WS-JDML: A Web Service Interface for Job Submission and Monitoring

1
WS-JDML A Web Service Interface for Job
Submissionand Monitoring

• Stephen MCGough
• William Lee
• London e-Science Centre
• Department of Computing, Imperial College London

2
What Services do we need to make the Grid Work?

• One of the key services required is job
  submission
• The ability to transparently submit a job to a
  resource (potentially through a DRM) where it
  will run
• Many DRM systems exist (Condor, Globus, SGE etc)
• Each have their own way to define a job
  (language)
• Each have their own submission mechanism (command
  line, API, Service)

3
The Problem

• Submitting jobs requires
• Knowledge of the job definition procedure
• The ability to interface with the appropriate DRM
• The Solution
• One common Job description language that can be
  used with all resources (eg RSL)
• A generic submission system for jobs
• Using community based standards that are in
  common use

4
Generic Job Submission
Web Services
WS-JDML
5
Web Service

• We are using a plain Vanilla Web Service
• Dont rely on any proposed WS standards
• Dont need anything more than core standards for
  this simple service
• Developed in Java
• Our work has been deployed into the J2EE
  enterprise platform
• This enables
• Scalability
• Fault tolerance

6
Job Description Markup LanguageJDML

• Originally developed from Condor ClassAds
• Developed for the European DataGrid project
• Used within the Imperial College ICENI project
• This work is now feeding into the Global Grid
  Forum Job Submission Description Language
  standardisation work
• JDML will morph to become JSDL

7
JDML (2)

• JDML documents are written in sections
• What job to run
• The environment to run the job in
• Where to get files from
• Where to send files to at the end
• JDML is strongly typed
• Consists of name/value pairs

8
JDML (3)

• Can have DRM specific sections
• It must be safe to ignore this section and the
  job still work correctly
• Seen as a set of hints to the DRM
• File transfer is defined for multiple protocols
• Grid FTP, HTTP, copy etc
• Each file may have multiple of these definitions
• DRM can select the appropriate ones to use

9
WS-JDML Architecture
10
Job Submission Port Type

• Takes a JDML document describing the job to run
• Validates the JDML so that an immediate response
  can be given
• Validates user credentials, passed as part of the
  SOAP header, using WS-Security
• Job is then placed into queue before being
  processed into a DRM specific version and
  deployed locally

11
Job Submission Port Type (2)

• Various results
• Unrecognised Job Term
• The JDML contains some term that the Service
  doesnt understand
• Invalid Job Term
• The JDML has a term which has the wrong type or
  an invalid value
• Successful Submission
• URI to identify the job instance is returned

12
Job Monitoring Port Type

• This port provides a means to observe the current
  status of a job and manipulate the output
  transfer mechanism
• Requires the URI representing a job provided from
  job submission
• Current job status is returned
• pending, scheduled, running, suspended, done,
  exit
• Not all DRMs support all states

13
Job Monitoring Port Type (2)File Transfers

• Port provides the ability to
• Get portions of the files specified in the JDML
  transferred
• Override the transfer methods given in the JDML
• Indicate that files should be transferred back as
  attachments to the SOAP document
• Allows easy monitoring of the job progress

14
Deployment

• DRM Specific Translators have been obtained from
  existing code within the ICENI project
• These include Shell, SGE, Globus and Condor
• Web Service architecture has been deployed in
  Java J2EE 1.4 platform
• This provides a number of support features for
  the services.

15
Demo

• Hopefully
• http//rhea.lesc.doc.ic.ac.uk9999/jdml-jobservice

• Need to run over SSH

16
Further Work

• Job State Transition
• The ability to represent the status of a job
  running within a resource
• Notification
• Currently to monitor a job requires the polling
  of the monitoring port
• Would be better if notifications to a sink
  service through say WS-Notification
• Job Term Semantics
• Definition of job terms using natural language
• No formal model makes JDML transformation error
  prone
• Develop an Ontology for Job submission terms

17
What do you use to build your service?

• Widely Implemented Standard Specification (1pt)
• ltDemonstrable Multiple Implementations, e.g.
  SOAP, WSDLgt
• Implemented draft specification (2pt)
• ltSpecification in standards body and supported by
  most/many companies. One/few implementations
  exist (e.g., WS-Security, BPEL)gt
• Implemented draft specification (3pt)
• ltSpecification in standards body but alternatives
  exist. Industry is divided. One/few
  implementations exist. (e.g., Transactions,
  coordination, notification, etc.).
• Implemented proposal (4pt)
• An implementation of an idea, a proposal but not
  submitted to standards body yet (e.g.,
  WS-Addressing, WS-Trust, etc.)
• Non-implemented proposal (5pt)
• ltAn idea that exits as a white paper, but no code
  and no specification detailsgt
• Concept (6pt)
• ltAn idea that exists only as power point
  slides!!gt
• TOTAL SOAP, WSDL, WS-Security 3

18
Service Dependencies

• What else does your service depend on (i.e.
  external dependencies)?
• RDBMs / J2EE EJBs
• Logging (Java Logging)
• Message Queue (JMS)
• What does your implementation depend on?
• Java
• J2EE 1.4 compliant

19
AAA Security

• What authentication mechanism do you use?
• WS-Security
• What authorisation mechanism do you use?
• Flexible composition of authorisation plugins.
• What accounting mechanism do you use?
• Java logging
• Does service interaction need to be encrypted?
• If these are not used now, will they be in the
  future?

20
Exploiting the Service Architecture

• What features from your plumbing do you use in
  your service?
• Event notification
• Meta-data

21
Service Activity

• Multiple interaction or single user?
• Multiple
• Throughput (1/per day or 100/per second?)
• Typical data volume moved in
• Typical data volume moved out

22
Service Failure

• Required Reliability
• Failure semantics?
• Positive ack (might need WS-ReliableMessaging)
• Required Persistence
• Job entered into the queue is always persisted
• Required Availability
• One of many or unique requirement

23
Required Service Management

• Remote access to
• Usage statistics
• Job Progress
• Job Diagnostic and repair interfaces

24
Acknowledgements

• Director Professor John Darlington
• Research Staff
• Anthony Mayer, Nathalie Furmento
• Stephen McGough, James Stanton
• Yong Xie, William Lee
• Marko Krznaric, Murtaza Gulamali
• Asif Saleem, Laurie Young, Gary Kong
• Contact
• http//www.lesc.ic.ac.uk/
• e-mail lesc_at_ic.ac.uk
