Title: Building a Better Backtrace: Techniques for Postmortem Program Analysis


1
Building a Better Backtrace Techniques for
Postmortem Program Analysis
  • Ben Liblit Alex Aiken

2
A Few Grim Realities
  • Programs fail post-deployment
  • Ship with known bugs
  • Users discover new bugs
  • Users are lousy testers
  • Never do the same thing twice
  • Wild variation in execution environment
  • Poor bug reporting, if any
  • Users bugs are the ones that really matter

3
Program Analysis for Pessimists
  • Assume prepare for postmortem analysis
  • Compile-time analysis, stashed away for later
  • Lightweight (deployable) instrumentation
  • Analyze failed program instances
  • Mix of automated / interactive tools
  • Not quite static analysis, not quite dynamic
  • Help humans find and fix bugs that matter

4
This Talk Reconstructing Execution Chronologies
  • Control flow decision history captures important
    properties
  • Fundamental questions
  • How in the world did I get here?
  • What happened just before this point?
  • How can I make this happen again?
  • Broader interest than just crashes

5
This Talk Reconstructing Execution Chronologies
  • Heavyweight (academic) approaches
  • Replay debugging
  • Program tracing
  • Lightweight (industrial) approaches
  • Examine stack trace in debugger
  • printf() debugging
  • Middleweight (our) approach
  • How might we have gotten here, given ?

6
This Talk Reconstructing Execution Chronologies
  • Heavyweight (academic) approaches
  • Replay debugging
  • Program tracing
  • Lightweight (industrial) approaches
  • Examine stack trace in debugger
  • printf() debugging
  • Middleweight (our) approach
  • How might we have gotten here, given ?

7
This Talk Reconstructing Execution Chronologies
  • Heavyweight (academic) approaches
  • Replay debugging
  • Program tracing
  • Lightweight (industrial) approaches
  • Examine stack trace in debugger
  • printf() debugging
  • Middleweight (our) approach
  • How might we have gotten here, given ?

8
This Talk Reconstructing Execution Chronologies
  • Heavyweight (academic) approaches
  • Replay debugging
  • Program tracing
  • Lightweight (industrial) approaches
  • Examine stack trace in debugger
  • printf() debugging
  • Middleweight (our) approach
  • How might we have gotten here, given ?

9
The Big Idea Gotten Here is Control Flow
Reachability
10
The Big Idea Gotten Here is Control Flow
Reachability
?
?
11
The Big Idea Gotten Here is Control Flow
Reachability
?
?
?
?
12
The Big Idea Gotten Here is Control Flow
Reachability
  • Interested in paths
  • How, not just yes/no
  • Transitive paths within one function
  • Multiple functions?
  • Matched call/return paths
  • This is a form of context free language
    reachability

?
?
?
?
?
?
13
Global Control Flow Graph
  • Split each function invocation site into
  • Call node
  • Return node
  • Edge call node ? function entry node
  • Edge function exit node ? return node
  • No edge call node ? return node

/
14
Global Control Flow Graph
call
return
entry
exit
call
return
15
Enforcing Matched Call/Return
  • Label call and return edges
  • ( for first call edge ) for return
  • and for next sites edges
  • and for next
  • In practice, (i and )i for invocation site i
  • Execution paths obey a context free language of
    matched parentheses

16
Global Control Flow Graph
call
return
(
)
entry
exit


call
return
17
Variations in Matching Grammar
()()()(())
  • Complete execution
  • All calls returns must be matched

18
Variations in Matching Grammar
()()()(())
  • Aborted execution
  • Some calls without returns
  • We use a variant of this

19
Variations in Matching Grammar
()()()(())
  • Arbitrary subinterval of execution
  • Prefix containing unmatched returns
  • Suffix containing unmatched calls
  • Used by context-sensitive points-to analyses

20
Implementation Notes
  • Similar to transitive graph search
  • Use a work list to incrementally extend frontier
  • Forward from a or backward from ?
  • Transitively adding flow edges is one case
  • Several additional cases for calls/returns
  • Complexity
  • O(N3) for arbitrary grammar and graph
  • O(E) for our analyses (and many others)

21
Case 1 Transitive Flow
22
Case 2 Seeding a New Function
)i
23
Case 3a Bridge Discovery
)i
(i
24
Case 3b Crossing Known Bridge
)i
(i
25
Case 4 Unmatched Call
(i
26
Reconstruction WithCrash Site Only
  • Work backward from crash site
  • Remember why each edge is added
  • Record justifications in route map
  • route(x, z) r1, , rn
  • ri cross from x to y, then see route(y, z)
  • x and y must be adjacent one of four cases
  • route(a, ?) defines possible chronologies

27
Reconstruction WithCrash Site Only
  • Case 4 (unmatched call) defines stack trace
  • Unmatched parens ()()()(())
  • Stack trace (
  • But we probably have a specific stack trace in
    mind

28
Reconstruction WithCrash Site Stack Trace
  • S vector of call edges
  • Build S 1 clones of global flow graph

29
Reconstruction WithCrash Site Stack Trace
  • S vector of call edges
  • Build S 1 clones of global flow graph
  • Two types of call edge
  • (i can match )i
  • Stays on same layer
  • ci are unmatched
  • Only way to next layer
  • Determined by S

c6
c3
c14
30
Reconstruction WithCrash Site Stack Trace
  • Possible histories
  • Start at a on top layer
  • End at ? on bottom layer
  • route(áa, 0ñ, á?, Sñ)
  • Backward, not forward
  • more deterministic
  • Complexity
  • O(E) work, S 1 times

c6
c3
c14
31
Reconstruction WithCrash Site Event Trace
  • V vector of trace nodes
  • Use V 1 layered clones, as before
  • Must report event when crossing trace node
  • On each layer, knock out all trace nodes but one
  • On bottommost layer, no trace nodes at all!
  • Further restricts set of possible paths
  • Complexity O(EV)

32
Reconstruction WithWhatever Youve Got Handy
  • Stack trace event trace
  • Multiple event traces
  • Ambiguous traces
  • Incomplete event trace
  • Recent-branch registers
  • Program counter sampling
  • Finite state machine of your choosing

33
Practical Considerations
  • Dynamic dispatch / function pointers
  • Usual static techniques (points-to,
    receiver-class, etc.)
  • Event tracing can help
  • Note stack trace is never dynamic
  • Interactivity
  • Backward analysis is ideal most bugs are close
    to crash
  • FIFO work list, demand-driven search
  • Deterministic versus non-deterministic state
    machines
  • Summarization / visualization
  • Dominator tree walk-back with progressive
    disclosure

34
Summary and Conclusions
  • Program analysis in an imperfect world
  • Post-crash unique challenges / leverage points
  • CFL path recovery as basis for analysis
  • Efficient, demand-driven, adaptable
  • Future work
  • Adaptive annotation to fill in gaps
  • Leveraging multiple runs
  • Data value modeling
