Offshore Wind Power: The European Experience

1
Offshore Wind Power The European Experience

• Bill Bulpitt, Mary Hallisey Hunt, Susan Stewart
• Georgia Tech Strategic Energy Institute
• Southeast Regional Offshore Wind Power Symposium
• February 27, 2007

2
Offshore Wind Deployment in Northern Europe

• Two phases
• Series of small demonstration projects built in
  sheltered shallow water (1991 1999)
• Larger projects of increasingly commercial nature
  built in more challenging situations (between
  2000 present)

3
European Experience
www.offshorewindenergy.org
red (built Mm windturbines), purple(built
small windturbines), blue(under construction),
grey(planned)
4
European Wind Farms
5
(cont.) European Wind Farms
6
Offshore Wind Development Drivers

• Europe imports 50 of energy needs
• Projected to be 70 within two decades if changes
  not implemented
• Looking for indigenous energy source free of
  social economic disadvantages associated with oil
  and gas
• Kyoto

7
Onshore Market Limited

• Less land available
• Greater and more consistent resource available
  offshore

8
European Policy Instruments

• Feed in Tariff
• Bidding
• Green Certificates
• Green Pricing

9
Main Instrument Feed-in-Tariff

• Guaranteed (by law) power purchase price to be
  paid by local utility
• Ex. Germany
• Fixed Tariff 6-8 cent/kWh, depending on
  location (offshore up to 9 cent/kWh)
• Pool price 3-4.5 cent/kWh
• Wind costs 5-6 cent/kWh _at_ 6-7 m/s
• Utilities have to pay feed-in tariff and have to
  connect

10
Instrument Fixed Quotas Combined with Green
Certificate Trading

• Government introduces fixed quotas for power
  retailers
• Producers of renewable power receive certificates
• Retailers must buy certificates
• A market for renewable power is created!
• Netherlands, Sweden, UK, etc.
• (Similar to Renewable Energy Portfolio)

11
Policy Drivers

• Shared agenda across governments departments
  instrumental in successful policy development
• Stable framework supported start-up incentives
  for projects and encouraged investment

12
Why Offshore Wind Advanced

• Ultimately, onshore wind will face practical and
  social limits
• Potential capacity factor that can be achieved is
  much greater offshore
• Offshore incentives and government pressure to
  fulfill alternative energy targets

13
Motivations Vary by Country

• Denmark
• Germany
• United Kingdom
• Ireland
• Belgium

14
Policy Synthesis

• Danish experience most advanced 20 of
  electricity generated from wind
• Other countries proceeded in parallel, not
  replicating Denmark, but meeting their own
  socio-political demands
• As yet, no formal attempt to benchmark
  experiences in offshore wind, but some common
  themes emerging

15
Common Themes in Offshore Wind

• Stable policy framework
• Provides incentive and encourages investment
• Plan for identifying strategically important
  locations
• Strategic Environmental Assessment (SEA)
  Directive was established by the European Union
  in 2001
• Initial efforts need targeted support measures
  from government
• Absence of specific market for offshore wind has
  not prevented offshore wind projects, but it has
  caused delays

16
Danish Offshore Wind - Key Environmental Issues

• Study based on 8 years of scientific research at
  two largest offshore wind farms in worlds (Horns
  Rev Nysted)
• Pre and post construction studies conducted

17
Overview of the Danish Monitoring Program

• Sea mammals harbor porpoises and seals
• Fish
• Birds
• Hydrography
• Coastal effects
• Artificial reef effects

• Socioeconomics
• Community acceptance
• Noise emissions
• Temp. gradients around cables
• Electromagnetic fields
• Benthic fauna
• Viewshed

18
Results of Danish Study

• Attitudes in neighboring coastal communities
  largely positive
• Support growing as pre-construction worries of
  drop in tourism have evaporated as people
  realized this had not occurred after the wind
  turbines were in view
• Virtually no negative impacts to birds, marine
  mammals or fish
• Strong avoidance behavior of birds

19
(No Transcript)
20
European Offshore Wind Project Detail
21
Arklow Bank Arklow, Ireland
22
Project Statistics

• Turbines 3.6MW x 7
• Depth of piles 35-45m
• Weight of piles 280tonne (5m diameter)
• Weight of turbines 290tonne
• Blades 50.5m, 15tonne each
• Nacelle/Hub height 73.5M
• Rotational speed 8.5 15 rpm
• Distance offshore 10km
• Onshore cable 5km
• Voltage 38kV distribution connected
• Rotor diameter 104m gt soccer pitch area
• 25MW serves 16,000 households (Irish)
• Sandbank 24 miles long 2.5 wide, depths 3 -20 m
• Largest commercially operating turbines installed
  to date
• Largest consented offshore site todate

Source McAdam
23
Arklow Bank Site Details

• 60 km south of Dublin
• 7 - 12 km from coast
• 24 km long 2.5 km wide

Arklow
24
Arklow Cable Routing
Source Airtricity
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Arklow Sand Characteristics
Source Airtricity
34
(No Transcript)
35
(No Transcript)
36
Arklow Turbine FoundationSource Airtricity
37
Scroby Sands WindfarmNorfolk, England
38
Scroby Sands

• Country United KingdomLocation East Anglian
  Coast, 3km east of Great YarmouthTotal Capacity
  60 MWNumber of Turbines 30Distance to Shore
  2.5 kmDepth 4-8 mCapital Costs about 110
  million EuroStatus BuiltConstruction Date
  2003Manufacturer VestasTotal Capacity 2
  MWTurbine-type V80 - 80m diameter/ 60m
  hubheightMean Windspeed 7.5 m/s Windfarm
  Developer E.ON UK

39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Siemens/BonusPrototype Factory
44
Wind Facility Locations
Siemens Facility Locations
Hovsore
Brande
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
Horns Rev Wind FarmDenmark
51
Horns Rev

• Country DenmarkLocation West CoastTotal
  Capacity 160 MWNumber of Turbines 80Distance
  to Shore 14-20 kmDepth 6-12 mCapital Costs
  270 million EuroStatus Operational
  Construction Date 2002 Manufacturer
  VestasTotal Capacity 2 MWTurbine-type V80 -
  80m diameter / 70m hubheightMean Windspeed 9.7
  m/sAnnual Energy output 600 GWhWindfarm
  Developer Elsam http//www.hornsrev.dk/Engelsk/d
  efault_ie.htm

52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
Thank You

• bill.bulpitt_at_energy.gatech.edu
• mary.hunt_at_energy.gatech.edu

57
Supporting Information
58
Denmark

• Government in power from 1991-2001
  (Social-Democratic) had strong environmental
  agenda
• A Public Service Obligation was realized by the
  (then) nationalized utilities
• Action Plan for offshore wind was published in
  1997 after realizing onshore sites were limited
• In 1999, electricity liberalization caused a
  rethinking of the way utilities in a now
  competitive market developed wind farms
• A public tender for construction was introduced
  and put forward by the new conservative coalition
  in 2001

59
Germany

• Under a feed-in tariff, offshore wind receives a
  higher per kWh price than onshore wind
• this will begin decreasing 2 per year in 2008
• Stable framework conditions and expected cost
  reductions were commended by developers
• Environmental and employment benefits were
  highlighted to public

60
United Kingdom

• Wide belief that offshore wind would be necessary
  to meet government targets for limiting fossil
  fuel production
• Government sought to provide a national framework
  via the Crown Estates Round 1 in call for
  offshore wind farms December, 2000
• Industry response to Round 1 was higher than
  expected
• Government support of Round 2 was more pro-active
  and supportive of offshore wind

61
Ireland

• Similar to UK in terms of first priority was to
  develop a framework for offshore wind
• Government developed a consent regime based on
  existing legislation
• Progress slow due to grid constraints, limited
  specified market, and no political preference for
  offshore wind
• New feed-in tariff may promote progress

62
Belgium

• Utilities obligated to procure renewable energy
• Progress due primarily to superior offshore wind
  resource potential
