MOM Essentials 5 Advanced Configuration and Administration

1
MOM Essentials 5 Advanced Configuration and
Administration

• Gordon McKenna MOM MVP
• Inframon Ltd.

2
Management Pack Tuning
3
Agenda

• Management Pack tuning
• - Management Pack Architectural Overview
• - Management Pack Overview Demo

4
Management Pack Architectural OverviewKey Terms

• Data sources
• Events Windows, application, WMI, service
  change, SNMP traps, timed events, missing events,
  UNIX syslogs
• Performance data Used for graphs, reports, and
  to set thresholds
• Alerts
• MOMs indication of a particular issue ? What
  operators see first
• Based on events, performance thresholds or script
  output
• Response
• Reaction to an alert (auto-resolve, send e-mail,
  page, run script)
• Management Pack (MP)
• Set of Processing Rules to monitor applications
• Supporting views and reports

5
MOM Rule Unit Of Instruction/Policy

• Event Rules
• Collection rules
• Filtering rules
• Missing event rules
• Consolidation rules
• Duplicate Alert Suppression

• Performance Rules
• Measuring
• Threshold
• Alert Rules

6
Management Packs

• Management Pack imported via MOM Server
• Discovery finds computers in need of a given
  Management Pack
• MOM deploys appropriate Management Packs
• No need to touch managed nodes to install
  Management Packs
• Rules Implement all MOM monitoring behavior
• Watch for indicators of problems
• Verify key elements of functionality
• Management Packs provide a definition of server
  health

7
Management Pack Overview
8
Basic rule of thumb when first deploying MPs

• DO NOT deploy all your required Management Packs
  at the same time
• - Install one, tune properly, then do the
  next
• Be brutal, switch off rules that you do not need
• - use Alert Overrides wherever possible (rather
  than just disabling)
• Document your changes
• - XML, Excel, Third party
• Put some form of change control in place to
  prevent random changes
• - Make sure that only the people who need MOM
  Admin or author rights get it.

9
Other Dos and Donts

• Do read each MP guide before you deploy
• Dont just disable a rule because it is giving
  you an error
• Do use the community to search for solutions to
  issues
• Dont let Alert Creep set in be pro-active
  with your tuning
• Do use reports to help you stay on top of alerts
• Do have regular reviews of the environment
• DONT PANIC !

10
Common Alerts After MP Deployment

• ADMP
• Replication taking too long need to modify
  script for worst case scenario
• Script Failures (access denied) usually
  permission related, make sure Local System has
  enough rights if unsure then create an AAA
  according to MP guide.
• Script Failures (failed to bind LDAP) If AD is
  behind firewall then FQDN will be missing from
  computer table.
• MOMLatencyMonitor not created Make sure your
  first AD Agent is on Infrastructure Master

11
Common Alerts After MP Deployment

• Exchange
• Mail flow scripts fail Permission related check
  out Top 3 issues effecting Exchange MP in
  product documentation on MS MOM site
• Disk Write Latency perf ctr Some
  re-configuration required (see Exchange MP guide)
• General perf ctrs Their will be a lot of base
  lining to do due to nature of application
• OWA\OMA\AS disable rule group if this does not
  apply

12
Key Processes for alert tuning strategy

• What to do with Alerts
• Who owns the MOM alert
• Who gets notified
• Who takes action
• How will it be recorded/closed
• What to do with Reports
• How to publish them
• Who reviews them

13
Using Reports To Evaluate Alert Flow
14
Tips for Getting Application Owners Onboard

• Sell each each MP to the technology owner i.e.
  SQL MP to the SQL Team
• Demonstrate how MOM can help them
• Scope them there own console
• Make sure they explain fully how their
  environment works
• Make them part of the deployment process
• Make them the MP owner
• Get them to own MP change documentation
• Put a process in place so they can be notified
  when changes take place to MPs
• Give them a sandpit environment.

15
Methods for Maintaining MPs

• Create an excel spreadsheet of all rules,
  documenting changes Can be time consuming
• Use MOM resource kit tools to convert .AKM file
  to .XML, then use XML editor or MPDiff (res kit)
  Fiddly
• Develop your own solution (web based\.NET)
• Use a third-party tool like Silect software
• http//www.silect.com

16
Application Engineering Standards

• Get App developers to think Manageability
• Design for Operations
• Write a good set of standards
• Introduce new technologies if need be like
  AVICode for .Net
• www.avicode.com
• Provide value to them with peformance and
  availability reporting
• Make them understand how hard your job is -)

17
Ideas for Standards

• Registry Keys Info on App, override criteria,
  thresholds
• Event Logs
• Performance Counters
• WMI Process and Thread IDs, app data
• Status Monitoring Health Modelling
• Scripting
• .NET (AVICode)
• Other Methods MOM API, C

18
Maintaining MPs
19
Advanced Administration Techniques
20
MOM OperationsGuiding principles

• Database Manage alert, event and perf data
  volumes
• Management Servers Monitor the health of the
  management server queues
• Agent administration Watch the Pending
  Actions computer group closely and watch for
  agents not heart beating (This principle is
  covered in the appendix)

21
MOM OperationsGuiding principles

• Database Manage alert, event and perf data
  volumes
• Management Servers Monitor the health of the
  management server queues
• Agent administration Watch the Pending
  Actions computer group closely and watch for
  agents not heart beating (This principle is
  covered in the appendix)

22
Database VolumeView Alert and event counts daily

• select count() from eventall -- all events in
  the db
• select count() from alertview -- all alerts
• -- Date/Time the System Center dts job last ran
• select timedtslastran from reportingsettings
• -- see appendix for perf data volume query

Tip The DTS job for the System Center data-base
logs a date/time when it completes successfully.
The grooming job (MOMXGroomByDays) will not groom
out any data newer than this date
23
Database GroomingAlert resolution criteria
Tip Perfmon, event and alert data is held in
the Onepoint database for Groom data older than
the following number of days The clock does
not start ticking for alerts until the alert is
resolved
24
Database GroomingAuto alert resolution

• Relevant code from stored procedure
  AlertUpdateNewToResolved.
• SET ResolutionState 255, TimeResolved
  _at_LastModified, LastModified _at_LastModified,
  LastModifiedBy 'AutoResolved', ResolvedBy
  'AutoResolved'
• WHERE ResolutionState 0 AND
• TimeOfLastEvent lt _at_dGroomDate AND
  (ProblemState ltgt 3 OR ProblemState IS NULL)

Tip Only alerts that are in a New resolution
state AND do NOT have an active problem state
AND whose last event is older than the number of
days you specify (Global Settings/Database
Grooming) get auto resolved
25
Management ServersIncoming and outgoing queues
Management Server
Outgoing Queue Blocked 22061 RTN 22062
Incoming Queue Blocked 21268 RTN 21269
MOM Agents
agent
No disruption of service is caused when
the outgoing queue fills up. If the incoming
queue is full, agents begin caching data
locally until they can find a management server
to write to
One pointData-base
26
Management ServersIncoming and outgoing queues

• During extreme alert, event, or perf data storms,
  the incoming queue may fill up. The management
  servers communicate this to their agents. Under
  this condition, agents will try hopping to
  their failover management server. They log
  event 21249 when they do so and 21250 when they
  come back
• During this time period, failed heartbeat alerts
  (21284, 21209) are inaccurate and you get a lot
  of agent stopped sending required config
  requests events (22085)
• This condition also defeats your agent load
  balancing strategies for management servers
• A soon to be public QFE is available to throttle
  how soon agents try their failover management
  server

27
Server Queue Full Pointers
Perf counters to watch under MOM Server
Perfmon object Db Perf Insert Simple Count Db
Alert Insert Simple Count Db Event Insert Simple
Count Queue Space Percent Used
28
Management ServersIncoming and outgoing queues

• Perf data incoming rate is fairly constant from
  measuring or collection rules. Rules that run
  scripts that submit perf data can cause large
  spikes. Scripts to watch out for if you have
  tens of thousands of mailboxes on your Exchange
  servers
• Exchange 2003 - Collect Mailbox Statistics
• Exchange 2003 - Collect number of mailboxes per
  server
• Exchange 2003 - Collect Message Tracking Log
  Statistics
• These scripts have parameters which you can use
  to tune how many mailboxes they report on. Some
  customers use them to report only one mailbox,
  as they still deliver very useful global counters
  for the information stores

29
Management ServersIncoming and outgoing queues

• Tip If the management server incoming queue is
  filling up there are three options
• Increase the size of the temporary storage on the
  management server Global Settings/ Management
  Servers/Temporary Storage (easiest)
• Reduce the volume of perfmon, event, and alert
  data by tuning rules (best)
• Increase throughput of SQL server by increasing
  disk I/O, memory, etc (usually least practical)

30
Appendix Agent Admin Pending actions computer
group

• The only legitimate reasons for computers that
  are pending action are
• Computer rules have discovered a new computer or
  more computers have been added to manualmc.txt
• Computer rules have changed to be less inclusive
  or computers have been removed from manualmc.txt

Tip When agents that match computer
discoveryrules or manualmc.txt are pending
uninstallation. Watch out for domain name
changes and failed computer discoveries
31
Appendix Agent Admin Pending actions - domain
changes

• If the agent computer changes domains
• You will get failed heartbeat and failed
  discovery alerts on the old computer account
• The agent will be in a new domain still trying to
  contact its management server. It will log this
  MOM Alert Name The MOM server received invalid
  or corrupt network data which may indicate a
  security problem. Description follows

The MOM Server rejected configuration or data
package from computer domain\computername.
Package failed to pass server security
verification. Event Number21289 SourceMicrosoft
Operations Manager
32
Agent Admin Pending actions - failed discoveries

• Give MOM agents a good healthy uninstall delay.
  Global Settings/Management Servers/Properties/
  Automatic Management/Uninstall Delay. This will
  ensure that discovery must fail gt once for a
  server to be marked for uninstall
• Disjoint AD name space Is the FQDN of your
  servers not the same as their primary DNS suffix?
  MOM discovery may have a few minor issues in
  this scenario. Mutual authentication with agents
  may not work either. We have almost 1800 agents
  in 12 domains. MOM has trouble discovery about 16
  servers. Most of those are in two domains but
  many other servers in these two domains are
  discovered successfully. We dont know what
  causes this but the problem can be remedied.

33
Agent AdminPending actions failed discoveries

• The manualmc.txt file can contain computer names
  with several different formats
• Fully Qualified Domain Name (FQDN) name
• NetBIOS name
• Domain\ComputerName
• Usually either NetBIOS name or Domain\Computer
  name works, but I have found that you get fewer
  discovery errors using NetBIOS name. Where
  discovery fails using NetBIOS name you should try
  domain\computername format. Sometimes it works
  where NetBIOS fails IF you add the FQDN to the
  hosts file (yes, the hosts file)!
• Computer discovery rules work somewhat better but
  are no guarantee for successful discovery

34
Agent Admin Agent management hints

• Install all the nodes of a cluster on the same
  management server or you will not get accurate
  heartbeat alerts
• Occasionally turn on rule Microsoft Operations
  Manager\Operations Manager 2005\Agents on all MOM
  roles\ Agent communication failure
  troubleshooting events These events can be
  viewed from a public view called Agent
  communication failure troubleshooting events
  under Microsoft Operations Manager/ Operations
  Manager 2005/Agent Configuration and
  Connectivity. You might be surprised at some of
  the warnings and errors your agents are logging
• If you turn agent proxying on and you submit an
  alert on behalf of a computer that does not have
  a MOM agent in the same management group as the
  box that submitted the alert then the computer
  you submitted the alert for will show up in the
  Unmanaged Computers group

35
Agent Admin Agent management hints

• If a push installation (automated from management
  server) fails on an agent try installing the
  agent manually using momagent.msi. When the agent
  starts check the NT eventlog for diagnostic
  messages. Some of them are pretty good
• Script a process to check your server database
  each day for populating the manualmc.txt file.
  Manualmc.txt allows you to chose what servers to
  manage rather than getting all the computers
  discovered by computer rules and adding exclude
  rules for those you dont want. Also, removing a
  computer from manualmc.txt can be automated
  whereas removing computer rules cannot

36
Agent AdminSource and Logging computers
MOM agents can generate alerts on behalf of other
computers if agent proxying is turned on for that
agent (Agent-managed computers/computername/proper
ties/Security/uncheck prevent agent proxying).
Management servers do this all the time for
failed heartbeats, discoveries, etc. This is what
the source and logging computer in the
advance criteria tab are all about
SELECT C.Name as 'Source', D.name as
'Logging', es.number,dateadd(hh,-6,e.timegenerated
),e.message FROM EventAll E INNER JOIN Computer C
ON (E.idGeneratedBy C.idComputer) INNER JOIN
Computer D ON (E.idloggedOn D.idComputer) INNER
JOIN EventSource ES ON (E.idEventSource
ES.idEventSource) where e.idloggedon ltgt
e.idgeneratedby order by 2 desc
37
Agent AdminUseful views in the MOM MP

• The MOM management pack has some extremely useful
  alert and event views under public
  views/Microsoft Operations Manager/Operations
  Manager 2005. Here are my favorites
• Everything under Computer Discovery. Great
  place to look for what discoveries are failing
  and why. To this folder I would add an event view
  for event number 21185 which shows a summary of
  failed discoveries
• Agent Configuration and Connectivity
• Agent communication failure troubleshooting
  events
• Agent communication failures
• Agent Deployment
• Agent Installation Failures All
• Agent Performance
• MOM Host - Processor Time
• MOM Service - Processor Time

38
Account AdminChanging account passwords

• Resetting an Action Account (domain user)
• SetActionAccount.exe ltmanagement groupgt options
• Options
• -query //returns the current Action Account
  settings for the specified management group.
• -set ltdomaingt ltusernamegt //sets the Action
  Account for the specified management group. Note
  - the tool will prompt you for the new password.
• Note - the management group must be specified,
  even if the agent is not multihomed.

39
Account AdminChanging account passwords

• Changing the DAS Account password

• Change the account settings on the Identity tab
  of the Microsoft Operations Manager Active
  Operations Data Access Service COM application
  on the Management Server.
• If you are using a different account, you must
  also add that account as a SQL Server Security
  Login with Permit server access.
• Give the db_owner Account access to the OnePoint
  database on the MOM database server, if you are
  using a different account. MOM setup grants the
  DAS account this access by default.
• If you also have the MOM to-MOM Product Connector
  installed, add the account to the MOM Service
  security group on the Management Server.
• Note
• You must restart the COM application to commit
  the changes.

40
Configuring the Webconsole

• Configuring the Web Console As Read-Only
• You can configure the Web console to be
  Read-only, so that operations data can be seen,
  but tasks cannot be run and changes cannot be
  made. This setting does not affect the Operator
  console read/write access.
• To enable or disable Read-Only access for the
  Web Console
• On the server hosting the Microsoft Operations
  Manager 2005 Web console application, open the
  INSTALLDRIVE\ Program Files\Microsoft
  Operations Manager 2005\WebConsole\web.config
  file in a text editor.
• In the ltappSettingsgt node, change the node
  lt!--add key"Readonly" value"true"/--gt to
  ltadd key"Readonly" value"true"/gt.
• Restart the Microsoft Operations Manager 2005
  Web console application in the Internet
  Information Services (IIS) snap-in.

41
For Further Information..

• Read the MOM 2005 Operations guide
• Use the microsoft.com\mom website
• Attend the Windows Management Webcasts on MOM
• ATTEND ALL OF THE TECHNET SESSIONS ON MOM

42
Troubleshooting MOM 2005
MOM 2005 Logs
43
Written by Developers for Developers

• Original concept by Mission Critical Software
• To assist developers with debugging their own
  code!
• Needs familiarity with the code itself
• Augmented by NetIQ
• Further augmented by Microsoft
• With a move away from mc8 to log files for easier
  troubleshooting by PSS

44
Logging Levels

• HKLM\Software\Mission Critical Software\Tracelevel

• Default 0x1
• Service restart not required for Trace Level
  changes
• Verbosity levels
• 0xFFFFFFFF Off
• gt 0 Errors (Err)
• gt 3 Errors and Warnings (Wrn)
• gt 6 Errors, Warnings and Info (Inf)
• gt 9 Errors, Warnings, Info and Debug (Dbg)

45
Log Locations

• Service logs (.mc8, .log)
• Systemroot\Temp\Microsoft Operations Manager
• DAS log (DllHost.mc8)
• Documents Settings\ltDas accountgt\Local
  Settings\Temp\Microsoft Operations Manager
• MOM MMC Snap-in log
• Documents Settings\All Users\Local
  Settings\Temp\Microsoft Operations Manager

46
Service Logs

• MOMService(Init).mc8
• Logged to for the first TraceInit seconds
• Circular line logging commences after TraceInit
  seconds (default 60)
• MOMService(A-B).mc8
• Circular line log files
• Logs roll over after TraceCircularLines
• TraceCircularLines default 50,000

47
Reading service logs

• Notepad
• Lacks translation of date/time
• Useful for quick examination search functions
• MOMLogViewer
• MOM ResKit utility
• Displays pertinent information such as Date/Time
• Realtime update
• Doesnt always read ALL lines!
• Trace32.exe
• From SMS support tools
• Useful for real-time logging and highlighting
• Lacks column translation

48
Which Trace Level?Which Trace Level was enabled
for log file analysis

• MOMLogViewer
• Add Column Trace Level
• Notepad / Trace32
• Fourth distinct column or Err,Wrn,Inf,Dbg in
  the text column

49
Why Trace?

• On PSS / PG Advice
• PSS or the Product Group ask for more data
• Used by CPR or developers to isolate code causing
  a potential problem
• Do not enable Trace Level gt6 unless advised (it
  is resource intensive)
• Obtaining more information
• Default Trace Level 1 Errors
• Mc8 logs will contain information on error
  (although not always significant)
• Review logs after crash or significant failure.

50
Err (0-2) Tracing (Errors)

• Expected errors
• ErrDirectory Service NT Event log not registered
  on this machine. Not processing Directory
  Service log.
• i.e. This is not a domain controller
• Unexpected errors
• ErrLogged event -1073715815(Error) args
  "momsrv.w2k3lab.com" "A connection attempt failed
  because the connected party did not properly
  respond after a period of time, or established
  connection failed because connected host has
  failed to respond." "1270"
• i.e. Communication failure

51
Wrn (3-5) Tracing (Warning)

• Often produced prior or during code failure
• Agent/Server queue nearing full
• e.g. WrnHigh water wait timed out. Waiting
  indefinitely for 957 bytes (exact space)
• WrnConnection failed with status 3 (ie. TCP
  connection failed unexpectedly)
• Sometimes expected
• E.g. WrnCannot start eventlog reader for
  target, log nameDirectory Service

52
Inf (6-8) Tracing (Information)

• More general output
• E.g. starting threads,host processes, registering
  callbacks, rule updates, computer grouping etc
• Logging Events to the EventLog
• Useful for log to eventlog tallying
  (troubleshooting by time of occurrence)
• Depth troubleshooting requires access to source
  code
• Often needs increase to TraceCircularLines
• Log wrap too fast to catch!

53
Dbg (gt9) Tracing (Debug)

• Not recommended in production
• Very resource intensive
• Logs roll over very quickly
• Needle in a haystack scenario!
• Can be of use for PSS for
• Troubleshooting channel errors
• Troubleshooting service failures
• Troubleshooting provider errors
• TraceCircularLines needs to be increased
• The level of logging will wrap logs quickly

54
Tallying EventLog Events
Inf Information Trace Level gt6
InfLogged event 9009(Information) args
"D\mom2005\MOMService.exe" Logged Time
02/21/2006 103500
Eventid 9009 Source Microsoft Operations
Manager Created 02/21/2006 103500 Description

55
9015 Error Tracing
Typical Event Log Entry
The Microsoft Operations Manager service
(MOMService.exe) received an unexpected
exception.nnThread Id 1nThread Name
6nException code 2nException description
3nException address 4nException flags 5

• Search the MOMService().mc8 file for 9015 event
  generation.
• Examine preceding log entries for cause of 9015
  and compare with the event log entry.
• Supply any additional log file information to PSS
  if raising a support call.

56
MOM Agent Cluster Discovery

• Trace Level 6 (Inf)

momclustermonitor.cpp - InfFound cluster
groupSQL InfFound cluster group
resourceDisk1 WrnGetClusterResourceNetworkName
return FALSE, resourceDisk1, GetLastError5002Th
e cluster resource dependency cannot be
found. InfFound cluster group resourceSQL IP
Address1(SQL01) WrnGetClusterResourceNetworkName
return FALSE, resourceSQL IP Address1(SQL01),
GetLastError5002The cluster resource dependency
cannot be found. InfFound cluster group
resourceSQL Network Name(SQL01) WrnGetClusterRes
ourceNetworkName return FALSE, resourceSQL
Network Name(SQL01), GetLastError5002The
cluster resource dependency cannot be
found. InfFound cluster group resourceSQL
Server (MOM1) InfFound virtual serverSQL01, for
cluster group resourceSQL Server
(MOM1) InfFound cluster group resourceSQL
Server Agent (MOM1) InfFound cluster group
resourceSQL Server Fulltext (MOM1) InfFound
cluster group resourcespool InfFound cluster
group nodeW2K3NODE2 InfFound cluster group
nodeW2K3NODE1 InfFound cluster groupGroup
0 InfFound cluster group resourceCluster IP
Address WrnGetClusterResourceNetworkName return
FALSE, resourceCluster IP Address,
GetLastError5002The cluster resource dependency
cannot be found. InfFound cluster group
resourceCluster Name WrnGetClusterResourceNetwor
kName return FALSE, resourceCluster Name,
GetLastError5002The cluster resource dependency
cannot be found. InfFound cluster group
resourceDisk Q WrnGetClusterResourceNetworkName
return FALSE, resourceDisk Q,
GetLastError5002The cluster resource dependency
cannot be found. InfFound cluster group
resourceMSDTC InfFound virtual
serverW2K3CLUSTERCE, for cluster group
resourceMSDTC InfFound cluster group
nodeW2K3NODE1 InfFound cluster group
nodeW2K3NODE2
57
MOM Cluster Discovery (cont)
momclustermanager.cpp InfDiscovered virtual
serverSQL01 InfFull virtual server
nameW2K3LAB\SQL01 InfDiscovered virtual
serverW2K3CLUSTERCE InfFull virtual server
nameW2K3LAB\W2K3CLUSTERCE
MMC
Microsoft Cluster Servers SQL01 W2K3CLUSTERCE
58
MOM Cluster Discovery (cont)

• MSCS APIs only
• MOM Cluster discovery registers for MSCS
  callbacks
• i.e. New cluster group added
• Cluster resource name change
• No need to stop and restart the MOM agent

59
Host Log files

• MOMAgentScriptHost-ltCGgt(A-B).MC8
• MOMAgentPerformanceHost-ltCGgt(A-B).MC8
• MOMAgentCPRHost-ltCGgt(A-B).MC8
• MOMAgentBatchHost-ltCGgt(A-B).MC8
• Similarly MOMServer.mc8 for server responses

60
DAS Logging (overview)

• Controlled by
• Trace Level
• HKLM\Software\Mission Critical Software\DasServer\
  LoggingFlagsREG_DWORD
• See KB329451 for details
• MOM 2005 specific article pending
• Note on dllhost(A-B).mc8
• May be in one or more locations
• systemroot\Temp\Microsoft Operations Manager
• Documents and Settings\ltdasAccountgt\Local
  Settings\Temp\Microsoft Operations Manager

61
MOM Resources

• Microsoft Operations Manager http//www.microsoft.
  com/MOM
• Getting Started Resourceshttp//www.microsoft.com
  /MOM/Beginners
• Technical Walkthrough
• Key Documentation
• MOM Evaluation Download
• Partner Product Cataloghttp//www.microsoft.com/M
  OM/ManagementPacks
• MOM Communityhttp//www.microsoft.com/MOM/communi
  ty/
• Solution Acceleratorshttp//www.microsoft.com/mom
  /evaluation/solutions/default.mspx

62
What else does TechNet give you?

• FREE TechNet Newsletter
• FREE Events and Webcasts
• FREE quarterly TechNet magazine
• FREE comprehensive technical website
• FREE TechNet Radio, Security Centre, Learning
  Paths and Virtual Labs
• TechNet Plus Subscription DVD

A range of tools and resources for IT
professionals that let you plan, manage ,deploy
To subscribe to the newsletter or just to find
out more, please visit www.microsoft.com/uk/techne
t
63
Thank you for attending this TechNet Event

• http//www.microsoft.com/uk/technet
• PS (The evaluation form is now sent out
  electronically with your thank you e-mail. This
  can take up to 5 working days. Please do
  feedback as we read all the comments and use them
  to shape future event content)
