Title: Informatics for Clinical Research


1
Informaticsfor Clinical Research
2
Clinical Research as an Activity
  • Fundamental to translation of basic research to
    medically useful interventions
  • Big business est. 95 B spent annually in U.S.
    in biomedical research/drug and device testing
  • Academic centers lag behind commercial clinical
    trials organizations in knowledge and skills
    related to efficient and high quality clinical
    research.
  • Academic center market share of clinical trials
    now est. at 20, was 80 in 1990
  • Generally inferior performance with respect to
    error rates, missing data, timeliness of
    submission

3
Importance of Informatics to Clinical Research
  • Structured observation and structured record
    keeping are the essence of science
  • Primary differentiation between routine clinical
    care and research is how processes are controlled
    (ie., protocol-driven) and information is managed
    to make it useful for analysis

4
Classical Data Management Flow for Clinical
Research
Scientific Hypotheses
Specific Data Elements Required to Test Hypotheses
Data Acquisition Instruments (forms)
Computer Data Model and Tool Selection to Support
Model and output to Analytical Software
People and Process Development (Who does What,
When and Where)
Documentation Standard Operating Policies
Procedures
5
Research Data Management Goals
  • Create processes and systems that result in
    research data that is
  • Accurate
  • Complete
  • Timely
  • Verifiable
  • Secure
  • Available for analysis

6
Regulatory Context Good Clinical Practice
Standards
  • General and uniform set of principles for
    conducting clinical research
  • Two themes
  • Respecting rights of participants
  • Conducting research so that data is accurate and
    verifiable
  • Required by FDA but a good (higher) standard for
    NIH and other sponsored research

7
GCP Standards Address...
  • Responsibilities of participating sites
  • Responsibilities of coordinating centers for
    multisite trials
  • Quality Assurance methods for data
  • Audits
  • Reporting to regulatory agencies

8
GCP Principles of Data Management
  • All data should be independently verifiable
  • Normally done by comparison with locally kept
    medical records in interventional trials
  • Structured approach to record keeping
  • Physical structure tabbed participant folders
    with dividers for different classes of
    information
  • Logical structure database designs and tracking
    systems

9
GCP Principles of Data Management
  • Research records are separately maintained from
    healthcare-related records
  • Source document place where observation first
    recorded
  • Source document verification comparison of Case
    Report Forms (CRFs) with source documents
  • corollary CRFs are not usually considered source
    documents

10
GCP standards example Paper Case Report Forms
  • Follow instructions
  • Write legibly
  • Originals normally go to Coordinating Center
    copies local
  • No marginalia (literally outside the box)
  • Forms designed so that all variables have a
    current value (may be code for Pending, Missing,
    Missed)
  • Correct units of measurement (best included with
    value as separate field)

11
GCP Standards for Case Report Forms, contd
  • Proper methods of correction
  • Line through incorrect value (value still
    visible)
  • Correct value added
  • Correction initialed
  • White-out is always red in an auditors eyes - no
    correction fluids or erasures
  • Check forms for completeness prior to submission
  • Double check and verify ID info on CRF
  • Submit on time

12
21 CFR 11Electronic Records Signatures
  • Applies (only) to data submitted to FDA in
    support of drug device applications
  • Address issues related to paperless data
    management systems where there is no source
    document for verification
  • Subpart C relates to digital signatures
  • Full compliance requires formal software
    validation testing and certification
  • To date, has paradoxically impeded rather than
    advanced use of electronic research data
    management systems

13
General Forms Design Principles
  • Have definitions of all data to be collected in
    hand before starting the study
  • Avoids unnecessary forms revisions that often
    confuse Clinical Research Associates (CRAs),
    participants, and creates statistical
    complexities
  • Avoids fishing expedition approach to iterative
    protocol modification

14
Web browser (thin client) electronic forms for
data entry and retrieval
  • Strengths
  • Deploy to any location on the Internet
  • Platform independent (sort of be careful and
    test all software on all potential clients)
  • No software to install or license on users
    machines
  • Weaknesses
  • Less efficient (compact interface)
  • Fewer controls available
  • Limited repertoire of widgets (buttons, lists,
    etc.)
  • Slower
  • Dependent upon Internet connectivity

15
Specialized Software for Clinical Trials
  • Registration
  • Randomization
  • Participant tracking
  • Site communications
  • Transaction or batch upload of local data to
    coordinating center
  • Websites for protocols, forms, administrative info

16
Specialized Software for Clinical Trials, contd
  • Performance measures
  • Site actual vs. projected accrual
  • Data completeness
  • Data accuracy
  • Data timeliness
  • Usually displayed as trends over time
  • Performance measures should include reference
    values for performance at all sites combined

17
Data Acquisition Technologies
18
Data acquisition TechnologiesKeyboard Data Entry
  • Average keystroke error rates will be 0.1 to 1,
    depending upon data type
  • Improve accuracy over baseline by
  • Double entry and file comparison (gold standard
    but inefficient and expensive)
  • Special technologies for referential integrity
    items (e.g., barcode visit and participant ID)
  • Event-driven auditing and source document
    verification of scientifically important
    variables

19
Data acquisition TechnologiesDouble keying
  • Common best practice forms entered by two
    different data entry operators
  • Computer generates difference (diff) file
  • Third person (usually data manager with clinical
    expertise) reviews and resolves differences
  • Increases personnel costs by factor of 2 - 2.5
    over single entry plus sample-based auditing

20
Data acquisition Technologies Barcoding
  • Applications
  • Referential integrity items identifiers for
    participant, study, site, protocol, event/visit
  • Physical object tracking e.g., tissue specimens,
    freezer inventory management systems
  • System-generated barcode labels
  • Various barcode standards 3-of-9 generally used
    for scientific applications
  • Produced by TrueType fonts or dedicated barcode
    printers

21
Data acquisition Technologies Barcoding, contd
  • Barcode readers
  • Keyboard wedge - wand or handheld scanner
    plugged between keyboard and computer
  • Self-contained scanners with infrared or USB bulk
    data upload (derived from warehouse inventory
    systems)

22
Data acquisition Technologies Mark-sensing
Technologies
  • Example Scantron (www.scantronforms.com)
  • Strengths
  • Mature technology
  • Efficient for re-usable form scanning
  • Weaknesses
  • Low information density poor for most biomedical
    uses
  • Susceptible to frame shift errors by users
  • Requires forms printing
  • Cost effective at level of 100K forms

23
Mark sensing technologies
24
Data acquisition Technologies POF Plain Old Fax
  • Design issues
  • Include signature or initials on faxable forms
  • Strengths
  • Widely used surrogate for paper
  • Weaknesses
  • Not considered a source document
  • Legibility
  • Requires additional effort to enter data into
    computable form

25
Data acquisition Technologies Fax Optical
Character Recognition
  • Example Teleform (www.cardiff.com)
  • Strengths
  • Can substitute for data entry staff
  • Includes design, recognition, and verification
    functionality
  • 90 recognition accuracy depending upon data
    type
  • Weaknesses
  • Error rates equivalent to single entry, higher
    than double entry
  • Cost vs. person hours becomes favorable only at
    large numbers of forms (50-100K)

26
Data acquisition Technologies Direct Computer
Entry by Participants
  • Can use thin client (HTML forms) or thick
    client i.e., workstation forms (e.g., MS Access)
  • Strengths
  • If well designed, eliminates data entry step
  • Can add multimedia explanations and tutorials
  • Can be more enjoyable for study participants than
    paper forms
  • Weaknesses
  • Requires basic computer skills (mouse /-
    keyboard)
  • Requires literacy skills
  • Requires staff assistance and verification

27
Data acquisition Technologies Computer to
Computer Messaging
  • Example import lab results from lab system
    directly into research database for study
    participants.
  • Strengths
  • If well designed, eliminates data entry step
  • Timeliness
  • Accuracy
  • Weaknesses
  • Requires specialized computer programming
    expertise
  • Requires standards for representing clinical data
    (most widely used HL-7)
  • Requires willingness of systems managers at
    source of data (e.g., medical center Information
    Services) to allow data connections

28
Data acquisition Technologies PDAs
  • Example Pendragon software
  • Strengths
  • Portable, relatively low cost
  • Nonprogrammer interfaces to MSAccess
  • Weaknesses
  • Limited screen size and navigation speed
  • Not suitable for text entry
  • Security lost or stolen PDA

29
Data Archiving and Database Design
30
Commonly used data archiving and analysis software
  • Single investigator, simple trial
  • Spreadsheet (MS Excel)
  • Beware using spreadsheets for HIPAA-regulated
    data no audit trail capability
  • Workgroup-capable database management software
    (MS Access, Filemaker Pro, 4th Dimension, MS
    Visual FoxPro)
  • Data Center, multiple studies
  • Enterprise relational database system
  • Sybase, Oracle, MS SQL Server
  • Dedicated statistical analysis packages
  • SAS, BMDP, SPSS, S Plus, JMP

31
Commonly used data archiving and analysis
software, contd
  • Pharmaceutical companies - multiple drugs,
    multiple sites, multiple studies, FDA audits
  • Dedicated clinical trials software (e.g., BBN
    ClinTrials, Oracle Clinical)

32
Sample data model for one-time administration of
a survey
one
Person (Participant) ParticipantID primary
key Last_name First_name Address City State Zip P
hone Fax E-mail MRN Birthdate SSN Gender Last_upda
te Update_by
one
Study_Data ParticipantID Date Answer1 Answer2 An
swer3 Answer4 Last_update Update_by
Best practices store Person table on removable
media with physical security OR store Person
encrypted by private key
33
Simple clinical study with a variable number of
identical repeat visits
one
Person (Participant) ParticipantID Last_name Fi
rst_name Address City State Zip Phone Fax E-mail M
RN Birthdate SSN Gender Last_update Update_by
many
Study_Data ParticipantID VisitID VisitDate BPsys
tolic BPdiastolic Weight Sodium Potassium Chloride
Bicarb BUN Creatinine Last_update Update_by
Note In best pactice, primary key of Study_Data
is the combination of Participant ID and the
study visit, which defines a unique protocol
event. VisitDate is the calendar date that event
occurs.
34
Clinical study with a baseline evaluation
followed by variable number of identical repeat
visits
one
Baseline ParticipantID VisitDate DataItem1 DataI
tem2 DataItem3 Last_update Update_by
Person (Participant) ParticipantID Last_name Fi
rst_name Address City State Zip Phone Fax E-mail M
RN Birthdate SSN Gender Last_update Update_by
one
many
Follow_Up ParticipantID VisitID VisitDate BPsyst
olic BPdiastolic Weight Sodium Potassium Chloride
Bicarb BUN Creatinine Last_update Update_by
35
Data Security
36
Information Security Elements
  • Availability - when and where needed
  • Authentication -a person or system is who they
    purport to be (preceded by Identification)
  • Access Control - only authorized persons, for
    authorized uses
  • Confidentiality - no unauthorized information
    disclosure
  • Integrity - Information content not alterable
    except under authorized circumstances
  • Attribution/non-repudiation - actions taken are
    reliably traceable

37
Research Records Security,General Principles
  • Physical Security
  • Locked file storage for physical files
  • Programmable locks best
  • Change combination on a regular basis (common
    practice twice a year)
  • Person-identifiable data
  • Keep separate from other study data
  • Consider additional protections such as two
    person access requirements

38
Research Records Security, contd
  • Electronic Security
  • No workstations viewable from public areas
  • Password-protected login
  • Screensaver timeouts
  • Separate login and password for database access
  • Store demographics data separately and encrypted
    if feasible
  • Regular backups and offsite backup storage

39
Research Records Security, contd
  • Network Security
  • Safest but least useful disconnect workstations
    with research data from network
  • Keep all workstations and servers patched with
    latest security updates
  • Run antivirus software on all machines
  • Consider firewall computer to protect Internet
    access point, and/or workstation firewall software

40
Information Security Elements
  • Availability - when and where needed
  • Authentication -a person or system is who they
    purport to be (preceded by Identification)
  • Access Control - only authorized persons, for
    authorized uses
  • Confidentiality - no unauthorized information
    disclosure
  • Integrity - Information content not alterable
    except under authorized circumstances
  • Attribution/non-repudiation - actions taken are
    reliably traceable

41
Security Rule Basic Concepts
  • Applies security principles well established in
    other industries
  • Like Privacy Rule, affects Covered Entities that
    create, store, use or disclose Protected Health
    Information (PHI)
  • Unlike the Privacy Rule, affects only PHI in
    electronic format (not oral or paper-based)
  • Like the Privacy Rule, written for health care
    research not the principal focus
  • Scalable burden relative to size and complexity
    of organization

42
Two types of Rule elements
  • Required standards
  • Addressable standards
  • CE must decide whether the standard is reasonable
    and appropriate to the local setting, and cost to
    implement
  • Can either
  • Implement the standard as published
  • Implement some alternative (and document why)
  • Not implement the standard at all (and document
    why)

43
Three Categories of Standards
  • Administrative safeguards
  • Policies and procedures to prevent, detect,
    contain and correct information security
    violations
  • Physical Safeguards
  • IT equipment and media protections
  • Technical Safeguards
  • Controls (mostly software) for access,
    information integrity, audit trails

44
Administrative Safeguards
  • Required
  • Risk Analysis
  • Risk Management Plan
  • Sanctions Policy
  • Information System Activity Review (audits)
  • Security Incident Response Reporting
  • Data Backup Plan
  • Disaster Recovery Plan
  • Emergency Mode Operations
  • Periodic Evaluations of Standards Compliance

45
Physical Safeguards
  • Required
  • Workstation Use Analysis
  • Workstation Security
  • Disposal of media
  • deletion of PHI prior to disposal, or
  • Secure disposal so data nonrecoverable
  • Media Reuse
  • Deletion of PHI prior to re-use

46
Technical Safeguards
  • Required
  • Unique User Identification
  • No shared logins
  • Emergency access procedures
  • Audit controls
  • Logs of who created, edited or viewed PHI
  • Person and/or Entity Authentication
  • No systems without access control

47
Implications for Research
  • Avoid HIPAA Security Rule entanglements if
    possible by
  • Thoughtful definition of Covered Entity with
    respect to research activities
  • E.g., Vanderbilt is Hybrid Covered Entity
    research not a covered function except for
    research that uses or creates medical records
  • Use of de-identified data and/or Limited Data
    Sets wherever possible
  • Not storing PHI in electronic format in research
    settings

48
If a research project maintains e-PHI
  • Responsible group must designate a Security
    Officer who has responsibility for implementing
    HIPAA-compliant policies and procedures for
    research use of e-PHI
  • Must do and document a risk analysis
  • Must create risk management plan based on the
    risk analysis
  • Must create and keep current a HIPAA Security
    Rule compliance document that includes
    description of how 17 Required elements are met,
    and decisions regarding Addressable elements

49
Widespread current research practices that dont
meet the standard
  • Research workgroups that create or use PHI in
    electronic format but have no written security
    procedures, policies or training
  • Workstations with no login security (e.g.,
    Windows98)
  • Data management and analysis applications used to
    store PHI that have no ability to generate audit
    trails
  • E.g., Excel spreadsheets with PHI in them

50
Using the Internetfor Clinical Research
51
Internet Functionality for Clinical Research
  • E-mail
  • Avoid putting HIPAA PHI in e-mail
  • Study participant recruitment

52
(No Transcript)
53
Internet Functionality for Clinical Research,
contd
  • E-mail
  • Avoid putting PHI in e-mail
  • Study participant recruitment
  • Private FTP site as drop box for study related
    file communications
  • encrypt files if they contain PHI
  • Data submission and reporting
  • Multi-site coordination and administration

54
Approved Internet Technologies relevant to
Clinical Research
1containing person-identifiable i.e., HIPAA PHI
2 must be encrypted to HCFA/CMS std
55
Sample Project administration website for
multi-center study
56
Putting it All TogetherResearch Data Management
  • An artful selection of physical and electronic
    management methods
  • Signed informed consent documents
  • Paper forms
  • Regulatory and project management binders
  • Data models and databases
  • Data acquisition and display technologies
  • Communications technologies for project
    management as well as data management

57
Attributes of Successful Data Management
  • Attention to detail
  • Explicit structure and process
  • Robust designs
  • Anticipate failures, lapses and mistakes
  • Design systems that identify and correct them
  • Mechanisms for verification
  • Well documented

58
Lessons Learned about Data Management in Clinical
Research
  • Effective data management is a continuous
    process, not a point in time analysis
  • Historically, health care organizations and
    providers have invested suboptimally in
    information systems and this provides an uneven
    infrastructure for clinical research
  • In health care organizations, data management and
    information systems implementation is 20
    technology and 80 sociology (R. Gardner) plan
    accordingly
Write a Comment
User Comments (0)
About PowerShow.com
