Title: IDENTITY Individualized Learning Enhanced by Virtual Reality


1
IDENTITY Individualized Learning Enhanced by
Virtual Reality
DIBE E-learning products
  • Anna Marina Scapolla
  • Department of Biophysical and Electronic
    Engineering
  • scapolla_at_unige.it

LisbonMarch 19-22, 2007
2
Outline
  • Learning materials and tools on Electronics
  • Analog Electronics
  • Electronics for telecommunications
  • Digital Electronics
  • Introduction to Electronic Systems
  • Simulators
  • The Remote Laboratory

3
Learning materials and tools on Electronics
4
ANALOG ELECTRONICS
Pedagogical level and target Fundamentals of analog electronic circuits analysis and design. Fundamentals of analog electronic circuits analysis and design.
Topics Diode used in discrete components circuits rectifier, zener, varactor, light emitter, light detector, solar cell, etc. Bipolar transistor used in discrete components circuits bias circuits, large and small signal analysis, models and equivalent circuits, frequency response. Linear and non linear circuit design criteria, switching applications. Field effect transistors their usage and classification, bias, large and small signal analysis, models and equivalent circuits, frequency response. Applications and linear/non linear circuit design criteria. Multistage circuits, block analysis of complex structures, operational amplifiers. Analog integrated circuits, design methodologies, circuits with operational amplifiers, conditioning of linear analog signals, non linear functions, astable operations, signals generation, etc. Thermal analysis of power circuits. Overview of analog complex circuits design. Diode used in discrete components circuits rectifier, zener, varactor, light emitter, light detector, solar cell, etc. Bipolar transistor used in discrete components circuits bias circuits, large and small signal analysis, models and equivalent circuits, frequency response. Linear and non linear circuit design criteria, switching applications. Field effect transistors their usage and classification, bias, large and small signal analysis, models and equivalent circuits, frequency response. Applications and linear/non linear circuit design criteria. Multistage circuits, block analysis of complex structures, operational amplifiers. Analog integrated circuits, design methodologies, circuits with operational amplifiers, conditioning of linear analog signals, non linear functions, astable operations, signals generation, etc. Thermal analysis of power circuits. Overview of analog complex circuits design.
Materials available Type Quantity
Tutorials PDF, Power Point and Flash documents with audio (mainly in the format of SCORM-conformant products) about 50 hours of audio presentation (Italian)
Software Simulations Design and simulation of analog circuits with PSPICE 160 exercises
Remote experiments Pre-assembled circuits available BJT amplifier BJT switch BJT complementary symmetry stage Operational amplifier inverting amplifier Operational amplifier non inverting amplifier Operational amplifier integrator Operational amplifier differentiator ISILab
5
ELECTRONICS FOR TELECOMMUNICATIONS
Pedagogical level and target Fundamentals of electronic circuits/systems for telecommunications. Fundamentals of electronic circuits/systems for telecommunications.
Topics RF amplifiers. Oscillators. Mixer. RF filters. PLL. Synthesizer. Modulators and demodulators, modem. Structure of transmission and receiving systems. RF amplifiers. Oscillators. Mixer. RF filters. PLL. Synthesizer. Modulators and demodulators, modem. Structure of transmission and receiving systems.
Materials available Type Quantity
Tutorials PDF
Simulations Design and simulation of circuits with the COMMSYM simulator Available only inside the DIBE LAN
Remote experiments Pre-assembled circuits available Analysis of analog complex signals by FFT analyzer. Characterization of software defined radio receiver and DRM transmissions. Analysis of QPSK modulations in DVB satellite transmissions. Windows remote desktop
6
DIGITAL ELECTRONICS
Pedagogical level and target Fundamentals of digital system design Fundamentals of digital system design
Topics Analysis of simple logic gates Multiplexers and Demultiplexers Application of Boolean Algebra Arithmetic circuits Delays and Hazards Flip-Flops and Registers Counters and other sequential networks Introduction to Finite State Machines Design of finite state machines Design of FSM-based digital systems Micro-computer systems introduction to assembly programming Micro-computer systems assembly programming techniques Micro-computer systems parallel interfacing and interrupt handling Analysis of simple logic gates Multiplexers and Demultiplexers Application of Boolean Algebra Arithmetic circuits Delays and Hazards Flip-Flops and Registers Counters and other sequential networks Introduction to Finite State Machines Design of finite state machines Design of FSM-based digital systems Micro-computer systems introduction to assembly programming Micro-computer systems assembly programming techniques Micro-computer systems parallel interfacing and interrupt handling
Materials available Type Quantity
Tutorials
Simulations Design and simulation of digital circuits with DEEDS 60 projects
Remote experiments Pre-assembled circuits available Propagation delay of a gate Maximum clock frequency of a counter ISILab
7
INTRODUCTION TO ELECTRONIC SYSTEMS
Pedagogical level and target Introductive material providing general concepts on state of-the art digital and mixed signals systems Introductive material providing general concepts on state of-the art digital and mixed signals systems
Topics A/D D/A conversion and data acquisition. Power supplies, AC/DC and DC/DC converters. Microcontrollers and digital signal processors. Programmable logic devices (CPLD, FPGA). Field bus. A/D D/A conversion and data acquisition. Power supplies, AC/DC and DC/DC converters. Microcontrollers and digital signal processors. Programmable logic devices (CPLD, FPGA). Field bus.
Materials available Type Quantity
Tutorials PDF, Power Point and Flash documents with audio (mainly in the format of SCORM-conformant products) about 10 hours of audio presentation (Italian)
Simulations
Remote experiments Pre-assembled circuits available A/ D and D/A converters ISILab
8
DEEDSDigital Electronics Education and Design
Suite
A digital systems simulation tool
specifically designed for educational
applications
  • The Deeds suite is composed by three simulators
  • d-DcS Digital Circuit Simulator
  • d-FsM Finite State Machine Simulator
  • d-McE Microcomputer Board Emulator
  • http//www.esng.dibe.unige.it/Projects/Netpro/Deed
    s/index.htm

9
DEEDS The browsers
  • The browsers show a list of the assignments and
    a specific assignment.
  • Text and objects in the page can be active, i.e.
    associated to simulation functions.
  • The browser interacts with simulators, providing
    a true interaction between problems and
    experiments (e.g. by clicking on the schematics,
    the circuit is loaded in the Digital Circuit
    Simulator, and can be tested or modified)

10
DEEDS The d-DcS Digital Circuit Simulator
  • The d-DcS has been designed to be easy to use,
    while maintaining quasi-professional features
  • The user interface is intuitive
  • The choice of digital components is based on
    their logical function, not on commercial lines
  • Two simulation modes
  • Interactive AnimationIn the interactive
    animation mode the simulator processes input
    commands and displays output values
  • Timing diagram

11
DEEDS - The d-FsM Simulator
  • Finite state machines (FSM) are designed with
    Algorithmic State Machine (ASM) charts
  • Algorithms can be functionally tested (with a
    timing diagram), without circuit syntesis
  • A FSM produced with the this tool can be used as
    a component by the d-DcS
  • A FSM can also be exported in VHDL language, to
    allow reusing it in professional design tools

12
DEEDS the d-McE mC Emulator
  • The Microcomputer Board Emulator is based on an
    eight bits microprocessor, a RAM and ROM memory
    system and a parallel input/output port system
  • The 8-bit micro-processor is the DMC8 (a revised
    and simplified version of the well-known
    Z80-CPU)
  • The board in figure is a representation of a
    possible hardware implementation of the emulated
    microcomputer

13
DEEDS the d-McE mC Emulator (2)
  • The architecture of the Microcomputer Board is
    classical
  • The board interfaces with the external world
    through four input and four output parallel ports
  • Address and data busses are not available outside
    the board, but port control signals are available
    for possible extension of the ports
  • Clock, Reset and Interrupt signal are available

14
DEEDS the d-McE mC Emulator (3)
  • The Microcomputer Board is a component of the
    library of the d-DcS
  • A digital circuit, embedding one or more
    Microcomputers, can be simulated by the d-DcS
  • The embedded Microcomputer can be programmed with
    the d-McE tool.
  • This feature opens a whole world of
    state-of-the-art educational application

15
DEEDS the d-McE mC Emulator (4)
  • The Microcomputer Board Emulator allows to edit
    assembly code with syntax highlighting
  • Assembling, linking and loading operation are
    transparent to the user
  • The Microcomputer Board Emulator allows to debug
    the program step-by-step or in animation mode
  • The interactive visual debugger shows memory,
    registers and ports contents
  • The tool allows a full control of the
    microcomputer operations, including I/O
    operations

16
ISILab
  • Functionalities
  • Interactivity between users and measurement
    instruments.
  • Management of repeated sequence of data
    acquisition, computation and presentation.
  • Real-time feedback from the test bench
    (human-in-the-loop case).
  • Uniqueness of resources (instruments are real
    devices connected to specific systems under
    test).
  • Instruments synchronization, when more
    instruments are involved in a measurement.
  • Test-bench access control (exclusive access or
    multi-user concurrent access).
  • http//isilab-esng.dibe.unige.it

17
ISILab (2)
  • Current version (0.1)
  • Core engine in LabVIEW
  • GUIs are applets
  • Assignments are part of the experiments
  • Next version (0.2) will be available in few
    months
  • Totally based on web services
  • Use of workflows to define measures
  • Developed with the Web Services Resource
    Framework .NET
  • GUIs are ASP.NET web pages (AJAX technology will
    follow)
  • Assignments will be delivered via the LMS
  • A protoype is available at
  • http//netlab2-esng.dibe.unige.it/WSRFRemoteL
    ab/WebSite/

18
ISILab v. 0.2
19
ISILab (3)
  • Different circuits, present on the same
    workbench, share the same instrumentation.

20
ISILab - The front end of ISILab (v. 0.1)
21
Some links
  • ISILab http//isilab-esng.dibe.unige.it
  • A course on analog electronic (login guest)
    http//inginfo.aulaweb.unige.it/course/view.php?id
    5
  • DEEDS http//www.esng.dibe.unige.it/Projects/Netp
    ro/Deeds/index.htm
