Title: Next Generation Network (NGN)


1
Next Generation Network(NGN)
2
Jaringan Saat ini
3
Network Evolution Transport 1980s
4
Network Evolution Transport 1990s
5
Network Evolution Transport 2000s
6
Paradigma Shift
7
Network Today and Future
8
New Public Network
9
ConvergenceWhat does it mean?
  • Convergence of voice, data and Internet into one
    seamless IP-based communications network
  • Adopting IP as common platform to plug in
    unlimited variety of applications and services,
    cost effectively
  • Enabling broader choice of devices for customer
    services provided over common platform
  • Unlocking content (voice, data, video, text,
    commerce, etc.) so it can flow seamlessly among
    applications

10
Convergence the before picture
11
After Convergence
DSL Modem
Partners and Content Providers
Soft IP Phone
Voice Call Server
IP Phone
DSLAM
Backbone Routers
DSL Modem
Distribution Routers
Internet Data Centres
IP Network
IAD / Res Gateway
Gateway
IP Phones
IP Phone
Wireless Network (Cellular)
Soft IP Phone
Legacy Voice Network
PSTN Switches
POTS Phones
12
Evolution to Convergence
13
Evolving to NGN
14
Next Generation Network
15
NGN Layer
16
NGN Layer
17
Network Architecture
18
NGN Architecture
  • Management Plane, gives Operation System Support
    (OSS) function
  • Transport Plane, as transport media for all
    message in the network
  • Call Control Signaling Plane, as connection
    process handler
  • Service/Application Plane , as supplier and
    executor of application (telephony, data,
    multimedia, include Features)

Source ISC and TELKOMs Standard System
19
Next Generation Network Softswitch System
  • Softswitch system is a part of next generation
    network based on ISC/IPCC reference model consist
    of Softswitch host, Application Server, OSS,
    Signaling Gateway, Trunk Gateway and Access
    Gateway.
  • Softswitch (call agent / call controller) as call
    control function
  • Application Server (AS) provides enhanced
    features which is not available in Softswitch
    host.
  • Operating Support System as network management,
    billing support, etc.
  • Signaling Gateway (SG) as interface to CCS-7
    (STP)
  • Trunk Gateway (TG) as interface to TE or LE of
    PSTN
  • Access Gateway (AG) as interface to CPE

20
Softswitch Protocols
  • SIP-T inter softswitch protocol
  • Media Gateway protocol
  • MGCP
  • Megaco (H.248)
  • Softswitch VoIP protocol H.323 (Min. ver 2)
  • Application Server and SIP phone protocol SIP
  • OSS protocol SNMP
  • Billing Server protocol FTP atau TFTP
  • Trunk Gateway has to support CODEC
  • G. 711
  • G. 729
  • G. 723

21
Challenges to Consolidate Network
  • Integrating existing network will be controlled
    by softswitch
  • VoIP Network, Call Manager Consolidation
  • DSLAM, Running as Access Gateway
  • RAS, Running as VoIP Gateway
  • CaTV network, Softswitch Implementation in HFC
    Network
  • PSTN, PSTN preparation to enable Softswitch
    implementation (reduce node for CCS-7 penetration)

22
Challenges to Consolidate Network
23
Converged Network
24
Softswitch Implementation Configuration
25
Convergence of Telephony and Internet World
26
Next Generation Services
27
Key Atribute NGN Service Architecture
28
NGN Service Characteristics
  • Ubiquitous, real-time, multi-media communications
  • More personal intelligence distributed
    throughout the network
  • More network intelligence distributed
    throughout the network
  • More simplicity for users
  • This shields users from the complexity of
    information gathering, processing, customization,
    and transportation.
  • Personal service customization and management
  • Manage personal profiles, self-provision network
    services, monitor billing information, customize
    user interfaces behavior of their applications,
    and create and provision new applications.
  • Intelligent information management
  • To manage information overload to search for,
    sort, and filter content, manage messages or data
    of any medium, and manage personal information
    (e.g., calendar, contact list, etc)

29
Basic Telephony Services
  • Basic Services (e.g. ISDN bearer services and
    ISDN tele-services)
  • Supplementary Services (e.g. CLIP, CLIR, CW)
  • IN-Services (e.g. shared cost, premium rate, free
    phone and personal number)
  • Value Added Services (e.g. Voice Messaging and
    Voice Mail, Audio/Video Conferencing, Calling
    Card and Directory)
  • Circuit Switch Based Services (e.g. OCB)
  • GSM Services (e.g. Voice, SMS)
  • Interconnection Services (e.g. Origination,
    Termination, unbundled access, Carrier Selection,
    collocation)
  • Services arising from open competition (e.g.
    collection, third party billing, clearing house,
    enquiry services)
  • Transport services (e.g. Leased-line, ATM, and
    frame relay services)

30
Enhanced Services (1)
  • Users roaming from one access network to another
  • The ability for users to manage their personal
    profiles
  • Self-provisioning network services
  • Monitoring of usage and billing information
  • Users customizing their own interfaces etc.
  • Making and receiving voice calls whilst using a
    data application without dropping out of the data
    application.

31
Enhanced Service (2)
  • NGN call centers
  • Full integration of communication applications in
    workflows
  • Multimedia, multi-channel interaction
  • End-users can call when, where and how they
    choose
  • Completely network-based virtual call centers
    that queue and route calls directly to individual
    agents throughout the world, without the need for
    any other call center platforms Call Center
    On-Demand

32
NGN call centers Architecture
33
Enhanced Services (3)
  • NGN multimedia conferencing
  • NGN multimedia conferencing is a kind of
    ubiquitous, real time, multi-media communication.
    High-speed access and transport allow for natural
    interactions between users and the network.
  • NGN multimedia conferencing not only allows
    multiple parties converse with each other while
    displaying visual information. In an NGN
    environment also the Internet/database access may
    be strongly involved in a communication.
  • NGN makes multimedia conferencing on-demand
    possible.

34
Enhanced Service (4)
  • Unified Messaging
  • Allows more simplicity for users by a unified
    environment for all forms of communication.
  • Unified Messaging means the delivery of voice
    mail, email, fax mail, SMS, MMS as well as paging
    through common interfaces independent of the
    means of access and terminals.
  • With NGN users will be encouraged to use Unified
    Messaging, because the usage of that will become
    easier.
  • Enhancing Unified Messaging solutions with more
    advanced capabilities by adding the real-time and
    multimedia components

35
Unified Messaging Model
36
Enhanced Services (5)
  • End-user controlled NGN services
  • Services of PABX
  • Premises-based, user controlled VPN
  • Type one and type two Call Center
  • Network Gaming
  • File Sharing
  • Home Monitoring/Control/Manager
  • Content
  • etc.

37
CASE Telkoms New Services Development
  • Click to Dial
  • Corporate Directory
  • PC to Phone / Phone to PC
  • Web Based Video Conference
  • Executive Briefing Network
  • Web Based Call Center
  • Multimedia Conferencing
  • IP PBX
  • IP Centrex

38
- We Can WIN, If We Are ONE -
T E R I M A K A S I H
