Barton Springs Zone: Basis for a Protection Strategy DRAFT

1
Barton Springs Zone Basis for a Protection
StrategyDRAFT
Watershed Protection and Development Review
Department

• July 14, 2006

2
Purpose

• Present information on Barton Springs Zone land
  use development patterns
• Grandfathered Properties Other Undeveloped Land
• Open Space
• Existing Developed Area
• City of Austin Jurisdiction and Beyond

3
Barton Springs Zone (BSZ)
4
BSZ All Jurisdictions
Land Use
5
BSZ City of Austin Jurisdiction
Land Use
6
BSZ City of Austin Jurisdiction
Undeveloped Parcel Analysis
7
BSZ City of Austin Jurisdiction
Undeveloped Parcel Analysis
8
Potentially Grandfathered
9
(No Transcript)
10
Barton Creek ABC West
Barton Creek Section O
Barton Creek Section N
Lantana
Autumn Woods Section 2
gt 50 Acres
11
BSZ Land Use for COA Jurisdiction
Potentially Grandfathered 2,727 ac.
SOS-Level Development Agreement 2,202 ac.
4
3
SOS (Unplatted) 10,769 ac.
Single-Family Residential 20,944 ac.
16
31
Undeveloped
8
Commercial/ Multi-Family 5,256 ac.
31
Open Space 21,483 ac.
7
Roads 4,954 ac.
12
BSZ Land Use for All Jurisdictions
Single-Family Residential 46,234 ac.
19
Commercial/ Multi-Family 8,234 ac.
3
Roads 8,823 ac.
4
60
Undeveloped 143,795 ac.
14
Open Space 32,685 ac.
13
Land Use for Entire Barton Springs Zone
Potentially Grandfathered
14
BSZ Jurisdictions
Travis County
(2.8)
(3.7)
City of Austin
(0.4)
Dripping Springs
(28.5)
(29.7)
(0.3)
Blanco County
Hays County
(1.4)
(30.7)
(1.2)
(0.8)
(0.4)
15
Barton Springs Zone Trends Impervious Cover
16
Barton Springs Zone Trends Population
17
Barton Springs Zone Trends Development
18
Barton Springs Zone Trends Vehicle Miles Traveled
19
Identify strategies for

• Existing Development
• How do we improve water quality with
  redevelopment?

• Open Space
• What is our future strategy for open space?
• How do we spend the bond package money?

• Undeveloped Land
• How do we minimize the impact of grandfathered
  tracts?
• How do we best work with other jurisdictions in
  the BSZ?

20
Pollutant/Problem Types

• Nutrients
• Pesticides
• Herbicides
• Hydrocarbons
• Flow Regime
• Sediment
• Bacteria

21
Pollutant Sources

• Impervious cover
• Pervious areas
• Infrastructure
• Activities
• Land Uses
• Fauna

22
Pollutant SourcesImpervious Cover

• Rooftops
• Roadways
• Parking lots
• Driveways
• Sidewalks
• Trails

23
Pollutant SourcesPervious Areas

• Residential landscaping
• Commercial landscaping
• Golf course landscaping
• Sparse vegetation
• Compacted soils
• Erosion/channelized flows
• Rangeland
• Agriculture

24
Pollutant SourcesInfrastructure

• Closed runoff conveyance
• Open runoff conveyance
• Wastewater lines
• Wastewater lift stations
• Septic/on-site wastewater systems
• Underground storage tanks

25
Pollutant SourcesActivities

• Site construction
• Spills
• Dumping
• Vehicle washing
• (soap)

26
Pollutant SourcesLand Uses

• Auto-related businesses
• Convenience stores, food take-out (litter)
• Other hotspot businesses

27
Pollutant SourcesFauna

• Pets
• Livestock
• Wildlife
• Illegal
• Camping

28
Water Quality Solutions

• Land Use
• Site Design
• Prevention
• Construction
• Site Treatment
• In-Channel

29
Land Use

• Regional Planning
• Natural Area Preservation
• Natural Area Restoration

30
Site Design

• Stream Buffers/CEF Setbacks
• Conservation Development
• Low-Impact Site Design

31
Prevention

• Education and Outreach
• IPM/Landscaping Practices
• Proper Waste Disposal Practices
• Hotspot Facility Inspections
• Wastewater Infrastructure OM

32
Construction

• Construction Phasing
• Erosion and Sedimentation Controls
• Construction Inspection

33
Site TreatmentRoof

• Green Roof
• Rainwater Harvesting
• Roof Disconnections

34
Site TreatmentLandscaping

• Compost Soil Amendments
• Rain Gardens
• Tree Cover/
• Reforestation

35
Site TreatmentLandscaping

• Impervious Cover Removal
• Impervious Cover Disconnection

36
Site TreatmentPavement

• Bioretention
• Smart Growth Road Dimensions
• Pervious Road Parking Systems

37
Site TreatmentConveyance

• Open/Daylighted Drainage
• Spills Response

38
Site TreatmentEnd of Pipe

• Recharge Enhancement Structure
• Stormwater Ponds
• Retention-Irrigation
• Wet Pond
• Sedimentation/Sand Filtration
• Extended Detention

39
Site TreatmentEnd of Pipe

• Pond Inspection Maintenance
• Non-Erosive Outfalls

40
In-Channel

• Natural Channel Armoring

Bear Creek Tributary at Barrel Bend Project
Before
After
41
Current WPDR Actions

• Structural WQ Retrofits
• Barton Hills Apartments sand filter retrofit.
• Lundelius tract retrofit.
• WQ Education
• Green Neighbor Program Barton Hills and Circle C
• Pesticide reduction campaign, Spring 2007
• Fertilizer leachate study
• Other
• Retention-irrigation control monitoring
• Land use pollutant load model
• Pond database upgrade
• Coal tar pavement sealant ban

42
Structural WQ Retrofits

• BSZ Retrofit Master Plan (1995).
• Lundelius tract retrofit.
• Barton Hills Apartments sand filter retrofit.

43
Structural WQ Retrofits
44
Selected Studies of theBarton Springs Zone

• BSZ Retrofit Master Plan (1995).
• CRWR Parsimonious Model (1996).
• BSZ Scientific Inventory (2002).
• Groundwater Tracing Study (2004).
• Effluent-Irrigated Golf Course Report (2005).
• Regional Water Quality Protection Plan (2005).
• Barton Springs Water Quality Trend Analysis
  Draft (2006).

45
Selected Studies of theBarton Springs Zone

• Barton Springs Zone Retrofit Master Plan (Loomis,
  1995).
• Parsimonious Model for Simulation of Flow and
  Transport in a Karst Aquifer (Barrett
  Charbeneau, 1996).
• Barton Springs Zone Scientific Inventory (COA
  WPDR, 2002).
• Groundwater Tracing Study of the Barton Springs
  Segment of the Edwards Aquifer, Southern Travis
  and Northern Hays Counties, Texas (COA WPDR
  BSEACD, 2004).
• Preliminary Report on Storm Water Runoff from
  Effluent-Irrigated Golf Courses (COA WPDR, 2005).
• Regional Water Quality Protection Plan for the
  Barton Springs Segment of the Edwards Aquifer and
  Its Contributing Zone (Naismith Engineering,
  2005).
• Update of Barton Springs Water Quality Temporal
  Trend AnalysisDraft (COA WPDR, 2006).

46
Potential Preservation Restoration
StrategiesBy Land Use
47
Single-Family Residential (31)
48
Strategies forSingle-Family Residential

• Education and outreach
• Low Impact Development (LID) retrofits
• Water quality pond retrofits
• Creek restoration

49
Multi-Family and Commercial (8)
50
Strategies forMulti-Family Commercial

• Education and outreach
• Low Impact Development (LID) retrofits
• Large-scaled pond retrofits
• Enhanced pond inspections enforcement
• Redevelopment opportunities (e.g., TOD)
• Mitigation land from redevelopment

51
Transportation and ROW (7)
52
Strategies forTransportation ROW

• Water quality control retrofits
• Collaborate with TxDOT Counties
• Reduced vehicle trips

53
Open Space (31)
54
Strategies forOpen Space

• Retrofit for increased recharge, pollution
  removal
• Rangeland management
• Public education

55
Undeveloped (23)
56
Strategies forUndeveloped Land

• Headwaters buffer zone enhancements per Regional
  WQ Plan
• Land acquisition conservation easements
• Grandfathered properties
• Eliminate grandfathering claims where invalid
• Buy down development rights
• Upgrade structural controls buffers
• Conservation development/clustering
• Mitigation/Transfer of Development Rights
• Improved construction-phase controls
