Title: Deliverables; Overview, Terminology and Use Cases


1
DeliverablesOverview, Terminology and Use Cases
Workshop on Focus Group on Smart Grid (Geneva,
9 January 2012)
  • Hyungsoo (Hans) KIM
  • Vice-chair
  • FG Smart
  • (KT, Korea)

2
Contents
  • Overview Deliverable
  • Smart-O-34Rev.4
  • Terminology Deliverable
  • Smart-O-30Rev.6
  • Use Case Deliverable
  • Smart-O.31Rev.7

3
Summary
Overview Deliverable
  • This Deliverable provides an overview of Smart
    Grid. For this, this Deliverable provides key
    concepts and objectives of Smart Grid and
    identifies architecture overview and fundamental
    characteristics.
  • This Deliverable specifies roles and key areas of
    Information and Communication Technology (ICT)
    for Smart Grid, networks/services architecture,
    and required capabilities

4
Scope
Overview Deliverable
  • Definition of Smart Grid
  • Objectives of Smart Grid
  • Conceptual model and reference architecture of
    Smart Grid
  • Fundamental characteristics of Smart Grid
  • Roles and key areas of ICT for Smart Grid
  • Architecture overview for Smart Grid and
  • Required capabilities for Smart Grid.

5
Content (1)
Overview Deliverable
6. Overview of Smart Grid 6.1. Concept of Smart
Grid 6.2. Goals and Objectives of Smart
Grid 6.3. Relationship with and among other SDOs
related to Smart Grid outside the ITU-T 6.3.1 IEC
(International Electrotechnical
Commission) 6.3.2 ISO/IEC JTC 1 6.3.3 ITU-R
(ITU-Radio communications) 6.3.4 Established
Regional Other SDOs 6.4. Conceptual model and
reference diagram for Smart Grid 7. Characteristi
cs of Smart Grid 7.1. Key elements for Smart
Grid 7.1.1 Smart Grid Services/Applications 7.1.2
Communication 7.1.3 Physical Equipment 7.2. Funda
mental characteristics of Smart Grid
6
Content (2)
Overview Deliverable
8. Role and Key Areas of ICT for Smart
Grid 8.1. Concepts and roles for Smart Grid in
the ICT perspective 8.2. Key areas for
standardization 8.3. Key applications and
platform in Smart Grid 9. Architecture overview
for Smart Grid in ICT perspective 9.1. Simplified
domain model in ICT perspective 9.2. Simplified
reference architecture for Smart
Grid 10. Required capabilities for Smart
Grid 10.1. Services/Applications
Plane 10.2. Communication Plane 10.3. Energy
Plane 10.3.1 Grid domain (bulk generation,
distribution and transmission) 10.3.2 Smart
metering (AMI) 10.3.3 Customer domain 10.4. Common
required capabilities in all of
planes 10.4.1 Security 11. Corresponding
activities between FG-Smart and relevant SGs of
ITU-T
7
Concept
Overview Deliverable
  • It has been recognized that the Smart Grid is a
    new electricity network, which highly integrates
    the advanced sensing and measurement
    technologies, information and communication
    technologies (ICTs), analytical and
    decision-making technologies, automatic control
    technologies with energy and power technologies
    and infrastructure of electricity grids

8
Goals and Objectives
Overview Deliverable
  • The general goals of Smart Grid are to ensure a
    transparent, sustainable and environmental-friendl
    y system operation that is cost and energy
    efficient, secure and safe. Objectives of
    developing the Smart Grid are quite different
    from country to country for their various demands
    and start points.
  • However, the common objectives of a Smart Grid
    are clear and listed such as Robustness, Secured
    operation, Compatibility, Economical energy
    usage, Integrated system, Optimization and Green
    energy

9
Conceptual model
Overview Deliverable
  • Domains and Actors in the model

Domain Actors in the Domain
Customers The end users of electricity. May also store, and manage the use of energy. Traditionally, three customer types are discussed, each with its own domain residential, commercial, and industrial.
Markets The operators and participants in electricity markets.
Service Providers The organizations providing services to electrical customers and utilities.
Operations The managers of the movement of electricity.
Bulk Generation The generators of electricity in bulk quantities. May also store energy for later distribution.
Transmission The carriers of bulk electricity over long distances. May also store and generate electricity.
Distribution The distributors of electricity to and from customers. May also store and generate electricity.
10
Key areas for Standardization
Overview Deliverable
11
Simplified domain model
Overview Deliverable
12
Appendices
Overview Deliverable
  • Appendix I. Other Smart Grid definitions
  • IEC, Wikipedia, US DoE, NIST, etc.
  • Appendix II. Standardization activities of ITU-T
    SGs for Smart Grid
  • SG2, 5, 12, 13, 15, 16, 17, etc. (including
    ITU-R)

13
Definitions
Terminology Deliverable
  • 90 Definitions
  • Power-related elements, functions, terminologies,
    etc.
  • Advanced metering infrastructure, Automatic
    voltage regulator, Demand response, Electric
    vehicle, etc.
  • Communications-related elements, functions,
    terminologies, etc.
  • Home area network, Next generation network,
    Session initiation protocol, etc.

14
Abbreviations
Terminology Deliverable
  • 60 Abbreviations
  • DER Distributed Energy Resource
  • DR Demand Response
  • EV Electric Vehicle
  • HAN Home Area Network
  • PHEV Plug-in Hybrid Electric Vehicle
  • V2G Vehicle to Grid, etc.

15
Scope
Use Case Deliverable
  • The objective of this deliverable is to analyse
    several use cases for smart grid in the ICT
    perspective and identify requirements and
    architectural considerations

16
Content
Use Case Deliverable
  • High-Level Use Cases
  • 7. Detailed Use Cases
  • 7.1. Demand Response
  • 7.2. WASA
  • 7.3. Energy Storage
  • 7.4. Electric Vehicle to Grid Interaction
  • 7.5. AMI Systems
  • 7.6. Distribution Grid Management
  • 7.7. Market Operations
  • 7.8. Existing Users Screens
  • 7.9. Managing Appliances Through/By Energy
    Service Interface
  • 7.10. Control of Electric Vehicle
  • 7.11. Distributed Energy Generation/ Injection
  • 7.12. Other use cases

17
12 High Level Use Cases
Use Case Deliverable
18
Example
Use Case Deliverable
No Title Description
1 Demand Response (DS) Mechanisms and incentives for utilities, business, industrial, and residential customers to cut energy use during times of peak demand or when power reliability is at risk. Demand response (DR) is necessary for optimizing the balance of power supply and demand.
2 Wide-Area Situational Awareness (WASA) Monitoring and display of power-system components and performance across interconnections and over large geographic areas in near real-time. The goals of situational awareness are to understand and ultimately optimize the management of power-network components, behavior, and performance, as well as to anticipate, prevent, or respond to problems before disruptions can arise.
3 Energy Storage (ES) Means of storing energy, directly or indirectly. Smaller forms of energy storage (ES) are anticipated within distribution systems as well as bulk power systems. New storage capabilitiesespecially for distributed storagewould benefit the entire grid, from generation to end use, but the resources need to be correctly integrated into transmission and distribution operations.
19
82 Detailed Use Cases
Use Case Deliverable
(15)
(11)
(10)
(7)
(5)
(2)
(9)
(7)
(7)
(4)
(4)
(1)
20
Template
Use Case Deliverable
Title - X high-level use case title Sub-title Specific title of use case related to the high-level use case
Description General description for use case of smart grid in the ICT perspective
Stakeholders (Actors)/ Domains Roles of related stakeholders and domains in the Appendix II
Information Exchanges Protocol procedures between entities
Source (References) FG-Smart contribution number and/or reference document, websites
21
Example (1)
Use Case Deliverable
WASA 7 Load Shedding
Description This procedure describes what activities are performed by an operator when he gets the order to release a determined value of load in a period, due to the possibility of partial or complete blackout. When the emergency situation is over, the operator has to restore the power. It is possible to create and execute certain jobs in order to restore power. Load shedding is a function to protect equipment against under-frequency. This kind of action is drastic and should only be used as a last resource. But there are situations where there is no other possibility. It can avoid danger to human life in sequence of a blackout, a voltage collapse, etc.
Stakeholders(Actors)/ Domains Operator in the transport/production control center, Operator in the distribution control room, Energy Management, Network Operation
Information Exchanges The operator in the distribution control room receives an order to release a determined value of load in a period. The system must build a list of feeders (or sub- feeders) that should be open in order to get the total of load shedding necessary. The operator (or automatic system) opens the breakers necessary according to the list, starting from the lowest priority to the highest. The system must build a list of priorities for the closing of the feeders The operator (or automatic system) restores the power to the feeder as soon as that action is possible according to the list of priorities (build in the previous step), from the highest to the lowest priority.
Source (References) b-IKB use cases
22
Example (2)
Use Case Deliverable
MA 1 Charging management for appliances including electric vehicle at home
Description Inside the users premise, PEV , PV system, home appliance, and household equipment participate in a home network and in load management that GW governs. PEV is considered both an electric load and an electric storage. PEV communicates to the home network.
Stakeholders(Actors)/ Domains Organization (company), Device, System, Stored information in computer memory or on media, Computer program(s) and displays / Operators, Customer(Home/Building/Commercial/Industrial)
Information Exchanges GW detects PEV coming into the garage. GW authenticates and authorizes PEV. PEV sends to GW information on e.g. charge level, miles driven, driving pattern. GW, while monitoring power generation of PV and electricity consumption of home appliances/household equipment, receives the information. GW decides whether to charge PEV, inject PEVs power to home, or do nothing. For charging of PEV, GW dictates PEV to change into the charge mode. PEV detects when its fully charged. PEV informs GW and stays stand-by. For injection of PEVs power to home, GW dictates PEV to change into the discharge mode. GW monitors status of discharging and load balance at home. GW judges and dictates PEV to stop discharging. PEV stays stand-by. When PEV goes out of the garage, GW detects it.
Source (References) Smart-I-0067
23
Appendices (1)
Use Case Deliverable
  • Appendix I. Use Case for Zigbee Forum
  • Appendix II. Stakeholders and Domains in the Use
    Cases
  • 6 Stakeholders Organization, device, person,
    system, stored information, Computer
    program/display
  • 5 Domains customer, market, service provider,
    operator, power company

24
Appendices (2)
Use Case Deliverable
  • Appendix III. Use Case for Building Management
  • Appendix II. Summary of Smart Grid Use Cases
    (Table of Titles of 12 High-level and 82 detailed
    Use Cases)

25
Thank you!
  • hans9_at_kt.com
