PWB 518 Build International Applications With
PowerBuilder 10
Jin-You Zhu Sr. Software Engineer jyzhu_at_sybase.com
August 15-19, 2004
2
The Enterprise. Unwired.
3
The Enterprise. Unwired.
Industry and Cross Platform Solutions
Unwire People
Unwire Information
Manage Information

• Adaptive Server Enterprise
• Adaptive Server Anywhere
• Sybase IQ
• Dynamic Archive
• Dynamic ODS
• Replication Server
• OpenSwitch
• Mirror Activator
• PowerDesigner
• Connectivity Options
• EAServer
• Industry Warehouse Studio

• Unwired Accelerator
• Unwired Orchestrator
• Unwired Toolkit
• Enterprise Portal
• Real Time Data Services

• SQL Anywhere Studio
• M-Business Anywhere
• Pylon Family (Mobile Email)
• Mobile Sales
• XcelleNet Frontline Solutions
• PocketBuilder
• PowerBuilder Family
• AvantGo

Sybase Workspace
4
What is Unicode?

• Unicode provides a unique number for every
  character, no matter what the platform, no matter
  what the program, no matter what the language.
• 2 sets of Unicode
• UCS-2 use one 16bit unit (2 bytes) to represent
  a character. (up to 65535 characters)
• UCS-4 use one 32bit unit (4 bytes) to represent
  a character. UCS-4 is a superset of UCS-2. It
  includes more characters.
• 3 popular Unicode Transformation Formats (UTF)
• UTF-8 Use 1 to 4 bytes to represent one Unicode
  character. ASCII characters is the same as those
  in ASCII. To represent UCS-2, need 1 to 3 bytes.
  To represent UCS-4, needs 1-4 bytes.
• UTF-16 Use 1 (UCS-2)or 2 (for UCS-4) 16bit unit
  to represent one Unicode character.
• UTF-32 Use 1 32bit unit to represent one Unicode
  character.

5
Why use Unicode ?

• Unicode allows a program or website to be
  targeted for multiple platforms, languages and
  countries.
• It defines codes for all characters used in all
  major languages today.
• It is able to encode multilingual text.
• Unicode is the official way to implement ISO/IEC
  10646.
• It is being adopted by many of the industry
  leaders.
• It allows data transfer between different systems
  without data corruption.

6
Benefit Pitfalls of Using Unicode

• Unicode can handle text in any language or any
  combination of languages.
• You can process and show characters in
  multi-language in the single form.
• It is possible that one application fits for all
  languages.
• Conversion is only necessary on incoming and
  outgoing data without corrupt.
• No data lose when convert from any code page to
  Unicode.
• It simplifies operations on text because there is
  no longer a need to keep track of what encoding
  scheme is being used.
• Disadvantages
• Because one character in Unicode take 2 bytes, it
  consume more memory.

7
PowerBuilder 10 Unicode Enabling

• PB10 uses Unicode internally. It can process and
  display Unicode characters, which support
  Multilanguage in your applications.
• Database Support DBCS Unicode databases.
• PowerScript PB10 has more PowerScript functions
  to process Unicode string and ANSI(DBCS) string.
• PowerScript Manipulation of ANSI Unicode files
• DW/XmlDW Select/Insert/Update of Multilanguage
  is supported.
• PBNI two sets of interface are implemented. The
  users have the choice to use Unicode API or ANSI
  API.
• Orca two sets of interface are implemented. The
  users have the choice to use Unicode API or ANSI
  API
• External Function Support ANSI Unicode
  parameters.
• A migration tool is developed to help solve
  migration issues.

8
PB10 Supports ANSI Unicode Databases (1)

• ANSI/DBCS Database
• A database that uses ANSI (or DBCS codepage) as
  its character set, such as CP1252 for European
  language, CP932 for Japanese, CP936 for
  Simplified Chinese.
• Unicode Database
• A Unicode database is a database whose character
  set is set to a Unicode format, such as UTF-8,
  UTF-16.
• All data in database is in Unicode format, and
  any data saved to the database must be converted
  to Unicode data implicitly or explicitly.
• Unicode column
• A database that uses ANSI (or DBCS) as its
  character set may use special data types to store
  Unicode data. These data types are NCHAR,
  NVARCHAR, / NVARCHAR2. Columns with this data
  type can store Unicode data. Any data saved into
  such a column must be converted to Unicode
  explicitly.

9
PB10 Supports ANSI Unicode Databases(2)

• In PB10, Most DB interfaces support Ansi
  Unicode Databases.
• ()-- Need a patch for EAServer 4.2.3/5.1.

10
DB interface SYC SYJ

• A new dbparm (UTF8) is defined for SYC/SYJ
• UTF8 could be 1 or 0. Default value is 0.
• If set this dbparm to 0, DB driver will convert
  the data to the client machines locale. Then
  client will convert it to Unicode.
• If set it to 1, the DB driver will gives data
  back in Unicode for Multilanguage support. In
  this case, the ASE server need to be specially
  configured.
• How?
• Sp_configure enable Unicode conversion 2

11
DB interface ODBC

• For client/Server applications PB10 can consume
  data from ANSI database and Unicode database. No
  special setting is needed.
• For N-tier applications if you use ODBC to
  connect to ASA Unicode database through
  connection cache, you need a special patch for
  EAServer 4.2.3/5.1, which add a new connection
  cache called ODBCU. With this new connection
  handle, PB component can access Unicode data from
  Unicode ASA database.

12
DB interface O90

• For Client/Server applications PB10 can consume
  data from Ansi database and Unicode database via
  O90/O84. No special setting is needed.
• For N-tier applications if you use O90 to
  connect to Oracle 9 database through connection
  cache, you need a special patch for EAServer
  4.2.3/5.1, which add a new connection cache
  called OCI_9U. With this new connection handle,
  PB component can access Unicode data for Oracle.

13
DB interface JDBC/OleDB/ADO.Net

• PB10 can consume data from Ansi database and
  Unicode database. No special setting is needed.

14
DB interface Informix Native

• PB10 can consume data from Ansi database of
  Informix. No special setting is needed.
• Note Informix Unicode database is not supported
  in PB10.

15
PowerScript

• Data types
• Functions to manipulate ANSI Unicode string
• Functions to process Unicode files

16
PowerScript Data types

• String
• String will always be a Unicode string. All data
  in a String will be Unicode. No ANSI String any
  more.
• Multilanguage characters are possible to put in
  one PB string.

• Blob
• Blob remains as a binary data type. It could
  store binary data, ANSI characters, or Unicode
  characters.
• How?

17
Conversion between String and Blobin PowerScript

• Conversion from Blob to String
• String ( blob, Encoding )
• Convert a Blob to a String
• Encoding could be EncodingANSI!, Encoding UTF8!
  , EncodingUTF16LE! And EncodingUTF16BE!. The
  default is EncodingUTF16LE!.

• Conversion from String to Blob
• Blob ( string, Encoding )
• Convert a String to a Blob
• Encoding could be EncodingANSI!, Encoding UTF8!
  , EncodingUTF16LE! And EncodingUTF16BE! . The
  default is EncodingUTF16LE!.

• Other Conversion Functions
• FromANSI()/ToANSI()/FromUnicode()/ToUnicode() are
  still supported, but obsolete, in PB10. We
  encourage users to shift to String/Blob
  functions.

18
PowerScript Functions to manipulate ANSI
Unicode string

• Len/Left/Mid/Right/
• These functions are Unicode character based.

• LenW/LeftW/MidW/RightW/
• All W functions are also Unicode character
  based.
• Same as Len Functions
• LenA/LeftA/MidA/RightA/
• A new set (A) of functions is added for string
  manipulation by byte. PB will convert the PB
  String (Unicode) to DBCS (based on machines
  locale), then apply the operation.

• Migration tool help identify/replace these
  functions.

19
PowerScript Functions to process Unicode files

• File Types
• ANSI/DBCS files
• Unicode (UTF16/UTF8) files (New)
• Binary files
• File Operation Functions
• FileEncoding(filename)
• FileOpen(filename ,filemode ,fileaccess
  ,filelock ,writemode ,Encoding)
• Filemode LineMode, StreamMode, TextMode
• FileRead/FileWrite ---- Read/Write in 32765 chunk
• FileReadEX/FileWriteEx ---- Read/Write a file
• FileSeek/FileSeek64
• Encoding
• EncodingANSI!, Encoding UTF8! , EncodingUTF16LE!
  And EncodingUTF16BE!
• Conversion
• When Read/Write, Conversion will take place if
  needed

20
PowerScript Examples

• Read an Ansi File
• Integer li_FileNum
• String s_rec
• li_FileNum FileOpen("Employee.txt")
• // or li_FileNum FileOpen("Emplyee.txt",
  TextMode!)
• FileRead(li_FileNum, s_rec)
• Read a Unicode File
• Integer li_FileNum
• String s_rec
• li_FileNum FileOpen("EmployeeU.txt", TextMode!,
  Read!, EncodingUTF16LE!)
• FileRead(li_FileNum, s_rec)
• Read a Binary File
• Integer li_FileNum
• blob bal_rec
• li_FileNum FileOpen("Employee.imp, Stream
  Mode!, Read!)
• FileRead(li_FileNum, bal_rec)

21
DataWindow

• DataWindow support Multilanguage display and
  manipulation in PB10.

• DW string related functions are changed to be
  consistent to PowerScript functions
• DW file manipulation functions extended to
  Unicode files also.

22
JSP Authoring Web Services

• JSP
• JSP Authoring tool also is Unicode enabled in
  PB10.
• The users have the choice to save the JSP files
  in different format. (Unicode, UTF8, ANSI are
  supported).
• JSP page can process ANSI Unicode request.
• Web Services
• In PB10, Web Services client can handle
  international characters.

23
XML DataWindow

• XML DataWindow
• Process ANSI Unicode data.

• Tips
• lt_at_ page contentType"text/html charsetUTF-8"
  gt
• request.setCharacterEncoding("UTF8")

24
PBNI ORCA APIs

• PBNI
• In PB10, PBNI offers 2 sets of APIs One is for
  ANSI, the other is for Unicode. So the users can
  develop PB extensions using ANSI build or Unicode
  build as they like.
• PBNI has templates for users to use.
• ORCA
• PB10 offers 2 sets of APIs(ANSI Unicode) for C
  functions to extract object form PBL or construct
  PBL from Object file.

25
External Function Call

• Purpose
• You can define PB global or local functions to
  map to external function call to system or 3rd
  party Dlls
• Change of the Syntax
• In PB9 and before the syntax is
• FUNCTION int MessageBoxA(int handle, string
  content, string title, int show type)
• LIBRARY "user32.dll"
• In PB10,
• FUNCTION int MessageBox(int handle, string
  content, string title, int showtype)
• LIBRARY "user32.dll" ALIAS FOR "MessageBoxAansi

• -- use ansi version of system function
• FUNCTION int MessageBox(int handle, string
  content, string title, int showtype)
• LIBRARY "user32.dll" ALIAS FOR MessageBoxW

• -- use Unicode version of system function
• Migration tool will help identify and replace the
  external function call in your existing
  application.

26
Summary

• PB10 supports Multilanguage process natively.
• PB10 supports both ANSI and Unicode databases.
• PowerScript can handle Ansi, Unicode, and binary
  files.
• DataWindow and XML DataWindow can process
  Multilanguage as well.
• JSP supports Multilanguage editing and
  deployment.
• Through PBNI, the users have the flexibility to
  develop Ansi extension or Unicode extension.
• PB10 can integrate Ansi and Unicode Dlls into
  PB10.

27
Q A

• ?
