Title: Welcome to Asbestos Awareness


1
Welcome to Asbestos Awareness
2
Aim
  • Raise the awareness of everyone to the new duty
    to manage asbestos in buildings
  • Enable staff to deal with general enquiries
    involving asbestos issues

3
Whats Asbestos all about?
  • Asbestos is a naturally occurring fibrous
    mineral, looks a bit like rockwool or fibreglass
    in its raw state
  • It was already in use by the Egyptians around
    2000BC, woven into cloth and used as a burial
    shroud.
  • The Romans used it and the Fins made cooking pots
    from it in the first millenium.
  • In the latter part of the Industrial revolution
    its use became common in industry.
  • New uses evolved particularly in building
    products where its range of properties were
    exploited to the full

4
(No Transcript)
5
What was so good about it?
  • Heat resistant, doesnt start to degrade until
    about 900 deg C
  • Doesn't burn
  • Resistant to acids corrosion
  • Can be woven into a strong cloth
  • Can be used as a reinforcement similar to fibre
    glass
  • Cheap easy to use

6
So, whats the problem
  • The wonderful properties that make it useful has
    a big downside if it gets into the lungs.
  • The tiny fibres are sharp and strong.
  • Breath in the fibres and they get stuck in the
    lung, in fact every time you take a breath they
    get drawn deeper.

7
Remember its properties
  • Resistant to acid and corrosion
  • Strong
  • Well, this means that the fibres stay in the
    lungs and cant be broken down by the body
  • They are also sharp and can penetrate lung
    tissue.
  • Thats where cancers can start

8
Asbestos related diseases
  • The inhalation of asbestos fibres has been shown
    to be the cause of three types of diseases.
  • Asbestosis
  • Asbestos Cancers
  • Mesothelioma

9
How big is the problem?
  • Around 3000 people will die from Asbestos related
    diseases
  • By 2020 that may rise to 10,000 per year
  • Nothing can be done for these people, these
    diseases are not treatable.
  • Can take 550 years to show
  • Horrible death

10
Why dont they do something?
  • Most intensive use from 1955 to 1970
  • Which meant that the significant effects only
    began to show in 1980s
  • Legislation was geared to protecting workers in
    manufacture and removal of asbestos

11
Jigsaw Puzzle
  • But the numbers kept rising when the should have
    started to fall
  • From a study in 1995 it was clear that 25 of
    people dying had previously worked in the
    construction industry

12
Then
  • 1998 The Asbestos (Licensing) Regulations were
    expanded to include any work done on asbestos
    board to be carried out by licensed contractors
  • In 1998 Control of Asbestos at Work Regulations
    was amended
  • In 1999 use of all asbestos in manufacture was
    banned

13
The Heritage
  • It is almost impossible to destroy it
  • Thousands of tonnes were used each year in
    buildings
  • Usage peaked 19501970
  • Estimated 2 4 Million of tonnes are still left
    in buildings

14
Ouch!
  • Workers, employers, building owners and operators
    were often completely unaware that asbestos
    containing materials were present
  • That largest single group at risk?
  • 1.4 million workers in the construction industry

15
Just who is at risk?
  • Anybody that disturbs ACM sufficiently to put
    dust in the air!
  • Demolition Workers
  • Building Maintenance Workers
  • Gas fitters
  • Joiners
  • Electricians
  • Heating and ventilating engineers
  • Plumbers

16
The Dilemma
  • Huge quantity of asbestos in buildings
  • To remove it all would cost billions
  • If removed what can be done with all waste
  • Increased risk to all the removers, people
    around, transport, waste dumps etc

17
The Good News
  • 2002 Asbestos at Work Regulations amended further
    and now include
  • Specific Duty, To Manage Asbestos in Buildings
  • Duty holder is principally the occupier
  • Mostly the employer

18
What the new Duty means
  • We have to find out where all asbestos
  • Risk assess
  • Decide whether to remove, encapsulate it, or
    leave as is
  • Keep register of all asbestos
  • Monitor its condition
  • Provide information on the location and condition
    of the materials to anyone who is liable to work
    on or disturb them

19
This doesnt happen here?
  • A few examples of possible ACM

20
Belgian Board containing Blue Asbestos Oh by the
way, its water resistant too !
Belgian Board containing Blue Asbestos Oh by the
way, its water resistant too !
21
(No Transcript)
22
Asbestos mill board used as a ceiling board for
fire resistance, plumber didnt recognise it when
he fixed the leak
23
Acoustic tiles often contained 15 Asbestos
fibres as reinforcement
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Next steps
  • By end of February 05 all data into database
  • By end March 05 all data transferred to our
    Repairs Management System
  • Asbestos information will automatically be
    included on every job ticket to help keep our
    partners safe

37
To meet our duties
  • Carry on collecting data on our stock
  • Tell anyone that works on our properties where
    there is any asbestos in that property
  • Make regular inspections of asbestos that is
    being managed

38
We ask you
  • If you suspect that the information on the job
    ticket is wrong tell us immediately
  • If you suspect asbestos, stop work immediately
    and tell us
  • If you suspect asbestos that does not affect the
    job in hand, tell us as soon as possible

39
Remember
  • If you work on ACMs you may put your health in
    danger
  • You are not insured to knowingly work on ACMs

40
What happens when ACMs are suspected
  • Report to
  • Independent surveyor takes samples and advises
    action
  • Remove, encapsulate or manage
  • Leave it to the experts

41
Remember
  • Its not a contagious disease
  • Its perfectly safe unless it is disturbed and
    dust gets into the air
