Title: Presented by Sgt' Scott Hilden


1
Home Security and Burglary Prevention
  • Presented by Sgt. Scott Hilden
  • Canton Police
  • Crime Prevention

2
Todays Topics
  • The Law
  • Burglary Statistics
  • Exterior Protection
  • Landscaping
  • Lighting
  • Doors
  • Locks
  • Windows
  • Alarms
  • Vacation Checklist
  • Personal Safety at Home

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Michigan Law
  • Home Invasion 1st degree- 20 year Felony, and or
    up to 5,000 fine
  • Intend to commit a larceny, felony or assault and
    one of the following
  • Possesses a dangerous weapon
  • An individual is lawfully present
  • Home Invasion 2nd degree- 15 year Felony, and or
    up to 3,000 fine
  • Intend to commit a larceny, felony or assault

12
Michigan Law
  • Home Invasion 3rd degree- 5 year Felony, and or
    up to 2,000 fine
  • Commits a misdemeanor
  • Is in violation of one of the following
  • Probation terms
  • Parole
  • PPO
  • Condition of bond or bail
  • Pretrial release conditions

13
National Statistics
  • 2,153,464 burglaries nationwide in 2003
  • 65.8 are residential
  • 62 of residential break-ins occur during
    daylight
  • 5,899 break ins per day
  • The rate of burglary in the United States was
    740.5 burglary offenses per 100,000 inhabitants

14
Local Statisticsall burglaries
  • 2001 265
  • 2002 297
  • 2003 291
  • 2004 266
  • 2005 343
  • National average in 2003 was 740.5 per 100,000,
    Canton is 403.5 per 100,000 !

15
Points of Entry
Source Simon Hakim-Temple University
16
(No Transcript)
17
(No Transcript)
18
Burglary Offenses March-June 2005
19
(No Transcript)
20
Exterior Protection
21
Lighting
  • Around the House
  • Use Photocell and Motion sensitive lights
  • Photo cell will automatically illuminate upon
    darkness
  • Motion light can startle an intruder and is not
    intrusive to neighbors
  • Protect all sides of the house
  • Over entry doors
  • Carports and Garages

22
Motion Sensitive Flood Lights
23
Good Lighting
Bad Lighting
24
Landscaping
  • Can conceal an intruder as he attempts entry into
    a window or door
  • Could also provide cover for the criminal as he
    lies in wait for the homeowner
  • Intruder looks for property they can get in and
    out of quickly
  • Ideal target is surrounded by large hedges and
    shrubs

25
(No Transcript)
26
(No Transcript)
27
Landscaping Burglary Prevention
  • Trim shrubbery and trees so that doors and
    windows are visible
  • Prune trees so they cannot be climbed up to a
    second floor (6 feet from the ground)
  • Shrubbery and bushes near walkways/driveways
    should be no taller than 4 ft

28
Landscaping Burglary Prevention
  • Place large gauge gravel on the ground near
    windows to create noise when walked on
  • Plant spiny (thorny) plants along fences and
    under windows
  • Can be as effective as barbed wire
  • Discourages the burglar

29
Landscaping that offers concealment
30
Concealment at front windows and door
31
Landscaping that offers no concealment
opportunities
32
Which home would you burglarize?
33
Limit Access
  • Fences can prevent burglars from carrying away
    large items if gates are locked
  • Store ladders and tools in locked garage or shed
  • Sheds, wood piles and other structures should not
    assist in gaining access to the roof

34
Access to the roof made easy
35
Doors
  • Exterior doors should be made of solid core wood
    or steel 2 ¾ inch thick
  • Hollow core or wood panel doors can be easily
    broken
  • Exterior doors should not have glass within 40
    of the lock
  • Should fit its frame properly no more than 1/8
    inch clearance

36
Why is this door vulnerable?
37
(No Transcript)
38
Doors
  • Door should be securely anchored to the frame
  • Frame often needs reinforcing otherwise it can be
    easily kicked in
  • Entry doors should have a wide angle viewer
  • If your door swings outward the hinge pins will
    be exposed. Replace with non-removable pins

39
(No Transcript)
40
(No Transcript)
41
Interior Garage Door
  • Solid core wood or metal and have a good quality
    deadbolt
  • This door should meet the same security
    requirements as a main entry door
  • Doggie doors can be a means of access for a
    burglar

42
Strike Plates
  • Use heavy duty strike plate installed with at
    least a 3 screw
  • Screws must be long enough to reach the stud
    behind the door jamb
  • Use a high security strike plate and box on wood
    frame doors

43
Screws should be long enough to reach the stud
behind the frame
44
This is not a Lock!!
45
Locks
  • Key-In-Knob Lock
  • Easily defeated
  • Wrench the knob with hands or vice grips
  • Use a credit card to slip the spring bolt
  • Simple kick the door

46
(No Transcript)
47
Deadbolt Lock
  • Can provide good protection for an entry door
  • When the key is turned the lock mechanism slides
    a strong metal bolt from the door to the frame
  • Bolt should be minimum of 1 throw
  • Strike plate connected by a minimum of 3 screws

48
Deadbolt Locks
  • The cylinder should have a steel guard-a ring
    around the key section
  • The cylinder guard should be tapered or rotate
    around the key section (if twisted) to prevent
    wrenching

49
(No Transcript)
50
Garage Doors
  • Forgetting to close the garage door is often the
    biggest problem
  • Keep garage door locked at all times
  • Overhead track operated doors are best secured
    with electronic door openers
  • Secure the garage door with a case hardened lock
    in the track

51
Sliding Glass Doors
  • Often can be lifted out of the track
  • Insert screws in the top of the track to prevent
    lifting
  • Install auxiliary lock such as a Charlie Bar or
    use a broom stick handle in the lower track

52
(No Transcript)
53
(No Transcript)
54
Double Hung Windows
55
Double Hung Windows
  • Most common windows found in homes
  • Consist of two sashes that slide vertically
  • Factory locks are easily jimmied or pried open
  • A simple way to secure-drill a 3/16th hole from
    the inside window sash three quarters of the way
    thru the outside sash at a slight downward angle.
    The insert a nail or pin to secure

56
(No Transcript)
57
Double Cylinder Deadbolt Lock
  • This lock is often used on doors with glass
    panels or on other doors as well
  • Can only be opened with a key from either side
  • The key should be kept near the door but not
    reachable from the glass panel
  • Some states prohibit this type of lock in
    residence due to fire safety reasons

58
Keys
  • If you move into a previously lived in home have
    all the locks re-keyed
  • Keep your keys secured both in your home and when
    out in public
  • When keys are given to valets or service
    departments only give the car key
  • Dont hide a key under the mat or flowerpot

59
A Cat Burglar caught red handed!!!
60
Windows
  • The primary interest in securing windows is to
    eliminate the means of entry by prying open or
    breaking a small area of glass to reach a single
    latch

61
Horizontal Sliding Glass Windows
  • Similar to a doorwall or sliding glass door
  • Can often be lifted from the track
  • Insert screws to prevent lifting off track
  • Piece of wood or dowel in the track can prevent
    sliding
  • Locking bar (Charlie Bar)

62
(No Transcript)
63
(No Transcript)
64
Basement Windows
  • Are particularly vulnerable to intrusion
  • Put two or three metal straps or bars across
    window to improve security
  • Replace with glass block windows
  • Must still be able to exit in case of emergency

65
(No Transcript)
66
Security Bars or Grills
  • Ornamental security bars or grills covering the
    inside and outside of windows can be an effective
    way to keep burglars out
  • Must be easy to open in the event of a fire
    emergency so it does not trap the occupant
  • Should never be installed on windows of sleeping
    rooms

67
Alarm Systems
  • Burglar alarms can provide valuable protection if
    installed properly and above all used responsibly
  • Have three primary elements sensors, controls,
    and annunciation

68
Important things to consider in an Residential
Alarm System
  • Must have a reliable power supply with emergency
    batter backup
  • Visual or audible signal to alert homeowner of
    system malfunction
  • Should be tamper resistant
  • Meet local standards, regulations or codes

69
Important things to consider in an Residential
Alarm System
  • Homeowner should be thoroughly knowledgeable in
    the operation of the system
  • Minimum 1 yr warrant from installer and
    manufacturer
  • Employees from the alarm installation company
    should be bonded
  • Check references when choosing an alarm company

70
(No Transcript)
71
Canton False Alarm Ordinance
  • 3 false alarms permitted per year
  • 1 offense we mail out warning letter
  • 3rd offense second letter requesting correction
    of the problem and offer to assist
  • Subsequent offenses can be cited if no corrective
    action is taken
  • Misdemeanor 90 days in jail and/or 500 fine

72
House Numbers
  • House or street numbers should be easily visible
    from the street
  • Emergency responders can locate your home quickly
  • Use numbers made of reflective material
  • 6 inches in height
  • Place under a light near the front door or on the
    garage
  • Paint the numbers on the curb

73
Safes
  • Fire Safes used to keep records and vital
    documents from being destroyed in the event of a
    fire
  • Money Safes designed to be resistant to
    burglary and a deterrent to robbery. They are
    designed to withstand attacks by tools, torch, or
    explosives

74
New Technology-Biometric Finger Scanner
75
Vacation Checklist
76
Vacation Crime Prevention Checklist
  • Discontinue mail and newspaper deliveries
  • Inform neighbors youll be gone and ask them to
    watch the house
  • Leave contact information with a friend or
    neighbor
  • Park a car in your driveway and have it
    periodically moved

77
Vacation Crime Prevention Checklist
  • Arrange to have your snow shoveled or during
    summer your lawn cut
  • Leave blinds, curtains and shades in normal
    positions
  • Have a neighbor put out your garbage cans on
    collection day
  • Place lights, television and radio on timers to
    go on and off at appropriate times

78
Personal Safety at Home
  • Dont flaunt valuables
  • Be wary of what you display in your trash
  • Leave inside and outside lights on if you are
    returning home after dark
  • Pull into your garage and shut the door before
    exiting your vehicle
  • Scan your home immediately upon entry

79
Personal Safety at Home
  • Dont admit strangers
  • Secure all firearms with gun locks
  • If you have been burglarized do not enter the
    home, call the police immediately from a
    neighbors (the burglar may still be inside)
  • If you encounter a burglar do not prevent them
    from fleeing. Get out and call the police.

80
THE END
Write a Comment
User Comments (0)
About PowerShow.com
