Physical and Chemical Properties

1

• Unit 2.2
• Physical and Chemical Properties

2
Objectives

• Match important physical and chemical properties
  to their effects on the chemical and container
• Identify the difference between exposure and
  contamination
• Determine the appropriate DOT class of the product

3
Physical/Chemical Properties

• Physical
• State
• Phase changes
• Vapor pressure
• Specific gravity
• Vapor density
• Solubility

• Chemical
• Flammability
• Reactivity
• Toxicity
• Radioactivity

4
Common Info Sources

• North American Emergency Response Guide Book
  (NAERG)
• NIOSH Pocket Guide to Chemical Hazards
• Material Safety Data Sheets (MSDS)

5
Material Safety Data Sheets

• Nine basic sections
• Various designs
• Some of better quality

6
Product Information
7
Hazardous Ingredients
8
Exposure Limits
9
Physical Data
10
Video ? Physical Properties
11
Vapor Pressure
Atmospheric Pressure 14.7 p.s.i. or 760 mm/Hg
Low Vapor Pressure
High Vapor Pressure
12
Specific Gravity
13
Physical Properties (cont.)

• Vapor density
• Comparison of the weight of a vapor to that of
  air being assigned the value of 1
• Solubility/miscibility
• The ability of a substance (solute) to blend
  uniformly with another (solvent)
• Solubility applied to a solid in liquid
• Miscibility applied to a liquid or gas in a
  liquid

14
Spill Types

• Physical properties determine spill types

15
Fire and Explosion Hazards
16
The Fire Triangle
17
Flash Point

• The temperature at which a liquid or volatile
  solid gives off vapors sufficient to form an
  ignitable mixture near the surface (NFPA)
• Remember, volatility is a product of vapor
  pressure

18
Flammable Range
19
Examples of Flammable Range
20
Other Flammable Hazards

• Ignition temperature
• Boiling Liquid Expanding Vapor Explosions (BLEVE)
• Boil-over
• Heavy fuels
• Water in the bottom of the storage tank
• Thermocline development during fire

21
Other Flammable Hazards

• Pyrophoric
• Hydrophoric
• Flammable solids

22
Health Hazards
23
Health Hazards

• Routes of exposure
• Local vs. systemic effects
• Dose response relationship
• Influences of toxicity

24
Reactivity Hazards
25
pH and Corrosives
26
Reactions

• Rate of reactions
• Quantity, concentration, temperature and pressure
• Explosives
• Fuel, oxidizer, energy, pressure
• Incompatibilities

27
EPA Table of Incompatibilities
28
Video ? Chemical Reactions
29
Spill, Leak and Fire Control
30
Personal Protective Equipment
31
Special Information

• Special handling
• Special packaging
• Disposal procedures
• Environmental information

32
Radioactive Hazards

• Ionizing radiation
• Common sources
• Natural
• Industrial
• Medical
• Agricultural
• Special nuclear materials

33
Types of Ionizing Radiation

• Alpha particle
• Beta particle
• Gamma emission
• X-ray
• Neutron particles

34
Radiological Exposure

• Standard unit of measure
• REM (Radiation Equivalence in Man)
• Sv (Seivert) internationally
• 1 Sv 100 REM
• 1 REM 1,000 mREM (milli REM)
• 1 mREM 1,000 ?REM (micro REM)

35
Exposure Limits

• Dose vs. dose rate
• Total dose dose rate x duration
• Action levels
• Normal background 8 to 16 ?R/hr
• All actions 5 REM (5,000 mREM)
• Valuable/critical property 10 REM (10,000 mREM)
• Life saving 25 REM (25,000 mREM)
• Any greater exposure must be voluntary
• TD(low) 100 REM, LD(50) 500 REM

36

• DOT Hazard Classes and Divisions

37
Hazard Classes and Divisions

• 1 ? Explosives
• 1.1 - Mass detonation
• 1.2 - Projectile
• 1.3 - Fire hazard
• 1.4 - No blast hazard
• 1.5 - Blasting agent
• 1.6 - Very insensitive
• 2 ? Gases
• 2.1 - Flammable
• 2.2 - Non-flammable
• 2.3 - Poisonous

• 3 ? Flammable liquid
• 3.1 - Flash point over 140 F
• 3.2 - Flash point less than 140 F
• 4 ? Flammable solids
• 4.1 - Flammable solid
• 4.2 - Spontaneous/pyrophoric
• 4.3 - Dangerous when wet
• 5 ? Oxidizers
• 5.1 - Oxidizers
• 5.2 - Organic peroxides

38
Hazard Classes and Divisions

• 6 ? Poisons
• 6.1 - Poisons
• 6.2 - Infectious substances
• 7 ? Radioactive
• 8 ? Corrosives
• 9 ? Miscellaneous

39
Summary

• Physical properties
• Chemical properties
• Common references
• NAERG
• NIOSH Pocket Guide
• MSDS

40

• Activity 2.2
• Assessing Physical and Chemical Properties
