MAGNETIC HYDROGEN PRODUCTION THROUGH INDIRECT
ELECTROLYSIS USING MAGNETIC INDUCTION BY CHRIS
HUNTER WASILLA, ALASKA CREATED THIS 18th DAY OF
MARCH OF THE YEAR 2006
2
THE OPERATION OF MAGNETISM IN A COIL WILL NOW BE
EXPLAINED AND DIAGRAMED WITH PICTURES. ALL
ILLUSTRATIONS CREATED BY CHRIS HUNTER, AND
COMPILED IN MICROSOFT PAINT FOR USE IN THIS
PRESENTATION.
3
A WIRE WITH ELECTRICITY PASSING THROUGH IT WILL
MAKE A MAGNETIC FIELD, SEE ILLUSTRATION BELOW.
4
The magnetic field surrounding a wire that has
power flowing through it (linear wire), the field
or magnetic flux rotates, like revolutions of a
wheel. See illustration below
5
NOW, WE TAKE THIS SAME WIRE, AND STRING OUT IN A
STRAIGHT LINE, AND LOOP IT BACK PARALLEL TO
ITSELF, AND OBSERVE THE MAGNETIC FLUX.
6
IN THIS VIEW, A CROSS SECTION OF THE WIRE SHOWS
THE EMF (ELECTRO-MAGNETIC FIELD/ FLUX) AROUND THE
WIRE.
7
THIS VIEW SHOWS THE RELATIONSHIP OF THE WIRE
LOOPED BACK NEXT TO ITSELF PARALLEL WITH EMF
SHOWN WITH CROSS SECTION OF WIRE.
8
THIS NEXT ILLUSTRATION SHOWS A PRIMARY COIL
ENERGIZED, THE POWER FLOW FROM THE PRIMARY COIL
WITH THE EMF FLOW. IT ALSO DEPICTS THE FLOW OF
EMF AND OF THE ENERGY IN THE SECONDARY COIL UPON
ENERGIZING THE PRIMARY COIL. IN THE NEXT
ILLUSTRATION, THE PRIMARY COIL IS CONSTANTLY
ENERGIZED WITH ONE POLARITY. IT IS OF NOTE THAT
THE POWER FLOW, AND EMF IN THE SECONDARY ARE
MIRRORED, EXACT OPPOSITE OF THE POWER FLOW AND
EMF OF THE PRIMARY COIL. NEXT ILLUSTRATION
FOLLOWS.
9
(No Transcript)
10
THIS NEXT ILLUSTRATION SHOWS THAT AFTER THE
PRIMARY COIL IS CHARGED, AND THEN POWER IS CUT
OFF, THE SECONDARY COILS EMF AND POWER FLOW
SWITCH TO REPRESENT THE EXACT OF WHAT THE PRIMARY
COIL HAD FOR NOT ONLY FIELD STRENGTH, BUT
VOLTAGE, AND FLOW OF BOTH EMF AND ENERGY. AS
IN MAGNETS, LIKE POLARITY REPELS, AND OPPOSITES
ATTRACT. IN TRANSFORMER TYPE SETUP, THE POWER OF
BOTH THE ELECTRICAL ENERGY EMF FLOWS DIRECTLY
OPPOSE EACH OTHER IN MIRRORED EXACTING OPPOSITE
PATTERNS, RESPECTIVELY.
11
(No Transcript)
12
NOW FOR THE DESIGN OF THE COILS IN OPERATION FOR
THE HYDROGEN GENERATOR. THE NEXT ILLUSTRATION
SHOWS AN ELECTRICAL SCHEMATIC OF THE COILS THAT
WILL BE WOUND AROUND A 6-11/16 INCH DIAMETER PIPE
THAT IS 18 INCHES LONG. THE NUMBER OF COILS WILL
BE DISCUSSED LATER. FOR NOW, THE OPERATION OF
SUCH COILS ARE GOING TO DISCUSSED HERE.
13
THIS NEXT ILLUSTRATION IS AN ELECTRICAL SCHEMATIC
OF THE HYDROGEN GENERATOR. NOT IN THE SCHEMATIC
ARE DC PULSE GENERATOR, MOSFET SWITCHING
MODULE, POWER SOURCE, OUTPUT TRANSFORMER, AND
PIPE.
14
(No Transcript)
15
THE NEXT ILLUSTRATIONS SHOW THE ELECTRICAL POWER
FLOW, AND THE EMF POWER FLOW. THERE IS ALSO A
BIT OF MATH INVOLVED TO GET THE DESIRED
FREQUENCIES. FOR NOW, JUST THE FLOW OF OPERATION
IN THE COIL CIRCUITS WILL BE THE FOCUS.
16
IN THE FIRST ILLUSTRATION THAT FOLLOWS, THE POWER
TO THE PRIMARY COIL IS ENERGIZED, AND POWER IS ON
CONSTANT IN ONE DC POWER DIRECTION. THE EMF AND
ENERGY FLOWS OF COILS 2, 3 4 ALL OPPOSE EACH
OTHER, AND THE ELECTRICAL FLOWS MOVE SAME
DIRECTION AS THE EMF.
17
(No Transcript)
18
IN THE NEXT ILLUSTRATION, THE POWER TO THE
PRIMARY CIRCUIT IS NOW TURNED OFF, AND THE
INSTANTANEOUS REACTION IN THE 2ND THROUGH 4TH
STAGE COILS IS OBSERVED.
AFTER THIS NEXT ILLUSTRATION, THERE WILL BE A
COMPARISON OF THE 2 POWER FLOWS TO ALLEVIATE ANY
CONFUSION.
19
(No Transcript)
20
NOW TO COMPARE FIRST, THE POWER ON, OBSERVE
POWER FLOW. NEXT, THE POWER OFF, OBSERVE POWER
FLOW.
21
POWER IS ON, OBSERVE POWER FLOW OF THE EMF.
22
POWER IS OFF, OBSERVE POWER FLOW OF THE EMF.
23
NOW THAT THE PRINCIPLES OF POWER FLOW AND
REVERSAL OF SUCH ARE THOROUGHLY EXAMINED, THE
NEXT SECTION DEALS WITH POWER AMPLIFICATION
THROUGH THE USE OF THE FLOW AND REVERSAL OF SUCH
AT HIGH SPEED AND INTENSITY TO AMPLIFY THE
EFFECTS INSIDE THE MAGNETIC FIELD. BUT FIRST
SOME MATH, TO SMOOTH OUT THE ROUGH EDGES.
24
PULSE STAGING EACH PULSE IS AN ELECTRICAL AND
MAGNETIC PULSE, AS EACH PULSE HAPPENS, THE EXACT,
AND OPPOSITE EMF PULSE IS EXPERIENCE IN BOTH THE
PREVIOUS COIL AND THE NEXT COIL. LOOKIG AT ONLY
THE NEXT COIL SCENERIO SEQUENCES 1ST PULSE INTO
PRIMARY GENERATES 2 PULSES IN SECONDARY. THE 2
PULSES IN THE SECONDARY GENERATE 2 PULSES FOR
EACH PULSE OF THE SECONDARY IN THE 3RD COIL
MAKING 4 PULSES IN THE 3RD COIL. THE 3RD COIL
NOW HAS 4 PULSES THAT FOR EACH PULSE IN THE 3RD
COIL, INDUCE 2 PULSES EACH IN THE 4TH COIL,
MAKING 8 PULSES OF THE 4TH COIL. SO THE RESULTS
ARE DEPICTED...
25
THE STAGING OUTPUT IS SIMPLE, AND IS CALCULATED
EXPONENTIALLY. NOW THE REVERSE OF POWER FLOW
ALSO OCCURS IN THE PREVIOUS COILS DOWNWARD, AND
THE PULSES ADDED TO EACH ARE IDENTICAL, AND
FURTHER ADDS TO THE OUTPUT FREQUENCY. FOLLOW
ALONG ON THE NEXT FEW PAGES.
26
NOW THE INPUT PULSE OUTPUT GENERATED 15 TOTAL
PULSES. THE FEEDBACK PULSES THAT MIRROR THE
REFLECTED INPUT/OUTPUT PULSES IN THE EXACT
OPPOSITE FLOW OF EACH GENERATE ANOTHER 21 PULSES
ON FEEDBACK ALONE!
FOLLOW ALONG THE 1ST COIL ENERGIZED, AND
GENERATED 1 PULSE IN ITSELF, AND ALSO GENERATED 1
PULSE IN THE 2ND COIL. 1ST COIL DE-ENERGIZED,
AND THE 2ND COIL GENERATED THE EXACT OPPOSITE
PULSE. NOW THIS PULSE IS ALSO MIRRORED IN THE
1ST COIL WHILE IN THE OFF STATE. THIS STATE OF
OFF OCCURS BETWEEN THE ON PULSES OF POWER
THAT THE 1ST COIL IS RECEIVING. MORE..
27
NOW THE 2ND COIL GENERATED 2 PULSES AS A DIRECT
INDUCTION RESULT OF THE 1ST PULSE OF THE FIRST
COIL. THESE 2 PULSES ARE TRANSFERRED NOT ONLY
INTO THE 3RD COIL, BUT THE FIRST COIL AS WELL.
THE FIRST COIL GETS 1 PULSE RETURN, BECAUSE IT IS
THE ENERGIZING MOTIVE FORCE AND IS THEREFORE THE
ONLY COIL TO RECEIVE EXTERNAL POWER.
SO THE 2ND COIL GENERATED 2 PULSES, THE 3RD MADE
4 PULSES, AND THE 4TH MADE 8. NOW EACH OF THESE
PULSES HAS A REFLECTION PULSE OF EXACTING
OPPOSITE INDUCTION BACK INTO THE PREVIOUS COILS
IN EXACTING OPPOSITION. EVERY ACTION HAS AN
EQUAL AND OPPOSITE REACTION
28
THE RESULTS OF SUCH AN OPPOSING REACTION CHAIN OF
EVENTS ARE SUCH 4TH 8 REVERSAL PULSES, INTO THE
3RD, WHICH FOR EVERY PULSE THERE IS 2 PULSES, SO
THE 3RD HAS 16 PULSES, AND THE SECOND HAS 32
PULSES, AND THE FIRST RECEIVES A HIGH SNAPPING 64
PULSES.
HOW CAN THIS BE? 1 PULSE INPUT AND
GETTING 15643281 EQUALLING A WHOPPING 120
PULSES WITH A SINGLE PULSE INPUT!!! HOW IS IT
SO? RE-READ THE PULSE TRANSFER OF THIS, AND TRY
AGAIN FOR YOURSELF. THE 1 IS FOR THE
ORIGINATION PULSE REFLECTION.
29
(No Transcript)
30
STILL BAFFLED?
OK NOW LOOK AT IT LIKE A CHILDS
TEETER-TOTTERPUSH DOWN ON ONE SIDE, AND IT LIFTS
ON THE OTHER, THE EXACTING OPPOSITE HAPPENS WHEN
THE OTHER SIDE IS PUSHED.
MORE STILL TO COME.
31
NOW WE CONNECT THE COILS TOGETHER, TO AMPLIFY THE
MAGNETIC EFFECTS AND ENERGY TRANSFER BETWEEN THE
COILS.
THE FOLLOWING ILLUSTRATION SHOWS THE CIRCUIT
COILS, AND ALSO SHOWS THE TERMINALS OF THE COILS
LABELED WITH LETTERS. AT THE BOTOM IS THE COIL
NUMBER AND TERMINAL NUMBER. THEY ARE CONNECTED
TOGETHER IN THE POWER SEQUENCE TO TRANSFER ENERGY
AROUND. THIS ALSO HAS THE POWER FROM EACH COIL
FEEDING THE ELECTRICAL POWER INTO THE NEXT AND
PREVIOUS COIL BUT ONLY AS THE FLOW WILL ALLOW.
MORE.
32
THE CONNECTIONS ARE LABELED, AND THE OUTPUTS ARE
SHOWN. IT IS ON THE DISCHARGE CYCLE, SO TAKE A
FEW MINUTES, AND OBSERVE THE POWER FLOW OF
ELECTRICAL POWER COMING OUT OF THE COILS AND INTO
THE CONNECTION T AT THE BOTTOM FOR EVERY
CONNECTION. NOW REVERSE THE FLOW MENTALLY AND
FOLLOW IT BACK. THE WIRING WORKS BOTH WAYS.
ILLUSTRATION NEXT...
33
(No Transcript)
34
NOW FOR THE OUTPUT FROM THE CONNECTION TREE
THE CONNECTION TREE OUTPUTS LEAD INTO YET ANOTHER
COIL, BUT THIS COIL IS OF A REGULAR TRANSFORMER.
THE POWER FLOWING BACK AND FORTH FROM THE
CONNECTION TREE IS SUCH THAT IS IS ALREADY
ALTERNATING CURRENT, AND SUCH THAT THE OUTPUT OF
THIS TRANSFORMER WILL ALSO BE ALTERNATING CURRENT
OR AC POWER.
THE NEXT ILLUSTRATION DEPICTS THE POWER OUTPUT
FROM THE COILS INTO THE TRANSFORMER.
35
(No Transcript)
36
NOW FOR WHAT YOU REALLY WANTED
HYDROGEN
37
TWO DISSIMILAR METALS IN AN ELECTROLYTE PRODUCE
AN ELECTRIC CHARGE. HMMEVER HEAR THAT? ME
TOO.BUT FOR ME IT REALLY MEANS SOMETHING
ELSE. BUT WHAT? THAT IS FOR YOU TO DECIDE FOR
YOURSELF. I WILL PRESENT ONE MEANING.
38
IN CONVENTIONAL ELECTROLYSIS, THERE ARE A GREAT
NUMBER OF LIMITING FACTORS TO THE EFFECTIVENESS
OF THE HYDROGEN AND OXYGEN OUTPUT PRODUCTION
LEVELS. THE FIRST OF THESE IS THE SURFACE
AREA. THE SURFACE FOR WHICH TO CONDUCT THE
ELECTRICAL POWER INTO THE WATER IS LIMITED TO THE
POWER POTENTIAL OF YOUR POWER SOURCE. IF YOU USED
A SURFACE OF 6 SQUARE INCHES PER ELECTRODE, AND
YOU HAD 2 OF THESE, YOU WOULD HAVE THE TOTAL OF
24 SQUARE INCHES WORTH OF SURFACE AREA WITH WHICH
TO WORK.
39
THAT SURFACE WHICH IN CONVENTIONAL SYSTEMS IS
USUALLY FLAT AND SMOOTH HAS A LIMIT. THAT LIMIT
IS FIRST BY SIZE, AND THEN BY CONDUCTIVITY DURING
PRODUCTION. THE CONDUCTIVITY DURING PRODUCTION
DROPS SEVERELY DUE TO THE FORMATION OF GAS
BUBBLES. THESE GAS BUBBLES ARE NOT CONDUCTIVE,
AND TEND TO COMPLETELY COAT THE SURFACE OF THE
ELECTRODE. ONE COULD EASILY SHAKE THE
ELECTRODES TO GET THE BUBBLES OFF, BUT THE ENERGY
TO DO SO IS IMMENSE, AND NOT WORTH IT.
40
SO ONE IS LEFT WITH HAVING TO FEED MORE
ELECTRICAL POWER INTO THE UNIT TO ACCOMPLISH THE
TASK. THIS VOLTAGE AND AMPERAGE WILL CONTINUALLY
GO UPWARD TO KEEP THE GAS PRODUCTION LEVELS
UP. THIS IS A SEVERE WASTE OF POWER POTENTIAL TO
MAKE HYDROGEN FOR AN ENERGY STORAGE MEDIUM, TO
RE-GENERAE MORE POWER.
WHAT IF I SUGGESTED A WAY TO INCREASE THE SIZE OF
THE ELECTRODE SURFACE AREA TO GREATER THAN THE
SURFACE AREA OF A FOOTBALL FIELD IN LESS THAN 2
CUBIC INCHES OF SPACE?
41
THE SURFACE AREA CAN BE MAJORLY INCREASED BYT
UTILIZING 2 DISSIMILAR METALS, BUT IN THE FORM OF
A SALT. THIS HAS THE ADVANTAGE OF COMPLETELY
FILLING A CONTAINER WITH THE ELECTRODE, AND THEN
WHEN WATER IS ADDED, THE ELECTRODE SOAKS UP THE
WATER LIKE A SPONGE, AND HAS ELECTRODE SURFACE OF
DISSIMILARITY THROUGHOUT THE ENTIRE CONTENTS.
THIS EFFECTS HAVING TWO ELECTRODES, OF DISSIMILAR
METALS IN WATER, AND USING A PULSED MAGNETIC COIL
AROUND THE OUTSIDE, EFFECTS THE ABILITY TO
GENERATE HYDROGEN WITHOUT A GASEOUS RESISTIVE
BARRIER TO OVERCOME. THE PRESSURE OF THE WATER
AND GRAVITY WILL PUSH INTO ANY PLACE OF LOWER
PRESSURE AND THE BUBBLES WILL RISE UP.
42
THE RISING GASSES WILL OBVIOUSLY HAVE TO BE
CAPTURED COMING OFF THE TOP, AND UTILIZED, OR
COMPRESSED AND STORED FOR LATER USE. THE ABILITY
TO RAISE THE SURFACE AREA INSIDE THE CONTAINER IS
KEY TO THE SUCCESS OF THIS METHOD OF HYDROGEN
PRODUCTION. NO OTHER MEANS OF MAKING A LARGER
SURFACE AREA HAVE YET TO BE ESTABLISHED, AND THUS
WILL ALLOW FOR THE SURFACE AREA TO CONTINUALLY BE
FAR SUPERIOR THAN THAT OF ANY AND ALL
CONVENTIONAL ELECTROLYSIS DESIGNS.
43
NOW IN THE TRANSFORMER AS DESCRIBED IN
AFOREMENTIONED OPERATION OF THE 4 STAGES OF
COILS, THE CORE IS NOT A SOLID CORE. THE CORE IS
WOUND AS AN AIR CORE FOR WHICH PROVISIONS OF A
CONTAINMENT VESSEL FOR THE WATER AND METALLIC
SALTS IS THUS CONTAINED.
WATER IS GENERALLY HELD TOGETHER BY 2 ELECTRIC
BONDS. EACH BOND HOLDS THE OXYGEN MOLECULE TO 1
HYDROGEN PER BOND. THE POWER POTENTIAL OF THIS
BOND IS YET TO BE CAPTURED. THE BOND IS EASILY
DISTURBED BY INTRODUCTION OF ELECTRICITY DIRECTLY
BY MEANS OF CONDUCTION TO SEPARATE THE HYDROGEN
FROM THE OXYGEN.
44
I SINCERELY HOPE THAT THIS HAS BEEN INFORMATIVE
AND HELPFUL. IF YOU HAVE ANY QUESTIONS, DO NOT
HESITATE TO CALL, WRITE, OR E-MAIL ME. MY
CONTACT INFORMATION FOLLOWS
CHRIS HUNTER MAILING 3150 SOUTH STORYBOOK CIRCLE
WASILLA, ALASKA, 99654 PHONE
[phone] (24 HOUR MESSAGE) ALASKA
STANDARD E-MAIL ALASKASTAR2000_at_HOTMAIL.COM
