Title: Structured Component Composition Frameworks for Embedded System Design


1
Structured Component Composition Frameworks for
Embedded System Design
  • Sandeep Shukla, Virginia Tech.
  • Frederic Doucet, Rajesh Gupta
  • University of California, San Diego.

2
The Context
  • Platform Based Design (PBD)
  • a platform is a partial design consisting of IP
    blocks
  • a platform is an IP at the next level of
    abstraction
  • A platform is a realized design pattern
  • Any given space has a limited number of good
    solutions to its basic problems.
  • A platform captures the good solutions to the
    important design challenges in that space.
  • A platform reuses architectures within
    architectural constraints
  • IP design needs a framework consisting of
  • component libraries, composition glue,
    validation, synthesis..
  • Component Composition Framework (CCF)

3
A CCF Provides the Basis for Composition
4
BALBOA A Composition Workbench
  • Module as a top-level class
  • Member functions
  • model blocks
  • create compound blocks
  • connect component objects
  • set parameters
  • A glorified schematic entry
  • gt set design new Module
  • gt set C0 design Component
  • gt design connect C0 C1
  • gt design attach_list
  • gt design copy_interface
  • gt design attach_behavior
  • gt ...

5
Components and Composition
  • C is increasingly being considered for system
    modeling
  • Accessible and good for managing system
    complexity through object orientation
  • While use of C enables higher abstraction
    levels, it does not per se guarantee increases in
    design efficiency and productivity
  • Enormous modeling choices in typing
  • Higher productivity requires ability to reuse
    system components
  • Need for adequate composability

6
High Design Efficiency Requires New abilities
  • Model Interoperability
  • The ability of the IP models to compose
  • Language and environments
  • The ability of the IP models to be reused
  • Methodological implications
  • We focus on composability here
  • There are two aspects to composability
  • Compatibility across modeling dimensions
  • Ability to quickly and accurately build complete
    system models

7
Modeling Dimensions and Composability
  • System Level Semantics Concerns
  • Different models of computation
  • Different levels of abstraction
  • Different data types
  • Different class libraries
  • Primary obstacle to composability
  • Semantic gap between hardware components and
    their software models

8
C Semantic Gap
Hardware elements
7
7
B1
B2
How to connect?
9
C Composability Implementations
10
C Composability Implementations (contd)
  • In both approaches, wrappers are implemented
  • Inheritance wrapping established during
    programming time
  • Composition wrapping established at run-time
  • Both approaches have dependencies
  • Inheritance has a stronger dependency than
    composition
  • We think that composition could be a better
    solution for system models which contains
    hardware

11
Dynamic Composition
  • What is dynamic composition?
  • Objects acquiring references at run-time
  • No recompiling necessary usage of compiled IP
    libraries
  • Key ideas
  • Use delegation instead of inheritance for model
    reuse
  • Wrapper has a separate identity from the
    component
  • Relies on a specialized Interface Definition
    Language (IDL) to generate the wrapper

12
BALBOA CCF
  • Layered composition
  • Built upon existing class libraries, to add a
    software layer for manipulation and configuration
    of C IP models
  • Ease software module connectivity
  • Run-time environment structure

13
BALBOA Key Technical Decisions
  • A development and runtime environment
  • Layered architecture
  • Use an interpreted language for
  • Architecture description
  • Component integration
  • Use delegation is used instead of inheritance for
    component wrapping
  • Split-level interfaces between interpreted and
    compiled domains
  • Use an interface definition language (IDL) to
  • Describe and generate the split-level interface
  • Implements the composition and object model
  • Extends the type system

14
BALBOA System Implementation
  • CIL Script Provides
  • Delayed and inferred typing
  • Introspection capabilities
  • The split-level interface do not rebuild, but
    uses the compiled structure as model instance
  • Built using Object Tcl for the composition
    environment

15
Language Layers CIL
  • Producer P
  • Consumer C
  • Queue Q
  • P query attributes
  • queue_out
  • C query attributes
  • queue_in
  • P.queue_out query methods
  • bind_to read
  • P.queue_out bind_to Q
  • Script-like language based on Object Tcl
  • Compose an architecture
  • Instantiate components
  • Connect components
  • Compose objects
  • Build test benches
  • Introspection
  • Query its own structure
  • Loose typing
  • Strings and numbers

16
Language Layers BIDL
templateltclass Tgt class Producer kind
BEHAVIORAL public QueueltTgt queue_out
unsigned int packet_count void
packet_generator process() INSTANCE (int)
OF_CLASS (Producer) INSTANCE (BigPacket)
OF_CLASS (Producer) INSTANCE (SmallPacket)
OF_CLASS (Producer)
  • Component description language to export
  • Attributes
  • Methods,
  • Relationships
  • Characteristics
  • Used to generate the split-level interface
  • Used to extend the type system in the environment

17
Language and Run-time Layers
Language
Tools
Run-time structure
CIL
Interpreter
BIDL
BIDL Compiler
Split Level Interfaces
GCC
C
Compiled objects
GCC
18
Split-level Interface
  • Links the interpreted and the compiled domain
  • Each compiled object has a split-level interface
  • Implements
  • Composition model
  • Full control on the internal object
  • Reflection and the introspection

Interpreter
SLI
SLI
SLI
O1
O3
O2
Note SLI is a EDA tool organization issue, not a
programming issue.
  • Parts of the type system
  • Maintains type compatibility
  • Perform type evaluation heuristics

19
Type System
  • Compiled types are weakened in the CIL
  • Data types are abstracted from signal and ports
  • Algorithm for data type inference
  • If a component is not typed in the CIL
  • The SLI delayed the instantiation of the compiled
    internal object
  • Interpreted parts of the component are accessible
  • Verify if types are compatible when a
    relationship is set
  • If a compatible type is found, the SLI allocates
    the internal object and sets the relationship
  • If not, the link command is delayed until the
    types are solved
  • Approach similar to ML
  • However, full type resolution is not guaranteed

20
Using the Environment
21
CIL Script Example
  • load the AMRM component library
  • load ./libamrm.so
  • Entity mem_sys
  • Cache mem_sys.L1
  • Memory mem_sys.Mem
  • Queue mem_se.r_q
  • L1.upper_request link_to ms.r_q
  • Mem.request_in link_to ms.r_q
  • Tb add_stimuli 100 read 0x399
  • Tb add_tcl_callback ms.r_q.activity
    simulator.do_monitoring this
  • simulator run 200

mem_sys
L1
r_q
Mem
22
Design Example Statistics AMRM
23
Closing Remarks
  • Good IP-model composability requires
  • focus on system-level design tasks while using
    programming environments
  • minimization of reliance on programming details
    to accomplish these tasks.
  • Our approach is to use a split-programming model
    for dynamic composition
  • where the design is entered in an interpreted
    domain
  • while at the same time avoiding need to separate
    languages and description by using a layered
    software architecture and automatic generation of
    SLI wrappers.

24
Related Work
  • System level language
  • Process-port-signal architectural style (SystemC,
    SpecC)
  • Architecture description languages (ADL)
  • Component frameworks
  • Type systems (Ptolemy, Colif)
  • Distributed programming
  • Skeletons generated from interface definition
    language (Corba IDL)
  • Split-level programming
  • Separate composition concerns from programming
  • e.g. NS, or scripting
  • Wrapper generation (SWIG)
