Improving life and endoflife care in advanced neurological conditions: Spasticity Management

1
Improving life and end-of-life care in advanced
neurological conditionsSpasticity Management

• Rory OConnor MD
• Consultant Physician in Rehabilitation Medicine
• Airedale General Hospital

2
Overview

• What is spasticity?
• Epidemiology
• Current spasticity treatment
• Pharmacotherapy

3
What is Spasticity?
4
Spasticity Diagnosis

• Central nervous system lesion
• Motor and sensory loss
• Increased muscle tone
• Especially rate dependent increase in tone
• Provoked or unprovoked spasms

5
Consequences of Spasticity

• Contractures
• Skin breakdown
• Pain and discomfort
• Impairments
• Restricted participation
• Caregiver strain

6
Spasticity
7
What is Spasticity?
8
Supraspinal Input

• Supraspinal or higher spinal lesion results in a
  net loss of inhibition below lesion
• Dorsal Reticulospinal tract ( - )
• Medial Reticulospinal tract ()
• Corticospinal tract ()
• Vestibulospinal tract ()
• Coerulospinal tract ()

9
Spinal Input

• Reflex disinhibition
• Nociceptive reflex flexor withdrawal
• Propriospinal phasic reflex tendon reflex
• Primitive reflex release
• Cutaneous extensor plantar response
• Proprioceptive positive support reaction
• Tonic stretch reflex

10
Tonic Stretch Reflex

• No reflex activity in response to muscle stretch
  in a relaxed normal person
• Mediated via 1a afferents from muscle spindle
• Length dependent
• Reflex inversely related to muscle length

11
Loss of Supraspinal Input

• Uncontrolled efferent drive
• Hemiplegic posture
• Associated reaction
• Failure to inhibit spread of motor activity
• Disordered muscle control
• Co-contraction

12
Neurotransmitters

• Gamma amino butyric acid (GABA)
• Inhibition of motor neurons
• Glutamate
• Excitation of motor neurons
• Alpha-2 adrenergic
• Spinal interneuron inhibition

13
Soft Tissues in Spasticity

• Muscle biochemical changes thixotropy
• Stiffness
• Contracture
• Fibrosis
• Atrophy
• Tendon changes
• Joint changes

14
What is Spasticity?

• An increased tonic stretch reflex resulting in
  velocity- and length-dependent hypertonia due to
  abnormal spinal processing of proprioceptive input

15
Epidemiology of Spasticity
16
Epidemiology of Spasticity

• Spinal
• Traumatic spinal cord injury 60
• Non-traumatic spinal cord injury
• Supraspinal
• Stroke 20
• Multiple Sclerosis 30
• Cerebral Palsy 50
• Traumatic Brain Injury 19

17
Current Spasticity Treatment
18
Current Spasticity Treatment

• Reduction of noxious stimuli
• Multidisciplinary programme
• Pharmacotherapy
• Generalised, regional, focal
• Surgery

19
Spasticity Treatment

• Cost may inhibit decision to treat
• Time-consuming and multidisciplinary
• Expensive equipment and seating systems
• But untreated spasticity
• May mask voluntary movement
• Result in permanent contractures
• Window of opportunity may be small

20
Reduction of Noxious Stimuli
21
Reduction of Noxious Stimuli
22
Reduction of Noxious Stimuli
23
Reduction of Noxious Stimuli
24
Reduction of Noxious Stimuli
25
Reduction of Noxious Stimuli
26
Multidisciplinary Teamwork

• Careful positioning throughout 24-hours
• Maintaining muscle length
• Reducing deformity
• Regular stretching
• Splinting and orthoses
• All act to reduce the tonic stretch reflex

27
Seating
28
Pharmacotherapy
29
Pharmacotherapy Follow-up

• No point in pharmacotherapy without
• Avoidance of precipitating factors
• Adequate therapy/splinting/orthosis
• Appropriate seating review

30
Pharmacotherapy

• Generalised
• Oral baclofen, dantrolene, tizanidine
• Regional
• Intrathecal baclofen or phenol
• Focal
• Intramuscular botulinum, phenol neurolysis

31
Generalised
32
Generalised

• Reduce excitatory neurotransmitters
• Tizanidine
• Facilitate inhibitory neurotransmitters
• Baclofen
• Inhibit skeletal muscle contraction
• Dantrolene

33
Regional
34
Intrathecal Baclofen

• Test dose to screen for effectiveness
• Non-destructive and reversible
• Dose titratable
• Reduction of side effects compared to oral
  baclofen
• 1 of oral dose

35
Intrathecal Pump

• Abdominal pocket for pump
• Intrathecal catheter tunnelled subcutaneously

36
Intrathecal Phenol

• Severe lower limb spasticity affecting care,
  positioning or causing pain
• Generalised treatments ineffective or causing
  side effects
• Other regional and focal treatments inappropriate
• Bowel, bladder and sexual dysfunction

37
Modified Right Lateral Position
30o
Spinal fluid
38
Modified Right Lateral Position
39
Injection of Phenol
40
Injection of Phenol
Spinal fluid
41
Injection of Phenol
42
End Result
Spinal fluid
43
Unexpected Findings
44
Final Outcome
45
Focal
46
Phenol Nerve Blocks

• Non-selective denervation
• Protein denaturation
• Destruction of nerve axons
• Effect apparent immediately and diminishes with
  time
• Injection of mixed nerves will cause anaesthesia
  as well as paralysis

47
Commonly Blocked Nerves

• Musculocutaneous
• Biceps brachii, brachialis
• Obturator
• Hip adductors
• Sciatic
• Hamstrings
• Posterior tibial
• Gastrocnemius, soleus

48
Botulinum

• Botulinum exotoxin
• Types A and B available commercially
• Intramuscular injection
• Endocytosed in pre-synaptic neuron
• Cleaves acetylcholine
• Neuromuscular junction function inhibited
• Axon sprouting terminates effect 2-6 months

49
EMG Guidance
50
Botulinum - FDS
51
Botulinum - FDP
52
Botulinum - Hypersalivation
53
Botulinum - Hypersalivation
54
Take Home Message I

• Spasticity limits activities in two ways
• Inhibiting muscle power and coordination
• Masking profound muscle weakness
• But anti-spasticity agents produce muscle weakness

55
Take Home Message II

• Spasticity is the result of
• Neural
• Non-neural

abnormalities
56
Take Home Message III

• Multidisciplinary treatment must comprise
• Neural
• Non-neural

modalities
