Title: Fig. 1.10 A midline Post-contrast Sagittal T1 Weighted MRI


1
Identify anatomical structures 1 - 24
18
19
17
20
21
16
22
15
23
Fig. 1.10 A midline Post-contrast Sagittal T1
Weighted MRI
2
1. Scalp fat 2. Bone 3. Inferior sagittal
sinus 4. Corpus callosum 5. Internal cerebral
vein 6. Vein of Galen 7. Superior sagittal
sinus 8. Parietal lobe 9. Occipital lobe 10.
Straight sinus 11. Vermis 12. IV ventricle 13.
Cerebellar tonsil 14. Cervical cord 15.
Medulla 16. Pons 17. Midbrain 18. Mass intermedia
of thalamus 19. Anterior III ventricle 20. Optic
chiasm 21. Pituitary gland 22. Sphenoid sinus 23.
Nasopharynx 24. Frontal lobe
18
19
17
20
21
16
22
15
23
Fig. 1.10 A midline Post-contrast Sagittal T1
Weighted MRI
3
3
1
Identify anatomical structures 1 - 8
Fig. 1.11. Coronal Section of the Brain at the
level of IV Ventricle Post Contrast Coronal T1
Weighted MRI
4
3
1
1. Cerebellar tonsil 2. Cerebellar hemisphere 3.
IV ventricle 4. Superior vermis 5. Tentorium 6.
Posterior temporal lobe 7. Choroid plexus within
lateral ventricle 8. Posterior frontal lobe
Fig. 1.11. Coronal Section of the Brain at the
level of IV Ventricle Post Contrast Coronal T1
Weighted MRI
5
2
3
4
8
11
10
Identify anatomical structures 1 - 12
12
Fig. 1.12. Coronal Section of the Brain at the
level of Pituitary gland Post Contrast Coronal T1
Weighted MRI
6
2
3
4
1. Frontal lobe 2. Corpus callosum 3. Frontal
horn 4. Caudate nucleus 5. III ventricle 6. Optic
nerve 7. Pituitary stalk 8. Pituitary gland 9.
Internal carotid artery 10. Cavernous sinus 11.
Sphenoid sinus 12. Nasopharynx
8
11
10
12
Fig. 1.12. Coronal Section of the Brain at the
level of Pituitary gland Post Contrast Coronal T1
Weighted MRI
7
Identify anatomical structures 1 - 5
Fig. 1.13. Coronal Section of the Brain at the
level of the orbits. Post Contrast Coronal T1
Weighted MRI.
8
1. Frontal lobe 2. Orbital Fat 3. Globe 4. Nasal
Cavity 5. Maxillary Sinus
Fig. 1.13. Coronal Section of the Brain at the
level of the orbits. Post Contrast Coronal T1
Weighted MRI.
