Managing Roles

1
Managing Roles Privileges with Grouper and
Signet Middleware
Internet2 Spring Members Meeting, April 26, 2006

• Tom Barton, University of Chicago
• Lynn McRae, Stanford University

2
Groups and Roles

• Roles and Groups
• Who someone is (identity)
• People sharing a common trait, e.g., rank or
  privilege
• Roles -- you know it when you see it
• Institutional role, e.g., faculty, Dean
• Departmental roles, e.g., chair, admin
• Professional role, e.g., mathematician, buyer
• Project role, e.g., analyst, engineer
• Groups
• Any collection of people, role-holders or not?
• Depends on how you name it?
• Role vs group is not what matters

3
Groups and Privileges

• Two categories of information are used in making
  access control decisions
• Who you are
• aka roles
• cf RBAC
• What you can do
• aka privileges
• cf value-based authority
• Both types of information are conveyed through
  attributes about a person
• Grouper and Signet are tools that let you enrich
  descriptive attributes about people in both ways

4
Grouper

• Grouper
• Middleware software/toolkit
• User access through a common UI
• Program access through a common API
• Defines a Groups Registry
• Brings scattered duplicative groups together for
  re-use
• Allows useful actions on these groups -- group
  math, group nesting, exclusion criteria
• Hierarchical name-space (name stems substems)
• Can leverage existing group information
• Supports the creation of new groups
• By schools, departments, and individuals!
• Distributed/delegated model of control

5
Signet

• Signet
• Middleware software/toolkit
• User access through a common UI
• Program access through a common API
• Brings privilege information together in one
  place -- a Privilege Registry
• Central granting, can apply across multiple
  systems
• Central reporting, history, auditing, review
• Accessible to managers AND holders of privileges
• Independent of specific vendors, systems,
  releases or technologies
• Distributed/delegated model of control

6
Relative Roles of Signet Grouper

• RBAC model
• Users are placed into groups
• Grouper allows local creation and management of
  group membership
• Privileges can then be assigned to groups
• Signet manages privileges to groups (as well as
  to individuals)
• Both role and privilege information can be
  leveraged by systems

Grouper
Signet
7
Access Control Decision

• Q Subject Resource Action Context
• Subject who wants to take an action, typically
  a person
• Resource what is the action against, e.g.,
  file, building, data, service, etc.
• Action what they want to do, e.g., view,
  modify, enter, approve, run, etc.
• Context time of day, academic term, weather,
  etc.
• A Policy interpretation and decision, e.g.
• Resource and action are available to a group,
  e.g., Faculty at MIT, Students in a class
• Available to anyone with entitlement for the
  service

8
Access Control Decision
Resource
Subject
Identity Provider
Service Provider
Subject tries to access resource
authd
Context
Provider evaluates required identity attributes
against rules for resource
Rules
Provider grants or denies access
Policy
9
Palace Access
Who are you?

organizationRoyalCourt affiliationmusketeer
What can you do?
permissionpalace_access
10
Identity Access Management

• Each persons online activities are shaped by
  many Sources of Authority
• Institutional policy making bodies
• Resource managers
• Program/activity heads
• Self
• Management of the information it conveys should
  be distributed
• Hook up all of those Sources of Authority to the
  middleware
• Common middleware infrastructure should be
  operated centrally
• Departments/programs/activities should not have
  to build their own core middleware

11
Big picture
12
Big picture, without Grouper/Signet
13
Groups is good
Identity Management
HR
Affiliation faculty Dept Biology
14
Departmental other local groups
Identity Management
HR
Affiliation faculty Dept Biology
biologybio-x
biologybio-xadmin
biologybio-xstaff
The Boss
15
Filling the gap
HR
Identity Management
Affiliation faculty Instructor CS-313
SIS Courses
Shib
16
Extending Course infrastructure
HR
Identity Management
Affiliation faculty Instructor CS-313
SIS Courses
U
ClassCS-313TA

isMemberOf CS-313
Shib
The Professor
17
Extending Course infrastructure
HR
Identity Management
Affiliation faculty
SIS Courses
faculty CS-313
U
classCS-313TA

isMember CS-313
Shib
Course Ware
The Professor
18
Creating new identity
Identity Management
Guest IDs
Affiliation ???
Sib
19
Creating new identity
Identity Management
Guest IDs
Affiliation guest
guestidsguests
blackboard(music103)
printing(max100)
guestidsadmin
athletic(gym,after5)
Sib
effective date expiration date
Rula Lenska
20
Distributing control of authority
Finance
phone
Identity Management
email
ticket
Affiliation staff
21
Distributing control of authority
Finance
Identity Management
Accounts
Affiliation staff
Depts
Scope
schooldept1 (view,all)
schooldept2 (approve,1472,100)
Grouper
while staff
A.Greenspan
B.Bernake
22
Distributing control of authority
Finance
Identity Management
Affiliation staff
school
schooldept
scope
schooldept1 (view,all)
schooldeptunit
schooldept2 (approve,1472,100)
Grouper
while staff
A.Greenspan
B.Bernake
23
The duck test

• Grouper
• Binary info youre either in some list or not
• Locally tweak or combine other groups
• Identification layer of an encompassing access
  management scheme
• Identity- or affiliation-based access control or
  distribution

• Signet
• Structured, qualified info limits, conditions,
  scope,
• Assignments to individuals as well as groups
• Delegation and chain of authority essential for
  access decisions
• Enable functional, not just technical, people to
  manage privileges
• Supports policy control closer to source of
  authority
• Audit requirements

24
Consider Signet when

• Complex group intersections and hierarchies
  become cumbersome
• Difficult to track who has what and when
• Cant easily move people need to delete/add
• Implementation of related access rules is
  scattered across systems
• different procedures, different contacts,
  managing changes across areas, over time
• You need to coordinate policy, privileges and
  audit activities across systems

25
Signet Grouper Overview
26
Grouper Overview

• Mix of manual and automation processes manage a
  common Groups Registry
• Stored in an RDBMS
• Automation processes provision info from the
  Groups Registry into LDAP, AD, directly into
  application-specific databases, wherever the
  value of the info warrants spending the resources
  to place it there
• Two types of managed objects groups and naming
  stems
• Groups are created named with a naming stem
• Group management authority is delegatable
• By group or by naming stem

27
Grouper Groups

• Any subject can be a group member or privilegee
• Persons, groups, site-defined subject types
• Uses Subject API developed by GrouperSignet
  teams
• Subgroups (now), composite groups (v1.0), and
  aging (v1.1) of groups and memberships
• Privileges
• ADMIN, UPDATE, READ, VIEW, OPTIN, OPTOUT
• Group attribute set can be site-extended

28
Naming Stems

• Groups are created with naming stems
• Limits the authority to create and name groups
• Support distinct activities with own authority
• Naming stems can be arranged hierarchically
• eg, uc, ucnsit, ucnsitlabs
• Privileges
• STEM
• Create subordinate naming stems
• Assign privs for this naming stem
• CREATE create groups with this naming stem

29
Composite Groups

• Membership is defined by composing the
  memberships of 2 other groups
• A B U C union
• A B n C intersection
• A B C relative complement
• Common use tweak existing groups
• Whitelist or blacklist factored in to another
  group

30
Example Computer Cluster Access
Allow access if in (nsitlabseligible
nsitlabsbarred)
nsitlabseligible (manual)
nsitlabsbarred (manual)
nsitlabswhitelist (manual)
nsitlabsblacklist (manual)
ucfaculty (auto)
ucstaff (auto)
categories of entitled students (auto)
31
Systems Integration

• API
• XML Import/Export Tool
• Snapshots Groups Registry, including naming stems
  and privileges
• A single group
• All subordinate to a specified naming stem
• All matching a search condition
• Entire Registry

32
Signet Overview

• Analysts define privileges in functional terms
  and specify associated system-level permissions
• Signet presents this functional view in a Web UI
  where users assign privileges delegate
  authority across all areas in which they have
  authority
• Signet internally maps assigned privileges into
  system-specific terms needed by applications
• Privileges are exported, transformed,
  provisioned into applications and infrastructure
  services
• Signet provides automated lifecycle controls

33
Privileges Building Blocks

• Functional view
• Subsystems
• Categories
• Functions
• Scope, Limits
• Prerequisites Conditions

• System view
• Permissions
• Subject
• Action
• Resource

34
Functional View
Subsystems contain

• Limits
• Qualifiers, constraints for a privilege
• Scope
• Organizational hierarchy governing distributed
  delegation

• Functions
• The things a person can do what they are
  getting privileges for
• Categories
• Provide useful arrangement of functions within a
  subsystem for reporting, ease of use

35
Functional View
Add/Drop students
Course Support
Student Admin
Which term
Schedule Classes
Which campus
Process Applicants
Financial Aid
For school
Award Scholarships
From Fund
Manage Accounts
For fund
Patient Records
Clinical Trial
Protocol A
Read/Write
Materials Control
Qty/day
Manage Grant
Admin
constraints
Lab Access
Hours
Categories
Subsystems
Functions
Limits
organizing
actions
36
Systems View

• Permissions
• Atomic units of control that map to specific
  access rules in systems
• Includes limits that must be evaluated when
  interpreting permissions
• Resources
• The target of a specific privilege things that
  have access rules to control their use

37
Functional View ? Permissions
Calendar
Student Admin
reserve_time
view_schedules
Add/Drop students
Course Support
Course
Schedule Classes
update_course_data
Facilities
reserve_room
Process Applicants
Financial Aid
Financial
Award Scholarships
view_fund_data
Manage Accounts
update_fund_data
Student
student_records
categories
functions
applicant_data
Functional View
Resources/Permissions
38
Systems Integration

• API
• Permissions document
• XML representation of privileges for an
  individual or group
• Will be compatible with XACML

39
Privileges Lifecycle

• Conditions
• Provides automatic revocation of privileges
• Date controls -- from date, until date
• Will be based on persons status, affiliation,
  etc.
• e.g., as long as person is at Stanford
• Prerequisites
• Pre-conditions that must be met to activate
  privileges
• e.g., training

40
Other features

• Assignments can be
• To an individual
• To a Group
• With/without ability to further delegate
• Distributed delegation using organizational
  hierarchy
• Records chain of command
• Proxy assignment
• Temporary granting of ones privilege to another

41
Privilege Elements by Example
Lifecycle
Privilege
42
Generic Integration Architecture
43
Further Integration Tasks

• Automated loading of groups privileges
• Authentication service
• Application-specific integration capabilities
• Site-specific LDAP schema
• Authoring/maintaining subsystem metadata
• Solution requisites
• Which groups should be made available to the
  calendaring, email list, wiki systems?
• The Boss may need an automatic grant of a Signet
  privilege to manage his wiki space
• Implementing service policies Grouper naming
  stems privileges or Signet privileges

44
Subject APISite IAM Integration Requirements

• Subject - a person, group, application, or other
  type of object whose identity is managed by your
  IAM system
• Abstract the underlying technology and data model
  from a relying application
• Enable identifier namespaces to be selected to
  match application needs
• Username vs. opaque registryID vs.
• Scenarios
• Map authenticated user to internal security
  principal
• Reference/search objects within application

45
Subject APIIntegration with Sites IAM
46
Source Adapter Configuration

• Name the source specify connection details
• Name the type or types of subjects residing there
• Identify attributes/columns distinguished as
  subjectID, name and description
• Specify back-end-specific searches for each type
  and each search method
• Select
• Search by identifier
• Search
• Sites should make consistent assignment of source
  and type names across all source adapter
  instances
• They are persisted by Subject API clients

47
Signet Grouper Roadmaps

• Now available
• Grouper v0.9. UI API source release
• Signet 1.0. UI, binary release
• Subject API v0.1b
• Signet Roadmap
• v1.1, ? 2006 full API source release
• v1.2, ? 2006, rules processor
• Grouper Roadmap
• v1.0, May 2006 group math
• v1.1, ? 2006 group membership aging
• Subject API
• v1.0, ? 2006 minor changes, updates to
  reference implementations

48
Resources Participation

• Grouper
• team University of Chicago University of
  Bristol
• http//grouper.internet2.edu
• Signet
• team Stanford University
• http//signet.internet2.edu
• Internet2 Middleware Initiative
• http//middleware.internet2.edu/
• Documents, software, cvs
• Details for subscribing to mailing lists
• Conference call agendas dialing instructions
