Azimuthal Correlation Studies Via Correlation Functions and Cumulants

1
Azimuthal Correlation Studies Via Correlation
Functions and Cumulants
N. N. Ajitanand Nuclear Chemistry, SUNY, Stony
Brook
2
Outline

• Motivation
• Why Correlation studies ?
• Correlation Techniques
• Cumulant Method
• Correlation Function Method
• Correlation Results
• Compatibility with Flow, Jets, etc. ?
• What the Measurements tell us
• Summary

3
Why Study Correlations at RHIC
BRAHMS rapidity distribution
Substantial Energy Density is Produced at RHIC
Large Energy Density Substantial
Flow (Hydro limit) Possible Access to EOS
4
Reminder - Single Particle Distributions
Au Au Experiment
d Au Control Experiment
Preliminary Data
Final Data

• Striking difference between dAu and AuAu
  results.
• Cronin effect dominates in dAu
• High-pT Jet Suppression dominate in AuAu.

5
Jets at RHIC
Correlation Studies Provide a Complimentary Probe
for Possible QGP formation. (Very Important
Signal)
6
Important Tools for Correlation Studies

• Anisotropy Relative to the Reaction
• Cumulants
• Correlation Functions

7
Measuring Azimuthal Correlations
Reaction Plane Method
Anisotropy Flow if non-flow is demonstrably
small
8
Measuring Azimuthal Correlations
9
Application of Cumulant Method in PHENIX

• Cumulant analysis non-trivial PHENIX analysis
• Simulations performed using a toy model MC
  generator with PHENIX acceptance as input
• Results show that the
• v2 extracted is robust and
• acceptance corrections are
• well implemented

10
pT and ? dependence of v2
PHENIX Preliminary
PHENIX Preliminary
PHENIX Preliminary

• No apparent dependence of v2 on ? over the
  PHENIX ? coverage
• Finite v2 at high pT
• jets are correlated with low pT particles
•
  Reaction Plane !

11
Cumulant Analysis Centrality Dependence

• Anisotropy driven by eccentricity v2 scales
  with Npart

12
Cumulant Analysis Dependence on integral pT range
PHENIX Preliminary
pT

• No significant dependence on integral pT of
  reference

13
Scaling of the anisotropy

• The differential anisotropy scales with the
  integral anisotropy

14
Assorted Two-particle Azimuthal
Correlation Functions
Virtues

• Asymmetry related to jet properties
• Comparison of dAu and AuAu can reveal
  in-medium effects
• Flavor dependence can probe details of jet
  fragmentation
• etc

15
Leading Hadron Assorted Correlations
Leading Hadron

• Associated particle
• Meson
• Baryon

Correlation Function
16
PHENIX Setup
Azimuthal Correlations Using DCPC1PC3EMC
Tracks
mesons
baryons
Baryon Meson identification done using EMC TOF
17
Assorted Correlation Functions
Associated Mesons
PHENIX Preliminary
Associated Baryons
Noticeable differences in the asymmetries For
associated baryons and mesons
18
Assorted Correlation Functions

• Similar asymmetry trends for associated mesons
  baryons in dAu

• Dissimilar trends
• for associated mesons and baryons in AuAu

De-convolution of Correlation Function Necessary
19
De-convolution Ansatz

Harmonic Contribution
Fractional yield
20
Test of de-convolution via Simulations
Two source 3d simulation Simulation Model

• jets and flow.
• Poisson sampling
• jets per event
• particles per jet
• flowing particles per event
• Jets produced with effective jT and kT
• Avg. number of near and far-side jet particles
  equal
• Exponential pT distribution for particles

Correlation functions generated in PHENIX
acceptance
21
Typical fit to 3d sim correlation
Good overall representation of the correlation
function is obtained
22
Measuring Azimuthal Correlations
Relative to the Reaction Plane
23
Results From Simulations
Correlations Parallel-to-RP
Correlations Perpendicular-to-RP
Simultaneous Fit Recovers Jet and harmonic
properties 10
24
Reliable yield extraction is achieved
25
Data Hadron-Hadron correlation (pT(trig)gt3GeV/c)
See Shinichis Talk
Flavor composition study in progress -- revealing
26
Emerging Picture
The high energy-density matter responsible for
Jet Quenching drives elliptic flow
27
Summary / Conclusion

• Differential azimuthal anisotropy has been
  measured in PHENIX
• using cumulants.
• 2nd order v2 measured as a function of pT and
  centrality
• Scaling behavior demonstrated
• Low and high pT reference study suggest that
  jets are correlated with RP
• Assorted Correlation Functions
• Azimuthal Correlation functions obtained fro
  high pT leading hadrons in association with
  flavor identified partners.
• dAu significant asymmetry observed for both
  flavors
• Au Au Asymmetry significantly reduced for
  associated baryons
• De-convolution method for extraction of jet and
  flow parameters demonstrated
