DEEP VENOUS THROMBOSIS

1
DEEP VENOUS THROMBOSIS
2
Definition

• formation of a blood clot in one of the deep
  veins of the body, usually in the leg

3
Anatomy
4
Etiology and risk factors

• 3 main factors contribute in development of DVT
• Stasis
• Endothelial injury
• Hypercoagulability

5
Venous stasis

• prolonged bed rest (4 days or more)
• a cast on the leg
• limb paralysis from stroke or spinal cord injury
• extended travel in a vehicle
• heart failure

6
Hypercoagulability

• Surgery and trauma - responsible for up to 40
  of all thromboembolic disease
• Malignancy
• Increased estrogen (due to a fall in protein S)
  Increased estrogen occurs during
• all stages of pregnancy
• the first three months postpartum,
• after elective abortion, and
• during treatment with oral contraceptive pills

7
Inherited disorders of coagulation

• deficiencies of protein S,
• protein C and
• antithrombin III.

8
Acquired disorders of coagulation

• nephrotic syndrome results in urinary loss of
  antithrombin III, this diagnosis should be
  considered in children presenting with
  thromboembolic disease
• Antiphospholipid antibodies accelerate
  coagulation and include the lupus anticoagulant
  and anticardiolipin antibodies.

9

• Inflammatory processes, such as
• systemic lupus erythematosus (SLE),
• sickle cell disease, and
• inflammatory bowel disease (IBD),
• also predispose to thrombosis, presumably due to
  hypercoagulability

10
Symptoms

• Dull pain, heaviness, oedema and warm limb
• With extensive DVT-massive oedema, cyanosis,
  dilated superficial collateral veins and low
  grade fever.
• With ilio-femoral DVT-
• Phlegmasia cerulea dolens (cyanosed limb due to
  obstructed vein)
• Phlegmasia alba dolens (pale, pulseless cold limb
  due to concurrent arterial spasm)
• AND THESE TWO UPPER CASES ARE LIMB THREATENING
  CONDITION!!

11
Phlegmasia cerulea dolens Venous
gangrene
12
Signs

• HOMAN'S sign (tenderness during passive
  dorsiflexion of foot). And it was contraindicated
  because of its role in thrombus deattachment
  and thus emobilization
• Hotness, cyanosis, oedema (non-pitting)

13
Diagnostic Studies

• - Clinical examination alone is able to confirm
  only 20-30 of cases of DVT
• - Blood Tests
• the D-dimer - have predictive value for DVT
• INR - useful for guiding the management of
  patients with known DVT who are on warfarin
  (Coumadin)

14
D-dimer

• D-dimer is a specific degradation product of
  cross-linked fibrin. Because concurrent
  production and breakdown of clot characterize
  thrombosis, patients with thromboembolic disease
  have elevated levels of D-dimer
• three major approaches for measuring D-dimer
• ELISA
• latex agglutination
• blood agglutination test - SimpliRED

15

• False-positive D-dimers occur in patients with
• recent (within 10 days) surgery or trauma,
• recent myocardial infarction or stroke,
• acute infection,
• disseminated intravascular coagulation,
• pregnancy or recent delivery,
• active collagen vascular disease
• metastatic cancer

16
Imaging Studies

• Invasive
• venography,
• radiolabeled fibrinogen
• Noninvasive
• ultrasound,
• plethysmography,
• MRI techniques

17
Imaging studies

• The standard tool for diagnosis is
  phlebography using fluoroscope. The use of this
  study limited by is complications which are
  allergy, nephropathy and phlebitis.
• Duplex ultrasound
• Test of choice
• Sensitivity and specificity gt95
• Able to detect other pathology like BAKER cyst.

18
Venography

• "gold standard modality for the diagnosis of DVT

• Advantages
• venography is also useful if the patient has a
  high clinical probability of thrombosis and a
  negative ultrasound,
• it is also valuable in symptomatic patients with
  a history of prior thrombosis in whom the
  ultrasound is non-diagnostic.

19
Venogram shows DVT
20
Ultrasonography

• color-flow Duplex scanning is the imaging test of
  choice for patients with suspected DVT
• inexpensive,
• noninvasive,
• widely available
• Ultrasound can also distinguish other causes of
  leg swelling, such as tumor, popliteal cyst,
  abscess, aneurysm, or hematoma.

21
clinical limitations

• reader dependent
• Duplex scans are less likely to detect
  non-occluding thrombi.
• During the second half of pregnancy, ultrasound
  becomes less specific, because the gravid uterus
  compresses the inferior vena cava, thereby
  changing Doppler flow in the lower extremities

22
The finding are

• Acute DVT
• Absence of spontaneous flow.
• Loss of flow variation with respiration.
• Failure to increase the flow after distal
  augmentation.
• Not visible thrombi (anechoic thrombi).
• Chronic DVT
• Not well established
• Narrow vein
• Patent collateral
• Visible thrombi

23
Color duplex scan of DVT
24

• The only disadvantage of duplex study is that, it
  is highly operator dependant!!!

25
Magnetic Resonance Imaging

• It detects leg, pelvis, and pulmonary thrombi
  and is 97 sensitive and 95 specific for DVT.
• It distinguishes a mature from an immature clot.
• MRI is safe in all stages of pregnancy.

26
Differential diagnoses

• Unilateral limb involvement muscular strain,
  tendon rupture, cellulites, lymphodema or
  retroperitoneal fibrosis pressing over the vein.
• Bilateral limb involvement liver, heart or renal
  failure or IVC obstruction.

27
Complication of DVT

• Recurrent DVT
• Varicose vein
• Chronic venous insufficiency
• Post phlebitic syndrome (pain, oedema and
  ulceration)
• PE

28
Patient with suspect symptomatic Acute lower
extremity DVT
negative
Venous duplex scan
Low clinical probability
observe
High clinical probability
positive
negative
Evaluate coagulogram /thrombophilia/ malignancy
Repeat scan / Venography
IVC filter
Anticoagulant therapy contraindication
yes
No
pregnancy
LMWH
OPD
LMWH
warfarin
hospitalisation
UFH
Compression treatment
29
Management

• The aim of management is
• Prophylaxis against DVT
• Treatment of ongoing DVT

30
Methods of Prophylaxis

• 1) Mechanical
• Leg elevation
• Graded compression stocking
• Early ambulation
• Pneumatic compression boo.

31

• 2) Pharmacological agents
• Aspirin (anti platelet factor) not recommended
  currently.
• Dextran solution (40 and70) branched
  polysaccharide. Decrease platelets adhesiveness
  and aggregation.
• Disadvantages
• Increase rate of bleeding
• Pulmonary edema (due to overload)
• Allergic reaction in 1
• Recommended dose is15-20 cc/h IV infusion before
  surgery.

32

• Warfarine (coumadine)-
• Decrease incidence of DVT by 66 and PE by 80.
• Disadvantages
• Sever hemorrhage
• Must be started 2-3 days preoperative.
• Require careful monitoring for PT.

33
Warfarine nomograph
34
Heparin

•

  Unfractionated heparin
• Inhibits AT III and potentiate disintegration of
  thrombi that form while it administered
• Low dose regimen is 5000 IU twice daily SQ two
  hours pre-operatively then q12hours post
  operative till the patient is completely
  ambulating.
• For morbidly obese patient - micro-heparin drip
  at 1u/kg/hour
• Disadvantages
• Risk of bleeding
• Thrombocytopenia (rare)
• Contraindicated in patient with actively bleeding
  peptic ulcer, uncontrolled HTN, bleeding disorder
  or recent use of ASA

35

• Heparin-dihydroergotamine (DHE) combination
• Cause vasoconstriction of capacitance veins and
  thus increase the venous return.
• Particular effectiveness in orthopedic cases.
• Contraindicated in case of hypotension, IHD and
  peripheral arterial occlusive diseases.
• Low molecular weight (enoxaparin)
• Lesser effect on thrombin and platelets
  aggregation.
• Longer life time so the dose will be once daily.
• More expensive than unfractionated heparin.

36
(No Transcript)
37
Heparin nomograph
38

• Fibrinogen-depleting compound
• New class of anticoagulants but not well known.
• Prophylactic IVC filter placement.
• Also known as Greenfield filter.
• Used in high risk patient when other methods are
  contraindicated.
• Effective in preventing PE not DVT.

39
An approach to Prophylaxis

• 1. determine patient at risk
• Low risk (lt40 years old, ambulating, minor
  surgery)
• Moderate risk (gt40 years old, abdominal,
  pelvic or thoracic surgery)
• High risk (gt60years old, prior DVT or PE
  malignancy, orthopedic surgery hypercoagulability
  state).

40

• 2. prohylaxis of choice
• Encourage all patients to ambulate as soon as
  possible
• Low risk patient don't need prophylaxis.
• Moderate risk pneumatic compression boot or low
  dose heparin prophylaxis.
• High risk combination of pneumatic compression
  boot and low dose heparin prophylaxis or Dextran.
• Coumadine or IVCfilter are considered.
• Ophthalmology or neurosurgery patient are NOT
  candidates for prophylaxis.

41

• Treatment of DVT
• A - anticoagulation
• Heparin bolus 100-150 u/kg IV stat then followed
  by constant infusion of 1000 u/hour with checking
  aPTT q 4-6hours and keeping the ratio 50-70sec.
• Coumadine (Warfarine) usually started at day 3-5
  after initial heparin is given and continue for
  3-6 months . PT should be 17-20sec. and INR
  2.0-2.5.

42
Duration of anticoagulation in patients with deep
vein thrombosis

• Transient cause and no other risk factors
  3 months
• Idiopathic 3-6 months
• Ongoing risk for example, malignancy
  6 -12 months
• Recurrent pulmonary embolism or deep vein
  thrombosis 6-12 months
• Patients with high risk of recurrent thrombosis
  exceeding risk of anticoagulation indefinite
  duration (subject to review)

43

• B-thrombolytic treatment(
  alteplase, streptokinase, urokinase)
• Promote rapid thrombus lysis. Used in cases of
  sever PE . They have more bleeding complication.
• C-venal cava interruption (IVC filter)
• Prevent further embolism of thrombi
• D- venous thrombectomy
• May be necessary in venous gangrene and septic
  thrombosis.

44
Thrombolytic therapy for DVT

• Advantages include
• prompt resolution of symptoms,
• prevention of pulmonary embolism,
• restoration of normal venous circulation,
• preservation of venous valvular function,
• and prevention of postphlebitic syndrome.

45

• Thrombolytic therapy does not prevent
• clot propagation,
• rethrombosis, or
• subsequent embolization.
• Heparin therapy and oral anticoagulant
• therapy always must follow a course of
• thrombolysis.

46

• Thrombolytic therapy is also not effective once
  the thrombus is adherent and begins to organize
• The hemorrhagic complications of thrombolytic
  therapy are formidable (about 3 times higher),
  including the small but potentially fatal risk of
  intracerebral hemorrhage.

47
Catheter directed-thrombolysis

• Consider in Acutelt 10 days iliofemoral DVT.
• Long-term benefit in preventing
  post-phlebitic syndrome is unknown.

48
Filters for DVT

• Indications for insertion of an inferior
• vena cava filter
• Pulmonary embolism with contraindication to
  anticoagulation
• Recurrent pulmonary embolism despite adequate
  anticoagulation

49
Filters for DVT

• Controversial indications
• Deep vein thrombosis with contraindication to
  anticoagulation
• Deep vein thrombosis in patients with
  pre-existing pulmonary hypertension
• Free floating thrombus in proximal vein
• Failure of existing filter device
• Post pulmonary embolectomy

50
Filters for DVT

• Inferior vena cava filters reduce the rate of
  pulmonary embolism but have no effect on the
  other complications of deep vein thrombosis.

51
(No Transcript)
52
Surgery for DVT

• Indications
• when anticoagulant therapy is ineffective
• unsafe,
• contraindicated.
• The major surgical procedures for DVT are
• clot removal and partial interruption of the
• inferior vena cava to prevent pulmonary
• embolism.

53

• These pulmonary emboli removed at autopsy look
  like casts of the deep veins of the leg where
  they originated.

54
This patient underwent a thrombectomy. The
thrombus has been laid over the approximate
location in the leg veins where it developed.
55
Prognosis

• All patients with proximal vein DVT are at
  long-term risk of developing chronic venous
  insufficiency.
• About 20 of untreated proximal (above the calf)
  DVTs progress to pulmonary emboli, and 10-20 of
  these are fatal. With aggressive anticoagulant
  therapy, the mortality is decreased 5- to
  10-fold.
• DVT confined to the calf virtually never causes
  clinically significant emboli and thus does not
  require anticoagulation

56
thank you
