ICM Minnesota

1
ICM Minnesota Interstate 394

• Brian Kary, Minnesota Department of
  Transportation

2
Operational I-394 Existing Corridor Networks
3
Operational Why our Site needs ICM
Locations of Recurring Congestion
4
Operational Why Are Site Needs ICM
I-394 Travel Times
Eastbound
Westbound
PM PEAK
5
Operational Why our Site needs ICM

• Gaps in Coordination Between Traffic and Transit
  Management Centers
• During Normal Conditions
• During Incident Conditions
• Gaps in Incident Data On Arterial Network
• State Patrol Response
• Local PD Response

6
Operational Why our Site needs ICM

• Lack of Traveler Information for Arterials and
  Transit
• Comparative Travel Times
• Park and Ride Availability
• Planning for Special Event Congestion
• Future Minnesota Twins Stadium
• Existing Minnesota Timberwolves Stadium

7
Operational How ICM will help our Site

• Provide Traveler Information Across All Networks
  and Modes
• Freeway Travel Times
• Transit Travel Times
• Arterial Travel Times
• Park and Ride Availability
• Improved Agency Communication and Coordination
• Improved Incident Management and Detection on
  Arterials
• Coordinated Incident Signal Timing Plans
• Transit Rerouting During Incidents
• Reduce Congestion and Improve Trip Reliability

8
Institutional Who are our ICM Stakeholders

• Mn/DOT (Freeway, Arterials, MnPASS)
• Hennepin County (Traffic, EMS dispatch)
• City of Minneapolis (Traffic, EMS dispatch)
• Transit Agencies (Metro Transit, SW Transit,
  Plymouth Transit)
• Minnesota State Patrol

9
Institutional How our Site defined Roles and
achieved Buy-in among ICM Stakeholders

• Mn/DOT Lead Role
• Consultant Hired to Write ConOps and SRS
• Steering Committee and Working Group Meetings
• Stakeholder Workshop
• Individual Stakeholder Meetings
• Project Management Team

10
Technical What our proposed ICMS will look like

• Connection of Existing Systems
• Add-ons to Existing Systems
• ICMS Data Hub

11
Technical What our proposed ICMS will look like
Logistical Diagram of Metro Transit Control Center
12
Technical What our proposed ICMS will look like
Functional Diagram of Metro Transit Control Center
13
Technical What our proposed ICMS will look like
Logistical Diagram of Mn/DOT Traffic Operations
14
Technical What our proposed ICMS will look like

• Planned Instrumentation of Hwy 55 and Hwy 7 with
  CMAQ Funds
• Gaps in Providing Arterial Travel Time Gaps
• Jointly Developed Incident Signal Timing Plans

15
Technical What our proposed ICMS will look like

• Existing AVL System on Metro Transit
• Plymouth Metrolinks and Southwest Currently Do
  Not Have AVL Systems
• Challenge in Providing Accurate Park and Ride Lot
  Vehicle Counts
• Comparative Travel Times Between Transit and
  Freeway
• Historical Data Vs. Real-time Data
• Planned UPA Transit Travel Time Comparison Project

16
Technical What our proposed ICMS will look like
OBJECTIVE PERFORMANCE MEASURE
Reduce the variation in travel times Buffer Index The amount of time travelers must allow to ensure they are on-time 95 of the time. Maximum travel times experienced by travelers throughout the corridor Range of travel times (and variability) experienced by travelers Percentage of late bus routes throughout the corridor.
Maintain options for travelers Average parking availability per facility and time of day Comparisons of transit, HOV/HOT lanes, Freeways, and arterial route performance Percentage of corridor (routes and modes) reported on in real-time (travel times, delays, space availability, speeds etc.)
Monitor and understand the ever changing available capacity Percentage of corridor (routes and modes) reported on in real-time (travel times, delays, space availability, speeds etc.)
Encourage pattern changes to better utilize spare capacity Percentage of drivers altering route or mode based on traveler information Average capacity utilization across all modes during incidents and normal conditions.
17
Technical What our proposed ICMS will look like
OBJECTIVE PERFORMANCE MEASURE
Inform travelers of incidents impacts Number of events where viable alternates are delivered to travelers (either via. phone, web or push) Number of callers receiving alternate route/mode information Web page hits and call volumes during incident events
Manage traffic around events Number of closures where vehicles are routed onto appropriate alternate routes Number of times alternate plans are implemented, and the real-world results. Response/ clearance times for major events.
Travelers are aware of their modal and route options Web page hits, phone requests, and push deliveries of specific route/mode options
Travelers do not experience delays without also being informed of options Travelers feedback after incidents and events.
18
Lessons Learned Operational

• Difficult Not to Focus on Technology
• Use of Operational Scenarios to Engage
  Stakeholders
• Recommend Developing Operational Scenarios First
• Assumed Connectivity or Coordination Between
  Centers
• Recognized New Partners During Discussions
• Near Term Strategies to Achieve Benefits of ICM
  Sooner

19
Lessons Learned - Operational

• Incident Data Sharing Example
• Near Term Strategy
• Manual sharing of incident data via email, phone
  or radio.
• Long Term Strategy
• Automated sharing of incident data via integrated
  CAD/AVL systems.
• Came From Meetings with Stakeholders!
• Either
• Require Basic Agreements / Procedural Changes
• Already Existing or Funded Development in process

20
Lessons Learned Operational

• I-35W Bridge Collapse
• Improved Coordination and Communications Between
  Stakeholders in Responding to Changing Traffic
  Conditions
• Weekly Traffic Operations Meetings Including
  Freeway, Arterials, and Transit Staff likely to
  continue as biannual meetings.

21
Lessons Learned Operational

• I-35W Urban Partnership Agreement
• Conversion of I-35W HOV Lanes to MnPass HOT Lanes
• Arterial Traffic Management on Hwy 13
• Transit Traveler Information
• Park and Ride Lot Availability
• Next Bus Arrival Times
• Travel Time Comparisons
• Improved Traveler Information Across All Networks
  and Modes.

22
Lessons Learned Institutional

• Stakeholder Concerns of Usefulness of ICM
• Lack of Spare Capacity on Alternate Routes
• Focus More on Incident Management and Buffer Time
  Index
• Overcoming the Legacy of Past Project Failures

23
Lessons Learned Institutional

• Ownership, Maintenance, Operations
• Legal Issues Allowing Joint Control Equipment
• Assigning Agency Responsibility eliminate wish
  list
• Virtual System Enhancements to existing systems

24
Lessons Learned Institutional

• Maintaining Stakeholder Interest in ICM
• Making ICM a Priority
• Whats in it for me?
• Major Incident Debriefing Related to ICM

25
Lessons Learned InstitutionalJanuary 9th
Tanker Rollover

• Occurred at 910 AM
• Tanker carrying 8,000 gallons of fuel
• Interchange of I-94 and I-394
• Multi-agency response
• Minneapolis Police and Fire
• State Patrol
• Mn/DOT
• HazMat
• Ambulance
• Minneapolis Traffic
• Transit

26
Lessons Learned Technical

• Develop Functional Diagrams and Logistical
  Diagrams Early
• Defining Requirements for New Techniques
• TT calculation frequency
• How often do you really need it?
• Storage of data? Associated cost?
