A Systematic Review of Cross- vs. Within-Company Cost Estimation Studies

1
A Systematic Review of Cross- vs. Within-Company
Cost Estimation Studies
EEL 6883 Research Paper Presentation

• Barbara Kitchenham, Emilia Mendes, Guilherme
  Travassos
• IEEE TRANSACTIONS ON SOFTWARE ENGINEERING, VOL.
  33, NO. 5, MAY 2007

Mustafa Ilhan Akbas Omer Bilal Orhan
2
Outline

• Motivation
• Objective
• Method
• Results
• Conclusions
• Comments

3
Motivation

• Cross vs within-company cost estimation
• Early studies suggested calibrating general
  purpose cost estimation models and using only
  single-company data. BUT
• Time required to collect data
• Older projects may not reflect current tech
• Care is necessary in data collection
• Cross-company models are favored. BUT

4
Motivation

• 1999 Maxwell Within-company model is more
  accurate
• 1999 Briand Cross-company model could be as
  acc.
• 2000 Briand (with Maxwell data) Cross-comp.
  model can be as good as within data.
• 2002 Wieczorek Ruhe Same trend with Briand data
• 2005 Mendes - Same trend with another data set
• But
• 2000,2001Jeffrey - Within-company models are
  superior
• 2003 Lefley Shepperd - Within-company model is
  more accurate with Briand data
• 2004 Mendes, Kitchenham - Within-company models
  are significantly better

5
Motivation

• Applicability of cross company models to the
  effort estimate for single company projects
  contradicts.

6
Objective

• To determine under what conditions individual
  organisations are able to rely on
  cross-company-based estimation models
• To provide advice to researchers about the value
  of cross-company models.

7
Method

• Prepare a systematic review to determine factors
  that influence the outcome of the studies.
• Discuss different variations in experimental
  procedure

8
Research Questions

• For the review, the authors follow the
  approach of Kitchenham paper
• Procedures For Performing Systematic Reviews
• Point of view is formed by research questions
• Question one
• What evidence is there that cross-company
  estimation models are not significantly different
  from within-company estimation models for
  predicting effort for software/Web projects?

9
Research Questions

• Question two
• What characteristics of the study data sets and
  the data analysis methods used in the study
  affect the outcome of within-company and
  cross-company effort estimation accuracy studies?

• Question three
• Which experimental procedure is most appropriate
  for studies comparing within-company and
  cross-company effort estimation models?

10
Method Population, Intervention, Comparison,
Outcome

• Population Cross-company benchmarking data bases
  of Web and software projects
• Intervention Effort estimation models
  constructed from cross-company data, used to
  predict effort for single company projects
• Comparison Intervention Effort estimation models
  constructed from the within- company data only
• Outcome The accuracy of the cross- and
  within-company models

11
Search Strategy used for Primary Studies

• The search terms used are constructed using the
  following strategy
• Derive major terms from the questions by
  identifying the population, intervention and
  outcome
• Identify alternative spellings and synonyms for
  major terms. Consultations with field experts
  and/or subject librarians to identify the terms
• Check the keywords in any relevant papers we
  already have
• Use the Boolean OR to incorporate alternative
  spellings and synonyms Use the Boolean AND to
  link the major terms from population,
  intervention and outcome.

12
The main search terms

• Population software, Web, project.
• Intervention cross-company, project, effort,
  estimation,model.
• Comparison single-company, project, effort,
  estimation,model.
• Outcomes prediction, estimate, accuracy

13
Sample search string
AND (software OR application OR product OR Web )
AND (method OR process OR system OR technique
OR methodology OR procedure) AND(cross company
OR multi organisation OR within organisation OR
single company OR single-organisational OR
company-specific) AND(model) AND(effort OR
cost) AND(estimation OR prediction OR
assessment) Complete set of search strings is
given in the paper.
14
Initial Search Phase

• Identification of candidate primary sources based
  on authors knowledge, and searches of electronic
  databases using the derived search strings
• 1344 papers were retrieved, 25 represented the
  set of 10 known papers.
• Manual scan of titles and/or abstracts of all
  1344 papers

15
Databases/Journals Searched(from an earlier work)

• Electronic Databases
• INSPEC
• El Compendex
• Science Direct
• Web of Science
• IEEExplore
• ACM Digital library
• Individual journals (J) and conference
  proceedings (C)
• Empirical Software Engineering (J)
• Information and Software Technology (J)
• Software Process Improvement and Practice (J)
• Management Science (J)
• International Software Metrics Symposium (C)
• International Conference on Software Engineering
  (C)
• Evaluation and Assessment in Software Engineering
  (manual search) (C)

16
Secondary search phase

• Has two sub-phases
• To review the references of each of the primary
  sources to find candidate primary sources
  repeatedly until no further relevant document is
  found.
• To contact researchers who authored the primary
  sources in the first phase, or who could be
  working on the topic. Six researchers were
  contacted, no one was working in the area.

17
Study Selection

• Criteria for including a primary study
• Any study compared predictions of cross-company
  with within-company models based on analysis of
  single-company project data.
• Criteria for excluding a primary study
• If projects were only collected from a small
  number of different sources
• If models derived from a within-company data set
  were compared with predictions from a general
  cost estimation model.

18
Study Quality Assessment

• Part 1 The quality of the study itself.
• Has four top-level questions and an additional
  quality issue related to data set size. (Weight
  1,5)
• Is the data analysis process appropriate?
• Did studies carry out a sensitivity or residual
  analysis?
• Were accuracy statistics based on the raw data
  scale?
• How good was the study comparison method?

19
Study Quality Assessment

• Part 2 The quality of the provided reporting.
• Has four top-level questions.
• (Weight 1)
• Is it clear what projects were used to construct
  each model?
• Is it clear how accuracy was measured?
• Is it clear what cross-validation method was
  used?
• Were all model construction methods fully
  defined?

20
Quality

• Quality is used in 2 different ways
• as a score to ensure that results are not largely
  confounded with quality
• a source of difference indicator between studies.
• Quality of the study, not the model used.
• The overall quality is good.
• The factors varied between papers are size of
  data set, the method for predictions and
  performance of sensitivity analyses.

21
Data Extraction Strategy

• For each paper a reviewer was nominated at random
  as data extractor, checker, or adjudicator.
• Extractor Reads the paper and completes the
  form
• Checker Reads the paper and verify the
  correctness of the form
• Adjudicator If there is a disagreement between
  first two, then reads the paper and give the
  final decision.

22
Data Extraction Strategy

• Roles were assigned at random with the following
  restrictions
• No one should be data extractor on a paper he/she
  authored.
• All reviewers should have an equal work load (as
  far as possible).

23
Results Question 1
What evidence is there that cross-company
estimation models are not significantly different
from within-company estimation models for
predicting effort for software/Web projects?

24
Results Question 1

• The Studies are organized into 3 groups
• Cross-company models are not significantly
  different from within-company models. (4 out of
  10)
• Cross-company models are significantly worse than
  within-company models. (All accuracy statistics
  are better for within-co models) (6 out of 10)
• Studies that didnt undertake formal statistical
  testing inconclusive ( 2 of them, S1 and S7)

25
Results Question 1

• Four studies stating cross-company models are not
  significantly different. Uses leave-one-out,
  which biases positively towards within-company
  models.
• S6 is not independent (uses S2 data), so this
  cannot be used as an evidence in group1.
• S1 and S7 did not test the statistical
  significance. They are regarded as inconclusive
  and cannot be used as evidence either.

26
Results Question 2

• What characteristics of the study data sets and
  the data analysis methods used in the study
  affect the outcome of within-company and
  cross-company effort estimation accuracy studies?
• S10 contradicts that quality control makes cross-
  models as good as within-company models.
• S3 and S1 take a different view on quality
  control (ESA database) Quality control isnt
  reliable.
• S2 and S6 both agree that stringent quality
  control is applied to data collection.
• Quality control can not ensure cross-company
  models perform as well as within-company models.

27
Results Question 2

• No consistent evidence that the quality of the
  studies influences the results
• S2 and S3 have lower scores
• S10 has the highest quality score

28
Results Question 2

• Number of projects in the within-company models.
• There is noticeable difference in this number for
  S2, S3, S10 (median 63) and S4, S5, S8, S9
  (median 10) are compared.
• All the studies where within-company predictions
  were significantly better than cross-company
  predictions used small within-company data sets
  of fair quality.
• Similar pattern applies to the range of effort
  values for the entire database

29
Results Question 2

• Number of projects in the within-company models.
• No clear patterns were observed for the size
  metrics used, nor for the procedure used to build
  the within-company model

30
Results Question 2

• The relationship between within-company and
  cross-company projects.
• Tukutuku suggests, greater the difference between
  projects, less likely it is that the
  cross-company model will provide accurate
  predictions for single company project.
• There is no clear indication that the strength of
  the cross-company relationship is a major factor
  in determining whether cross-company prediction
  models are as good as within-company models.

30
31
Results Question 3

• Which experimental procedure is most
  appropriate for studies comparing within-company
  and cross-company estimation models?
• There is a large variation in the adopted
  procedures.

31
32
Results Question 3

• Studies aimed at assessing the conditions
  that would favor (or not) the use of a
  cross-company model should adopt the following
  procedure
• Use new within-co data sets independent of
  existing cross-co data sets
• Perform sensitivity analysis using residual
  analysis for non-regression-based methods and
  influence analysis for regression-based methods.
• Use regression analysis as the default model
  construction method.
• Use a stepwise approach on the cross-company data
  based on variables collected in within-company
  data set.
• Apply data transformations appropriate to the
  specific application
• Perform statistical tests based on the absolute
  residuals on the raw data scale.
• Report the residuals for each model or the effort.

33
Results Question 3

• Unable to provide definitive advice on cross
  validation but the authors believe that
  leave-one-out cross validation is not
  sufficiently stringent criterion.

33
34
Conclusions

• Some organizations would benefit from models
  derived from cross-company databases, while some
  others would not.
• The review is not able to conclusively explain
  the reason for this but shows some trends.

34
35
Conclusions

• Some trends
• In all cases where within-company datasets
  significantly outperformed, the datasets are
  small and cross validation method was not very
  stringent.
• Within-co data is a subset of cross-co in all
  studies which shows no significant difference
  between two.
• Similarly, the within-co data sets had been
  collected separately in half of the studies that
  shows within-company dataset is significantly
  better.

35
36
Conclusions

• Authors advice
• Consider the similarity of the projects in the
  cross-company dataset to your project and
  characteristics of your own company.
• Further research is required. To researchers
• Come to consensus about the appropriate
  experimental procedure for this type of study.
  (authors suggest their procedure ?)

36
37
Comments

• There were no other reviews on the same topic
  that have been previously conducted.
• The review criteria are not well-defined.
• Only 6 of 10 studies give results for Q1.
• No definitive results.
• There is no information about company size for
  some projects.
• If the projects undertaken in the company are
  similar to the dataset of cross-co model, it can
  be used. But deciding this similarity is another
  problem.
• The authors contributed to 3 of 10 studies.
• The paper cant go further away from the starting
  point.
