EHR Hardware

1
EHR RoadmapWebEx

• EHR Hardware

2
Presenter

• Margret Amatayakul
• RHIA, CHPS, CPHIT, CPEHR, FHIMSS
• President, Margret\A Consulting, LLC,
  Schaumburg, IL
• Consultant on the DOQ-IT Project for several
  QIOs
• Independent information management and
  systems consultant,
  focusing on EHRs and
  their value proposition
• Adjunct faculty College of St. Scholastica,
  Duluth, MN, masters program in health informatics
• Founder and former executive director of
  Computer-based Patient Record Institute,
  associate executive director AHIMA, associate
  professor Univ. of Ill., information services
  IEEI
• Active participant in standards development,
  HIMSS BOD, and co-founder of and faculty for
  Health IT Certification

3
Objectives

• Describe the purpose of understanding hardware
  requirements for EHR
• Compare and contrast various human-computer
  interfaces
• Identify hardware for user authentication
• Define different networking architectures and
  criteria for service evaluation
• Identify considerations for data management and
  storage

4
EHR Hardware

• Understanding
• Hardware (H/W) Requirements

5
Hardware Requirements

• Hardware inventory provides baseline for vendors
  to develop EHR price proposal
• Vendors often have hardware preferences to
  which they have developed their applications and
  know they work
• Vendors may require hardware certification
  if purchased separately

6
Hardware Preferences

• IT staff may have preferences based on past
  experience
• End users may have preferences based on
  familiarity or comfort
• Organizations may have preferred vendor
  relationships that ease cost

• Technology is continuously advancing, and so must
  IT staff skills
• Device standards make it easier to maintain
  equipment
• New applications, such as EHR, may require
  hardware not supported by present trading partner

7
Hardware Considerations

• Servers
• Database
• Application
• Terminal
• Domain
• Network
• E-mail
• Fax
• Others . . .
• Clients
• Workstations
• Desktops
• Notebooks/laptops
• Tablets
• PDAs

• Peripherals
• Keyboard
• Navigational devices
• Monitors
• Other input/output
• Printers
• Scanners
• Document
• Card
• Bar Code
• RFID
• Network
• Data Storage

8
EHR Hardware

• Human-Computer Interfaces
• (HCI)

9
a.k.a. User Input Devices

• Monitors
• High resolution
• Flat panel
• Touch screen
• Keyboards
• Ergonomic
• Liquid proof
• Navigation
• Wireless
• Tethered
• Foot controlled

• Workstation
• Personal computer
• Desktop
• Notebook/ laptop
• Tablet
• Slate
• Convertible
• PDA
• Cellular phone

10
Desktop vs. Tablet PCs

• Desktop PCs
• Require space for monitor and keyboard
• User position
• Patient position
• Some space issues can be overcome by
• COWs
• Suspended/flat panel monitors
• Special trays for keyboards
• Some issues of infection control
• Require log-on/log-off
• Always available
• Network connection
• Power
• Lower cost

• Tablet PCs
• Including
• Slate
• Convertibles
• Issues of
• Weight
• Heat
• Space
• Navigational precision
• Mobility
• Affords continuous log-on
• Requires wireless network or docking stations
• Battery life issue
• More expensive

11
Speech Recognition

• Speech is digitized and matched against coded
  dictionaries to
  recognize words
• Older voice recognition systems required discrete
  speech
• Newer speech recognition systems accommodate
  continuous speech
• Many systems must be "trained
• All words or sample of words that will be spoken
  by user
• New systems are speaker-independent, requiring no
  training
• Speech recognition is improving in accuracy, but
  it is often in commonly used terms rather than
  medical terms where errors occur
• Next week is spoken as nexweek
• Correction may be performed
• Retrospectively by a correctionist
• Concurrently by the user
• Speech recognition is not natural language
  processing.
• Speech recognition at the point of care can be
  cumbersome, unless used primarily to issue voice
  commands to a structured data template. Even
  then, many clinicians find this more awkward/less
  natural than navigating a template by hand or
  keyboarding

12
Bar Code / RFID

• Line of site requires human intervention to
  scan a barcode, whereas an RFID tag can be
  detected "hands off"
• Barcodes must be visible on outside of product
  packaging. RFID tags can be placed inside of
  packaging or in the product itself to reduce
  counterfeiting and black marketeering
• RFID tags are not impaired by dirt, moisture,
  abrasion, or packaging contours as are barcodes
• RFID tags have a longer read range than barcodes
• RFID tags have read/write memory capability
  barcodes do not
• More data can be stored in an RFID tag than can
  be stored on a barcode

• FDA will require manufacturers to apply bar code
  labels for all human drug and biological products
  by April 26, 2006
• Bar codes/RFID has been primarily used in
  hospital medication administration (and
  pharmaceutical inventory) scenarios, but, they
  can also be used for
• Lab specimen management
• RFID chips can be implanted in persons to track
  their movement

Also for lab specimen management
13
EHR Hardware

• User Authentication

14
Authorization, Access Controls, and
Authentication(All Required by HIPAA)

• Authorization is the process by which someone is
  allowed to have information they are permitted to
  have
• Access controls provide the means to allow or
  disallow someone information they want
• Administrative
• Physical
• Technical

• Authentication is the process by which you verify
  that someone is who they claim they are

Microsoft Active Directory
15
Access Control List
16
Authentication

• Wet signature
• Digitized signature
• Electronic signature
• UserID and password
• Token
• Biometric
• Digital signature

17
Public Key Infrastructure (PKI)

• A system of digital certificates, certificate
  authorities, and other standards and programs
  that verify and authenticate the validity of each
  party involved in an Internet transaction.
• PKIs are currently evolving.
  There is no single PKI nor
  even
  a single agreed-upon

  standard for setting up PKI
• PKI is also called a trust
  hierarchy

18
EHR Hardware

• Network Computing

19
Networking Basics

• Networks transport data among computers
• Network components
• Architecture
• Topology and protocols
• Media
• Devices
• Routers
• Hubs
• Switches
• Bridges
• Repeaters
• Gateways

20
Client/Server Architecture (C/S)

• A network architecture in which each computer or
  process on the network is either a client or a
  server
• Servers are powerful computers or processes
  dedicated to managing specific functions
• Clients are PCs or workstations on which users
  run applications. Clients rely on servers for
  resources, such as files, devices, and even
  processing power
• Clients
• Thick/Fat Clients are traditional PCs or
  workstations
• Thin/Network Clients
• Software and hardware configuration of client in
  which bulk of processing occurs on the server
• Often lower cost, but may not be suitable for all
  EHR applications (check with your vendor first)

21
Servers

• Variety of server functions
• Database server supports multiple, simultaneous
  transactions
• Application server middleware that connects a
  database server and end user
• Other servers include file servers print
  servers Web, email, and fax servers
• Proxy server sits between client and an external
  server to filter requests, improve performance,
  and share connections
• Server platform is the servers operating system
• Blade servers are circuit boards that slide into
  existing servers
• Servers are often rack mounted for convenience

22
Web Services Architecture

• Web services architecture (WSA)
• A standardized way of integrating Web-based
  applications using open standards over an
  Internet protocol backbone
• Unlike traditional C/S architecture using a Web
  server, WSA does not provide a graphical user
  interface (GUI).
• Instead, WSA shares business logic, data, and
  processes through a programmatic interface across
  a network.
• The WSA can then be added to a GUI to offer
  specific functionality to users
• WSA allows different applications from different
  sources to communicate with each other without
  time-consuming custom coding.
• Because all communication is in XML, WSA is not
  tied to any one operating system or programming
  language. Web services do not require the use of
  browsers or HTML

23
OSI Model of Computer Networks
24
Local Area Networks (LAN)

• Means to communicate data
• Twisted pair wire
• Inexpensive wire cable, limited speed and
  capacity, subject to interference
• Coaxial cable
• Expensive wire cable, not as susceptible to
  interference, widely used
• Fiber optics
• Extremely expensive threads of glass that carry
  data very rapidly with little interference
• Radio waves (wireless)
• Many standards, susceptible to interference
  bandwidth increasing and cost decreasing
• Transmission Control Protocol/Internet Protocol
  (TCP/IP)
• Used in private networks to mimic Internet
  functionality
• LAN Intranet
• WAN Extranet

• Protocols - rules for sending data from one node
  (place) on the network to another
• Speed
• Ethernet
• Supports very fast data transfer
• Token ring
• Closed loop around a central hub, relatively slow
• Fiber Distributed Data Interface (FDDI)
• Dual rings in token ring structure, supports many
  users at relatively fast speeds

25
Wide Area Networks (WAN)

• Geographically dispersed LANs
• Connected by telephone lines or radio waves
• Leased lines are permanent trunk lines offered by
  the telephone company (e.g., T1, T3)
• Dial up connection via modem and public telephone
  network
• Plain old telephone service (POTS) slow, some
  potential interference
• Frame relay and Integrated Services Digital
  Network (ISDN) offer increased speed to POTS
• Digital subscriber line (DSL) special
  configuration to link two specific locations
  (e.g., provider and a switching service) for
  faster and less expensive service than ISDN

26
Virtual Private Network
IPSec
SSL
27
Wireless Network

• Wi-Fi refers to a network based on the IEEE
  802.11 standards
• Consider the data transfer rates, security
  standards supported, and other factors for LAN
• 802.11a
• 802.11b
• 802.11g
• Metropolitan Area Networks (MAN)
• 802.16 (WiMAX)
• Bluetooth short range radio
  technology

28
VoIP

• VoIP allows you to make telephone calls using a
  computer network, over a data network like the
  Internet
• VoIP converts the voice signal from your
  telephone into a digital signal that travels over
  the internet then converts it back at the other
  end so you can speak to anyone with a regular
  phone number
• When placing a VoIP call using a phone with an
  adapter, you'll hear a dial tone and dial just as
  you always have
• VoIP may also allow you to make a call directly
  from a computer using a conventional telephone or
  a microphone

29
Important Security H/W

• Firewall hardware, software, or combination
  thereof that is designed to prevent unauthorized
  access to or from a private network by screening
  the messages against specific criteria
• Anti-Virus (AV) software that detects known
  malware, including spyware, spam, adware, content
  filtering, etc.
• Vulnerability Assessment (VA), Intrusion
  detection systems (IDS) and intrusion prevention
  systems (IPS) more sophisticated software that
  analyzes patterns and either provides an alert
  about a potential problem or restricts entry

30
Key Network Capabilities

• Bandwidth - Data carrying capacity, usually
  expressed as megabits per second (Mbps)
• Latency - Time required for a packet of data to
  be transmitted between communicating entities on
  a network
• Response Time Amount of time required for
  entire message or file to be transferred and
  acknowledged
• Availability - Likelihood that the network is
  able to provide service and is functioning
  properly
• Security - Capability of a network to ensure
  confidentiality and integrity of information
  transmitted across it.
• Ubiquity - Degree of access to a network

31
EHR Hardware

• Data
• Management
• and Storage

32
Document Imaging Systems

• Electronic document management systems (EDMS) are
  transition systems to EHR
• Basic functions include
• Creating document repositories
• Profiling document properties
• Managing document versions
• Searching and retrieving documents
• Viewing, editing, printing, importing and
  exporting documents
• Scanning documents
• Routing documents for workflow
• Content management through indexing

33
Storage

• Redundant Array of Independent (or Inexpensive)
  Disks (RAID)
• A category of disk drives that employ two or more
  drives in combination for fault tolerance
• Network attached storage (NAS)
• Device dedicated to file sharing, capable of
  adding hard disk storage space to a network
• Storage area network (SAN)
• High-speed sub-network of storage devices
• Content-addressed storage (CAS)
• System for storing data that are not intended to
  be changed (e.g., medical images, archived email)

34
Important Data Back Up Concepts

• Uninterruptible power supply (UPS), provides a
  battery to keep a computer running for several
  minutes after a power outage,
• Enables the ability to save data that is in RAM
  and shut down the computer gracefully.
• Many UPSs offer software that automates backup
  and shut down
• Dual-core refers to a CPU that includes two
  complete execution cores per physical processor.
• Failover is the capability to switch over
  automatically to a redundant or standby computer
  server, system, or network upon the failure or
  abnormal termination of the previously active
  server, system, or network. Failover happens
  without human intervention.
• Fault-tolerance, or graceful degradation, is the
  property of a system that continues operating
  properly in the event of failure of some of its
  parts.

35
This presentation was created by MetaStar under a
contract with the Centers for Medicare Medicaid
Services (CMS). The contents do not necessarily
reflect CMS policy.
