Title: WINDOWS EMBEDDED


1
  • WINDOWS EMBEDDED
  • STUDENT CHALLENGE
  • COMPETITION
  • Juan E. Vargas, Ph. D.
  • (juanv_at_microsoft.com)
  • Academic Relations Manager
  • Microsoft Corporation

2
Outline
  • Windows Embedded Challenge Competition
  • Windows CE as a Platform
  • Windows CE Platform Builder Tools

3
Windows Embedded Challenge Overview
  • Goal Supplement faculty initiatives by giving
    students the opportunity to work on real world
    projects, with hardware, software and technical
    support provided by Microsoft
  • Target Audience Undergraduate Computer
    Engineering/ CS students worldwide.
  • Especially relevant for Senior Design/ Senior
    Project courses
  • Prizes
  • 1st Prize - 8,000 US
  • 2nd Prize - 6,000 US
  • 3rd Prize - 4,000 US
  • 4th Prize - 3,200 US
  • 5th Prize - 2,400 US
  • Key dates for participating
  • Registration ends February 6, 2005
  • Final reports due to both CSIDC and Microsoft -
    April 23, 2005Finalists announced - May 6, 2005
  • Finals - June 1718, 2005 in Redmond, WA

4
How does it work
Windows Embedded Challenge
Application
Students build apps using .Visual Studio .NET (C
VB) or Embedded Visual C (C or C)
Windows CE.NET
Customizable by students with Platform Builder,
the Windows CE IDE (also provided to teams)
Board Support package
Provided to participating teams through ICOP
Hardware
  • Contest among undergraduate students
  • Build a computer based system based on the theme
    Going beyond the boundaries
  • Collaboration with CSIDC - IEEE
  • James Madison University Champions, 2004

5
Microsoft Technical Support
Windows Embedded Challenge
  • Helpp_at_microsoft.com
  • Manned by over 25 Windows CE developers
  • Get answers to questions about Windows CE
    Software how to configure, build, debug and
    deploy OS image
  • This was one of the most valuable resources last
    year for students
  • Will not help with writing code
  • Frequent Online chats
  • Other resources (books, etc) available on request

Be part of this exciting contest! Register
Now!! www.windowschallenge.com/register.aspx
6
29 TEAMS INVITED TO THE FINALS in 2004
SUNY Stony Brook -3 SUNY Binghamton
UNL -3 UNO-1
Wisconsin Madison
Utah State
Boston College UMass Dartmouth
DePaul Bradley
James Madison University
University of S.Carolina - 2
Cal Poly Pomona -2 CSU- Northridge CSU Chico CSU
Long Beach San Diego State San Jose State-2 Santa
Clara -2
Georgia State
LSU
Be part of this exciting contest! Register
Now!! www.windowschallenge.com/register.aspx
7
OS Versus Platform Why distinguish between the
two?
  • Because Windows desktop development blurs
    differences between them, causing confusion
    w.r.t. the embedded space.
  • To draw attention at some differences between
    Windows CE and other Windows OS.
  • To set the stage for talking about Tools.
  • To highlight some opportunities and design
    choices coming at us like an avalanche.

8
Avalanche Wide Range of Devices
Voice-over IP Devices
Gateways
Thin Clients
Set-Top Boxes
Digital Audio Receivers and Players
Mobile Handhelds
Medical Devices
IndustrialAutomation
Smart Displays
9
Avalanche Devices in Automobiles
10
Avalanche 2500 Partners
  • Over 2,500 Windows Embedded Partners worldwide
  • Exponential growth in China, Taiwan, India
  • Gold partners in all major regions
  • Industry experts
  • Demonstrating value across product line

11
Operation Systems Are
  • Webster Dictionary
  • The Master Control Program that starts when a
    Computer boots
  • Abstracts the hardware for applications
  • Offers standard APIs to access Hardware
  • Is not useful without hardware
  • You cannot just develop for an OS
  • Examples
  • Windows XP, Windows CE, Linux,

12
Platforms Are
  • A specified set of OS technologies defined as
    components for a specific set of hardware
  • In the embedded space these are usually defined
    by the OEM
  • Applications are developed targeting the
    platform
  • The Platform SDK defines the platform
  • Microsoft platforms
  • Windows 3.1, Windows 98, Windows XP, Pocket PC,
    Pocket PC 2002, SmartPhone

13
Windows XP versus Windows CE
  • Windows XP as a platform
  • Uniform platform with significant app
    compatibility
  • Restricted hardware architecture
  • Readily available, inexpensive
  • Windows CE as OS
  • A collection of components that can be assembled
    into a wide variety of platforms
  • Much more flexibility about the hardware since it
    supports 4 processor architectures
  • X86
  • SH4
  • ARM
  • MIPS

14
Design Choices
  • Build your own platform
  • Greater flexibility regarding choice of
    components to include
  • Platform designer supplies kernel and drivers
  • More work
  • Develop towards an existing platform
  • App level environment already exists
  • You probably cant change it
  • You can get stuck if you need a component thats
    not available

15
CE Technology ComponentsKernel, Power Manager,
File System
  • Hard real-time preemptive multitasking kernel
  • Interprocess communication (IPC), sync objects
  • Memory mapped files, message queues, fibers
  • Virtual memory with hardware access protection
  • Installable ISRs, Multimedia timers, DMA APIs
  • more flexibility for drivers apps
  • Kernel hooks for profiling and debugging
  • Flexible Power Manager with power profile states
  • Layered Storage Manager Architecture
  • File system Filters
  • E.G. for adding FS Encryption
  • Sample file system drivers in PB
  • FATFS, CDFS/UDFS, BinFS (Flash file system)

16
CE Technology ComponentsNetworking
Communications
  • Self tuning TCP/IP stack, incl. IPv6 Support
  • NDIS 5.1 driver architecture RNDIS supported
  • Winsock 2 WinINet
  • Wireless networking
  • Bluetooth, including qualified profiles
  • 802.11, Auto configuration 802.1x security
  • Services LDAP, DCOM, SOAP, MSMQ, UPnP,
  • Gateway functionality
  • V4 NAT/ICS and v6 routing router advertisement
    (RA)
  • Firewall, DNS Proxy, DHCP allocation

17
CE Technology ComponentsGraphics Multimedia
  • Windowing
  • Window / Dialog Manager
  • Basic / Common Controls
  • Graphics
  • DirectDraw,
  • Direct3D
  • GDI
  • Audio
  • DirectSound, WaveOut,
  • DirectMusic
  • Media Playback
  • DirectShow
  • Windows Media Technologies
  • Windows Media Player and ActiveX Control
  • Stream from media server, web, local file
  • Support for many types and formats
  • WMA, WMV, MPEG-1, MPEG-4, Wav, MP3, ADPCM, G.711,
    GSM 6.10

18
CE Technology ComponentsServices Applications
  • Shell (Desktop)
  • Two browsers
  • Email client
  • Wordpad
  • Viewers for MSWord, Excel, PowerPoint PDF
  • Instant Messenger client
  • Terminal services client
  • Windows Media Player
  • Component Object Model / ActiveX Control
    infrastructure
  • .NET Compact Framework
  • Data synchronization infrastructure
  • Device Management
  • HTTP Server
  • FTP Server
  • Telnet Server

19
CE Technology ComponentsBoard Support Packages
  • Improve out-of-the-box experience
  • Evaluation Learning
  • Prototype Demonstration
  • Shorten time to booting prototype
  • Sample drivers based on integrated peripherals
  • Many source examples available
  • Decouple high-level app development from hardware
    and driver development
  • At least one BSP per supported kernel included in
    PB, additional on the web
  • Additional BSPs available on the web and included
    in reference hardware products

20
Embedded Devices Vs Mobile Devices
  • Mobile Devices
  • Smart Phone
  • PDA
  • Gaming device
  • Web Pad
  • Inventory Scanner
  • Portable Music Device
  • Robot
  • Embedded Devices
  • Soft PLC
  • HMI Panel
  • HVAC Controller
  • Sewing Machine
  • Traffic Light
  • Set-top Box / Stereo Component
  • Cash Register

21
Embedded Devices
  • No power consumption optimization
  • Might not have a display
  • Application durability is most important
  • Software gets pre-installed
  • By OEM, Machine Builder, SP
  • Optimize for application footprint
  • Mobile Devices
  • Optimization for power management
  • 99 have displays
  • User Experience and ease of use is essential
  • Footprint still important
  • Larger application may not install with default
    memory settings

22
Platform Builder
  • Creates platforms with Windows CE
  • Assembles OS components into a device image
  • Mainly for OEM but also for driver development
  • Exports the platform SDK for embedded Visual
    Tools
  • Windows CE.NET PB exports to eVC 4.0
  • Emulator facilitates software development
    independent of hardware
  • Platform wizards walk you through component
    selection for common device types
  • Components can be added by dragging and dropping
    from the catalog
  • Dependency checking automatically brings in other
    needed components
  • New components can be written from scratch

23
Development CycleFrom Platform to Applications
Device Development Builds and Brings
Up Device
Application Development Builds Rich
Applications
Export SDK with Device Specific Win32 APIs or
use Standard SDK
Platform Builder
eMbedded Visual C 4.0 C/C MFC/ATL
Download Device Specific Windows CE OS and
Applications
Component Catalog incl. .NET CF
Visual Studio .NET VB/C
via KITL
via KITL
Build DeviceImage
Smart Device Programmability
Debug Device
24
Windows CE Core Operating System Architecture
Applications
Programming Interfaces (Win32, COM, MFC, ATL)
Communication Interfaces (Winsock, RAS, TAPI)
Networking and Communication System
Kernel Library
GWES
Device Manager
Filesys
Device Drivers
OAL Bootloader
OEM Hardware
25
Does Microsoft share its source code ?
  • Yes, through two programs
  • Shared Source
  • Premium Share

26
Shared Source What is Included
Not Available
ISV, OEM Provided
Mostly Available
Applications
Embedded Shell
Kernel Library
IrDA
GWES
TCP/IP IPv6
Device Manager
File Manager
File Drivers
OAL Bootloader
Drivers
Device Drivers
OEM Hardware
27
Premium Source What is Included
Not Available
ISV, OEM Provided
Mostly Available
Applications
Embedded Shell
Kernel Library
IrDA
GWES
TCP/IP IPv6
Device Manager
File Manager
File Drivers
OAL Bootloader
Drivers
Device Drivers
OEM Hardware
28
  • Resources

29
More Shared Source Information
  • Working with Shared Source code for Windows CE
    .NET
  • http//msdn.microsoft.com/library/?url/library/en
    -us/dncenet/html/privatesource.asp
  • Shared Source Licensing Overview for Windows CE
    .NET
  • http//msdn.microsoft.com/embedded/ce.net/sharedsr
    ccode/
  • List of Shared Source Files for Windows CE .NET
  • http//msdn.microsoft.com/library/default.asp?url
    /library/en-us/wcepb40/htm/pbconsharedsourcecodedi
    rectories.asp?frametrue
  • Microsoft Windows Embedded Community
  • http//msdn.microsoft.com/embedded/community/defau
    lt.aspx
  • E-mail questions to cesrc_at_microsoft.com or
    wemap_at_microsoft.com

30
For More Information
  • Join the Windows Embedded Academic Program
    (WEMAP)
  • Contact us at wemap_at_microsoft.com
  • Visit us online at http//www.microsoft.com/wind
    ows/Embedded/ce.NET/evaluation/offers/academic.asp
  • CSIDC IEEE Contest
  • http//www.computer.org/csidc/
  • Windows Embedded Community (support, newsgroups,
    chats, events, newsletters)
  • http//www.microsoft.com/windows/embedded/communit
    y
  • Hardware Empowerment Program
  • http//www.research.microsoft.com/collaboration/un
    iversity/hep.aspx
  • MSDN Embedded (technical articles, documentation)
  • http//msdn.microsoft.com/embedded

31
Additional Useful Links
  • Real-Time TechInsight
  • www.microsoft.com/windows/embedded/techinsights/re
    altime.asp
  • DevWire (newsletter including links to latest
    downloads, articles, content)
  • www.microsoft.com/windows/embedded/devwire
  • Windows CE .NET Downloads (Evaluation Edition,
    Smartphone SDK, etc)
  • www.microsoft.com/windows/embedded/ce.net/download
    s
  • All Microsoft Downloads
  • www.microsoft.com/downloads
  • Case Studies
  • Windows CE .NET
  • www.microsoft.com/windows/Embedded/ce.NET/evaluati
    on/casestudies
  • Windows XP Embedded
  • www.microsoft.com/windows/Embedded/xp/evaluation/c
    asestudies

32
Books
  • Source Code Analysis of Windows CE .NET -
    released in China
  • Integration of a chapter (or more in some cases)
    into their core textbooks
  • Survey Of Operating Systems McGraw-Hill
    Companies
  • Advanced Concepts In Operating Systems
    McGraw-Hill Companies
  • Real-Time Programming A Guide to 32-bit Embedded
    Development - Addison Wesley Benjamin Cummings
  • An Embedded Software Primer - Addison Wesley
    Benjamin Cummings
  • Introduction to Operating Systems - Addison
    Wesley Benjamin Cummings
  • Industry books in progress and of interest to
    academia
  • Windows XP Embedded with Service Pack 1 Step by
    Step
  • Written by Sean Liming, A7 Engineering (MVP) -
    Release Date  June 2003
  • Inside Windows CE
  • Written by John Murray
  • Programming Windows CE .NET
  • Written by Doug Boling, Boling Consulting (MVP)
About PowerShow.com
