Ch 21 Electrostatics

1
Ch 21 Electrostatics

• The study of the properties of stationary charges

2
Properties of Charge

• Fundamental Property of Matter
• Two types of charge
• positive
• negative
• Like charges repel
• Unlike charges attract
• Charge is quantized (distinct fundamental units)
• e 1.602 10-19 C
• Coulomb (C) is the SI unit of charge
• Law of Conservation of Charge The total charge
  of any isolated system is a constant

3
Charge Conservation
There are 92 protons on either side of this
nuclear reaction equation.
4
Charge Conservation Particle Physics
The decay of a neutral photon into and electron
and a positron (positively charge electron) in
GREEN !!!
5
Method of generating static charge

• Process of inducing a positive charge on a
  conducting sphere.
• Contact or induction on isolated (insulated)
  conductors

6
Material Behaviors

• Insulator - large effort required to move charges
  through material
• Examples wood, plastic, rubber, glass, dry air,
  vacuum
• Conductor - very little effort required to move
  charges through material
• Examples most metals, ionic solutions, plasmas
• Semi-conductor - intermediate effort required to
  move charges through material
• Examples germanium, silicon

7
Charge and Force
Insulators
Conductor and Inuslator
8
Coulombs Law (Force Law between charges)

• Charles Auguste Coulomb - 1785
• Force between two point charges is proportional
  to each charge
• Force between two point charges is inversely
  proportional to the distance separating them
• Force between charges obey the Law of
  Superposition (vector addition)

9
Coulombs Law (point Charges)
10
Example 1

• A positive 1.0 mC charge is located at the
  origin and a -0.3 mC charge is located at x
  2.0 cm. What is the force on the negative charge?

11
Example 2

• A positive 0.1 mC charge is located at the
  origin, a 0.2 mC charge is located at (0.0 cm,
  1.5 cm), and a -0.2 mC charge is located at (1.0
  cm, 0.0 cm). What is the force on the negative
  charge?

12
Determine the force between the negative charge
and each positive charge.
The force between charges 1 and 2.
13
The force between charges 3 and 2.
14
Determine the components of each force.
15
a
Determine the sum of the components of the forces.
Determine the resultant force
from x axis
16
Sample prob 21-3

• What is force between spheres
• b) Ground sphere A, then what is the force ?

17
Field

• Region of space influenced by some physical
  phenomena e.g., temperature, gravity, electric,
  magnetic behaviors

18
Electric Field

• Region of space where another charge would be
  influenced by a charge or distribution of charges
• Units of electric field is Newtons/Coulomb (N/C)
• Electric Field points away from positive charge
  and toward negative charge

19
Field of a point charge
20
Effect of a finite test charge on a conductor
