Duffings Equation as an Excitation Mechanism for
Plucked String Instrument Models

• by
• Justo A. Gutierrez
• Masters Research Project
• Music Engineering Technology
• University of Miami School of Music
• December 1, 1999

2
Purpose

• The objective of this study is to provide the
  basis for a new excitation mechanism for plucked
  string instrument models which utilizes the
  classical nonlinear system described in Duffings
  Equation.

3
Advantages

• Using Duffings Equation provides a means to use
  a nonlinear oscillator as an excitation
• A mathematical model lends itself to user control
• Removes the need for saving samples in a wavetable

4
Overview

• Plucked String Instrument Modeling
• Excitation Modeling with Duffings Equation
• Model Performance and Analysis

5
Wavetable Synthesis

• Method of synthesis that uses tables of waveforms
  that are finely sampled
• Desired waveform is chosen and repeated over and
  over producing a purely periodic signal
• Algorithm written as Yt Yt-p
• p is periodicity parameter
• frequency of the tone is fs/p

6
The String Model

• z-L is delay line of length L
• H(z) is the loop filter
• F(z) is the allpass filter
• x(n) and y(n) are the excitation and output
  signals respectively

7
Length of String

• Effective delay length determines fundamental
  frequency of output signal
• Delay line length (in samples) is L fs/f0

8
The Comb Filter

• Works by adding, at each sample time, a delayed
  and attenuated version of the past output

9
Standing Wave Analogy

• Poles of the comb filter occur in the z-plane at
  2np/L
• This is the same as the natural resonant
  frequencies for a string tied at both ends
• Does not sound like a vibrating string because it
  is a perfectly periodic waveform
• Does not take into account that high frequencies
  decay much faster than slow ones for vibrating
  strings

10
The Loop Filter

• Idea is to insert a lowpass filter into the
  feedback loop of the comb filter so that
  high-frequency components are diminished relative
  to low-frequency components every time the past
  output signal returns
• Original Karplus-Strong algorithm used a two-tap
  averager that was simple and effective

11
Loop Filter (continued)

• Valimaki et al proposed using an IIR lowpass
  filter to simulate the damping characteristics of
  a physical string
• Loop filter coefficients can be changed as a
  function of string length and other parameters
• H1(z) g(1a1)/(1a1z-1)

12
Loop Filter Signal Flowchart
13
Loop Filter Magnitude Response and Group Delay
14
Loop Filter Impulse Responses
15
The Allpass Filter

• Used to fine-tune the pitch of the string model
• If feedback loop were only to contain a delay
  line and lowpass filter, total delay would be the
  sum of integer delay line plus the delay of the
  lowpass filter
• Fundamental frequency of fs/D is usually not an
  integer number of samples

16
Allpass Filter (continued)

• Fundamental frequency is then given by
  f1 fs/(Dd) where d is fractional delay
• Allpass filters introduce delay but pass
  frequencies with equal weight
• Transfer function is H(z) (z-1a)/(1az-1)
• a (1-d)/(1d)

17
Allpass Phase Response
18
Allpass Delay Response
19
Inverse Filtering

• KS algorithm used a white noise burst as
  excitation for plucked string because it provided
  high-frequency content as a real pluck would
  provide
• Valimaki et al found a pluck signal by filtering
  the output through the inverted transfer function
  of the string system

20
Inverse Filtering (continued)

• The transfer function for the general string
  model can be given as S(z) 1/1-z-LF(z)H(z)
• The inverse filter is simply S-1(z) 1/S(z)

21
Inverse Filtering Procedure

• Obtain residual by inverse filtering
• Truncate the first 50-100 ms of the residual
• Use the truncated signal as the excitation to the
  string model
• Run the string model

22
Steel-string Guitar Sample
23
Residual After Inverse Filtering
24
Truncated Residual Signal
25
Resynthesized Guitar
26
Duffings Equation

• In 1918, Duffing introduced a nonlinear
  oscillator with a cubic stiffness term to
  describe the hardening spring effect in many
  mechanical problems
• It is one of the most common examples in the
  study of nonlinear oscillations

27
Duffings Equation (continued)

• The form used for this study is from Moon and
  Holmes, which is one in which the linear
  stiffness term is negative so that x
  dx - x x3 g cos wt.
• This model was used to describe the forced
  oscillations of a ferromagnetic beam buckled
  between the nonuniform field of two permanent
  magnets

28
Experimental Apparatus (Moon and Holmes)
29
Modeling the Excitation

• For this experiment, the coefficients in Moon and
  Holmes modification of Duffings Equation were
  adjusted to produce the desired residuals
• The Runge-Kutta method was the numerical method
  used to calculate Duffings Equation

30
Procedure for manipulating Duffings Equation

• Generate a waveform of desired frequency with (x,
  y). f ?10y is a good rule of thumb for starters.
• Adjust the damping coefficient so that its
  envelope resembles the desired waveforms
• Adjust b, g, and w to shape the waveform, holding
  one constant to change the other
• Normalize the waveform to digital maximum

31
Guitar Residual Synthesized by Duffings Equation
32
Synthesizing the Plucked String
33
Synthesized Guitar Using Duffings Equation as
the Excitation
34
Timbral Characteristics

• Synthesized guitar from Duffings Equation very
  similar to that from inverse filtering
• Frequency of both residuals different from pitch
  of synthesized strings?inharmonicity
• Sonograms of both residuals also very similar

35
Sonogram for Guitar (Inverse Filtering)
36
Sonogram for Guitar(Duffings Equation)
37
Tuning Performance (Harmony)

• For individual pitches, the algorithm played
  fairly close to being in tune (perhaps slightly
  sharp). The allpass filter parameters can be
  adjusted to remedy this.
• The C major chord played very well in tune,
  sounding very consonant with no apparent beats.

38
Tuning Performance (Range)

• To test effective range of the algorithm, the
  lowest and highest pitches in a guitars range
  were synthesized.
• Low E played in tune by itself. High E was flat.
• This was more readily apparent when sounded
  together.

39
Summary of Tuning Performance

• Algorithm performed as expected it performed
  like Karplus-Strong high frequencies tend to go
  flat, and this would have to be accounted for in
  the overall system.

40
Changing Damping Coefficient

• Changing the damping coefficient can have
  pronounced effect on timbre of sound,
  specifically difference between type of pick used
  and type of string
• The damping coefficient was adjusted to attempt
  to produce different sounds

41
Synthesized Residual (d 0.2)
42
Synthesized Guitar (d 0.2)
43
Synthesized Residual (d 0.5)
44
Synthesized Residual (d 0.5)
45
Summary of Damping Coefficient Adjustments

• For d 0.2, contribution of residual made for a
  very hard attack, as if picked
• For d 0.5, guitar tone had much softer attack,
  as if finger-picked
• Sonograms confirm that the latter had more
  high-frequency content

46
Sonogram for d 0.2
47
Sonogram for d 0.5
48
Production of Other Waveforms

• Duffings Equation can be used to form a variety
  of waveforms
• User has some control over its behavior if
  properties of the oscillator can be controlled to
  obtain the desired waveform

49
Residual with Damping Only
50
Residual with Beta Only
51
Residual with Forcing Function Only
52
Residual with Strong High-Frequency Forcing
Function
53
Algorithm Speed

• For 200 MHz Pentium Pro, Karplus-Strong with an
  inverse filtered residual took 57.46 s. with
  approximately 2500 samples saved on a wavetable
• With synthesized residual, Duffings Equation
  added only 4.057 s total computation time
  increased by only about 5 with no saved samples

54
Conclusion

• Plucked string sounds were successfully produced
• Model plays in tune
• Different plucked string sounds can be produced
  by changing the damping coefficient
• Algorithm is fast
