Early Stages of Design

1
Early Stages of Design

• CPE x350-01 F07
• Lynne Slivovsky

2
Outline

• Overview of design process
• A variety of models
• Requirements Specification
• (Chapter 3 of Ford Coulston)

3
Phases of Design

• Engineering Your Future, Great Lakes Press
• Stage 1 Identify the problem/product innovation
• Stage 2 Define the working criteria/goals
• Stage 3 Research and gather data
• Stage 4 Brainstorm/generate creative ideas
• Stage 5 Analyze potential solutions
• Stage 6 Develop and test models
• Stage 7 Make the decision
• Stage 8 Communicate and specify
• Stage 9 Implement and commercialize
• Stage 10 Perform post-implementation review and
  assessment

4
IEEE Std 1220-2005
5
IEEE Std 1220-2005
6
IEEE Std 1220-2005
CPE 350
CPE 450
7
Ullmans Mechanical Design Process

• Phase 1 Specification development/planning
• Phase 2 Conceptual design
• Phase 3 Product design
• Phase 4 Production
• Phase 5 Service
• Phase 6 Retirement

8
Phases of the Design Cycle
Specification Development
Redesign
Conceptual Design
Retirement
Disposal
Product Design
Service
Production
9
Ford Coulston
Image taken from Design for Electrical and
Computer Engineers, Ford and Coulston
10
Design Process Models

• MANY formal models for the design process
• IEEE Std 1220-2005 IEEE Standard for Application
  and Management of the Systems Engineering Process
• The Mechanical Design Process, McGraw Hill, 1997,
  2003
• Design for Electrical and Computer Engineers,
  Ford and Coulston, McGraw Hill, 2007
• Take Home Points
• Do not use a hobbyist/hacker approach
• Be explicit with the process model you select
• (e.g., in your documentation)

11
Inside or Outside the Box?
How your problem is constrained.....

..determines the variability in its design
Many Possible Designs
Few Specifications
Many Specifications
One Design
Where do specifications comes from?
12
Requirements Specification (Ch 3)

• Requirements Setting Process
• Marketing Requirements
• Engineering Requirements
• Taxonomy of Requirements
• Developing Requirement Specifications
• Example
• Criteria

13
Requirements Specification

• The requirements specification identifies those
  requirements that the design must satisfy in
  order for it to be successful.

14
Requirements Setting Process

• Three stakeholder groups
• Customer
• Gives raw (marketing) requirements
• Gives feedback based on usability, marketing
• Environment
• Imposes constraints and standards
• Technical Community
• Gives feedback based on engineering knowledge

15
Requirements Setting Process
Customer
Marketing, Customer Feedback
Customer Representation
Develop System Requirements
Constraints and Standards
Technical Feedback
Technical Representation
Technical Community
Environment
16
Marketing Requirements

• Short statements that address a user need
• The system should be small
• The positioning should be accurate
• Not specific enough to complete a design

17
Engineering Requirements

• Engineering requirements are short statements
  that address a technical need of the design.
• The system should be able to supply 50W of power

18
Engineering Requirements

• Four Properties
• Abstract
• Verifiable
• Unambiguous
• Traceable

19
Engineering Requirements

• Abstract
• A requirement should specify what the system
  should do, not how it will be implemented
• Beware of preconceived concepts for solutions
• Example
• In getting more people from Oakland to San
  Francisco, the requirement should not be to
  design a bridge.
• It could be transport people from one side of
  the river to the other.

20
Engineering Requirements

• Verifiable
• There should be a way to measure (or demonstrate)
  the requirement is met
• Allows us to continually answer the question
  Are we building the system correctly?
• Example
• One requirement might be the flying robot must
  be able to hide 3.5 meters below the surface.
• A better requirement could be the flying robot
  must be able to determine its ground based
  position with a tolerance of 2cm.

21
Engineering Requirements

• Unambiguous
• Each requirements must have a single meaning,
  stated with short complete sentences
• Example
• Not The robot must operate with a battery life
  of 1 hour.
• Maybe The robot must operate for a minimum of 1
  hour.

22
Engineering Requirements

• Traceable
• Each requirement should be traceable to marketing
  requirements
• Example
• Engineering requirement
• Must be manufactured for less than 2.00
• Marketing requirement
• Must be affordable

23
Engineering Requirements

• Realism
• Realistic
• Justified
• This comes from experience (e.g. technical
  feedback from the technical community).

24
Engineering Requirements

• Constraints
• In design, a constraint is a special type of
  requirement
• It is a design decision imposed by the
  environment or a stakeholder that impacts or
  limits the design
• Windows platform must be used
• Note that constraints can violate the
  abstractness property
• Can make a design decision that adheres to the
  constraint
• In choosing between windows and Unix, windows is
  chosen because 99999 out of the 100000 customers
  use windows.

25
Engineering Requirements

• Standards
• Established ways of doing things to ensure
  interoperability
• Ensure products work together
• Safety, testing, reliability, communications,
  data formats, documentation, design methods,
  programming languages, connector standards,
  metastandards
• Knowing details of standards is often required at
  the Implementation stage of development

26
Taxonomy of Requirements

• Identifying Engineering Requirements
• Structured workshops and brainstorming sessions
• Interviews, surveys, questionnaires
• Observation of processes or devices in use
• Competitive benchmarking and market analysis
• Prototyping and simulations
• Research and technical documentation review

27
Taxonomy of Requirements

• Performance
• Functionality
• Economic
• Energy
• Environmental
• Health and Safety
• Legal

• Maintainability
• Manufacturing
• Operational
• Political
• Reliability and Availability
• Social and Cultural
• Usability

28
Criteria

• The requirements provide an minimum set of
  objectives that the design must meet.
• What if you have two designs that meet all
  requirements? Which one should you use?

29
Criteria

• Criteria provide a method for comparing different
  designs.
• Example robot speed (m/s)
• They should have all the properties of
  engineering requirements.
• They are often confused with requirements. BUT
  THEY ARE DIFFERENT!

30
Criteria

• Example
• Requirement
• The dimensions of the prototype should not exceed
  6 x 4 x 1.5
• Criteria
• The dimensions of the prototype (smaller is
  better) in inches
