Windows 2000 I/O System, Cache Manager and File Systems

1
Windows 2000 I/O System, Cache Manager and File
Systems

• Computing Department,
• Lancaster University, UK

2
Overview

• Goals
• Overview of I/O System
• Overview of Cache Manager
• Overview of File Systems

3
I/O System

• Design goals
• Make I/O processing fast on both single and
  multiprocessor systems
• Protect shareable resources by using standard
  Windows 2000 security mechanisms
• Meet requirements for the various sub-systems
  available
• Provide services to make device driver
  development as easy as possible
• Allow device drivers to be added or removed
  dynamically
• Provide support for multiple installable file
  systems

4
I/O System Components (1)

• The I/O manager
• Connects applications and system components to
  virtual, logical and physical devices
• A device driver
• Typically provides an I/O interface for a
  particular type of device
• The PnP manager
• Responsible for loading a device driver when a
  device is detected
• The power manager
• Guides the system through power-state transitions

5
I/O System Components (2)

• The registry
• Serves as a database that stores a description of
  basic hardware devices attached to the system
• INF files
• Driver installation files
• The link between a particular device, and the
  driver that assumes its primary control
• Hardware Abstraction Layer (HAL)
• Insulates the drivers from the specifics of the
  processor and interrupt controller
• Provides APIs that hide the differences between
  platforms

6
I/O Operations

• Most I/O operations dont involve all components
• Typical request starts with an app executing an
  I/O related function, that is processed by the
  I/O manager, one or more device drivers and the
  HAL
• The OS abstracts all I/O requests as operations
  on a virtual file
• Hiding the fact that the target might not be a
  file-structured device
• Abstraction generalises an applications
  interface to devices
• All data that is read or written is regarded as a
  simple stream of bytes directed to these files
• The I/O manager dynamically directs these virtual
  file requests to the appropriate device driver

7
Flow of a Typical I/O Request
User-mode API
I/O Subsystem API
I/O Manager
Driver support routines
Kernel mode device drivers
HAL I/O access routines
8
Types of Device Drivers

• File system drivers
• Accept I/O requests to files
• Windows 2000 drivers
• Include drivers for mass storage devices, net.
  adaptors
• Legacy drivers
• Written for NT
• Display drivers
• Translate device-independent graphics requests to
  device-specific requests
• WDM drivers (Windows Driver Model)
• Includes support for power management, PnP, etc

9
User-mode Drivers

• Virtual device drivers (VDDs)
• Used to emulate 16-bit MS-DOS applications
• Printer drivers
• Translate device-independent graphics requests to
  printer-specific commands

10
Win32 Input/Output APIs

• A few device-independent APIs available
• CreateFile
• ReadFile / WriteFile
• CloseHandle
• Many (over 100) device-type-dependent APIs
• disk
• tape
• console
• pipes
• sound cards
• etc

11
Device and File Naming

• File names
• \\.\disk\directory\\file
• \\server\disk\directory\\file
• Local device names
• \\.\name-of-device
• Remote device names Universal Name Convention
• \\server\name-of-shared-resource
• DOS-style built-in device names for compatibility
• A, B, D etc
• Windows 2000 internal name differ from externally
  visible names

12
Overview of Cache Manager

• What is the cache manager?
• A set of kernel-mode functions and system
  threads that cooperate with the memory manager to
  provide data caching for all Windows 2000 file
  system drivers
• Most OSs rely on each individual file system to
  cache data
• Duplicate caching / memory management code
• Limitations on the kinds of data that can be
  cached
• Windows 2000 facilitates the caching of all
  externally stored data
• Whether on local hard disks, floppy disks,
  network file servers, CD-ROMs
• Any kind of data can be cached
• User data streams (the contents of a file,
  on-going r/w)
• File system metadata (e.g. directory and file
  headers)

13
Cache Manager Key Features

• Supports all file system types
• Removes the need for each file system to
  implement its own cache management code
• Uses the memory manager to control what parts of
  the files are in physical memory (see next slide)
• Allowing a trade-off for physical memory between
  user processes and the OS
• Caches data on a virtual block basis
• In contrast to most caching systems, which cache
  on a logical block basis
• ? provides fast I/O intelligent read-ahead and
  high-speed access to the cache without involving
  file-system drivers

14
Interaction Between the Cache and the Memory
Manager

• Unusual aspect Cache manager never actually
  knows how much cached data is in physical memory!
• This is because it maps views of files into
  system virtual address spaces
• The memory manager then pages in blocks that
  arent in physical memory, and pages data out
  too
• The approach avoids the cache manager generating
  read or write I/O request packets to access the
  data for files its caching
• Instead, it copies data from the virtual address
  of where the portion of the file is, and relies
  on the memory manager to fault in the data, if
  needed

15
Overview of File Systems

• NTFS native file system format for Win2000
• Also includes support for
• CDFS
• UDF
• FAT12, FAT16 and FAT32

16
CDFS File System

• CD-ROM file system simple format defined in
  1998 as the read-only formatting standard for CD
• Format has a number of restrictions
• Directory and file names must be fewer than 32
  characters long
• Directory trees can be no more than eight levels
  deep
• Now considered legacy. because of

17
UDF File System

• Format replacing CDFS for optical storage media
• DVD-ROM in mind
• Designed with rewritable media in mind, Windows
  2000 UDF driver only provides read-only support
• File systems have the following features
• Filenames can be 255 characters long
• Maximum path length is 1023 characters
• Filenames can be upper and lower case

18
FAT12, FAT16 and FAT32

• Supported to enable upgrades from other versions
  of Windows, and for compatibility with other
  OSs, and for use as a floppy disk format
• 12, 16 and 32 represent the number of bits the
  format uses to identify clusters on a disk
• Windows 2000 uses cluster sizes of 512 bytes to 8
  KB in size, limiting a FAT12 volume to 32MB
• Windows 2000 uses FAT12 as the format for floppy
  disks
• FAT32 (most recently defined)
• Used in Win95 (OSR2), Win98 and Win Millennium

19
NTFS

• Uses 64-bit cluster indexes
• NTFS has the ability to address volumes up to 16
  exabytes (16 million GB)
• Windows 2000 limits the size of an NTFS volume to
  that addressable using 32-bit clusters
• 128 TB (using 64KB clusters)

20
NTFS Advanced Features (1)

• Recoverability
• File system structures can be repaired to a
  consistent state (no loss of file or directory
  structure info file data can be lost)
• File and directory security
• Files and directories are protected from
  unauthorised access using a combination of a
  security ID (stored as part of the file) and the
  password entered
• File compression
• Transparent to application
• Directory compression also possible

21
NTFS Advanced Features (2)

• Disk quotas
• Per-user volume quotas
• NTFS tags files and directories with the security
  ID of the user who created them
• Encryption
• Supports EFS Encrypting File System
• Transparent to application
• Files are accessed using using the private key of
  an accounts EFS private / public key pair
• etc
