Johns Hopkins University Software Engineering Fall 2002

1
Johns Hopkins UniversitySoftware
EngineeringFall 2002

• 5 November 2002
• Bill Akin

2
Tonights Agenda

• Review the in-class exam
• Additional object-oriented concepts
• Architectures
• Infrastructures
• Analysis
• Modeling
• Requirements specification
• The revised schedule

3
Definition

• An object is an entity or module that has a state
  and a defined set of operations to access and
  modify that state. (an old definition)
• We can also think of an object as a closed
  system, subsystem, or component that maintains
  its own state, accepts a specified set of
  messages (usually called methods), provides
  responses, and/or performs pre-defined functions.
• No external entity is able to see inside a
  correctly constructed object or directly control
  any of the objects internal processes.

4
Methods, Operations, and Attributes

• Methods are the messages we send to objects that
  cause them to perform actions.
• Operations are the things we cant see that
  happen inside the objects to accomplish their
  defined actions.
• Attributes are the things an object knows about
  itself, e.g., its state data.
• Users of an object cannot see its operations or
  attributes.

5
Concepts

• I have an abstract data class called CHECKING.
• I can create an object of that class and use it.
• Here are some methods
• PFCU.ESTABLISH as CHECKING with 1001
• PFCU.DEPOSIT 500
• PFCU.CHECK 25 Daily Times Herald
• print PFCU.BALANCE
• PFCU.REGISTER 1-January-2001 31-March-2001

6
Applications

• I have an object-oriented air traffic control
  system.
• Here are some object concepts and methods
• RECEIVE_HANDOFF.3666R Denver
• SHOW.3666R
• PASS_HANDOFF.3666R Dallas
• SHOW_ALL FL3 FL6
• DISPLAY_SPEED.3666R
• DISPLAY_ETA.3666R VOR.Pecos
• DISPLAY_PILOT.3666R

7
Special Object Uses

• Collaborative -- An object used in support of
  another object. A CHECKING object can use the
  services of a DATABASE object to maintain its
  state. This is hidden from the users of the
  CHECKING object.
• Guardian -- An object visible to the enterprise
  that provides the only available access to
  another resource.
• These two concepts can enable many objectives.

8
Architecture

• Software architecture
• the structure of the components of a
  program/system, their interrelationships, and
  principles and guidelines governing their design
  and evolution over time.
• Definition from the SEI

9
Architecture

• Architecture
• A minimal set of rules governing the arrangement,
  interaction, and interdependence of the parts or
  elements of a system whose purpose is to ensure
  that a conformant system satisfy a specified set
  of requirements.
• Identifies the services, interfaces, standards,
  their relationships.
• Provides the technical guidelines for
  implementation of systems upon which engineering
  specifications are based, common building blocks
  are built, and product lines are developed.
• Ingredients
• Rules Design Rules, Standards, Conventions
• Reference model(s)

10
What is an Architecture?

• Definition The structure of components, their
  interrelationships, and the principles governing
  their design and evolution.
• Architecture types
• Operational
• Technical
• System

11
Object-Oriented Architecture

• I will discuss the concept of object-oriented
  techniques applied to the development and
  maintenance of information processing
  architectures.
• I will outline the goals and objectives of the
  approach and the way I believe the objectives can
  be met.
• I will provide some simple examples of
  architecture level objects and discuss their
  implementation.

12
Goals and Objectives

• Goals
• Improve the ability to maintain an information
  system, application, or enterprise
• Extend the useful life of an information system
• Enable inclusion and evolution of legacy elements
  in an information system
• Objectives
• Reduce the breakage for change requests
• Abstract system component implementation detail
• Shroud incorporated components

13
Definition Information System

• An Information System is a set or arrangement of
  elements organized to accomplish some predefined
  goal by processing information.
• According to Fred Brooks, The hardest single
  part of building a software system is deciding
  what to build.No other part of the work so
  cripples the resulting system if done wrong. No
  other part is more difficult to rectify later.

14
OO Architecture Classes
Client Class
DB Class

• An information system built on an object-oriented
  architecture has a set of classes, rules for
  using them, and an infrastructure that holds it
  all together.
• In the example we show two classes and an
  infrastructure.
• We can build a system using objects that are
  instances of the classes and plugging them into
  the infrastructure.

15
Some Sample Classes

• User Application
• Server Application
• Archive Application
• Database Server
• Backup Server
• External Access Server

16
OO Architecture Concept
DB-A
Client 2
Client 1
DB-D
DB-B
DB-C
New Client

• We could build a plug-and-play architecture.
• New databases can be plugged in.
• New Clients can be plugged in.
• It is a maintainable enterprise on a
  plug-and-play architecture.

New DB
17
Example Object-oriented Architecture
User-II
Sys-B Data Manager
User-I
Sys-A Data Manager
Sys-B Backup
Security Admin
Sys-A Load Processor
Sys-C Data Manager
Audit Trail Archiver
Security Admin
Sys-B Load Processor
Loads Admin
Zip Data Manager
18
Implementations

• Remember the objectives?
• Reduce the breakage for change requests
• Because state and process implementation are
  completely contained in an object, only the
  internal components are broken.
• Abstract(v) component implementation detail
• By definition all details of an object
  implementation are hidden.
• Shroud incorporated components
• Use guardian objects to own foreign components
  brought into a system.

19
Global Resources

• Global resources should be treated as abstract
  objects.
• A guardian object should own such servers.
• As an example, consider a database to hold a
  companys inventory. The guardian is an object
  that advertises methods to its clients.
• Inside the guardian are commands understood by a
  small access database.
• If we change to oracle, only the guardian is
  modified, not the clients in our system.

20
Technical Architecture

• Technical Architecture
• A minimal set of rules governing the arrangement,
  interaction, and interdependence of the parts or
  elements of a system whose purpose is to ensure
  that a conformant system satisfies a specified
  set of requirements.
• Identifies the services, interfaces, standards,
  their relationships.
• Provides the technical guidelines for
  implementation of systems upon which engineering
  specifications are based, common building blocks
  are built, and product lines are developed.
• Ingredients
• Rules Design Rules, Standards, Conventions
• Reference model(s)

21
Information Infrastructure

• An information infrastructure is an integrated
  collection of elements based on technical
  architecture components that form the foundation
  on which functional components are supported
• An infrastructure may contain global resources
  available to all enterprise users
• Standard interfaces enable infrastructure use

22
CII Concept of Operations
Internal
External
CII
Our Systems Outside the CII
Type III Applications
Type II Applications
Type I Applications
External Systems
Interoperability Services
Interoperability Services
Corporate Database (CD)
Pre-existing External Interfaces
CII Common Environment

• Infrastructure Services
• Hardware and Software Platforms

CII External Interfaces
Common Support Applications
Corporate Warehouse (CW)
Corporate Repository (CR)
COE
23
CII Layers
CII Component A
CII Component B
Virtual Connection
Request
API
Response
Request
API
Response
Request
Response
Request
Response
COE APIs
COE APIs
Request
Response
Request
Response
Interfaces
Interfaces
Actual Connection
24
Context
Client
Server
Virtual Connection
Layer - 1
Layer - 1
1 - PDU
Layer - 2
Layer - 2
2 - PDU
Layer - 3
Layer - 3
3 - PDU
Layer - 4
Layer - 4
4 - PDU
Common Operating Environment (COE)
25
Anatomy of a Layer
N service primitive (request or response)
N service primitive (confirm or indication)
Layer-N
N-1 service primitive (request or response)
N-1 service primitive (confirm or indication)
Terms
SAP Service Access Point SDU Service Data Unit
26
Anatomy of a Layer External View
N service primitive (request or response)
N service primitive (confirm or indication)
Layer-N
N-SAPs
Term
SAP Service Access Point
N-SAPs
N-1 service primitive (request or response)
N-1 service primitive (confirm or indication)
27
Anatomy of a Layer Internal View
N-SAPs
Layer-N
Term
SAP Service Access Point
N-Service Entity
N-SAPs
28
Analysis and Modeling

• Data modeling specify all data produced or
  consumed by the system
• Functional modeling and information flow all
  data flows and related functional processes
• Behavioral Modeling state transition diagrams
  or finite state machines
• User interface uses and use cases or other
  prototyping models
• Now lets work an example together

29
Specify Requirements

• Identify major, intermediate, and minor
  functional views and elements
• Break a document into their boundaries
• Write a descriptive narrative at each level
• At the lowest (minor) level write all the
  requirement statements that specify that element
• Each requirement statement is either a capability
  or a constraint.
• Now lets expand our example

30
Where are we

• Six class meetings left including tonight
• Project needs to be completed, demonstrated, and
  delivered
• Several topics left to be covered, including
• Design
• Testing
• SCM
• SQA
• Component-based design
• Additional object-oriented techniques

31
Schedule

• Class Date Chapters Events and Deliveries
• 10 12-Nov 8, 9, 24 Deliver requirements
  document
• 11 19-Nov 17, 18 High Level Design Presentation
• 12 26-Nov Deliver high level design document
• 13 3-Dec Final Exam
• 14 10-Dec Project Demonstrations - Deliver
  project
