Summarizing Variation Matrix Algebra

1
Summarizing VariationMatrix Algebra Mx
Michael C Neale PhDVirginia Institute for
Psychiatric and Behavioral GeneticsVirginia
Commonwealth University19th International
workshop on Methodology Twin and Family Studies
2
Overview

• Mean/Variance/Covariance
• Calculating
• Estimating by ML
• Matrix Algebra
• Normal Likelihood Theory
• Mx script language

3
Computing Mean

• Formula E(xi)/N
• Can compute with
• Pencil
• Calculator
• SAS
• SPSS
• Mx

4
One Coin toss
2 outcomes
Probability
0.6
0.5
0.4
0.3
0.2
0.1
0
Heads
Tails
Outcome
5
Two Coin toss
3 outcomes
Probability
0.6
0.5
0.4
0.3
0.2
0.1
0
HH
HT/TH
TT
Outcome
6
Four Coin toss
5 outcomes
Probability
0.4
0.3
0.2
0.1
0
HHHH
HHHT
HHTT
HTTT
TTTT
Outcome
7
Ten Coin toss
9 outcomes
Probability
0.3
0.25
0.2
0.15
0.1
0.05
0





Outcome
8
Fort Knox Toss

Infinite outcomes
0.5
0.4
0.3
0.2
0.1
0
0
1
2
3
4
-1
-2
-3
-4
Heads-Tails
De Moivre 1733 Gauss 1827
9
Dinosaur (of a) Joke

• Elk
• The Theory by A. Elk brackets Miss brackets.
  My theory is along the following lines.
• Host
• Oh God.
• Elk
• All brontosauruses are thin at one end, much
  MUCH thicker in the middle, and then thin again
  at the far end.

10
Pascal's Triangle
Probability
Frequency
1 1 1 1 2 1 1 3 3 1 1 4 6 4 1 1 5 10 10 5 1 1 6
15 20 15 6 1 1 7 21 35 35 21 7 1
1/1 1/2 1/4 1/8 1/16 1/32 1/64 1/128
Pascal's friend Chevalier de Mere 1654 Huygens
1657 Cardan 1501-1576
11
Variance

• Measure of Spread
• Easily calculated
• Individual differences

12
Average squared deviation
Normal distribution

xi
di
0
1
2
3
-1
-2
-3
Variance G di2/N
13
Measuring Variation
Weighs Means

• Absolute differences?
• Squared differences?
• Absolute cubed?
• Squared squared?

14
Measuring Variation
Ways Means

• Squared differences

Fisher (1922) Squared has minimum variance under
normal distribution
15
Covariance

• Measure of association between two variables
• Closely related to variance
• Useful to partition variance

16
Deviations in two dimensions
x














y



















17
Deviations in two dimensions
x
dx

dy
y
18
Measuring Covariation
Concept Area of a rectangle

• A square, perimeter 4
• Area 1

1
1
19
Measuring Covariation
Concept Area of a rectangle

• A skinny rectangle, perimeter 4
• Area .251.75 .4385

.25
1.75
20
Measuring Covariation
Concept Area of a rectangle

• Points can contribute negatively
• Area -.251.75 -.4385

1.75
-.25
21
Measuring Covariation
Covariance Formula Average cross-product of
deviations from mean
F E(xi - x)(yi - y)
xy
N
22
Correlation

• Standardized covariance
• Lies between -1 and 1

r F
xy
xy
2
2
F F
y
x
23
Summary
Formulae for sample statistics i1N observations
(Exi)/N
Fx E (xi - x ) / (N)
2
2
Fxy E(xi-x )(yi-y ) / (N)
r F
xy
xy
2
2
F F
x
x
24
Variance covariance matrix
Several variables
Var(X) Cov(X,Y) Cov(X,Z) Cov(X,Y)
Var(Y) Cov(Y,Z) Cov(X,Z) Cov(Y,Z)
Var(Z)
25
Variance covariance matrix
Univariate Twin Data
Var(Twin1) Cov(Twin1,Twin2)
Cov(Twin2,Twin1) Var(Twin2) Only
suitable for complete data Good conceptual
perspective
26
Conclusion

• Means and covariances
• Basic input statistics for Traditional SEM
• Easy to compute
• Can use raw data instead

27
Likelihood computation
Calculate height of curve
-1
28
Height of normal curve
Probability density function
x
N(xi)
0
1
2
3
-1
-2
-3
xi
N(xi) is the likelihood of data point xi for
particular mean variance estimates
29
Height of bivariate normal curve
An unlikely pair of (x,y) values
y
yi
x
xi
30
Exercises Compute Normal PDF

• Get used to Mx script language
• Use matrix algebra
• Taste of likelihood theory
