail.com
