ELEC 52700016270001Fall 2006 LowPower Design of Electronic Circuits Power Analysis: Logic Level

1
ELEC 5270-001/6270-001(Fall 2006)Low-Power
Design of Electronic CircuitsPower Analysis
Logic Level

• Vishwani D. Agrawal
• James J. Danaher Professor
• Department of Electrical and Computer Engineering
• Auburn University, Auburn, AL 36849
• http//www.eng.auburn.edu/vagrawal
• vagrawal_at_eng.auburn.edu

2
Power Analysis

• Motivation
• Specification
• Optimization
• Reliability
• Applications
• Design analysis and optimization
• Physical design
• Packaging
• Test

3
Abstraction, Complexity, Accuracy
4
Spice

• Circuit/device level analysis
• Circuit modeled as network of transistors,
  capacitors, resistors and voltage/current
  sources.
• Node current equations using Kirchhoffs current
  law.
• Average and instantaneous power computed from
  supply voltage and device current.
• Analysis is accurate but expensive
• Used to characterize parts of a larger circuit.
• Original references
• L. W. Nagel and D. O. Pederson, SPICE
  Simulation Program With Integrated Circuit
  Emphasis, Memo ERL-M382, EECS Dept., University
  of California, Berkeley, Apr. 1973.
• L. W. Nagel, SPICE 2, A Computer program to
  Simulate Semiconductor Circuits, PhD
  Dissertation, University of California, Berkeley,
  May 1975.

5
Logic Model of MOS Circuit
VDD
pMOS FETs
a
Da
c
Dc
a
b
Db
c
Cc
b
Da and Db are interconnect or propagation
delays Dc is inertial delay of gate
Cb
nMOS FETs
Cd
Ca , Cb , Cc and Cd are node capacitances
6
Spice Characterization of a 2-Input NAND Gate
7
Spice Characterization (Cont.)
8
Switch-Level Partitioning

• Circuit partitioned into channel-connected
  components for Spice characterization.
• Reference R. E. Bryant, A Switch-Level Model
  and Simulator for MOS Digital Systems, IEEE
  Trans. Computers, vol. C-33, no. 2, pp. 160-177,
  Feb. 1984.

G2
Internal switching nodes not seen by logic
simulator
G3
G1
9
Delay and Discrete-Event Simulation (NAND gate)
Transient region
a
Inputs
b
c (CMOS)
c (zero delay)
c (unit delay)
Logic simulation
X
rise5, fall5
c (multiple delay)
Unknown (X)
c (minmax delay)
min 2, max 5
Time units
5
0
10
Event-Driven Simulation(Example)
Activity list d, e f, g g
Scheduled events c 0 d 1, e 0 g 0 f
1 g 1
a 1
e 1
t 0 1 2 3 4 5 6 7 8
2
c 1?0
g 1
2
2
d 0
Time stack
4
f 0
b 1
g
8
4
0
Time, t
11
Time Wheel (Circular Stack)
max
Current time pointer
t0
Event link-list
1
2
3
4
5
6
7
12
Gate-Level Power Analysis

• Pre-simulation analysis
• Partition circuit into channel connected gate
  components.
• Determine node capacitances from layout analysis
  (accurate) or from wire-load model
  (approximate).
• Determine dynamic and static power from Spice for
  each gate.
• Determine gate delays using Spice or Elmore delay
  analysis.

Wire-load model estimates of a net by its
pin-count. See Yeap, p. 39.
13
Elmore Delay Model

• W. Elmore, The Transient Response of Damped
  Linear Networks with Particular Regard to
  Wideband Amplifiers, J. Appl. Phys., vol. 19,
  no.1, pp. 55-63, Jan. 1948.

2
R2
C2
1
R1
s
4
R4
C4
C1
R3
3
R5
Shared resistance R45 R1 R3 R15 R1 R34
R1 R3
C3
5
C5
14
Elmore Delay Formula
N Delay at node k 0.69 S Cj Rjk
j1 where N number of capacitive nodes in
the network Example Delay at node 5 0.69R1
C1 R1 C2 (R1R3)C3 (R1R3)C4
(R1R3R5)C5
15
Gate-Level Power Analysis (Cont.)

• Run discrete-event (event-driven) logic
  simulation with a set of input vectors.
• Monitor the toggle count of each net and obtain
  capacitive power dissipation
• Pcap S Ck V 2 f
• all nodes k
• Where
• Ck is the total node capacitance being switched,
  as determined by the simulator.
• V is the supply voltage.
• f is the clock frequency, i.e., the number of
  vectors applied per unit

16
Gate-Level Power Analysis (Cont.)

• Monitor dynamic energy events at the input of
  each gate and obtain internal switching power
  dissipation
• Pint S S E(g,e) f(g,e)
• gates g events e
• Where
• E(g,e) energy of event e of gate g pre-computed
  from Spice.
• F(g,e) occurrence frequency of the event e at
  gate g observed by logic simulation.

17
Gate-Level Power Analysis (Cont.)

• Monitor the static power dissipation state of
  each gate and obtain the static power
  dissipation
• Pstat S S P(g,s) T(g,s)/ T
• gates g states s
• Where
• P(g,s) static power dissipation of gate g for
  state s, obtained from Spice.
• T(g,s) duration of state s at gate g, obtained
  from logic simulation.
• T vector period.

18
Gate-Level Power Analysis (Cont.)

• Sum up all three components of power
• P Pcap Pint Pstat
• References
• A. Deng, Power Analysis for CMOS/BiCMOS
  Circuits, Proc. International Workshop Low Power
  Design, 1994.
• J. Benkoski, A. C. Deng, C. X. Huang, S. Napper
  and J. Tuan, Simulation Algorithms, Power
  Estimation and Diagnostics in PowerMill, Proc.
  PATMOS, 1995.
• C. X. Huang, B. Zhang, A. C. Deng and B. Swirski,
  The Design and Implementation of PowerMill,
  Proc. International Symp. Low Power Design, 1995,
  pp. 105-109.
