AMM225 Manual Drivetrain

1
AMM225 - Manual Drivetrain

• Winter Quarter 2009

AMM 224 AutomaticTransmissions/Transaxles
2
Texts

• You will need two books this quarter.
• Automotive Technology, A Systems Approach 4th
  Edition Jack Erjavec
• and
• Automatic Transmission Tech One Jack Erjavec,
  Delmar Learning

3
First Year Tools (You should have by now)

• Torx Bit Socket Set
• Pin Punch Set
• Brass Drift
• 12V Test Light
• Pry Bars
• O Ring Pick Set
• Air Blow Gun (WITH SMALL RUBBER TIP)
• Snap Ring Pliers
• Internal and External
• (Snap-on style SRP2)

4
2nd Year Tools You Will Need

• Pry Bar screwdriver style 30 or larger
• Torque Wrench ½ Drive
• Inch lb Torque Wrench (Optional)
• Micrometer
• 3/8 Air Ratchet
• Impact Socket Set ½ Drive ½ to 1
• Digital Multi-meter
• Feeler Gauge (Go-NoGo Type)

5
Quarter Overview

• 4 Weeks
• Clutches
• Manual Transmissions/Transaxles
• Differentials
• 6 Weeks
• Automatic Transmissions/Transaxles

6
Course Syllabus

• Student Handbook
• Lecture 10 hours per week
• Lab Hours 20 hours per week
• My Office Hours 3pm to 4pm daily
• My Office phone [phone]

7
Objectives/Outcomes

• Understand basic theory of drivetrain components
• Understand Geartrain systems
• Understand CV Joints/Axles/Drive Shafts
• Understand Torque and speed relationships
• Understand Planetary Gear Sets
• Understand Hydraulics
• Maintain, Diagnose and Repair Manual and
  Automatic Transmission/Transaxles Drivetrain
• Overhaul Manual and Automatic Drivetrain

8
Course Evaluation

• Periodic Quizzes and Terminology Worksheets
• Weekly Test in Computer Lab
• Lab Evaluation of Tasks by Instructors
• Quality of Work in Lab
• Work Habits and Care of Tools Equipment
• Quantity of Work in Lab
• Work Order Preparation
• Competency Book Preparation
• Attitude
• Attendance
• Tardiness
• Classroom participation

9
A Grade Expectations

• Score 90 percent or higher on quizzes
• Score 70 percent or higher on tests
• Perform Drivetrain Maintenance/Service
• Perform Drivetrain Diagnosis
• Replace One Clutch
• Overhaul One Manual Transmission
• Overhaul One Automatic Transmission
• Overhaul/Repair Differential

10
Reading Assignment

• Classroom
• Chapter 35 Clutches
• Chap 35 Quiz due by Thursday 11 p.m.
• Test on Friday over Chap 35 and Lecture material
• LAB
• Perform assigned work
• Homework
• Review chapter and internet powerpoints
