Title: BlackBerry BES Version 3.6 powered by Vodafone


1
(No Transcript)
2
BlackBerry BES Version 3.6 powered by Vodafone
  • Agenda
  • Product Overview
  • Elements of a BlackBerry Solution
  • Review of Functionality
  • Server Architecture and Message Flow
  • Device Overview
  • Questions

3
Product Overview
  • BlackBerry is a RIM (Research In Motion) product
    which enables secure access to e-mail, tasks,
    calendar and contacts.
  • Designed for corporate environments using
    Microsoft Exchange and Lotus Domino .
  • Operating over GPRS, the BlackBerry handheld
    device permanently links the user into their
    corporate e-mail.
  • GPRS functionality integrated into the device ,
    no need to connect to a GPRS terminal.
  • Utilises push technology, no dial up necessary.

4
BlackBerry What does Blackberry comprise
of ?
5
Component parts of the BlackBerry solution
  • A handheld mobile terminal
  • Desktop synchronisation software
  • BlackBerry Enterprise Server (Upto 500 users
    (Software only no hardware provided))
  • Blackberry APN blackberry.net
  • Client Access License. A 20 user licence is
    included with the BES.

6
Product Functionality
  • OTA Access to e-mail calendar
  • Access to tasks and contacts.
  • Web and WAP Browser.
  • Remote Address Look Up Facility.
  • Ability to view attachments ( .doc, .xls, .ppt,
    .pdf, .wpd and .txt.)
  • Ability to work off line.

7
Wireless Email Reconciliation
  • A user can read, move, or delete email messages
    on either their handheld or their computer and
    have those changes synchronized wirelessly.
  • One-way folder synchronization enables users to
    create, delete, rename, or move a folder on their
    computer and sync these changes wirelessly so
    that they appear on the handheld.
  • OTA deletion etc can be turned off on a per user
    basis. This will require users to cradle to
    update folders, file emails and delete emails.

8
Browser
  • The BlackBerry Browser, in conjunction with the
    Mobile Data Service, provides a simple and
    effective mechanism for the delivery of corporate
    applications to BlackBerry.

Test URL to MDS Page from Handheld IP address of
BES8300/admin/common MDS Homepage URL from BES
PC Internet explorer 127.0.0.18300/admin/common
9
Remote Address Lookup Facility
  • Handheld users can search for recipients in the
    Global Address List over the air, during an email
    composition, forward or reply.
  • Search using letters from the entrys First Name,
    Last Name or Both
  • Search results can be viewed in bundles of 20
  • Matched user(s) can be added to handheld address
    book

10
Attachment Service
  • The attachment service is installed automatically
    with the BlackBerry Enterprise Server Software
    and supports the following file types
  • Format Versions
  • Adobe PDF 1.1, 1.2, 1.3, 1.4
  • Microsoft PowerPoint 97- XP
  • Microsoft Word 97-XP
  • Corel WordPerfect 6-2000
  • ASCII Text
  • Excel 97-XP

11
Device Security
  • IT is advised that the Handheld Device is set up
    to be Password protected.
  • From the Options / Security Menu.
  • A Security Timeout and password can be enforced
    from the BES for
  • each device through IT Policy creation.
  • If a password is entered incorrectly 10 times the
    device is wiped.
  • The device can easily be Disabled or killed from
    the BES.
  • Triple DES security end to end, therefore all
    data is encrypted.
  • Each Handheld has a unique Key between the
    Handheld Device and the BES

12
Server Architecture and Message Flow
13
BlackBerry Network Architecture
Triple DES Encryption (Data Encryption
Standard) Translates data into a secret code
a common key (translation table used by host and
recipient) allows encrypted data to be decrypted
and read
Firewall
New Email
Mail Server
BES
Outlook Client
Internet
RIM GPRS Infra structure
Blackberry.net APN
MAPI (Message Application Programming
Interface) Standard Messaging protocol that
allows applications to utilise messaging services
SRP/TCP (Server Relay Protocol) Propriety RIM
protocol Encrypts compresses email (Transmissio
n Control Protocol) Sets up connection reliable
stream delivery. Guarantees delivery correct
order of packets. Acknowledgement re-delivery
as necessary.
GGSN
SGSN
VF GSM / GPRS Network
BES (BlackBerry Enterprise Server) Checks for
filters created by BlackBerry Desktop Manager
separate to Outlook filters
BSC
BTS
14
BlackBerry Network
Architecture
Company B LAN SRP 123 PIN 456 PIN 654
Internet
Company C SRP 545 PN 868
RIM Relay
Company D SRP 354 PN 999
Company A SRP 213 PN 123
Company E SRP 789 PN 111
15
Message Flow to the Handheld
  1. New Message arrives on the Exchange server.
  2. The BES maintains a MAPI connection to the users
    mailbox and detects new message arrival.
  3. Messages filters are applied on the BES to decide
    whether the message should be forwarded.
  4. A random message ID (RefId) and tag are assigned
    to the message.
  5. The message is compressed and encrypted.
  6. The message is sent to the wireless network
    through port 3101.
  7. The message arrives on the handheld. It is
    decompressed and unencrypted.
  8. The handheld then sends confirmation of receipt
    back to the BES.

Forward? Compress Encrypted
16
Message Flow from the Handheld
  1. A user sends a message from the handheld with a
    RefID is assigned.
  2. The message is compressed and encrypted.
  3. It is sent over GPRS to the BES Server.
  4. The message is decrypted and decompressed. If the
    message cannot be decrypted using the users key
    then the message is discarded.
  5. The message is placed in the user outbox. If this
    is a forwarded email or a reply then the RefID is
    used to locate and append the original message.
  6. Exchange delivers the message.
  7. A copy is saved in the users Sent items unless
    the user specifies otherwise through desktop
    manager.

Decompress Decrypted
17
E mail delivery
  • E mails delivered to the BlackBerry device are
    compressed and broken down into 1.5 KB chunks.
  • Customer will view the first part of the e mail
    and then request the next section by selecting
    the more option.
  • Maximum e mail size of 32KB e.g. any mails larger
    then this will be part delivered to the
    BlackBerry device. This is true for attachments
    as well.

18
E mail delivery
  • If the device is out of coverage, RIM will
    deliver as soon as signal restored.
  • RIM Infer structure will only store 5 messages
    per device if the user is out of coverage.
  • Once 5 messages have been received the relay will
    inform the BES not to send out any further
    messages.
  • Messages are stored on the RIM Infer structure
    for 7 days and then deleted however the
    messages stay on the customers Exchange server.
  • Filters can be set by the end user e.g. if they
    are on holiday so that no messages are pushed out
    to the BlackBerry device.
