PEEK CABLE TIE PT2A

1
PEEK CABLE TIE - PT2A

• Uneeda Yorkshire Ltd
• Tel [phone]
• Fax [phone]
• Email peek_at_uneeda.co.uk

2
Presentation Aims

• Features Benefits of PEEK
• Technical Data
• Technical Illustration
• Where to find peek

3
Features Benefits
high operating temperature up to 260C not
hygroscopic high tensile strength only
6N insertion force high impact resistance

With as little as 4.5mm² strap cross-section PT2A
holds a tensile strength of 230N.
4
Features Benefits
high chemical resistance, even against acid
low out gassing high radiation
resistance good abrasion resistance
flammability according to UL 94 V0
5
Features Benefits
contoured head takes up less space usage
in areas with space restrictions outsid
e serration Rounded edges save to
the bundle and to operators hand
Minimises any indention or damage to cable
insulation
6
Technical Data

• PEEK PolyEtherEtherKetone
• main global PEEK supplier is Victrex
• raw material type 151G, approved by Airbus
• melting point 343 C
• high injection temperature of approx. 430C
• operating temperature 55C to 260C
• RoHS conform
• halogen free
• flammability according to UL94 V0

7
Technical Illustration

• Technical Drawing similar to our CT2 cable tie
• Bundle diameter 1.6 mm up to 35 mm
• Tensile strength 230N
• Tension tool MK7 and MK7P
• Weight 0,800kg per 1000 pieces
• Brown in colour

8
Thank you for your time

• Any questions?

9
Call us now

• Tel [phone]
• Fax [phone]
• Email peek_at_uneeda.co.uk

We at UNEEDA are excited. Are you!
