New Architectural Coatings Technology Targeted At Stricter Hospital Infection Protocols

1
New Architectural Coatings Technology Targeted At
Stricter Hospital Infection Protocols
From Great Raw Materials Come Great Coatings

2

• Agenda

• Introduction to the Problem
• Research and Input from Healthcare Decision
  Makers
• The Technology Durability Testing and
  Comparisons
• Summary
• Questions and Answers

3

• Agenda

• Introduction to the Problem
• Research and Input from Healthcare Decision
  Makers
• The Technology Durability Testing and
  Comparisons
• Summary
• Questions and Answers

4
Hospital acquired infections are the fourth
largest cause of death in U.S
Medicare Will Not Pay For Hospital Mistakes And
Infections, New Rule (Source http//www.medicalne
wstoday.com/articles/80074.php)
Deadly Admissions Hospital-Acquired Infections
Are 4th-Largest Killer in U.S., But Ohioans
Cannot Get Statistics to Compare Facilities By
Tracy Wheeler, The Akron Beacon Journal, Ohio
Jan. 9--But for 20 million Americans each year
-- about one in every 10 to 20 patients -- a trip
to the hospital results in dangerous, lingering
infections, whether through surgery, dialysis,
ventilators, IVs, or catheters. At an estimated
90,000 deaths a year, these hospital-acquired
infections kill as many people in the United
States as AIDS, breast cancer and car accidents
combined. (Sourcehttp//www.redorbit.com/news/he
alth/351010/deadly_admissions_hospitalacquired_inf
ections_are_4thlargest_killer_in_us_but/)
HOSPITAL-ACQUIRED INFECTIONS KILL 270 PEOPLE A
DAY in NYC alone (Sourcehttp//www.nyinjurytalk.c
om/2008/01/hospitalacquired_infections_ki_1.html)
The issue is significant and actions are being
taken Timing is right
5
The ProblemValue Proposition Safety and
Economics
Healthcare related organizations develop more
stringent standards

• The Center for Disease Control (CDC) puts out
  Guidelines for Disinfection and Sterilization in
  Healthcare Facilities, 2008 outlining
• Harsher disinfection chemicals
• More frequent cleaning
• The Joint Commission (TJC) incorporates tougher
  disinfection protocols in their guides for high
  risk environments in hospitals such as emergency
  and operating rooms, trauma bays, procedure
  rooms.
• The Result Traditional wall paints are not
  holding up long term to the increased scrubbing
  and harsher chemicals

6
The ProblemValue Proposition Safety and
Economics
Meanwhile, insurers recognize the issue and take
action

• Medicare changes their insurance protocols
• As of January 2009, will not pay for Hospital
  Acquired Infections (HAI)
• Treatment costs will belong to the hospital
• Soon after, most major medical insurers follow
• The Result Hospitals enact increased
  preventative measures to greatly reduce the
  chance for HAI for patient safety and economic
  viability

7

• Agenda

• Introduction to the Problem
• Research and Input from Healthcare Decision
  Makers
• The Technology Durability Testing and
  Comparisons
• Summary
• Questions and Answers

8
Defining the ProblemMultiple Points in the Value
Chain

• To define the unmet need, we engaged
  stakeholders
• Hospital Facility Managers
• Architect/Spec Writers
• Hospital Administrators
• Painting Contractors
• Hospital Accreditation Organizations
• And listened to how they defined the problem

9
Research from Key Hospital PersonnelGoal Reduce
repaint cycle, keep areas safe, save money

• After listening, we heard that they wanted
• A more durable, scrubbable wall coating in the
  high risk areas
• A very low odor coating that would not disrupt
  operations
• Warmer eggshell or matte coatings but still
  have durability
• An easier to clean and seamless surface
• Less downtime in these high operating cost areas
• To use their in-house painters more on patient
  rooms and hallways

10
Research from Key Hospital PersonnelGoal Reduce
repaint cycle, keep areas safe, save money
Values are Typical
11
Input from Healthcare CommunityHospital Facility
Managers and Administrators
The Preferred Attributes from Around the Country
12
The Value PropositionFrom the Hospitals Point
of View
For the hospital administrator who is concerned
with meeting the CDC protocols without
sacrificing aesthetics and durability, a new high
durability coating technology has been developed
for rooms requiring frequent cleaning that offers
improved durability and resistance to harsh
cleaners and disinfectants without sacrificing
appearance.

• Compared with conventional wall paint
• 4x more durable and scrub-able
• Same ease of use, color palette, and low gloss
  finish
• Compared to tile
• 4-5x lower cost
• Better design latitude for future color schemes

13

• Agenda

• Introduction to the Problem
• Research and Input from Healthcare Decision
  Makers
• The Technology Durability Testing and
  Comparisons
• Summary
• Questions and Answers

14
The HD Wall Coating TechnologyArchitectural Wall
Paint Alternative

• Two Component Waterborne Polyurethane Technology
• Built on Bayers HD Wall Coating Technology
• Attributes
• High Durability even in an eggshell or flat
  finish
• Silky surface makes cleaning easier
• Excellent chemical and disinfectant resistance
• Very low odor during installation and drying
• Ultra low VOC and solvent at 15g/l or less
• Same color palette as traditional architectural
  wall paint

15
The Technology2K Waterborne Coatings

• Waterborne Technologies
• 2K chemistry with excellent
• overall properties
• Water is Green
• Early waterborne coatings had as much as 300g/l
  of co-solvent
• New commercial systems are now at 0-15 g/L
• Offer viable replacement products to solventborne
  epoxy or polyurethane systems

16
The Technology2K Waterborne Coatings

• Chemistry
• 2K aliphatic polyurethane based on polyurethane
  or polyacrylate dispersions and aliphatic
  isocyanates

Polyurethane Dispersion
Aliphatic Isocyanate
React to form
A Polyurethane Coating
17
Durability Testing and ComparisonTested with
Typical Disinfection Chemicals
Paint or Coating VOC g/l Clorox Cleanup Double Rubs Ecolab Disinfectant Cleaner Double Rubs Betadine 1 hr. spot test
1K Waterborne Acrylic 1 44 54 104 3
1K Waterborne Acrylic 2 40 62 380 2
1K Waterborne Acrylic 3 0 250 400 2
1K Waterborne Epoxy A 155 280 400 2
1K Waterborne Epoxy B 96 320 400 2
1K Waterborne Epoxy C 96 275 400 2
2K Solventborne Epoxy 169 205 400 2
2K Waterborne Polyurethane based on Bayers HD technology 2 400 400 1
0 no stain 1 faint stain 2 yellow stain
3 brown stain
From published literature
Values are typical
18
Durability Testing and ComparisonTested with
Typical Disinfection Chemicals
Picture 1 Typical Waterborne Acrylic
Picture 2 2K Waterborne Polyurethane
19
Comparison - Odor TestingSniff Test Developed
to Quantify a Qualitative Observation
Paint or Coating Odor Value (1 low, 5 high)
1K Waterborne Acrylic 1 1
1K Waterborne Acrylic 2 1
1K Waterborne Acrylic 3 2
1K Waterborne Epoxy A 4
1K Waterborne Epoxy B 4
1K Waterborne Epoxy C 4
2K Solventborne Epoxy 5
2K Waterborne Polyurethane based on Bayers HD technology 1
values are typical
20
Additional TestingQuantitative Comparisons
System 2K WB HD Technology 2K WB HD Technology Latex A Latex B Latex C 1K WB Epoxy A 1K WB Epoxy B 1K WB Epoxy C 2K WB Epoxy
Theoretical VOC g/L 2 4 44 40 0 155 96 96 169
Gloss (60º) 6 3 2 5 7 11 28 12 12
Dry Time
set to touch (min) set to touch (min) 7 100 60 9 60 60 8 9 60
mar free (min) mar free (min) 10 120 20 11 13
Sag (mils) 6 12 12 12 12 12 12 12 12
values are typical
21

• Agenda

• Introduction to the Problem and Technology
• Research and Input from Healthcare Decision
  Makers
• Durability Testing and Comparisons
• Summary
• Questions and Answers

22
Summary

• There is a real need for a high durability
  architectural wall coating due to new protocols
  related to Hospital Acquired Infection control
• Bayer has developed a two component waterborne
  polyurethane technology has been developed that
  allows for
• High durability when exposed to harsh chemicals
  and repeated scrubbing
• Low odor during application and drying needed in
  a healthcare environment
• Meeting aesthetic requests for eggshell finish
  without compromising durability

23
Thank you!Questions?
