General Latent Variable Modeling Approaches to
Measurement Issues using Mplus

• Rich Jones jones_at_mail.hrca.harvard.edu
• Psychometrics Workshop
• Friday Harbor, San Juan Island, WA
• August 24, 2005

2
Overview

• Part 1
• IRT overview
• DIF overview
• Part 2
• IRT via Factor Analysis
• Factor analysis and general latent variable
  models for measurement issues using Mplus
• Limitations of Mplus approach
• Part 3
• Applied Example
• Part 4 (time permitting)
• Bells and Whistles
• Discussion

3
Part 1a

• IRT overview

4
Semantics

• Multiple Fields, Conflicting Language
• Educational Testing, Psychological Measurement,
  Epidemiology Biostatistics, Psychometrics
  Structural Equation Modeling
• Characteristics of People
• ability, trait, state, construct, factor level,
  item response
• Characteristics of Items
• difficulty, severity, threshold, location
• discrimination, sensitivity, factor loading,
  measurement slope

5
Key Ideas of IRT

• Persons have a certain ability or trait
• Items have characteristics
• difficulty (how hard the item is)
• discrimination (how well the item measures the
  ability)
• (I wont talk about guessing)
• Person ability, and item characteristics are
  estimated simultaneously and expressed on unified
  metric
• Interval-level measure of ability or trait
• Used to be hard to do

6
Some Things You Can Do with IRT

• Refine measures
• Identify biased test items
• Adaptive testing
• Handle missing data at the item level
• Equate measures

7
Latent Ability / Trait

• Symbolized with qi or hi
• Assumed to be continuously, and often normally,
  distributed in the population
• The more of the trait a person has, the more
  likely they are to ...whatever...(endorse the
  symptom, get the answer right etc.)
• The latent trait is that unobservable,
  hypothetical construct presumed to be measured by
  the test (assumed to cause item responses)

8
Item Characteristic Curve

• The fundamental conceptual unit of IRT
• Relates item responses to ability presumed to
  cause them
• Represented with cumulative logistic or
  cumulative normal forms

9
Item Response Function
P(yij1qi) Faj(qi-bj)
10
(No Transcript)
11
Example of an Item Characteristic Curve High
Ability
12
Example of an Item Characteristic Curve Low
Ability
13
Example of an Item Characteristic Curve Item
Difficulty
14
Example of two ICCs that Differ in Difficulty
15
Example of an Item Characteristic Curve Item
Discrimination
16
Example of two ICCs that Differ in Discrimination
17
Item Response Function
18
Extra Creditone way to get estimates of
underlying ability
Remember Bayes Theorem
19
Extra Creditone way to get estimates of
underlying ability
Bayes modal estimates of latent ability
(h) (modal a posteriori MAP estimates)
20
Part 1b

• DIF Overview

21
Identify Biased Test ItemsDifferential Item
Functioning (DIF)

• Differences in likelihood of error to a given
  item may be due to
• group differences in ability
• item bias
• both
• IRT can parse this out
• Item Bias Differential Item Function
  Rationale
• Most workers in IRT identify DIF when two groups
  do not have the same ICC

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Part 2

• IRT and Factor Analysis

26
IRT and Factor Analysis

• IRT describes a class of statistical models
• IRT models can be estimated using factor analysis

• Appropriate routines for ordinal dependent
  variables (tetrachoric/polychoric correlation
  coefficients)
• Factor analysis models can be extended in very
  general ways using structural equation modeling
  techniques / software

27

• www.statmodel.com
• Used to be LISCOMP, owes lineage to LISREL
• Does just about everything other continuous
  latent variable / structural equation software
  implement (LISREL, EQS, AMOS, CALIS)
• Plus, very general latent variable modeling
• Continuous latent variables (latent traits)
• Categorical latent variables (latent classes,
  mixtures)
• Missing data
• Estimation with data from complex designs
• Expensive, demo version available

28
Mplus approach to IRT Model

• One or Two-parameter IRT models (not explicit)
• Discrimination Factor loadings/slopes
• Difficulty Item thresholds
• Two estimation methods
• Weighted Least Squares
• Limited information
• Multivariate probit (theta or delta
  parameterization)
• Latent response variable formulation (Assume
  underlying continuous variables)
• Maximum Likelihood
• Full information
• Multivariate logistic
• Conditional probability formulation
• More experience, fit statistics with WLS
• Some model types require ML, others WLS

29
Latent Response Variable Formulation (picture)
30
Latent Response Variable Formulation (words)

• Assume observed ordinal (dichotomous) y has
  corresponding underlying continuous normal but
  unobservable (latent) form (y)
• When a persons value for y exceeds some
  threshold (t), y1 is observed, otherwise, y0 is
  observed
• Analysis is focused on relationship among the y
  and estimating the thresholds (t)

31
Latent Response Variable Formulation (equation)
32
Conditional ProbabilityFormulation
33
Factor Analysis Model
34
Factor Analysis Model
35
Factor Analysis with Covariates
36
Multiple Group CFA
37
Multiple Group (MG) MIMIC
38
MIMIC and MG-MIMIC Model

• Disadvantages
• Not so good for factor score generation
• Not exactly the IRT model
• different conceptualization of NU-DIF
• Some work to get as bs and standard errors
• Relatively little experience / literature in
  field
• Confusing / overlapping measurement noninvariance
  literature from SEM field

39
MIMIC and MG-MIMIC Model

• Advantages
• Can be easy to estimate, good for modeling
• No need to equate parameters
• No data re-arrangements required, missing data
  tricks
• Simultaneous analysis/evaluation of all items and
  possible sources of model mis-fit (including
  potential DIF or bias)
• Multiple independent variables (with DIF)
• Ys and Xs can be categorical or continuous
• Anchor items not necessary, but...
• Embed in more complex models
• Complimentary measurement noninvariance
  literature from SEM field

40
MIMIC Model how to do it
From within STATA using runmplus.ado
runmplus y1-y4 x1, categorical(y1-y4)
type(meanstructure) model(eta by y1-y4 eta_at_1
eta on x1 y1 on x1)
Mplus syntax file
Title MIMIC model Data File is
__000001.dat Variable Names are y1 y2 y3 y4
x1 categorical y1-y4 Analysis
type meanstructure MODEL eta by
y1-y4 eta_at_1 eta
on x1 y1 on x1
41
Some Applied Examples and Technical Articles

• Muthén, B. O. (1989). Latent variable modeling in
  heterogeneous populations. Meetings of
  Psychometric Society (1989, Los Angeles,
  California and Leuven, Belgium). Psychometrika,
  54(4), 557-585.
• McArdle, J., Prescott, C. (1992). Age-based
  construct validation using structural equation
  modeling. Experimental Aging Research, 18(3),
  87-116.
• Gallo, J. J., Anthony, J. C., Muthén, B. O.
  (1994). Age differences in the symptoms of
  depression a latent trait analysis. Journals of
  Gerontology, 49(6), 251-264.
• Salthouse, T., Hancock, H., Meinz, E.,
  Hambrick, D. (1996). Interrelations of age,
  visual acuity, and cognitive functioning. Journal
  of Gerontology Psychological Sciences, 51B(6),
  P317-P330.
• Grayson, D. A., Mackinnon, A., Jorm, A. F.,
  Creasey, H., Broe, G. A. (2000). Item bias in
  the Center for Epidemiologic Studies Depression
  Scale effects of physical disorders and
  disability in an elderly community sample. The
  Journals of Gerontology. Series B, Psychological
  Sciences and Social Sciences, 55(5), 273-282.
• Jones, R. N., Gallo, J. J. (2002). Education
  and sex differences in the Mini Mental State
  Examination Effects of differential item
  functioning. The Journals of Gerontology. Series
  B, Psychological Sciences and Social Sciences,
  57B(6), P548-558.
• Macintosh, R., Hashim, S. (2003). Variance
  Estimation for Converting MIMIC Model Parameters
  to IRT Parameters in DIF Analysis. Applied
  Psychological Measurement, 27(5), 372-379.
• Rubio, D.-M., Berg-Weger, M., Tebb, S.-S.,
  Rauch, S.-M. (2003). Validating a measure across
  groups The use of MIMIC models in scale
  development. Journal of Social Service Research,
  29(3), 53-68.
• Fleishman, J. A., Lawrence, W. F. (2003).
  Demographic variation in SF-12 scores true
  differences or differential item functioning? Med
  Care, 41(7 Suppl), III75-III86.
• Jones, R. N. (2003). Racial bias in the
  assessment of cognitive functioning of older
  adults. Aging Mental Health, 7(2), 83-102.

42
Part 3

• An Applied Example

Jones, R. N. (2003). Racial bias in the
assessment of cognitive functioning of older
adults. Aging Mental Health, 7(2),
83-102. Acknowledgement R03 AG017680
43
Example Racial bias in TICS (HRS/HEAD)

• Nationally representative, very large sample
  (N15,257)
• Over-sample of Black or African-Americans
  (N2,090)
• Assessment of cognition
• Very adequate assessment of SES (education,
  income, occupation)

44
Objective

• Evaluate the extent to which item level
  performance is due to test-irrelevant variance
  due to race (White, non-Hispanic vs. Black or
  African-American participants)
• Control for main and potentially differential
  effects of background variables
• Sex, Age
• Educational attainment
• Household income, occupation groups
• Health Conditions and Health Behaviors

45
TICS/AHEAD Measure of Cognitive Function (Herzog
1997)

• Points
• Orientation to time (weekday, day, month, year) 4
• Name President, Vice-President 2
• Name two objects (cactus, scissors) 2
• Count Backwards from 20 1
• Serial Sevens 5
• Immediate recall (10 nouns) 10
• Delayed free-recall (10 nouns, 5 min delay) 10

46
Background Variables

• Sex
• Age (9 groups)
• Education (6 groups)
• Household Income (5 groups)
• Highest household occupation (8 groups)

• Health Conditions (HBP, DM, heart, stroke,
  arthritis, pulmonary, cancer)
• Health Behaviors (current smoking, drinking
  three groups)

47
(No Transcript)
48
(No Transcript)
49
Results

• All items show DIF by race, some by sex, age,
  education
• Effect of covariates (age, occupation, income,
  smoking status) significantly different across
  racial group
• Greater variance in latent cognitive function for
  Black or African-American participants
• No significant race difference in mean latent
  cognition by race after adjusting for measurement
  differences

Jones. Aging Ment Health, 2003 783-102.
50
Differences in Underlying Ability between Whites
and African Americans

• 60 is due to measurement differences (DIF, item
  bias)
• 12 is due to main effect of background variables

• 7 is due to structural differences (i.e.,
  interactions of group and background variables)
• What remains (about .2 SD) is not significantly
  different from no difference

Jones. Aging Ment Health, 2003 783-102.
51
Differences in Underlying Ability ignoring
measurement bias
Jones. Aging Ment Health, 2003 783-102.
52
Differences in Underlying Ability after
controlling for measurement bias
Jones. Aging Ment Health, 2003 783-102.
53
Differences in Underlying Ability after
controlling for measurement biasinteraction with
age group
Jones. Aging Ment Health, 2003 783-102.
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
Model Fit / Parsimony

• Model fitting accomplished more than shifting
  group differences in mental status to item-level
• New model provides greater fit to observed data
  using fit statistics that reward model parsimony

58
Part 4

• Bells and Whistles
• Discussion

59
Latent Growth Model
60
Multiple Indicator Latent Growth Model
61
Measurement Mixture Models
62
(No Transcript)
63
(No Transcript)
64
Part 4b

• Discussion
