Experimental Evaluation of the Seismic Performance of Piping Subassemblies

1
Experimental Evaluation of the Seismic
Performance of Piping Subassemblies

• Presenter Dr. Emmanuel Manos Maragakis
• Dr. Ahmad Itani, Robert Corbin and Elliott Goodwin

2
Personnel

• Authors
• Robert C. Corbin
• Elliot R. Goodwin
• Dr. Emmanuel Manos Maragakis (PI)
• Dr. Ahmad M. Itani (CoPI)
• Graduate Students
• Elliot R. Goodwin
• Robert C. Corbin

3
Outline

• Motivation
• Objectives and Scope
• Experimental Program
• Input Motion Generation
• Experimental Protocol
• Experimental Results
• Experimental Comparisons
• Observations and Conclusions

4
Motivation

• Why Minimize Nonstructural Damage?
• Life Safety
• Property Loss
• Direct Damage
• Consequential Damage
• Loss of Function

5
Investment Costs
6
Background/Objectives

• Background
• Experimental Evaluation
• Steel/Welded and Steel/Threaded Piping Systems
  (Goodwin 2004)
• Copper/Soldered Piping Systems (Corbin 2006)
• Objectives
• Understand the seismic behavior of braced and
  unbraced piping systems
• Identify the capacity characteristics
• Investigate and compare responses

7
Scope

• Scope
• Experimental Specimen
• Generated Input Motions
• Experimental Protocol
• Displacement and Acceleration Responses

8
Experimental Configuration

• Modeled after University of California, Davis
  Medical Center piping system
• Modified to accommodate dimensions and geometry
  restrictions of testing facility
• Consisted of 100 feet of 3 inch and 4 inch
  diameter piping
• Four typical valves including a y-strainer, a
  check valve, and two gate valves
• Two water heaters
• One simulated heat exchanger
• Heat exchanger and water heaters were anchored to
  the shake table
• System was braced and hung from a stationary frame

9
Test Set-up and Specimen Configuration
10
Plan View
11
Elevation View
12
Piping System Setup
13
Bracing Details
Transverse Brace Longitudinal Brace
14
Bracing Layout
15
Instrumentation
29 Stringpot (SP) (20 stroke) Displacement
Transducers
16 Crossbow (xbow) Kinemetrics
(2g) Accelerometers
16
Input Motion Generation

• ICBO AC156
• A synthetic motion must be generated that
• Meets a desired response spectra based on 1997
  UBC
• Build, hold and decay envelope of 5, 10 and 15
  seconds, respectively
• SIMQKE Program
• A maximum acceleration of 1 g

17
Synthetic Input Motions SIMQKE
18
Input Motion Generation

• Northridge Near-Fault Ground Motions were
  utilized to perform dynamic analyses
• Earthquakes were generated utilizing the Specific
  Barrier Model (Wanitkorkul and Filiatrault)
• A total of 4 cases, 2, 5, 10, 20, probability
  of exceedance in 50 years
• 2 components per case, Fault-normal (Large) and
  Fault-parallel (Small)
• 25 earthquakes simulated for each component

19
Synthetic Input Motions OpenSees
20
Experimental Protocol

• 4 steel systems tested (SIMQKE Motions)
• Welded braced
• Welded unbraced
• Threaded braced
• Threaded unbraced
• 2 copper systems tested (Northridge Motions)
• Braced
• Unbraced
• Subjected to increasing intensities of the
  derived input motions in the principle axes, N-S
  and E-W, as well as a biaxial excitation at 45
  with respect to the principle axes

21
Experimental Results

• Observations and Performance
• Steel/Welded Braced and Unbraced
• Steel/Threaded Braced and Unbraced
• Copper/Soldered Braced and Unbraced
• Instrument Comparisons
• Braced and Unbraced Subassemblies
• Copper/Soldered, Steel/Welded and Steel/Threaded
  Braced Subassemblies
• Copper/Soldered, Steel/Welded and Steel/Threaded
  Unbraced Subassemblies

22
Experimental Results Welded Braced System

• Two failed braces
• Cable portion only
• Occurred at highest input motion (100 SIMQKE E-W
  )
• Permanent displacement of braces

23
Experimental Results Welded Unbraced System

• Two failed hanger rods
• Occurred at highest input motion (100 SIMQKE
  Biaxial )

24
Experimental Results Threaded Braced System

• Flanged connection to heat exchanger began to
  leak at relatively low amplitudes
• 50 of SIMQKE Generated Input Motion
• Leak formed at the vertical run above the heat
  exchanger at
• 70 of SIMQKE Generated Input Motion
• The testing protocol was stopped after the first
  100 SIMQKE motion

25
Flange Connection Failure
26
Selected Instrument Response nv17 Steel Piping
Subassembly
nv17
27
Experimental Results Copper
Braced Subassembly

• 2 Probability of Exceedance of the Northridge
  Earthquake Ground Motion in the East/West
  Direction at 100 Strength
• Maximum displacement response 3.80 in
• Maximum acceleration response 2.64 g
• Experimental Observations
• Piping did not experience any damage
• Permanent displacement of several braces
• 3 inch piping risers permanently offset due to
  damage experienced by water heaters

28
Experimental Results Copper
Braced Subassembly

• Cable and Brace Damage (Brace B7)

Sag
Displacement
29
Experimental Results Copper
Unbraced Subassembly

• 2 Probability of Exceedance of the Northridge
  Earthquake Ground Motion in the North/South
  Direction at 100 Strength
• Maximum displacement response 11.14 in
• Maximum acceleration response 2.64 g

30
Experimental Results Copper
Unbraced Subassembly

• Experimental Observations
• Displaced Hanger Rod
• 20 PE East/West Direction
• Drift of 2.3
• Hanger Rod Failure
• 10 PE North/South Direction
• Drift of 2.8
• Two Flange Failures
• 10 PE East/West Direction
• Drift of 2.6

31
Experimental Results Copper
Unbraced Subassembly
32
Experimental Results Copper
Unbraced Subassembly

• Failed Hanger Rod Connection

33
Experimental Results Copper
Unbraced Subassembly

• Flange Connection Failure

34
Experimental Comparisons Copper Braced vs.
Unbraced

• Displacement Responses
• Ranged between 1.12 to 16.8 times larger
• Acceleration Responses
• Ranged between 0.82 to 6.19 times larger
• Subjected to story drifts up to 3.13
• Braced subassembly suffered no damage
• Unbraced subassembly suffered minor damage
  beginning at 2.3 and extensive damage at 2.6

35
Response Summary

• SP34 xbow12

• SP21 xbow2

36
Experimental Comparisons Copper Steel
Braced Subassemblies

• Experimental Observations
• Copper/Soldered
• Withstood a story drift of 3.13
• Steel/Welded
• Withstood a story drift of 5
• Steel/Threaded
• Leaks formed at a story drift of 2.17
• Failed in response to a story drift of 4.34

37
Experimental Comparisons Copper Steel
Braced Subassemblies

• Displacement Responses
• Copper/Soldered produced the smallest
• Steel systems ranged between 1.42 and 13.1 times
  larger
• Acceleration Responses
• All three subassemblies were very similar
• Steel systems ranged between 0.57 and 4.00 times
  larger

38
Experimental Comparisons Copper
Steel Unbraced Subassemblies

• Experimental Observations
• Copper/Soldered
• Rod failure at 2.8 story drift
• Piping flanges failed at 2.6 story drift
• Steel/Welded
• Rod failure at 4.34 story drift
• Piping withstood a 4.34 story drift
• Steel/Threaded
• Minor joint leaks started at 1.08 story drift
• Joint failures at 2.17 story drift

39
Experimental Comparisons Copper
Steel Unbraced Subassemblies

• Unbraced responses were inconsistent
• Displacement Responses
• Steel systems produced the largest longitudinal
  responses
• Ranged between 1.88 and 4.65 times larger
• Transverse and vertical responses were similar
• Acceleration Responses
• Longitudinal responses were similar
• Steel systems produced the largest transverse and
  vertical responses
• Ranged between 1.01 and 3.55 times larger

40
Response Summary

• Longitudinal Responses of SP21 and xbow2

41
Observations and Conclusions

• Piping systems were determined to be drift
  sensitive
• Braces significantly reduced system displacement
  response
• Braces did not reduce the system acceleration
  response

42
Observations and Conclusions, continued

• Copper system
• Braced
• Survived 3.13 drift
• Unbraced
• Flanges were the weak points
• Welded system
• Braced and Unbraced
• Survived 4.34 drift
• Threaded system
• Braced
• Complete failure at 4.34 drift
• Unbraced
• Leaks began at 1.08 drift
• Complete failure at 2.17 drift
• Fittings were weak point

43
Observations and Conclusions, continued

• 1997 UBC code limit on story drift is 2.5
• Braced
• Copper/Soldered experienced no damage
• Steel/Welded experienced no damage
• Steel/Threaded would have leaks
• Unbraced
• Copper/Soldered experienced damage
• Steel/Welded experienced no damage
• Steel/Threaded would have leaks at half of UBC
  requirement

44
