Title: NMR%20Spectroscopy


1
NMR Spectroscopy
  • Relaxation Time
  • Phenomenon Application

2
Relaxation- Return to Equilibrium
t
t
z axis
x,y plane
Longitudinal
Transverse
0
0
1
1
t
t
2
2
E-t/T2
1-e-t/T1
8
8
Transverse always faster!
3
Relaxation
magnetization vector's trajectory The initial
vector, Mo, evolves under the effects of T1 T2
relaxation and from the influence of an applied
rf-field. Here, the magnetization vector M(t)
precesses about an effective field axis at a
frequency determined by its offset. It's ends up
at a "steady state" position as depicted in the
lower plot of x- and y- magnetizations.
http//gamma.magnet.fsu.edu/info/tour/bloch/index.
html
4
Relaxation
The T2 relaxation causes the horizontal (xy)
magnetisation to decay. T1 relaxation
re-establishes the z-magnetisation. Note that T1
relaxation is often slower than T2 relaxation.
5
Relaxation time Bloch Equation
  • Bloch Equation

6
Relaxation time Bloch equation
7
Spin-lattice Relaxation time (Longitudinal) T1
Relaxation mechanisms 1. Dipole-Dipole
interaction "through space" 2. Electric
Quadrupolar Relaxation 3. Paramagnetic
Relaxation 4. Scalar Relaxation 5. Chemical
Shift Anisotropy Relaxation 6. Spin Rotation
8
Relaxation
  • Spin-lattice relaxation converts the excess
    energy into translational, rotational, and
    vibrational energy of the surrounding atoms and
    molecules (the lattice).
  • Spin-spin relaxation transfers the excess energy
    to other magnetic nuclei in the sample.

9
Longitudinal Relaxation time T1
  • Inversion-Recovery Experiment

180y (or x)
90y
tD
10
(No Transcript)
11
T1 relaxation
12
(No Transcript)
13
Spin-spin relaxation (Transverse) T2
  • T2 represents the lifetime of the signal in the
    transverse plane (XY plane)
  • T2 is the relaxation time that is responsible for
    the line width.
  • line width at half-height1/T2

14
Spin-spin relaxation (Transverse) T2
  • Two factors contribute to the decay of transverse
    magnetization.
  • molecular interactions
  • ( lead to a pure pure T2 molecular effect)
  • variations in Bo
  • ( lead to an inhomogeneous T2 effect)

15
Spin-spin relaxation (Transverse) T2
180y (or x)
90y
tD
tD
  • signal width at half-height (line-width ) (pi
    T2)-1

16
Spin-spin relaxation (Transverse) T2
17
Spin-Echo Experiment
18
Spin-Echo experiment
19
MXY MXYo e-t/T2
20
Carr-Purcell-Meiboom-Gill sequence
21
T1 and T2
  • In non-viscous liquids, usually T2 T1.
  • But some process like scalar coupling with
    quadrupolar nuclei, chemical exchange,
    interaction with a paramagnetic center, can
    accelerate the T2 relaxation such that T2 becomes
    shorter than T1.

22
(No Transcript)
23
Relaxation and correlation time
For peptides in aqueous solutions the
dipole-dipole spin-lattice and spin-spin
relaxation process are mainly mediated by other
nearby protons
24
Why The Interest In Dynamics?
  • Function requires motion/kinetic energy
  • Entropic contributions to binding events
  • Protein Folding/Unfolding
  • Uncertainty in NMR and crystal structures
  • Effect on NMR experiments- spin relaxation is
    dependent on rate of motions ? know dynamics to
    predict outcomes and design new experiments
  • Quantum mechanics/prediction (masochism)

25
Application
26
(No Transcript)
27
Characterizing Protein Dynamics
Parameters/Timescales
Relaxation
28
NMR Parameters That Report On Dynamics of
Molecules
  • Number of signals per atom multiple signals for
    slow exchange between conformational states
  • Linewidths narrow faster motion, wide
    slower dependent on MW and conformational states
  • Exchange of NH with solvent requires local
    and/or global unfolding events ? slow timescales
  • Heteronuclear relaxation measurements
  • R1 (1/T1) spin-lattice- reports on fast motions
  • R2 (1/T2) spin-spin- reports on fast slow
  • Heteronuclear NOE- reports on fast some slow

29
Linewidth is Dependent on MW
  • Linewidth determined by size of particle
  • Fragments have narrower linewidths

30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
