Correlation

1
Correlation

• The relationship between X and Y

2
Scatter Plot

• Graph of values of X and Y
• When look at scatterplot, see relationship
  between 2 variables

3
(No Transcript)
4
Correlation Coefficient

• The size of the correlation indicates the
  strength of the relationship between X and Y
• 1.0 indicates a perfect relationship
• The closer the number is to 1.0, the stronger the
  relationship
• Positive or negative sign indicates the direction
  of the relationship

5
Factors that affect size of correlation

• Linearity
• Homogeneity of group
• Size of the group

6
Spearman rho (?)

• Correlation of variables measured using ordinal
  scale

7
Simple Linear Regression

• The relationship between X and Y

8
Conceptualization

• Take a scatterplot
• Fit a line to the points to minimize how much
  each point deviates from the line

9
Fitting the Line

• Obviously, cannot draw a straight line among the
  points
• If we try to minimize each points deviance from
  the line, we are fitting a least squares line.

10
(No Transcript)
11
Fitting a Line The Equation

• Y ß0 ß1X e
• Y predicted score
• ß1 slope (amount of change in Y that
  corresponds to a change of 1 unit in X)
• ß0 Y intercept (value of Y when X0)
• ei independent errors in distribution of Y at
  each level of X

12
Slope (ß)

• Slope can be positive or negative
• Refers to direction (slant) of line
• Slope 0 means horizontal line

13
Examples
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Determining the Regression Line

• Ordinary Least Squares
• Minimize the squared deviations of the actual
  value (Y) from the predicted value (Y)

19
Simple Regression
20
Purpose

• Predicting score on Y variable based on knowledge
  of score on X variable.
• Examines relationship among 2 or more variables
• Variables may be either continuous or categorical

21
Example

• Random sample of 11 children
• Can we predict IQ from birthorder (Zajonc)?

22
(No Transcript)
23
Simple Regression

• 1 Dependent Variable (Criterion)
• 1 Independent Variable (Predictor)
• Mathematically, doesnt matter which is which in
  case of simple regression

24
Assumptions for Simple Regression

• Linear relationship between dependent variable
  (Y) and predictor (X)
• The errors are independent of each other
• The errors have constant variance
• The errors are normally distributed with a mean
  of 0

25
Ways to Assess Violations of Assumptions

• Plot the residuals against predicted values
• Residuals are the deviations of each individual
  score from the regression line
• If violations are tenable, the scatterplot should
  not have any obvious pattern

26
Testing Hypotheses

• H0 ß1 0
• X and Y are unrelated (slope of regression line
  is 0 and horizontal line)
• Simple Regression is nothing more than t-test
• Slope (b) represents correlation between X and Y

27
Computer Examples
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
Correlation between X Y when only one predictor
36
Amount of variance in Y explained by predictors
(X)
37
Predictors (X) significantly predict Y (F(1, 9)
21.74, p.001
38
Y2.2 .98(X) e
39
X is a statistically significant predictor of Y
(t4.66, p.001)
40
Results

• Using simple regression analyses, X was a
  statistically significant predictor of Y (F (1,
  9) 21.74, p.001) explaining 67.5 of the
  variance in Y using the adjusted R squared
  statistic. The standardized beta coefficient for
  X was .84.

41
Homework

• Hinkle p. 117-120 6 (find correlation with
  SPSS), 13 (find correlation with SPSS)
• p. 136 2b (use SPSS), 3b (use SPSS)
• Stangor p. 38 3
