Title: Energy in Thermal Processes


1
Chapter 11 Energy in Thermal Processes
2
  • Temperature and heat
  • Heat (Q) energy transferred between a system
    and its environment because of a temperature
    difference that exists between them
  • SI Unit Joule
  • Alternative unit calorie (cal)

3
  • Absorption of heat
  • Specific heat (c) heat capacity per unit mass
  • Common states (phases) of matter solid, liquid,
    gas
  • Latenet heat (L) the amount of energy per unit
    mass transferred during a phase change (boiling,
    condensation, melting, freezing, etc.)

4
Absorption of heat
5
Absorption of heat
6
Absorption of heat
7
Chapter 11 Problem 17
A 100-g aluminum calorimeter contains 250 g of
water. The two substances are in thermal
equilibrium at 10C. Two metallic blocks are
placed in the water. One is a 50-g piece of
copper at 80C. The other sample has a mass of 70
g and is originally at a temperature of 100C.
The entire system stabilizes at a final
temperature of 20C. Determine the specific heat
of the unknown second sample.
8
  • Heat transfer mechanisms
  • Thermal conduction
  • Conduction rate
  • Thermal resistance
  • Conduction through a composite rod

9
  • Heat transfer mechanisms

10
Chapter 11 Problem 36
A box with a total surface area of 1.20 m2 and a
wall thickness of 4.00 cm is made of an
insulating material. A 10.0-W electric heater
inside the box maintains the inside temperature
at 15.0C above the outside temperature. Find the
thermal conductivity k of the insulating
material.
11
  • Heat transfer mechanisms
  • Thermal radiation
  • Radiation rate
  • Stefan-Boltzmann constant
  • Absorption rate

12
Chapter 11 Problem 46
At high noon, the Sun delivers 1.00 kW to each
square meter of a blacktop road. If the hot
asphalt loses energy only by radiation, what is
its equilibrium temperature?
13
  • Heat transfer mechanisms
  • Convection

14
Heat transfer mechanisms
15
Questions?
16
Answers to the even-numbered problems Chapter 11
Problem 4 0.152 mm
17
Answers to the even-numbered problems Chapter 11
Problem 12 467 pellets
18
Answers to the even-numbered problems Chapter 11
Problem 16 1.7 kg
19
Answers to the even-numbered problems Chapter 11
Problem 20 49 kJ
20
Answers to the even-numbered problems Chapter 11
Problem 40 7.2 10-2 W/(m C)
21
Answers to the even-numbered problems Chapter 11
Problem 50 14.1 h
