VHA Support Service Center

1
VHA Support Service Center

• ProClarity Desktop
• Pat Gadbaw
• Scot Dingman

2
Course Objectives

• Learn how to Access Cubes and Briefing Books via
  ProClarity Desktop
• Cubes (Data) currently available
• Desktop Layout
• Navigating the Desktop Using the Commands
• Customize Pre-built Views
• Create Your own View
• Saving Sharing Data
• Additional Training Resources

3
Definitions

• A Cube is a multi-dimensional database based on
  SQL and OLAP cube technology
• ProClarity is an analytical platform that sits on
  top of the database designed for rapid queries
  and reports
• web based version (PAS- ProClarity analytic
  server)
• desktop version ( class focus)
• A Briefing Book is a series of views (reports)
  displaying data from a cube(s)

4
Course Tools

• VSSC Web Site vssc.med.va.gov
• ProClarity Desktop
• ProClarity Briefing Books (BB)
• ProClarity Desktop (need software)
• Protected Health Information
• (PHI Task Code Required for PHI Cubes BBs)

5

• Link to VSSC Home Page
• http//vssc.med.va.gov/

6

Cube Library
ProClarity Downloads
7

• Link to Cube Documentation
• http//fcdm.vssc.med.va.gov/Definitions/default.as
  px
• Link to Cube Library will take you directly to
  the chosen cube via ProClarity Desktop
• http//vssc.med.va.gov/cube.asp

8
Cube Library
9
Protected Health Information (PHI Task Code)

• A Protected Health Information (PHI) task code,
  implemented in January 2007, is required to
  access products with PHI icon on the VSSC web
  site or ProClarity Analytics Server This task
  code is a lower level access code than real ssn
  therefore, if you already have station, visn or
  national level real ssn, you do not need to
  apply. To access PHI, including provider-specific
  information, the PHI 110NN07 task code must be
  added to VA Form 9957 to allow a user to see all
  variables that were previously removed to
  de-identify the PHI such as dates, scrambled
  social security number, zip codes, names, and any
  other unique identifying number, characteristics
  or codes. The approval process for this task code
  is as follows Requesting Individual signs VA
  Form 9957, first approval official is the
  Supervisor and second approval official is the
  Director. The point of contact will either be the
  ACRS Point of Contact or the Information Security
  Officer. When signatures are completed, the ACRS
  POC will enter the information in the National
  Security SSN Database (NSSD).

10
Begin Class Demo Exercises

11
Two Options Cube or Briefing Book Server (PAS)
To PAS
To Cube
12
ProClarity Desktop To Cube Servers
13
ProClarity Desktop Cube Server Addresses

• SQL2000 database cubes (all cubes on these server
  are being converted to sql2005)
• Vhaaacdw04.vha.med.va.gov
• Vhaaacdw05.vha.med.va.gov
• SQL2005 database cubes (will be expanding to
  other servers as sql2000 cubes are converted)
• Vhaaacdw14.vha.med.va.gov
• Vhaaacdw17.vha.med.va.gov

14
ProClarity Desktop Cube Server CDW17 Libraries
Can change connection to different server
15
ProClarity DesktopCube
16
To Pre-built Briefing Books on ProClarity
Analytics Server (PAS)
17
ProClarity Desktop To Pre-built Briefing Books
BB server address
Security Requirements Domain\NTuserID password
(should not be needed)
18
Briefing Book Library (PAS) via ProClarity
Desktop
19
ProClarity BB via Desktop
Briefing Book Options
Set-Up Panel
View
Status Bar
20
Menu Bar (File, View, Navigate, Book, Tools,
Help)
Briefing Book Views
Toolbar (back, forward, Apply, Setup, View,
Sort, Filter, Decomp, Analytics Server, KPI
Designer, Selector)
Setup Panel Measures, Dimensions, Rows, Columns,
Background
21

• Setup panel (hierarchies, rows, columns,
  background) The area where you will design the
  look of your report. You can click and drag the
  measures and dimensions to create a display that
  has your desired rows, columns and background
  detail.
• Measures Measures are quantitative values
  contained in a cube. Ex Number Unique Pts, Total
  Cost, ALOS
• Dimensions Dimensions are the data elements/
  attributes that you select to focus your
  analysis. They can be composed of hierarchical
  members. Ex Facilities (VHA-VISN-Facility-Divisio
  n), Time (FY-Quarter-Month- Day), Blood Pressure
  ranges.
• Selected dimensions will be in Rows, Columns
  Background

22

• Menu Bar Primarily used for saving and
  retrieving views and books. My Views are
  saved screen shots of a report you have created.
  The views will automatically update with new data
  when the cubes updates. Books contain one or
  more views that you have saved to a file on your
  hard drive. You can send these books to other
  people through e-mail.
• Additional Menu Bar options include File, View,
  Navigate, Tools, Help.

23

• Toolbar Commands for extracting data from cubes
  and displaying data. Apply is an important
  command that you must use each time you change a
  layout and want to update data. Reset brings you
  back to the original view. Back takes you back
  one step. Setup shows and hides the Setup Panel.
  We recommend you leave the Setup Panel
  displaying at all times as you are learning
  ProClarity.

24

• Toolbar View, Sort, Filter additional commands
  used in defining the data to display.
• Views (4) grid, graph 2 with grid graph
• Sort ordering of data from largest to smallest
  or reverse
• Filter remove empty rows columns, functions
  for lt, gt,
• Advanced Functions Analytic Server, Wizard,
  Decomp tree, Performance Map, Perspective, KPI
  Designer, Selector
• Status Bar _at_ Bottom shows the Server, Catalog and
  Cube to which you are currently connected

25
Creating Reports (right click provides many
options)

• Arrange Report Layout
• Select Measures and Dimensions
• Select Members (Items)
• Select Descendants Option
• Select Background Items set up slicers
• Create a Report

26

• Sets, New Members and Measures, Search Hierarchy
• Creating a Set (will see individual members) A
  group of Members or Measures that are given a
  common name so they can be easily retrieved as a
  unit. For example, you can define a Set to
  include all facilities within one state, or
  within a consolidated health care system. If you
  select a saved Set, you will see each individual
  Member in the report.
• New Member (will see combined data) automatically
  sums the values of two or more Members from a
  Dimension to derive a single value.
• New Calculated Measure performs a calculation (a
  formula the user defines) of selected Measures to
  derive a value.
• Sets, New Members or New Measures are given a
  name and saved to the My Items folder.
• Search Function (hierarchy dimensions )
  (Particularly useful for large dimensions like
  ICD9 codes or CPT codes)

27
(No Transcript)
28
Search Function on Set up Panel
29
Formatting Reports and Charts
(important function right click on mouse to
display format options)

• Exceptions Highlighting
• Flatten rows Column headers
• Actions Drill to detail (SSN, data updates
  documentation, etc.) Real SSN access required
  appropriate Task code. Complete VA Form 9957. See
  VSSC FAQ 2.
• Analyze in decom tree

• View (Grid, Chart, Both)
• Grid functions by right click
• Drill functions on a views cells (up, down,
  hide, expand, collapse)
• Totals
• Sorting Data
• Filter Data
• Pivot view
• Grid properties

30
Formatting Reports (right click on report)
31
Chart functions by right click

• Drill Down
• Drill Up
• Show only
• Hide
• Actions
• Chart type
• Series properties
• Chart properties

32
Formatting charts(right click on chart)
33
Briefing Books and Views

• Saving a View Views are saved screen shots of a
  report you have created. The views will
  automatically update with new data when the cubes
  updates
• Briefing Book Books contain one or more views
  that you have saved to a file on your hard drive.
  You can send these books to other people through
  e-mail.
• Creating a Briefing Book step 1
• Saving a Briefing Book to your computer step 2
  (go to File -gt Save As)
• Adding a Page to a Briefing Book
• Opening a Saved Briefing Book
• E-Mailing a Briefing Book
• Exporting Data to Excel PP
• Add view to BB from another Cube
  (File-gtcube-create view- save in open BB)

34
Add a view to Briefing Book
35
Send a Briefing Book via email
Go to File on Menu select Send
36
Export Data to Excel Power points
Export grid data to Excel. Export graphs to
PowerPoint
37
Advanced Functions

• Decom tree
• Exception Highlighting
• Perspective
• Performance Map
• KPI Designer
• Selector
• Attribute dimension in sql 2005
• How to re-point briefing book

38
Decomposition Tree
39
Perspective (Scatter Diagram)
40
Performance Map
41
Training Resources

• VSSC Portal
• http//vssc.med.va.gov/
• ProClarity Desktop built in tutorial
• VSSC training calendar http//training.vssc.med.va
  .gov/default.aspx
• VSSC online training 24/7 webcams, PowerPoints,
  practice exercises http//training.vssc.med.va.gov
  /Topics/default.aspx
• Newsletter latest information on new VSSC
  products- sign up for listserv http//vaww.listser
  v.med.va.gov/archives/dwdm-fcdm-l.html
• Downloading ProClarity Desktop from VSSC
• http//vhaaacapp3.vha.med.va.gov/proclarityea/

42
ProClarity Software Downloads

• We recommend for all Data Analysts
• ProClarity Desktop Professional and
  Business Reporter
• ProClarity KPI Designer
• http//vhaaacapp3.vha.med.va.gov/proclarityea/
